66
Model
Dimensions:
Overall length 1,870 mm
Overall width 655 mm
Overall height 1,050 mm
Seat height 755 mm
Wheelbase 1,190 mm
Minimum ground clearance 130 mm
Basic weight:
With oil and full fuel tank 96 kg
Minimum turning radius: 1,800 mm
Engine:
Type Air cooled 4 stroke, SOHC
Cylinder arrangement Forward inclined single cylinder
Displacement 101.8 cm
3
Bore
×stroke 49.0
×54.0 mm
Compression ratio 9.0 : 1
Starting system Electric and kick starter
Lubrication system: Wet sump
SPECIFICATIONS
