YAMAHA MT-10 2016 Owners Manual

9-1
1
2
3
4
5
6
7
8910
11
12
Specifications
EAU70621
Dimensions:Overall length:2095 mm (82.5 in)
Overall width: 800 mm (31.5 in)
Overall height: 1110 mm (43.7 in)
Seat height:
825 mm (32.5 in)
Wheelbase: 1400 mm (55.1 in)
Ground clearance: 130 mm (5.12 in)
Minimum turning radius:
3.3 m (10.83 ft)Weight:Curb weight:210 kg (463 lb)Engine:Combustion cycle:4-stroke
Cooling system: Liquid cooled
Valve train:
DOHC
Cylinder arrangement: Inline
Number of cylinders: 4-cylinder
Displacement:
998 cm
3
Bore  stroke:
79.0  50.9 mm (3.11  2.00 in) Compression ratio:
12.0 : 1
Starting system:
Electric starter
Lubrication system: Wet sump
Engine oil:Recommended brand:
YAMALUBE
Type: Full synthetic
SAE viscosity grades: 10W-40, 15W-50
Recommended engine oil grade:
API service SG type or higher, JASO stan-
dard MA
Engine oil quantity:
Oil change:3.90 L (4.12 US qt, 3.43 Imp.qt)
With oil filter removal:
4.10 L (4.33 US qt, 3.61 Imp.qt)Coolant quantity:Coolant reservoir (up to the maximum level
mark): 0.25 L (0.26 US qt, 0.22 Imp.qt)
Radiator (including all routes): 2.25 L (2.38 US qt, 1.98 Imp.qt)Air filter:Air filter element:Oil-coated paper elementFuel:Recommended fuel:
Premium unleaded gasoline (Gasohol
[E10] acceptable) Fuel tank capacity:
17 L (4.5 US gal, 3.7 Imp.gal)
Fuel reserve amount:
4.0 L (1.06 US gal, 0.88 Imp.gal)
Fuel injection:Throttle body:ID mark:B671 00Spark plug(s):Manufacturer/model:
NGK/LMAR9E-J
Spark plug gap: 0.6–0.7 mm (0.024–0.028 in)Clutch:Clutch type:
Wet, multiple-discDrivetrain:Primary reduction ratio:1.634 (67/41)
Final drive:
Chain
Secondary reduction ratio: 2.688 (43/16)
Transmission type: Constant mesh 6-speed
Gear ratio:
1st:2.600 (39/15)
2nd:
2.176 (37/17)
3rd: 1.842 (35/19)
4th: 1.579 (30/19)
B67-9-E0.book 1 ページ ２０１６年２月２９日　月曜日　午前９時３０分

Specifications
9-2
1
2
3
4
5
6
7
89
10
11
12
5th: 1.381 (29/21)
6th:
1.250 (30/24)
Chassis:Frame type: Diamond
Caster angle:
24.0 
Trail: 102 mm (4.0 in)Front tire:Type:
Tubeless
Size: 120/70ZR17M/C(58W)
Manufacturer/model: BRIDGESTONE/BATTLAX HYPERS-
PORT S20FRear tire:Type:Tubeless
Size: 190/55ZR17M/C(75W)
Manufacturer/model: BRIDGESTONE/BATTLAX HYPERS-
PORT S20RLoading:Maximum load:170 kg (375 lb)
* (Total weight of rider, passenger, cargo and accessories)
Tire air pressure (measured on cold
tires):1 person:Front:
250 kPa (2.50 kgf/cm
2, 36 psi)
Rear: 290 kPa (2.90 kgf/cm2, 42 psi)
2 persons: Front: 250 kPa (2.50 kgf/cm2, 36 psi)
Rear: 290 kPa (2.90 kgf/cm2, 42 psi)
Front wheel:Wheel type:Cast wheel
Rim size: 17M/CxMT3.50Rear wheel:Wheel type:Cast wheel
Rim size: 17M/CxMT6.00Front brake:Type:Hydraulic dual disc brake
Specified brake fluid: DOT 4Rear brake:Type:Hydraulic single disc brake
Specified brake fluid: DOT 4
Front suspension:Type:Telescopic fork
Spring: Coil spring
Shock absorber: Hydraulic damper
Wheel travel:
120 mm (4.7 in)Rear suspension:Type:Swingarm (link suspension)
Spring:
Coil spring
Shock absorber: Gas-hydraulic damper
Wheel travel: 120 mm (4.7 in)Electrical system:System voltage:12 V
Ignition system: TCI
Charging system:
AC magnetoBattery:Model:YTZ10S
Voltage, capacity:
12 V, 8.6 Ah (10 HR)Bulb wattage  quantity:Headlight:
LED
B67-9-E0.book 2 ページ ２０１６年２月２９日　月曜日　午前９時３０分

Specifications
9-3
1
2
3
4
5
6
7
8910
11
12
Brake/tail light:LED
Front turn signal light:
LED
Rear turn signal light: LED
Auxiliary light: LED
License plate light:
LED
Meter lighting: LED
Neutral indicator light: LED
High beam indicator light:
LED
Oil pressure warning light: LED
Turn signal indicator light: LED
Coolant temperature warning light:
LED
Engine trouble warning light: LED
Steering damper warning light: LED
ABS warning light:
LED
Cruise control “SET” indicator light: LED
Cruise control “ON” indicator light: LED
Immobilizer system indicator light:
LED Shift timing indicator light:
LED
Traction control system indicator/warning
light:
LED
Fuse(s):Main fuse:50.0 A
Terminal fuse 1: 2.0 A
Headlight fuse:
10.0 A
Brake light fuse: 1.0 A
Signaling system fuse: 7.5 A
Ignition fuse:
15.0 A
Radiator fan motor fuse: 15.0 A
Sub radiator fan motor fuse: 10.0 A
Hazard fuse:
7.5 A
ABS ECU fuse: 7.5 A
Fuel injection system fuse: 15.0 A
ABS motor fuse:
30.0 A
ABS solenoid fuse: 10.0 A
Cruise control fuse: 1.0 A Backup fuse:
7.5 A
Electronic throttle valve fuse:
7.5 A
B67-9-E0.book 3 ページ ２０１６年２月２９日　月曜日　午前９時３０分

10-1
1
2
3
4
5
6
7
8
910
11
12
Consumer information
EAU53562
Identification numbersRecord the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUM-
BER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26401
Vehicle identification number
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in yourarea.
EAU26442
Engine serial number
The engine serial number is stamped
into the crankcase.
1. Vehicle identification number
1
1. Engine serial number
1
B67-9-E0.book 1 ページ ２０１６年２月２９日　月曜日　午前９時３０分

Consumer information
10-2
1
2
3
4
5
6
7
8
91011
12
EAU26481
Model label
The model label is affixed to the frame
under the seat. (See page 4-22.) Re-
cord the information on this label in the
space provided. This information will be
needed when ordering spare parts from
a Yamaha dealer.
EAU69910
Diagnostic connectorThe diagnostic connector is located as
shown.
1. Model label
1
1. Diagnostic connector
1
B67-9-E0.book 2 ページ ２０１６年２月２９日　月曜日　午前９時３０分

11-1
1
2
3
4
5
6
7
8
9
1011
12
IndexAABS ....................................................... 4-18
ABS warning light.................................... 4-7
Air filter element .................................... 7-17
Auxiliary DC jack ................................... 4-28BBattery................................................... 7-30
Brake and clutch levers, checking and lubricating .................................... 7-28
Brake and shift pedals, checking
and lubricating .................................... 7-27
Brake fluid, changing ............................ 7-24
Brake fluid level, checking .................... 7-23
Brake lever ............................................ 4-17
Brake lever free play, checking ............. 7-21
Brake light switches .............................. 7-22
Brake pedal ........................................... 4-18CCables, checking and lubricating .......... 7-26
Canister................................................. 7-10
Care ........................................................ 8-1
Catalytic converter ................................ 4-21
Clutch lever ........................................... 4-16
Clutch lever free play, adjusting ............ 7-21
Coolant.................................................. 7-13
Coolant temperature warning light .......... 4-6
Cruise control indicator lights .................. 4-6
Cruise control switches ........................... 4-4
Cruise control system ............................. 3-1DDiagnostic connector ............................ 10-2
Dimmer/Pass switch ............................... 4-4
D-mode (drive mode) .............................. 3-3
Drive chain, cleaning and lubricating .... 7-26 Drive chain slack .................................. 7-24
Drive mode switch .................................. 4-4
EEngine break-in ...................................... 6-3
Engine idling speed, checking .............. 7-17
Engine oil and oil fi
lter cartridge ........... 7-10
Engine serial number............................ 10-1
Engine trouble warning light ................... 4-6
EXUP system ....................................... 4-27FFront and rear brake pads, checking .... 7-22
Front fork, adjusting .............................. 4-23
Front fork, checking .............................. 7-29
Fuel....................................................... 4-20
Fuel consumption, tips for reducing........ 6-3
Fuel tank cap ........................................ 4-19
Fuel tank overflow hose........................ 4-21
Fuses, replacing ................................... 7-32HHandlebar switches ................................ 4-3
Hazard switch ......................................... 4-4
High beam indicator light ........................ 4-5
Horn switch ............................................. 4-4IIdentification numbers .......................... 10-1
Ignition circuit cut-off system ................ 4-29
Immobilizer system ................................. 4-1
Immobilizer system indicator light........... 4-8
Indicator lights and warning lights .......... 4-5LLuggage strap holders .......................... 4-27MMain switch/steering lock........................ 4-2
Maintenance and lubrication, periodic .... 7-5 Maintenance, emission control system ... 7-3
Matte color, caution ................................. 8-1
Model label ............................................ 10-2
Multi-function meter unit .......................... 4-8
NNeutral indicator light .............................. 4-5OOil pressure warning light........................ 4-5PParking .................................................... 6-4
Part locations .......................................... 2-1SSafety information ................................... 1-1
Seat ....................................................... 4-22
SELECT switch ....................................... 4-4
Shifting .................................................... 6-2
Shift pedal ............................................. 4-17
Shift timing indicator light ........................ 4-7
Shock absorber assembly, adjusting .... 4-24
Sidestand .............................................. 4-28
Sidestand, checking an
d lubricating...... 7-28
Spark plugs, checking ............................. 7-9
Special features ...................................... 3-1
Specifications .......................................... 9-1
Starting the engine .................................. 6-1
Steering, checking................................. 7-30
Steering damper warning light ................ 4-7
Stop/Run/Start switch.............................. 4-4
Storage.................................................... 8-4
Supporting the motorcycle .................... 7-35
Swingarm pivots, lubricating ................. 7-29TThrottle grip and cable, checking and lubricating ........................................... 7-27
B67-9-E0.book 1 ページ ２０１６年２月２９日　月曜日　午前９時３０分

Index
11-2
1
2
3
4
5
6
7
8
9
101112
Throttle grip free play, checking ........... 7-17
Tires...................................................... 7-18
Tool kit .................................................... 7-2
Traction control system .......................... 3-4
Traction control system indicator light .... 4-7
Traction control system switch ............... 4-4
Troubleshooting .................................... 7-35
Troubleshooting charts ......................... 7-37
Turn signal indicator lights ...................... 4-5
Turn signal switch ................................... 4-4VValve clearance .................................... 7-18
Vehicle identification number................ 10-1
Vehicle lights ........................................ 7-35WWheel bearings, c hecking .................... 7-30
Wheels.................................................. 7-20
B67-9-E0.book 2 ページ ２０１６年２月２９日　月曜日　午前９時３０分

B67-9-E0.book 3 ページ ２０１６年２月２９日　月曜日　午前９時３０分

Original instructions
PRINTED ON RECYCLED PAPERPRINTED IN JAPAN
2016.03-1.1×1 !
(E)
