6-2
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU03685
Periodic maintenance and lubrication chartPeriodic maintenance and lubrication chartNOTE:
8The annual checks must be performed every year, except if a kilometer-based maintenance is performed instead.
8From 50,000 km, repeat the maintenance intervals starting from 10,000 km.
8Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and
technical skills.
NO. ITEM CHECK OR MAINTENANCE JOBODOMETER READING (× 1,000 km)
ANNUAL
CHECK
1 10203040
1
*Fuel line•Check fuel hoses for cracks or damage.√√√√ √
2 Spark plugs•Check condition.
•Clean and regap.√√
•Replace.√√
3
*Valves•Check valve clearance.
•Adjust.Every 40,000 km
4 Air filter element•Replace.√
5 Clutch•Check operation.
•Adjust.√√√√√
6
*Front brake•Check operation, fluid level and vehicle for fluid leakage.
(See NOTE on page 6-4.)√√√√√ √
•Replace brake pads.Whenever worn to the limit
7
*Rear brake•Check operation, fluid level and vehicle for fluid leakage.
(See NOTE on page 6-4.)√√√√√ √
•Replace brake pads.Whenever worn to the limit
8
*Brake hoses•Check for cracks or damage.√√√√ √
•Replace. (See NOTE on page 6-4.)Every 4 years
9
*Wheels•Check runout and for damage.√√√√
5PS-28199-E1 8/29/02 9:16 AM Page 47

6-7
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU01880
Checking the spark plugsSpark plugs, checkingThe spark plugs are important engine
components, which should be
checked periodically, preferably by a
Yamaha dealer. Since heat and
deposits will cause any spark plug to
slowly erode, they should be
removed and checked in accordance
with the periodic maintenance and
lubrication chart. In addition, the con-
dition of the spark plugs can reveal
the condition of the engine.
The porcelain insulator around the
center electrode of each spark plug
should be a medium-to-light tan (the
ideal color when the motorcycle is rid-
den normally), and all spark plugs
installed in the engine should have
the same color. If any spark plug
shows a distinctly different color, the
engine could be defective. Do not
attempt to diagnose such problems
yourself. Instead, have a Yamaha
dealer check the motorcycle.Clean the surface of the spark plug
gasket and its mating surface, and
then wipe off any grime from the
spark plug threads.
a. Spark plug gap
If a spark plug shows signs of elec-
trode erosion and excessive carbon
or other deposits, it should be
replaced.
Before installing a spark plug, the
spark plug gap should be measured
with a wire thickness gauge and, if
necessary, adjusted to specification.
Tightening torque:
Spark plug:
17.5 Nm (1.75 m·kgf)
Specified spark plug:
DPR8EA-9 (NGK) or
X24EPR-U9 (DENSO)
Spark plug gap:
0.8–0.9 mm
5PS-28199-E1 8/29/02 9:16 AM Page 52

6-44
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU02990
Troubleshooting chartsTroubleshooting chartsStarting problems or poor engine performanceEW000125
w
Keep away open flames and do not smoke while checking or working on the fuel system.
Check the fuel level in
the fuel tank.
1. FuelThere is enough fuel.
There is no fuel.Check the compression.
Supply fuel.
The engine does not start.
Check the compression.
Operate the electric starter.
2. CompressionThere is compression.
There is no compression.Check the ignition.
Have a Yamaha dealer
check the vehicle.
Remove the spark plugs
and check the electrodes.
3. IgnitionWipe off with a dry cloth and correct the
spark plug gaps, or replace the spark plugs.
Have a Yamaha dealer check the vehicle.
The engine does not start.
Have a Yamaha dealer
check the vehicle.
The engine does not start.
Check the battery.
Operate the electric starter.
4. BatteryThe engine turns over
quickly.
The engine turns over
slowly.The battery is good.
Check the battery lead connections,
and charge the battery if necessary.
Dry
WetOpen the throttle halfway and operate
the electric starter.
5PS-28199-E1 8/29/02 9:17 AM Page 89
