SPECIFICATIONS
9-3
9
EAU51132
For Europe only
The figures quoted are emission levels
and are not necessarily safe working
levels. Whilst there is a correlation be-
tween the emission and exposure lev-
els, this cannot be used reliably to
determine whether or not further pre-
cautions are required. Factors that in-
fluence the actual level of exposure of
work-force include the characteristics
of the work room, the other sources of
noise, etc. i.e. the number of machines
and other adjacent processes, and the
length of time for which an operator is
exposed to the noise. Also the permis-
sible exposure level can vary from
country. This information, however, will
enable the user of the machine to make
a better evaluation of the hazard and
risk.
U2CJ82E0.book Page 3 Monday, June 23, 2014 2:58 PM

CONSUMER INFORMATION
10-1
10
EAU53562
Id entification num bersRecord the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUMBER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26401
Vehicle i dentification num ber
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26441
En gine serial num ber
The engine serial number is stamped
into the crankcase.
EAU26481
Mo del la bel
1. Vehicle identification number
1
1. Engine serial number
1. Model label
1
1
U2CJ82E0.book Page 1 Monday, June 23, 2014 2:58 PM

CONSUMER INFORMATION
10-2
10
The model label is affixed to the frame
under the seat. (See page 4-8.) Record
the information on this label in the
space provided. This information will
be needed when ordering spare parts
from a Yamaha dealer.
EAU48121
Vehicle Emission Control Informa-
tion la
bel (For Cana da)
The Vehicle Emission Control Informa-
tion label is affixed at the location in the
illustration. This label shows specifica-
tions related to exhaust emissions as
required by federal law, state law and
Environment Canada.1. Vehicle Emission Control Information label
1
U2CJ82E0.book Page 2 Monday, June 23, 2014 2:58 PM

11-1
11
INDEXAAir filter element, cleaning ...................... 7-8BBattery .................................................. 7-23
Brake lever .............................................. 4-3
Brake lever, checking and lubricating ........................................... 7-20
Brake lever free play, adjusting ............ 7-15
Brake pedal............................................. 4-3
Brake pedal, checking and lubricating ........................................... 7-21
Brake pedal free play, adjusting ........... 7-16
Brake shoes, checking ......................... 7-17CCables, checking and lubricating ......... 7-20
Carburetor, adjusting ............................ 7-11
Care ........................................................ 8-1
Clutch free play, adjusting .................... 7-15DDrive chain, cleaning and lubricating .... 7-19
Drive chain slack................................... 7-18EEngine break-in....................................... 6-3
Engine idling speed .............................. 7-11
Engine oil ................................................ 7-7
Engine serial number ............................ 10-1
Engine, starting a warm .......................... 6-2
Engine stop switch ................................. 4-2FFront fork, checking .............................. 7-22
Fuel ......................................................... 4-4
Fuel cock ................................................ 4-7
Fuel tank breather hose .......................... 4-6
Fuel tank cap .......................................... 4-4 Fuse, replacing ..................................... 7-25
HHandlebar switches ................................ 4-1IIdentification numbers .......................... 10-1LLabels, location ...................................... 1-1MMain switch ............................................ 4-1
Maintenance and lubrication, periodic ... 7-3
Maintenance, emission control
system.................................................. 7-2
Matte color, caution ............................... 8-1
Model label ........................................... 10-1PParking ................................................... 6-4
Part locations ......................................... 3-1SSafety information .................................. 2-1
Seat ........................................................ 4-8
Shifting ................................................... 6-2
Shift pedal .............................................. 4-3
Shift pedal, checking ............................ 7-17
Sidestand ............................................... 4-9
Sidestand, checking an d lubricating .... 7-21
Spark arrester, cleaning ....................... 7-10
Spark plug, checking.............................. 7-6
Specifications ......................................... 9-1
Speed limiter .......................................... 4-2
Starter (choke) lever ............................... 4-8
Starting and warming up a cold engine .................................................. 6-1
Starting circuit cut-off system ................ 4-9
Start switch ............................................ 4-2 Steering, checking ................................7-22
Storage ...................................................8-3
Supporting the motorcycle ...................7-26
Swingarm pivots, lubricating ................7-21
TThrottle grip and cable, checking and
lubricating ...........................................7-20
Throttle grip free play, checking ...........7-12
Tires ......................................................7-13
Troubleshooting ....................................7-30
Troubleshooting chart ...........................7-31VValve clearance .....................................7-12
Vehicle Emission Control Information label (For Canada)...............................10-2
Vehicle identification number ................10-1WWheel bearings, checking .....................7-23
Wheel (front) ..........................................7-26
Wheel (rear) ...........................................7-28
Wheels ..................................................7-14
