7-2
8Do not use any harsh chemical
products on plastic parts. Be
sure to avoid using cloths or
sponges which have been in
contact with strong or abra-
sive cleaning products, sol-
vent or thinner, fuel (gasoline),
rust removers or inhibitors,
brake fluid, antifreeze or elec-
trolyte.
8Do not use high-pressure
washers or steam-jet cleaners
since they cause water seep-
age and deterioration in the
following areas: seals (of
wheel and swingarm bearings,
fork and brakes), electric com-
ponents (couplers, connec-
tors, instruments, switches
and lights), breather hoses
and vents.8For motorcycles equipped
with a windshield: Do not use
strong cleaners or hard
sponges as they will cause
dulling or scratching. Some
cleaning compounds for plas-
tic may leave scratches on the
windshield. Test the product
on a small hidden part of the
windshield to make sure that it
does not leave any marks. If
the windshield is scratched,
use a quality plastic polishing
compound after washing.
After normal useRemove dirt with warm water, a mild
detergent, and a soft, clean sponge,
and then rinse thoroughly with clean
water. Use a toothbrush or bottle-
brush for hard-to-reach areas.
Stubborn dirt and insects will come
off more easily if the area is covered
with a wet cloth for a few minutes
before cleaning.After riding in the rain, near the sea
or on salt-sprayed roadsSince sea salt or salt sprayed on
roads during winter are extremely
corrosive in combination with water,
carry out the following steps after
each ride in the rain, near the sea or
on salt-sprayed roads.NOTE:
Salt sprayed on roads in the winter
may remain well into spring.1.Clean the motorcycle with cold
water and a mild detergent, after
the engine has cooled down.
ECA00012
cCDo not use warm water since it
increases the corrosive action of
the salt.2.Apply a corrosion protection
spray on all metal, including
chrome- and nickel-plated, sur-
faces to prevent corrosion.
MOTORCYCLE CARE AND STORAGE
5AE-9-E4 (ENG) 8/30/00 5:04 PM Page 80

1
2
3
4
5
6
7
8
9
7-3
After cleaning
1.Dry the motorcycle with a
chamois or an absorbing cloth.
2.Immediately dry the drive chain
and lubricate it to prevent it from
rusting.
3.Use a chrome polish to shine
chrome, aluminum and stainless-
steel parts, including the exhaust
system. (Even the thermally
induced discoloring of stainless-
steel exhaust systems can be
removed through polishing.)
4.To prevent corrosion, it is recom-
mended to apply a corrosion pro-
tection spray on all metal, includ-
ing chrome- and nickel-plated,
surfaces.
5.Use spray oil as a universal
cleaner to remove any remaining
dirt.
6.Touch up minor paint damage
caused by stones, etc.
7.Wax all painted surfaces.8.Let the motorcycle dry complete-
ly before storing or covering it.
EWA00001
w8Make sure that there is no oil
or wax on the brakes or tires.
If necessary, clean the brake
discs and brake linings with a
regular brake disc cleaner or
acetone, and wash the tires
with warm water and a mild
detergent.
8Before operating the motorcy-
cle test its braking perfor-
mance and cornering behav-
ior.
ECA00013
cC8Apply spray oil and wax spar-
ingly and make sure to wipe
off any excess.
8Never apply oil or wax to any
rubber and plastic parts, but
treat them with a suitable care
product.
8Avoid using abrasive polish-
ing compounds as they will
wear away the paint.NOTE:
Consult a Yamaha dealer for advice
on what products to use.
MOTORCYCLE CARE AND STORAGE
7
5AE-9-E4 (ENG) 8/30/00 5:04 PM Page 81

StorageShort-term
Always store your motorcycle in a
cool, dry place and, if necessary, pro-
tect it against dust with a porous
cover.
ECA00014
cC8Storing the motorcycle in a
poorly ventilated room or cov-
ering it with a tarp, while it is
still wet, will allow water and
humidity to seep in and cause
rust.
8To prevent corrosion, avoid
damp cellars, stables (because
of the presence of ammonia)
and areas where strong chemi-
cals are stored.
Long-term
Before storing your motorcycle for
several months:
1.Follow all the instructions in the
ÒCareÓ section of this chapter.
2.For motorcycles equipped with a
fuel cock that has an ÒOFFÓ posi-
tion: Turn the fuel cock lever to
ÒOFFÓ.
3.Drain the carburetor float cham-
ber by loosening the drain bolt;
this will prevent fuel deposits
from building up. Pour the
drained fuel into the fuel tank.
4.Fill up the fuel tank and add fuel
stabilizer (if available) to prevent
the fuel tank from rusting and
the fuel from deteriorating.
5.Perform the following steps to
protect the cylinder, piston rings,
etc. from corrosion.a.Remove the spark plug cap
and spark plug.
b.Pour a teaspoonful of engine
oil into the spark plug bore.
c.Install the spark plug cap onto
the spark plug, and then place
the spark plug on the cylinder
head so that the electrodes
are grounded. (This will limit
sparking during the next step.)
d.Turn the engine over several
times with the starter. (This
will coat the cylinder wall with
oil.)
e.Remove the spark plug cap
from the spark plug, and then
install the spark plug and the
spark plug cap.
EWA00003
wTo prevent damage or injury from
sparking, make sure to ground the
spark plug electrodes while turn-
ing the engine over.
MOTORCYCLE CARE AND STORAGE
7-4
75AE-9-E4 (ENG) 8/30/00 5:04 PM Page 82

1
2
3
4
5
6
7
8
9
7-5
6.Lubricate all control cables and
the pivoting points of all levers
and pedals as well as of the
sidestand/centerstand.
7.Check and, if necessary, correct
the tire air pressure, and then lift
the motorcycle so that both of its
wheels are off the ground.
Alternatively, turn the wheels a
little every month in order to pre-
vent the tires from becoming
degraded in one spot.
8.Cover the muffler outlet with a
plastic bag to prevent moisture
from entering it.
9.Remove the battery and fully
charge it. Store it in a cool, dry
place and charge it once a
month. Do not store the battery
in an excessively cold or warm
place (less than 0 ¡C) or more
than 30 ¡C). For more informa-
tion on storing the battery, see
page 6-33.
NOTE:
Make any necessary repairs before
storing the motorcycle.
MOTORCYCLE CARE AND STORAGE
7
5AE-9-E4 (ENG) 8/30/00 5:04 PM Page 83

SPECIFICATIONS
1
2
3
4
5
6
78
9
Specifications
ModelTDR125
Dimensions
Overall length2,120 mm
(F, GB, IRL, B, P, GR, E)
2,185 mm (S, SF, D, CH, A)
Overall width840 mm
Overall height1,295 mm
Seat height850 mm
Wheel base1,405 mm
Ground clearance270 mm
Minimum turning radius2,200 mm
Basic weight (with oil and full
fuel tank)135 kg
136 kg (CH, A)
Engine
Engine typeLiquid cooled 2-stroke,
gasoline
Cylinder arrangementForward inclined single
cylinder
Displacement125 cm
3
Bore ´Stroke56.0 ´50.7 mm
Compression ratio6.6:1
Starting systemElectric starter
Lubrication systemSeparate lubrication
(Yamaha Autolube)Engine oil (2-cycle)
TypeYamalube 2 or equivalent
2-stroke engine oil
Capacity
Total amount1.2 L
Transmission oil
TypeSAE 10W30 SE motor oil
Capacity
Periodic oil change0.75 L
Total amount0.8 L
Cooling system capacity
(total amount)1.05 L
Air filterWet type element
Fuel
TypeRegular unleaded gasoline
Fuel tank capacity11 L
Reserve amount2.2 L
Carburetor
ManufacturerMIKUNI
Model ´quantityTM28SS ´1
EAU01038
SPECIFICATIONS
8-1
5AE-9-E4 (ENG) 8/30/00 5:04 PM Page 84

SPECIFICATIONS
1
2
3
4
5
6
78
9
8-2 Spark plug
Manufacturer/modelNGK / BR9ES
Spark plug gap0.7Ð0.8 mm
Clutch typeWet, multiple-disc
Transmission
Primary reduction systemHelical gear
Primary reduction ratio71/22 (3.227)
Secondary reduction systemChain drive
Secondary reduction ratio3.563
Number of drive chain
sprocket teeth (Rear/front)57/16
Transmission typeConstant mesh 6-speed
OperationLeft foot
Gear ratio1st2.833
2nd1.875
3rd1.412
4th1.143
5th0.957
6th0.818
Chassis
Frame typeSemi double cradle
Caster angle26¡
Trail116 mmTires
Front
TypeTubeless
Size100/90-18 56P
Manufacturer/BRIDGESTONE / TW53
modelDUNLOP / D602F
Rear
TypeTubeless
Size130/80-17 65P
Manufacturer/BRIDGESTONE / TW54
modelDUNLOP / D602
Maximum load*180 kg
179 kg (CH, A)
Air pressure (cold tire)
up to 90 kg load*
Front175 kPa (1.75 kg/cm
2, 1.75 bar)
Rear200 kPa (2.00 kg/cm2, 2.00 bar)
90 kg loadÐMaximum
load*
Front175 kPa (1.75 kg/cm2, 1.75 bar)
Rear225 kPa (2.25 kg/cm2, 2.25 bar)
* Total weight of rider, passenger, cargo and accessories
5AE-9-E4 (ENG) 8/30/00 5:04 PM Page 85

SPECIFICATIONS
1
2
3
4
5
6
78
9
Wheels
Front
TypeCast
Size18 ´MT2.15
Rear
TypeCast
Size17 ´MT2.50
Brakes
Front
TypeSingle disc brake
OperationRight hand
FluidDOT 4
Rear
TypeSingle disc brake
OperationRight foot
FluidDOT 4
Suspension
Front
TypeTelescopic fork
Rear
TypeSwingarm (Monocross)Spring/shock absorber
Front
TypeCoil spring / oil damper
Rear
TypeCoil-gas spring / oil damper
Wheel travel
Front180 mm
Rear180 mm
Electrical
Ignition systemC.D.I.
Charging system
TypeC.D.I. magneto
Standard output14 V, 12A @5,000 r/min
Battery
TypeYTX5L-BS
Voltage, capacity12 V, 4 AH
Headlight typeQuartz bulb (halogen)
Bulb voltage, wattage ´quantity
Headlight12 V, 60/55W ´2
12 V, 35/35W ´2 (GB, IRL)
8-3
5AE-9-E4 (ENG) 8/30/00 5:04 PM Page 86

SPECIFICATIONS
1
2
3
4
5
6
78
9
8-4 Tail/brake light12 V, 5/21W ´2
Front turn signal light12 V, 21W ´2
Rear turn signal light12 V, 21W ´2
Auxiliary light12 V, 4W ´2
12 V, 3.4W ´2 (GB, IRL)
Meter lighting12 V, 3.4W ´3
Neutral indicator light12 V, 3.4W ´1
High beam indicator light12 V, 3.4W ´1
Oil level warning light12 V, 3.4W ´1
Turn indicator light12 V, 3.4W ´1
Fuse20A
5AE-9-E4 (ENG) 8/30/00 5:04 PM Page 87

SPECIFICATIONS
8
8-5
EAU01064
Conversion tableAll specification data in this manual are listed in SI and
METRIC UNITS.
Use this table to convert METRIC unit data to
IMPERIAL unit data.
Ex.
METRICMULTIPLIERIMPERIAL
** mm´0.03937=** in
2 mm´0.03937=0.08 inCONVERSION TABLE
METRIC TO IMPERIAL
Metric unitMultiplierImperial unit
m¥kg7.233ft¥lb
Torquem¥kg86.794in¥lb
cm¥kg0.0723ft¥lb
cm¥kg0.8679in¥lb
Weightkg2.205lbg0.03527oz
Speedkm/hr0.6214mph
km0.6214mi
m3.281ft
Distancem1.094yd
cm0.3937in
mm0.03937in
cc (cm
3)0.03527oz (IMP liq.)
Volume/cc (cm3)0.06102cu¥in
CapacityL (liter)0.8799qt (IMP liq.)
L (liter)0.2199gal (IMP liq.)
kg/mm55.997lb/in
Misc.kg/cm
2
14.2234psi (lb/in
2)
Centigrade (¡C)9/5+32Fahrenheit (¡F)
5AE-9-E4 (ENG) 8/30/00 5:04 PM Page 88

9-1
EAU01039
CONSUMER INFORMATION
9
1
1
EAU02944
Identification numbersRecord the key identification number,
vehicle identification number and
model label information in the spaces
provided below for assistance when
ordering spare parts from a Yamaha
dealer or for reference in case the
vehicle is stolen.
1.KEY IDENTIFICATION
NUMBER:
2.VEHICLE IDENTIFICATION
NUMBER:
3.MODEL LABEL INFORMATION:
EAU01041
Key identification numberThe key identification number is
stamped into the key tag.
Record this number in the space pro-
vided and use it for reference when
ordering a new key.
EAU01043
Vehicle identification numberThe vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.NOTE:
The vehicle identification number is
used to identify your motorcycle and
may be used to register your motor-
cycle with the licensing authority in
your area.
1.Key identification number1.Vehicle identification number
1
6
5AE-9-E4 (ENG) 8/30/00 5:04 PM Page 89
