engine YAMAHA TDM 850 2000 Owner's Guide

PERIODIC MAINTENANCE AND MINOR REPAIR
6-25
6
EAU00773
Throttle cable and grip
lubricationThe throttle twist grip assembly should
be greased at the time that the cable is
lubricated, since the grip must be re-
moved to get at the end of the throttle
cable. After removing the screws, hold
the end of the cable up in the air and
put in several drops of lubricant. With
the throttle grip disassembled, coat the
metal surface of the grip assembly with
a suitable all-purpose grease.
EAU02984
Brake and shift pedal
lubricationLubricate the pivoting parts.
EAU02985
Brake and clutch lever
lubricationLubricate the pivoting parts.
Recommended lubricant:
Engine oil
Recommended lubricant:
Engine oil
E_4tx_Periodic.fm Page 25 Saturday, October 16, 1999 9:37 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-26
6
EAU02986
Sidestand lubricationLubricate the sidestand pivoting point
and metal-to-metal contact surfaces.
Check that the sidestand moves up
and down smoothly.
EW000113
WARNING
@ If the sidestand does not move
smoothly, consult a Yamaha dealer. @
EAU00790
Rear suspension lubricationLubricate the pivoting parts.
Recommended lubricant:
Engine oilRecommended lubricant:
Molybdenum disulfide grease
E_4tx_Periodic.fm Page 26 Saturday, October 16, 1999 9:37 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-27
6
EAU02939
Front fork inspectionVisual check
EW000115
WARNING
@ Securely support the motorcycle so
there is no danger of it falling over. @Check for scratches or damage on the
inner tube and excessive oil leakage
from the front fork.
Operation check
1. Place the motorcycle on a level
place.
2. Hold the motorcycle in an upright
position and apply the front brake.
3. Push down hard on the handle-
bars several times and check if the
fork rebounds smoothly.
EC000098
CAUTION:@ If any damage or unsmooth move-
ment is found with the front fork,
consult a Yamaha dealer. @
EAU00794
Steering inspectionPeriodically inspect the condition of the
steering. Worn out or loose steering
bearings may be dangerous. Place a
stand under the engine to raise the
front wheel off the ground. Hold the
lower end of the front forks and try to
move them forward and backward. If
any free play can be felt, ask a Yamaha
dealer to inspect and adjust the steer-
ing. Inspection is easier if the front
wheel is removed.
EW000115
WARNING
@ Securely support the motorcycle so
there is no danger of it falling over. @
E_4tx_Periodic.fm Page 27 Saturday, October 16, 1999 9:37 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-33
6
EAU02990*
Troubleshooting chart
EW000125
WARNING
@ Never check the fuel system while smoking or in the vicinity of an open flame. @
Check if there is fuel
in the fuel tank.1. Fuel
Enough fuel.
No fuel.
Go to compression check.
Supply fuel.
Engine doesn’t start, go to compression check.
Use the electric starter.2. Compression
There is compression.
No compression.
Go to ignition check.
Ask a Yamaha dealer to
inspect.
Remove spark plugs
and check electrodes.3. Ignition
Wet.
Dry.
Wipe clean with dry cloth and correct
spark gap or replace spark plugs.
Ask a Yamaha dealer to inspect.
Engine doesn’t start, ask a Yamaha
dealer to inspect.Engine doesn’t start, go to battery
check.Open throttle half-way and start
the engine.
Use the electric starter.4. Battery
Engine turns over
quickly.
Engine turns over
slowly.
Battery good.Check connections or
recharge.
E_4tx_Periodic.fm Page 33 Saturday, October 16, 1999 9:37 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-34
6
Engine overheating
EW000070
WARNING
@ Do not remove the radiator cap when the engine and radiator are hot. Scalding hot fluid and steam may be blown
out under pressure, which could cause serious injury. Open the radiator cap as follows. Wait until the engine has
cooled. Remove the radiator cap stopper by removing the screw. Place a thick rag like a towel over the radiator cap
and slowly rotate the cap counterclockwise to the detent. This procedure allows any residual pressure to escape.
When the hissing sound has stopped, press down on the cap while turning counterclockwise and remove it. @NOTE:@ If it is difficult to get the recommended coolant, tap water can be temporarily used, provided that it is changed to the recom-
mended coolant as soon as possible. @
Wait until the
engine has cooled.
Check the coolant level in the
reservoir tank and/or radiator.
Level is OK.Level is low, check the
cooling system for leakage.
No
leakage.Leakage.
Ask a Yamaha dealer to inspect
and repair the cooling system.Add coolant. (See NOTE.)
Restart the engine. If the engine overheats again, ask a
Yamaha dealer to inspect and repair the cooling system.
E_4tx_Periodic.fm Page 34 Saturday, October 16, 1999 9:37 AM

MOTORCYCLE CARE AND STORAGE
7-3
71. Clean your motorcycle with cold
water and soap after the engine
has cooled down.
ECA00012
CAUTION:@ Do not use warm water since it in-
creases the corrosive action of the
salt. @2. Be sure to apply a corrosion pro-
tection spray on all (even chrome-
and nickel-plated) metal surfaces
to prevent corrosion.After cleaning
1. Dry the motorcycle with a chamois
or an absorbing cloth.
2. Immediately dry the drive chain
and lubricate it to prevent it from
rusting.
3. Use a chrome polish to shine
chrome, aluminum and stainless-
steel parts, including the exhaust
system. (Even the thermally in-
duced discoloring of stainless-
steel exhaust systems can be re-
moved through polishing.)
4. To prevent corrosion, it is recom-
mended to apply a corrosion pro-
tection spray on all (even chrome-
and nickel-plated) metal surfaces.
5. Use spray oil as a universal clean-
er to remove any remaining dirt.
6. Touch up minor paint damage
caused by stones, etc.
7. Wax all painted surfaces.
8. Let the motorcycle dry completely
before storing it or covering it.
EWA00001
WARNING
@ Make sure that there is no oil or wax
on the brakes and tires. If neces-
sary, clean the brake discs and lin-
ings with a regular brake disc
cleaner or acetone, and wash the
tires with warm water and mild soap.
Then, carefully test the motorcycle
for its braking performance and cor-
nering behavior. @
E_4tx_Cleaning.fm Page 3 Saturday, October 16, 1999 9:38 AM

MOTORCYCLE CARE AND STORAGE
7-5
7a. Remove the spark plug caps and
spark plugs.
b. Pour a teaspoonful of engine oil
into each spark plug bore.
c. Install the spark plug caps onto the
spark plugs and place the spark
plugs on the cylinder head so that
the electrodes are grounded. (This
will limit sparking during the next
step.)
d. Turn the engine over several times
with the starter. (This will coat the
cylinder walls with oil.)
e. Remove the spark plug caps from
the spark plugs, install the spark
plugs and then the spark plug
caps.
EWA00003
WARNING
@ When turning the engine over, be
sure to ground the spark plug elec-
trodes to prevent damage or injury
from sparking. @
6. Lubricate all control cables and
the pivoting points of all levers and
pedals as well as of the sidestand/
centerstand.
7. Check and, if necessary, correct
the tire air pressure, then raise the
motorcycle so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
8. Cover up the muffler outlets with
plastic bags to prevent moisture
from entering.9. Remove the battery and fully
charge it. Store it in a cool, dry
place and recharge it once a
month. Do not store the battery in
an excessively cold or warm place
(less than 0 °C or more than
30 °C). For more information, see
“Battery storage” in the chapter
“PERIODIC MAINTENANCE AND
MINOR REPAIRS”.
NOTE:@ Make any necessary repairs before
storing the motorcycle. @
E_4tx_Cleaning.fm Page 5 Saturday, October 16, 1999 9:38 AM

8-1
8
EAU01038
8-SPECIFICATIONSSpecifications
Model TDM850
Dimensions
Overall length 2,165 mm
(for GB, NL, B, F, E, P, I, GR, D,
DK)
2,200 mm (for N, S, SF)
Overall width 790 mm
Overall height 1,285 mm
Seat height 805 mm
Wheelbase 1,475 mm
Ground clearance 165 mm
Minimum turning radius 2,900 mm
Basic weight (with oil and full
fuel tank)
232 kg
Engine
Engine type Liquid cooled 4-stroke, DOHC
Cylinder arrangement Forward inclined parallel
2-cylinder
Displacement 849 cm
3
Bore ´ Stroke 89.5 ´ 67.5 mm
Compression ratio 10.5:1
Starting system Electric starter
Lubrication system Dry sumpEngine oil
Ty p e
Recommended engine oil
classification API Service SE, SF, SG type or
higher
Quantity
Periodic oil change 3.5 L
With oil filter replacement 3.6 L
Total amount 4.2 L
Cooling system capacity
(total amount)
1.7 L
-20˚ -10˚ 0˚
10˚20˚ 30˚
40˚50˚C
SAE 10W/30
SAE 15W/40SAE 20W/40SAE 20W/50
SAE 10W/40
CAUTION:Be sure to use motor oils that do not contain anti-friction
modifiers. Passenger car motor oils (often labeled
“Energy Conserving”) contain anti-friction additives which
will cause clutch and/or starter clutch slippage, resulting in
reduced component life and poor engine performance.
E_4tx_Spec.fm Page 1 Saturday, October 16, 1999 9:38 AM

10-INDEXAAir filter .................................................. 6-13
Antitheft alarm (optional) ..........................3-5BBattery ................................................... 6-28
Brake and clutch lever lubrication........... 6-25
Brake and shift pedal lubrication ............ 6-25
Brake fluid replacement ......................... 6-23
Brake light switch adjustment ................. 6-21CCable inspection and lubrication ............ 6-24
Carburetor adjustment ........................... 6-15
Care.........................................................7-1
Changing the coolant ............................. 6-11
Checking the front and
rear brake pads ................................... 6-21
Clutch lever ..............................................3-8
Clutch lever free play adjustment ........... 6-19
Controls/Instruments ................................2-3
Coolant temperature indicator light...........3-2
Cooling system ...................................... 6-10
Cowling and panel removal and
installation .............................................6-5
Cowlings A and B ....................................6-5DDiagnosis device......................................3-5
Dimmer switch .........................................3-6
Drive chain lubrication ............................ 6-24
Drive chain slack adjustment.................. 6-23
Drive chain slack check.......................... 6-23
EEngine break-in ....................................... 5-5
Engine oil ................................................ 6-8
Engine overheating ................................. 6-34
Engine stop switch................................... 3-7FFront brake lever ..................................... 3-9
Front fork adjustment............................. 3-14
Front fork inspection .............................. 6-27
Fuel ....................................................... 3-11
Fuel gauge .............................................. 3-5
Fuel indicator light ................................... 3-3
Fuel tank breather hose
(for Germany only) .............................. 3-12
Fuel tank cap ......................................... 3-10
Fuse replacement.................................. 6-29GGive safety the right of way ..................... 1-1HHandlebar switches ................................. 3-6
Dimmer switch ................................... 3-6
Engine stop switch ............................. 3-7
Hazard switch .................................... 3-6
Horn switch ........................................ 3-6
Lights switch ...................................... 3-7
Pass switch ........................................ 3-6
Start switch ........................................ 3-7
Turn signal switch .............................. 3-6
Hazard switch .......................................... 3-6
Headlight bulb replacement ................... 6-30
Helmet holder ........................................ 3-13
High beam indicator light ..........................3-2
Horn switch ..............................................3-6IIdentification number records ...................9-1
Idle speed adjustment ............................6-15
Indicator lights ..........................................3-2
Coolant temperature indicator light .....3-2
Fuel indicator light...............................3-3
High beam indicator light ....................3-2
Neutral indicator light ..........................3-2
Turn indicator lights ............................3-2
Inspecting the brake fluid level ...............6-22KKey identification number .........................9-1LLeft view...................................................2-1
Lights switch ............................................3-7
Luggage strap holders ...........................3-17MMain switch/steering lock .........................3-1
Model label ..............................................9-2NNeutral indicator light ...............................3-2PPanels A and B ........................................6-6
Parking.....................................................5-6
Pass switch ..............................................3-6
Periodic maintenance and lubrication .......6-2
Pre-operation check list ............................4-1
E_4txIX.fm Page 1 Saturday, October 16, 1999 9:38 AM

INDEX
RRear brake pedal ..................................... 3-9
Rear brake pedal height adjustment ...... 6-20
Rear shock absorber adjustment ........... 3-15
Rear suspension lubrication................... 6-26
Right view................................................ 2-2SSeat....................................................... 3-12
Shifting .................................................... 5-4
Shift pedal ............................................... 3-8
Sidestand .............................................. 3-17
Sidestand/clutch switch operation
check .................................................. 3-17
Sidestand lubrication ............................. 6-26
Spark plugs ............................................. 6-6
Specifications .......................................... 8-1
Speedometer ........................................... 3-3
Starter (choke) “ ”................................ 3-7
Starting a warm engine ............................ 5-4
Starting the engine .................................. 5-1
Start switch .............................................. 3-7
Steering inspection ................................ 6-27
Storage.................................................... 7-4
Storage compartment ............................ 3-13TTachometer ............................................. 3-4
Tail/brake light bulb replacement ........... 6-31
Throttle cable and grip lubrication .......... 6-25
Throttle cable free play inspection ......... 6-16
Tips for reducing fuel consumption .......... 5-5
Tires ...................................................... 6-17
Tool kit..................................................... 6-1
Troubleshooting .................................... 6-32
Troubleshooting chart ........................... 6-33
Turn indicator lights ................................. 3-2
Turn signal light bulb replacement ......... 6-32
Turn signal switch ................................... 3-6VValve clearance adjustment .................. 6-16
Vehicle identification number................... 9-1WWheel bearings ..................................... 6-28
E_4txIX.fm Page 2 Saturday, October 16, 1999 9:38 AM
