PERIODIC MAINTENANCE AND MINOR REPAIR
6-15
1
2
3
4
5
6
7
8
9

with the local regulations.
Tire information
This motorcycle is equipped with tube
tires.
WARNING

EWA10460

The front and rear tires should
be of the same make and de-
sign, otherwise the handling
characteristics of the vehicle
cannot be guaranteed.

After extensive tests, only the
tires listed below have been
approved for this model by
Yamaha Motor Co., Ltd.
WARNING

EWA10560

It is dangerous to ride with a
worn-out tire. When a tire tread
begins to show crosswise lines,
have a Yamaha dealer replace
the tire immediately.

The replacement of all wheel-
and brake-related parts, includ-
ing the tires, should be left to a
Yamaha dealer, who has the
necessary professional knowl-
edge and experience.

It is not recommended to patch
a punctured tube. If unavoid-
able, however, patch the tubevery carefully and replace it as
soon as possible with a
high-quality product. Front tire:
Size:
130/80-18M/C 66P
Manufacturer/model:
BRIDGESTONE/TW31
Rear tire:
Size:
180/80-14M/C 78P
Manufacturer/model:
BRIDGESTONE/TW34

SPECIFICATIONS
8-2
1
2
3
4
5
6
7
8
9

3rd:
29/22 (1.318)
4th:
26/25 (1.040)
5th:
23/28 (0.821)
Chassis:
Frame type:
Diamond
Caster angle:
26.0 °
Trail:
95.0 mm (3.74 in)
Front tire:
Type:
With tube
Size:
130/80-18M/C 66P
Manufacturer/model:
BRIDGESTONE/TW31
Rear tire:
Type:
With tube
Size:
180/80-14M/C 78P
Manufacturer/model:
BRIDGESTONE/TW34
Loading:
Maximum load:
180 kg (397 lb)
(Total weight of rider, passenger, cargo
and accessories)
Tire air pressure (measured on cold
tires):
Loading condition:
0–90 kg (0–198 lb)
Front:
125 kPa (18 psi) (1.25 kgf/cm
2

)
Rear:
125 kPa (18 psi) (1.25 kgf/cm
2

)
Loading condition:
90–180 kg (198–397 lb)
Front:
150 kPa (22 psi) (1.50 kgf/cm
2

)
Rear:
175 kPa (25 psi) (1.75 kgf/cm
2

)
Off-road riding:
Front:
125 kPa (18 psi) (1.25 kgf/cm
2

)
Rear:
125 kPa (18 psi) (1.25 kgf/cm
2

)
Front wheel:
Wheel type:
Spoke wheel
Rim size:
18x2.50
Rear wheel:
Wheel type:
Spoke wheel
Rim size:
14M/C x MT4.50
Front brake:
Type:
Single disc brake Operation:
Right hand operation
Recommended fluid:
Dot 4
Rear brake:
Type:
Drum brake
Operation:
Right foot operation
Front suspension:
Type:
Telescopic fork
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
160.0 mm (6.30 in)
Rear suspension:
Type:
Swingarm (monocross)
Spring/shock absorber type:
Coil spring/gas-oil damper
Wheel travel:
150.0 mm (5.91 in)
Electrical system:
Ignition system:
C.D.I.
Charging system:
A.C. magneto
Battery:
Model:
GM7CZ-3D
Voltage, capacity:
12 V, 7.0 Ah
