YAMAHA T105 2009 Owner's Manual

INSTRUMENT AND CONTROL FUNCTIONS
3-7
3 or premium unleaded fuel. Use of un-
leaded fuel will extend spark plug life
and reduce maintenance costs.
EAU13433
Catalytic converter This model is equipped with a catalytic
converter in the exhaust system.
WARNING
EWA10862
The exhaust system is hot after op-
eration. To prevent a fire hazard or
burns:

Do not park the vehicle near
possible fire hazards such as
grass or other materials that
easily burn.


Park the vehicle in a place
where pedestrians or children
are not likely to touch the hot
exhaust system.


Make sure that the exhaust sys-
tem has cooled down before do-
ing any maintenance work.


Do not allow the engine to idle
more than a few minutes. Long
idling can cause a build-up ofheat.
NOTICE
ECA10701
Use only unleaded gasoline. The use
of leaded gasoline will cause unre-
pairable damage to the catalyticconverter.
U40BE0E0.book Page 7 Wednesday, January 7, 2009 10:05 AM

INSTRUMENT AND CONTROL FUNCTIONS
3-8
3
EAU13590
Starter (choke) lever“” Starting a cold engine requires a richer
air-fuel mixture, which is supplied by
the starter (choke).
Move the lever in direction (a) to turn on
the starter (choke).
Move the lever in direction (b) to turn off
the starter (choke).
EAU47860
Kickstarter If the engine fails to start by pushing the
start switch, try to start it by using the
kickstarter. With the transmission in
neutral, fold out the kickstarter lever,
move it down lightly with your foot until
the gears engage, and then push it
down smoothly but forcefully.
EAU13891
Seat To open the seat
1. Insert the key in the lock, and then
turn it as shown.
2. Fold the seat up.
To close the seat
1. Fold the seat down, and then push
it down to lock it in place.
2. Remove the key.TIPMake sure that the seat is properly se-cured before riding.
1. Starter (choke) lever“”
1
(a)
(b)
1. Kickstarter
1
1. Seat lock
1
U40BE0E0.book Page 8 Wednesday, January 7, 2009 10:05 AM

INSTRUMENT AND CONTROL FUNCTIONS
3-9
3
EAU37481
Helmet holders The helmet holders are located under
the seat.
To secure a helmet to a helmet hold-
er
1. Open the seat. (See page 3-8.)
2. Attach a helmet to a helmet holder,
and then securely close the seat.
WARNING! Never ride with a
helmet attached to the helmet
holder, since the helmet may hit
objects, causing loss of control
and possibly an accident.
[EWA10161]
To release a helmet from a helmet
holder
Open the seat, remove the helmet from
the helmet holder, and then close the
seat.
EAU14452
Storage compartment The storage compartment is located
under the seat. (See page 3-8.)
WARNING
EWA10961


Do not exceed the load limit of
1.0 kg (2.2 lb) for the storage
compartment.


Do not exceed the maximum
load of 159 kg (351 lb) for the ve-hicle.
When storing the Owner’s Manual or
other documents in the storage com-
partment, be sure to wrap them in a
plastic bag so that they will not get wet.
1. Helmet holder
1
1. Storage compartment
1
U40BE0E0.book Page 9 Wednesday, January 7, 2009 10:05 AM

INSTRUMENT AND CONTROL FUNCTIONS
3-10
3When washing the vehicle, be careful
not to let any water enter the storage
compartment.
EAU15112
Carrier
WARNING
EWA10171


Do not exceed the load limit of
3.0 kg (6.6 lb) for the carrier.


Do not exceed the maximum
load of 159 kg (351 lb) for the ve-hicle.
1. Carrier
1
U40BE0E0.book Page 10 Wednesday, January 7, 2009 10:05 AM

FOR YOUR SAFETY – PRE-OPERATION CHECKS
4-1
4
EAU15596
Inspect your vehicle each time you use it to make sure the vehicle is in safe operating condition. Always follow the inspection
and maintenance procedures and schedules described in the Owner’s Manual.
WARNING
EWA11151
Failure to inspect or maintain the vehicle properly increases the possibility of an accident or equipment damage.
Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided inthis manual, have the vehicle inspected by a Yamaha dealer.
Before using this vehicle, check the following points:
ITEM CHECKS PAGE
FuelCheck fuel level in fuel tank.
Refuel if necessary.
Check fuel line for leakage.3-6
Engine oilCheck oil level in engine.
If necessary, add recommended oil to specified level.
Check vehicle for oil leakage.6-8
Front brakeCheck operation.
If soft or spongy, have Yamaha dealer bleed hydraulic system.
Check brake pads for wear.
Replace if necessary.
Check fluid level in reservoir.
If necessary, add recommended brake fluid to specified level.
Check hydraulic system for leakage.6-16, 6-17
Rear brakeCheck operation.
Check pedal free play.
Adjust if necessary.6-15, 6-16
Throttle gripMake sure that operation is smooth.
Check cable free play.
If necessary, have Yamaha dealer adjust cable free play and lubricate cable and
grip housing.6-12, 6-21
U40BE0E0.book Page 1 Wednesday, January 7, 2009 10:05 AM

FOR YOUR SAFETY – PRE-OPERATION CHECKS
4-2
4
Control cablesMake sure that operation is smooth.
Lubricate if necessary.6-21
Drive chainCheck chain slack.
Adjust if necessary.
Check chain condition.
Lubricate if necessary.6-18, 6-20
Wheels and tiresCheck for damage.
Check tire condition and tread depth.
Check air pressure.
Correct if necessary.6-13, 6-14
Shift pedalMake sure that operation is smooth.
Correct if necessary.—
Brake pedalMake sure that operation is smooth.
Lubricate pedal pivoting point if necessary.6-22
Brake leverMake sure that operation is smooth.
Lubricate lever pivoting point if necessary.6-21
CenterstandMake sure that operation is smooth.
Lubricate pivot if necessary.6-22
Chassis fastenersMake sure that all nuts, bolts and screws are properly tightened.
Tighten if necessary.—
Instruments, lights, signals
and switchesCheck operation.
Correct if necessary.— ITEM CHECKS PAGE
U40BE0E0.book Page 2 Wednesday, January 7, 2009 10:05 AM

OPERATION AND IMPORTANT RIDING POINTS
5-1
5
EAU15951
Read the Owner’s Manual carefully to
become familiar with all controls. If
there is a control or function you do not
understand, ask your Yamaha dealer.
WARNING
EWA10271
Failure to familiarize yourself with
the controls can lead to loss of con-
trol, which could cause an accidentor injury.
EAU47850
Starting and warming up a
cold engine 1. Turn the key to“”.
2. Shift the transmission into the neu-
tral position. (See page 5-2.) The
neutral indicator light should come
on. If not, ask a Yamaha dealer to
check the electrical circuit.
3. Place the vehicle on the center-
stand.
WARNING
EWA14200
Before starting the engine, make
sure the transmission is in neutral
and that the vehicle is placed on thecenterstand.
4. Turn the starter (choke) on and
completely close the throttle. (See
page 3-8.)
5. Start the engine by pushing the
start switch or by pushing the kick-
starter lever down.
If the engine fails to start by push-
ing the start switch, release the
switch, wait a few seconds, and
then try again. Each starting at-
tempt should be as short as possi-ble to preserve the battery. Do not
crank the engine more than 10
seconds on any one attempt. If the
engine does not start with the
starter motor, try using the kick-
starter.
6. After starting the engine, move the
starter (choke) back halfway.
NOTICE: For maximum engine
life, never accelerate hard when
the engine is cold!
[ECA11041]
7. When the engine is warm, turn the
starter (choke) off.TIPThe engine is warm when it responds
normally to the throttle with the starter(choke) turned off.
U40BE0E0.book Page 1 Wednesday, January 7, 2009 10:05 AM

OPERATION AND IMPORTANT RIDING POINTS
5-2
5
EAU16640
Starting a warm engine Follow the same procedure as for start-
ing a cold engine with the exception
that the starter (choke) is not required
when the engine is warm.
EAU47840
Shifting Shifting gears lets you control the
amount of engine power available for
starting off, accelerating, climbing hills,
etc. When shifting gears, fully return the
throttle grip. The use of the shift pedal
is shown in the illustration.NOTICE
ECA15180


Make sure that the transmission
is completely shifted into gear.


Be sure to fully close the throttle
grip when shifting.


Make sure the neutral indicator
light comes on when the trans-
mission is in the neutral posi-tion.
1. Shift pedal
2. Neutral position
1
2
21
2
3
4 N
N3
2
1 4
U40BE0E0.book Page 2 Wednesday, January 7, 2009 10:05 AM

OPERATION AND IMPORTANT RIDING POINTS
5-3
5
EAU16800
Tips for reducing fuel con-
sumption Fuel consumption depends largely on
your riding style. Consider the following
tips to reduce fuel consumption:

Turn the starter (choke) off as
soon as possible.


Shift up swiftly, and avoid high en-
gine speeds during acceleration.


Do not rev the engine while shifting
down, and avoid high engine
speeds with no load on the engine.


Turn the engine off instead of let-
ting it idle for an extended length of
time (e.g., in traffic jams, at traffic
lights or at railroad crossings).
EAU16830
Engine break-in There is never a more important period
in the life of your engine than the period
between 0 and 1000 km (600 mi). For
this reason, you should read the follow-
ing material carefully.
Since the engine is brand new, do not
put an excessive load on it for the first
1000 km (600 mi). The various parts in
the engine wear and polish themselves
to the correct operating clearances.
During this period, prolonged full-throt-
tle operation or any condition that might
result in engine overheating must be
avoided.
EAU16861
0–150 km (0–90 mi)
Avoid prolonged operation above 1/3
throttle.
After every hour of operation, stop the
engine, and then let it cool for five to ten
minutes.
Vary the engine speed from time to
time. Do not operate the engine at one
set throttle position.150–500 km (90–300 mi)
Avoid prolonged operation above 1/2
throttle.
500–1000 km (300–600 mi)
Avoid prolonged operation above 3/4
throttle. NOTICE: After 1000 km (600
mi) of operation, the engine oil must
be changed.
[ECA10281]
1000 km (600 mi) and beyond
Avoid prolonged full-throttle operation.
Vary the speed occasionally.NOTICE
ECA10270
If any engine trouble should occur
during the engine break-in period,
immediately have a Yamaha dealercheck the vehicle.
U40BE0E0.book Page 3 Wednesday, January 7, 2009 10:05 AM

OPERATION AND IMPORTANT RIDING POINTS
5-4
5
EAU17213
Parking When parking, stop the engine, and
then remove the key from the main
switch.
WARNING
EWA10311


Since the engine and exhaust
system can become very hot,
park in a place where pedestri-
ans or children are not likely to
touch them and be burned.


Do not park on a slope or on soft
ground, otherwise the vehicle
may overturn, increasing the
risk of a fuel leak and fire.


Do not park near grass or other
flammable materials whichmight catch fire.
