EAU00260
Helmet holder
To open the helmet holder, insert the
key into the lock, and then turn the
key as shown.
To lock the helmet holder, place it in
the original position, and then remove
the key.
EW000030
w
Never ride with a helmet attached
to the helmet holder, since the hel-
met may hit objects, causing loss
of control and possibly an acci-
dent.
INSTRUMENT AND CONTROL FUNCTIONS
3
1
1. Helmet holder
EAU01343
Shock absorberEAU00315
w
This shock absorber contains high-
ly pressurized nitrogen gas. For
proper handling, read and under-
stand the following information
before handling the shock
absorber. The manufacturer cannot
be held responsible for property
damage or personal injury that may
result from improper handling.
8Do not tamper with or attempt
to open the gas cylinder.
8Do not subject the shock
absorber to an open flame or
other high heat sources, other-
wise it may explode due to
excessive gas pressure.
8Do not deform or damage the
gas cylinder in any way, as
this will result in poor damp-
ing performance.
8Always have a Yamaha dealer
service the shock absorber.
EAU00320
CarrierEW000032
w
8Do not exceed the load limit of
3 kg for the carrier.
8Do not exceed the maximum
load of 180 kg for the vehicle.
1
1. Carrier
5RS-9-E1 (TW125) 8/23/02 11:37 AM Page 20

6-1
EAU00462
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU00464
Safety is an obligation of the owner.
Periodic inspection, adjustment and
lubrication will keep your vehicle in
the safest and most efficient condi-
tion possible. The most important
points of inspection, adjustment, and
lubrication are explained on the fol-
lowing pages.
The intervals given in the periodic
maintenance and lubrication chart
should be simply considered as a
general guide under normal riding
conditions. However, DEPENDING
ON THE WEATHER, TERRAIN,
GEOGRAPHICAL LOCATION, AND
INDIVIDUAL USE, THE MAINTE-
NANCE INTERVALS MAY NEED TO
BE SHORTENED.
EW000060
w
If you are not familiar with motor-
cycle maintenance work, have a
Yamaha dealer do it for you.
EAU01175
Owner’s tool kit
The owner’s tool kit is located behind
panel B. (See page 6-6 for panel
removal and installation procedures.)
The service information included in
this manual and the tools provided in
the owner’s tool kit are intended to
assist you in the performance of pre-
ventive maintenance and minor
repairs. However, additional tools
such as a torque wrench may be nec-
essary to perform certain mainte-
nance work correctly.
1
1. Owner’s tool kit
NOTE:
If you do not have the tools or experi-
ence required for a particular job,
have a Yamaha dealer perform it for
you.
EW000063
w
Modifications not approved by
Yamaha may cause loss of perfor-
mance and render the vehicle
unsafe for use. Consult a Yamaha
dealer before attempting any
changes.
5RS-9-E1 (TW125) 8/23/02 11:37 AM Page 32

6-4
PERIODIC MAINTENANCE AND MINOR REPAIR
6EAU03541
NOTE:
8The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
8Hydraulic brake service
9Regularly check and, if necessary, correct the brake fluid level.
9Every two years replace the internal components of the brake master cylinder and caliper, and change the brake
fluid.
9Replace the brake hoses every four years and if cracked or damaged.
21*Carburetor•Check starter (choke) operation.
•Adjust engine idling speed.√√√√√ √
22 Engine oil•Change.
•Check oil level and vehicle for oil leakage.√√√√√ √
23 Engine oil filter element•Clean.√√√
24
*Engine oil strainer•Clean.√
25
*Front and rear brake
switches•Check operation.√√√√√ √
26 Moving parts and cables•Lubricate.√√√√ √
27
*Throttle grip housing
and cable•Check operation and free play.
•Adjust the throttle cable free play if necessary.
•Lubricate the throttle grip housing and cable.√√√√ √
28
*Lights, signals and
switches•Check operation.
•Adjust headlight beam.√√√√√ √ NO. ITEM CHECK OR MAINTENANCE JOBODOMETER READING (× 1,000 km)
ANNUAL
CHECK
1 6 12 18 24
5RS-9-E1 (TW125) 8/23/02 11:37 AM Page 35

6-14
PERIODIC MAINTENANCE AND MINOR REPAIR
6 To clean the air filter check hose
1. Check the hose at the bottom of
the air filter case for accumulated
dirt or water.
2. If dirt or water is visible, remove
the hose, clean it, and then
install it.
1
1. Air filter check hose
EAU00629
Adjusting the carburetor
The carburetor is an important part of
the engine and requires very sophisti-
cated adjustment. Therefore, most
carburetor adjustments should be left
to a Yamaha dealer, who has the
necessary professional knowledge
and experience. The adjustment
described in the following section,
however, may be serviced by the
owner as part of routine mainte-
nance.
EC000094
cC
The carburetor has been set and
extensively tested at the Yamaha
factory. Changing these settings
without sufficient technical knowl-
edge may result in poor perfor-
mance of or damage to the engine.
EAU04757
Adjusting the engine idling
speed
The engine idling speed must be
checked and, if necessary, adjusted
as follows at the intervals specified in
the periodic maintenance and lubrica-
tion chart.
The engine should be warm before
making this adjustment.
NOTE:
8The engine is warm when it
quickly responds to the throttle.
8A diagnostic tachometer is need-
ed to make this adjustment.
1. Attach the tachometer to the
spark plug lead.
5RS-9-E1 (TW125) 8/23/02 11:37 AM Page 45

6-27
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU01106
Lubricating the drive chain
The drive chain must be cleaned and
lubricated at the intervals specified in
the periodic maintenance and lubrica-
tion chart, otherwise it will quickly
wear out, especially when riding in
dusty or wet areas. Service the drive
chain as follows.
EC000097
cC
The drive chain must be lubricated
after washing the motorcycle or
riding in the rain.
1. Remove all dirt and mud from
the drive chain with a brush or
cloth.
2. Spray a drive chain lubricant on
both sides and on the middle of
the chain, making sure that all
side plates and rollers have been
sufficiently oiled.
NOTE:
For a thorough cleaning, have a
Yamaha dealer remove the drive
chain and soak it in solvent.
EAU02962
Checking and lubricating the
cables
The operation of all control cables
and the condition of the cables
should be checked before each ride,
and the cables and cable ends
should be lubricated if necessary. If
a cable is damaged or does not move
smoothly, have a Yamaha dealer
check or replace it.
Recommended lubricant:
Engine oil
5RS-9-E1 (TW125) 8/23/02 11:37 AM Page 58

6-37
PERIODIC MAINTENANCE AND MINOR REPAIR
62. Remove the defective bulb by
pushing it in and turning it coun-
terclockwise.
3. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
4. Install the lens by installing the
screws.
EC000108
cC
Do not overtighten the screws,
otherwise the lens may break.
1
1. Bulb
EAU01579
Supporting the motorcycle
Since this model is not equipped with
a centerstand, follow these precau-
tions when removing the front and
rear wheel or performing other main-
tenance requiring the motorcycle to
stand upright. Check that the motor-
cycle is in a stable and level position
before starting any maintenance. A
strong wooden box can be placed
under the engine for added stability.
To service the front wheel
1. Stabilize the rear of the motorcy-
cle by using a motorcycle stand
or, if an additional motorcycle
stand is not available, by placing
a jack under the frame in front of
the rear wheel.
2. Raise the front wheel off the
ground by using a motorcycle
stand.To service the rear wheel
Raise the rear wheel off the ground
by using a motorcycle stand or, if a
motorcycle stand is not available, by
placing a jack either under each side
of the frame in front of the rear wheel
or under each side of the swingarm.
5RS-9-E1 (TW125) 8/23/02 11:37 AM Page 68

6-38
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU04387
Front wheel
To remove the front wheelEW000122
w
8It is advisable to have a
Yamaha dealer service the
wheel.
8Securely support the motorcy-
cle so that there is no danger
of it falling over.
1. Pull outward on the rubber cover
at the bottom of the right-side
fork leg, and then slide it up
along the fork leg.
1
1. Rubber cover
2. Pull outward on the rubber cover
at the bottom of the left-side fork
leg, and then pull it off.
1
1. Rubber cover
5RS-9-E1 (TW125) 8/23/02 11:37 AM Page 69

6-40
PERIODIC MAINTENANCE AND MINOR REPAIR
6
NOTE:
Make sure that there is enough
space between the brake pads
before inserting the brake disc and
that the slot in the speedometer gear
unit fits over the retainer on the fork
leg.
3. Insert the wheel axle, and then
install the axle nut.
4. Lower the front wheel so that it is
on the ground.
2 1
1. Retainer
2. Speedometer cable
5. Tighten the axle nut to the speci-
fied torque.
6. Place the rubber cover at the
bottom of the right-side fork leg
in the original position.
7. Install the rubber cover at the
bottom of the left-side fork leg.
8. Connect the speedometer cable.
EAU03519
Rear wheel
To remove the rear wheelEW000122
w
8It is advisable to have a
Yamaha dealer service the
wheel.
8Securely support the motorcy-
cle so that there is no danger
of it falling over.
1. Loosen the axle nut.
5a
2
1
34
1. Axle nut
2. Brake pedal free play adjusting nut
3. Brake rod
4. Brake camshaft lever
5. Drive chain adjusting plate
Tightening torque:
Axle nut:
90 Nm (9.0 m·kgf)
5RS-9-E1 (TW125) 8/23/02 11:37 AM Page 71

6-42
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EW000103
w
After adjusting the brake pedal
free play, check the operation of
the brake light.
EAU01008
Troubleshooting
Although Yamaha motorcycles
receive a thorough inspection before
shipment from the factory, trouble
may occur during operation. Any
problem in the fuel, compression, or
ignition systems, for example, can
cause poor starting and loss of
power.
The following troubleshooting chart
represents a quick and easy proce-
dure for checking these vital systems
yourself. However, should your
motorcycle require any repair, take it
to a Yamaha dealer, whose skilled
technicians have the necessary tools,
experience, and know-how to service
the motorcycle properly.
Use only genuine Yamaha replace-
ment parts. Imitation parts may look
like Yamaha parts, but they are often
inferior, have a shorter service life
and can lead to expensive repair
bills.
5RS-9-E1 (TW125) 8/23/02 11:37 AM Page 73

8-1
EAU01038
SPECIFICATIONS
8
SpecificationsSpecifications
Model TW125
Dimensions
Overall length 2,135 mm
Overall width 820 mm
Overall height 1,120 mm
Seat height 820 mm
Wheelbase 1,350 mm
Ground clearance 255 mm
Minimum turning radius 2,100 mm
Basic weight (with oil and full
fuel tank)127 kg
Engine
Engine type Air-cooled 4-stroke, SOHC
Cylinder arrangement Forward inclined
single cylinder
Displacement 124 cm
3
Bore ×Stroke 57.0 ×48.8 mm
Compression ratio 10:1
Starting system Electric starter
Lubrication system Wet sumpEngine oil
Type
Recommended engine oil
classification API Service SE, SF, SG type
or higher
cC
In order to prevent clutch slippage (since the engine oil also
lubricates the clutch), do not mix any chemical additives. Do
not use oils with a diesel specification of “CD” or oils of a
higher quality than specified. In addition, do not use oils
labeled “ENERGY CONSERVING II” or higher.
Capacity
Without oil filter element
removal 1.0 L
With oil filter element removal 1.1 L
Total amount (dry engine) 1.3 L
–10° 0° 10° 20° 30°
40°
SAE 10W/30
SAE 10W/40
SAE 20W/40
SAE 20W/50
–20°
SAE 15W/40 50°C
5RS-9-E1 (TW125) 8/23/02 11:37 AM Page 80
