INTRODUCTION
EAU41075
Congratulations on your purchase of the Yamaha PW50/PW50E/PW50E1. This model is the result of Yamaha’s vast expe-
rience in the production of fine sporting, touring, and pacesetting racing machines. It represents the high degree of crafts-
manship and reliability that have made Yamaha a leader in these fields.
This manual will give you an understanding of the operation, inspection, and basic maintenance of this motorcycle. If you
have any questions concerning the operation or maintenance of your motorcycle, please consult a Yamaha dealer.
The design and manufacture of this Yamaha motorcycle fully comply with the emissions standards for clean air applicable
at the date of manufacture. Yamaha has met these standards without reducing the performance or economy of operation
of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention
to the recommended maintenance schedules and operating instructions contained within this manual.
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most cur- rent product information available at the time of printing, there may be minor discrepancies between your motorcycle and
this manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA10032
Please rea d this manual carefully an d completely before operatin g this motorcycle.
WARNING
EWA14352
This motorcycle is d esigne d an d manufactured for off-road use only. It is ille gal to operate this motorcycle on any
pu blic street, roa d or hi ghway. Such use is prohi bite d b y law. This motorcycle complies with almost all state off-
hi ghway noise level an d spark arrester laws an d re gulations. Please check your local ri din g laws an d re gulations
b efore operatin g this motorcycle.AN IMPORTANT SAFETY MESSAGE:
 Read this manual carefully and completely before operating this motorcycle. Make sure you understand all instructions.
 Pay close attention to the warning and notice labels on the motorcycle.
 Never operate a motorcycle without proper training or instruction.
 Weight of the rider should not exceed 25 kg (55 lb).
U2SA80E0.book Page 1 Monday, June 3, 2013 5:25 PM

INTRODUCTIONAN IMPORTANT NOTE TO PARENTS:
This motorcycle is not a toy. Before you let your child ride this motorcycle, you should understand the instructions and warn-
ings in this Owner’s Manual. Then be sure your child understands and will follow them. Children differ in skills, physical abil-
ities, and judgment. Some children may not be able to operate a motorcycle safely. Parents should supervise their child’s
use of the motorcycle at all times. Parents should permit continued use only if they determine that the child has the ability
to operate the motorcycle safely.
Your motorcycle is equipped with an adjustable speed limiter and a power reduction plate. Yamaha recommends that all
beginners start off with the speed limiter adjusting screw turned in and the power reduction plate installed in the exhaust
manifold to limit the power available while they learn. The limiter screw may be gradually turned out to increase maximum
speed as the beginner becomes more familiar with operating the motorcycle. Parents should decide when to adjust the
motorcycle for more power as their youngster’s riding skills improve. Once the rider can operate with skill at the top speed
permitted by adjusting the speed limiter alone, the power reduction plate can be removed. Since removal of this plate will
result in a significant increase in power, turn the speed limiter back in again; adjust it out in stages as you did before.
Motorcycles are sin gle track vehicles. Their safe use an d operation are d ependent upon the use of proper ri din g
techniques as well as the expertise of the operator. Every operator shoul d know the followin g requirements b efore
ri din g this motorcycle.
He or she should:  Obtain thorough instructions from a competent source on all aspects of motorcycle operation.
 Observe the warnings and maintenance requirements in this Owner’s Manual.
 Obtain qualified training in safe and proper riding techniques.
 Obtain professional technical service as indicated in this Owner’s Manual and/or when made necessary by mechanical
conditions.U2SA80E0.book Page 2 Monday, June 3, 2013 5:25 PM

IMPORTANT MANUAL INFORMATION
EAU10134
Particularly important information is distinguished in this manual by the following notations:
*Product and specifications are subject to change without notice. This is the safety alert sym
bol. It is use d to alert you to potential personal injury
hazar ds. Ob ey all safety messag es that follow this sym bol to avoi d possi ble injury
or death.
A WARNING in dicates a hazar dous situation which, if not avoi ded , coul d result in
d eath or serious injury.
A NOTICE in dicates special precautions that must be taken to avoi d d ama ge to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICETIP
U2SA80E0.book Page 1 Monday, June 3, 2013 5:25 PM

IMPORTANT MANUAL INFORMATION
EAU10201
PW50/PW50E/PW50E1OWNER’S MANUAL
©2013 by Yamaha Motor Co., Lt d.
1st e dition, May 2013
All ri ghts reserve d.
Any reprintin g or unauthorize d use
without the written permission of
Yamaha Motor Co., Ltd .
is expressly prohi bite d.
Printe d in Japan.
U2SA80E0.book Page 2 Monday, June 3, 2013 5:25 PM

TABLE OF CONTENTS
LOCATION OF IMPORTANT
LABELS..............................................1-1
SAFETY INFORMATION ...................2-1
DESCRIPTION ...................................3-1
Left view ..........................................3-1
Right view ........................................3-2
Controls and instruments ................3-3
INSTRUMENT AND CONTROL
FUNCTIONS .......................................4-1
Handlebar switch ............................4-1
Speed limiter and power reduction plate .............................................4-1
Front brake lever .............................4-2
Rear brake lever ..............................4-3
Fuel tank cap ...................................4-3
Fuel ..................................................4-3
Fuel tank breather hose...................4-5
2-stroke engine oil ...........................4-6
Fuel cock .........................................4-6
Starter (choke) lever .......................4-7
Kickstarter .......................................4-7
Seat .................................................4-7
Cable lock (for Europe) ....................4-8 FOR YOUR SAFETY –
PRE-OPERATION CHECKS
............. 5-1
OPERATION AND IMPORTANT
RIDING POINTS ................................ 6-1
Starting and warming up a cold engine .......................................... 6-1
Starting a warm engine................... 6-1
Starting off ...................................... 6-2
Acceleration and deceleration ........ 6-2
Braking............................................ 6-2
Engine break-in............................... 6-3
Parking ............................................ 6-4
PERIODIC MAINTENANCE AND
ADJUSTMENT .................................. 7-1
Owner’s tool kit............................... 7-2
Periodic maintenance chart for the
emission control system ............. 7-3
General maintenance and
lubrication chart .......................... 7-4
Checking the spark plug................. 7-6
Removing the power reduction plate............................................. 7-7
Transmission oil .............................. 7-8
Middle and final gear cases ............ 7-9
Cleaning the air filter element ......... 7-9
Cleaning the spark arrester .......... 7-10
Adjusting the carburetor ............... 7-11
Adjusting the engine idling speed......................................... 7-11 Checking the throttle grip free
play ............................................ 7-12
Tires .............................................. 7-12
Panel wheels ................................. 7-14
Adjusting the front and rear brake lever free play ............................ 7-14
Checking the front and rear brake shoes ......................................... 7-15
Checking and lubricating the cables ........................................ 7-16
Checking and lubricating the
throttle grip and cable ............... 7-16
Adjusting the Autolube pump ....... 7-16
Lubricating the front and rear brake levers ............................... 7-17
Checking and lubricating the centerstand ................................ 7-17
Checking the front fork ................. 7-17
Checking the steering ................... 7-18
Checking the wheel bearings ........ 7-18
Front wheel ................................... 7-19
Rear wheel .................................... 7-20
Troubleshooting ............................ 7-23
Troubleshooting chart ................... 7-24
MOTORCYCLE CARE AND
STORAGE .......................................... 8-1
Matte color caution ......................... 8-1
Care................................................. 8-1
Storage............................................ 8-3
