YAMAHA VIKING VI 2016 Owners Manual

9-2
9
5. Rinse the vehicle off immediately withclean water and dry all surfaces with a
clean chamois towel or soft, absorbent
cloth.
6. Clean the seats with a vinyl upholstery
cleaner to keep the covers pliable and
glossy.
7. Automotive-type wax may be applied to
all painted and chrome-plated surfaces.
Avoid combination cleaner-waxes. Many
contain abrasives which may scratch the
paint or protective finish. When finished,
start the engine and let it idle for several
minutes.EBU32740StorageLong term storage (60 days or more) of your
vehicle will require some preventive proce-
dures to guard against deterioration. Make
any necessary repairs before storing the vehi-
cle. After thoroughly cleaning the vehicle, prepare
for storage as follows:
1. Fill the fuel tank with fresh fuel and add the specified amount of Yamaha Fuel
Stabilizer and Conditioner or equivalent
product. Operate the vehicle for at least 5
minutes to distribute treated fuel through
the fuel system.
2. Remove the spark plug, pour about one tablespoon of SAE 10W-40 or 20W-50
motor oil in the spark plug hole and install
the spark plug. Ground the spark plug
wire and turn the engine over several
times to coat the cylinder wall with oil.
3. Lubricate all control cables.
4. Block up the frame to raise all wheels off the ground.
Specified amount:1 oz of stabilizer to each gallon of fuel (or
7.5 ml of stabilizer to each liter of fuel)
UB857AE0.book Page 2 Monday, August 24, 2015 8:59 AM

9-3
9
5. Tie a plastic bag over the exhaust pipeoutlet to prevent moisture from entering.
6. If storing in a humid or salt-air atmo- sphere, coat all exposed metal surfaces
with a light film of oil. Do not apply oil to
any rubber parts or the seat covers.
7. Remove the battery and charge it. Store it in a dry place and recharge it once a
month. Do not store the battery in an ex-
cessively warm or cold place [less than 0
°C (30 °F) or more than 30 °C (90 °F)].
Use of fuel stabilizer and conditioner elimi-
nates the need to drain the fuel system. Con-
sult a Yamaha dealer if the fuel system needs
to be drained.UB857AE0.book Page 3 Monday, August 24, 2015 8:59 AM

10-1
10
EBU32750
SPECIFICATIONS
Dimensions:Overall length:3900 mm (153.5 in)
Overall width: 1570 mm (61.8 in)
Overall height:
1945 mm (76.6 in)
Wheelbase: 2935 mm (115.6 in)
Ground clearance: 290 mm (11.4 in)
Minimum turning radius:
6200 mm (244 in)Weight:Curb weight:769.0 kg (1695 lb)Noise and vibration level:Noise level (77/311/EEC):83.0 dB(A) (EUR,FRA,GBR)
A-weighted sound power level: 93.0 dB(A) (EUR,FRA,GBR)
Vibration on seat (EN1032, ISO5008):
Will not exceed 0.5 m/s² (EUR,FRA,GBR)
Vibration on handle (EN1032, ISO5008): Will not exceed 2.5 m/s² (EUR,FRA,GBR)Engine:Engine type:
Liquid cooled 4-stroke, SOHC Cylinder arrangement:
Single cylinder
Displacement: 686 cm³
Bore × stroke:
102.0 × 84.0 mm (4.02 × 3.31 in)
Compression ratio:
10.0 : 1
Starting system: Electric starter
Lubrication system: Wet sump
Engine oil:Recommended brand:YAMALUBE
UB857AE0.book Page 1 Monday, August 24, 2015 8:59 AM

10-2
10
Type:SAE 5W-30, 10W-30, 10W-40, 15W-40, 20W-40 or 20W-
50
Recommended engine oil grade: API service SG type or higher, JASO standard MA
Engine oil quantity: Without oil filter cartridge replacement: 2.20 L (2.33 US qt, 1.94 Imp.qt)
With oil filter cartridge replacement: 2.30 L (2.43 US qt, 2.02 Imp.qt)Final gear oil:Type:SAE 80 API GL-4 Hypoid gear oil
Quantity: 0.40 L (0.42 US qt, 0.35 Imp.qt)Differential gear oil:Type:SAE 80 API GL-4 Hypoid gear oil Quantity:
0.18 L (0.19 US qt, 0.16 Imp.qt)
Coolant quantity:Coolant reservoir (up to the maximum level mark):
0.28 L (0.30 US qt, 0.25 Imp.qt)
Radiator (including all routes): 3.24 L (3.42 US qt, 2.85 Imp.qt)Air filter:Air filter element:
Wet elementFuel:Recommended fuel:Regular unleaded gasoline only
Fuel tank capacity:
36.7 L (9.69 US gal, 8.07 Imp.gal)Fuel injection:Throttle body:ID mark: 1XD1 00Spark plug (s):Manufacturer/model:
NGK/CPR7EA-9
Spark plug gap: 0.8–0.9 mm (0.031–0.035 in)Clutch:Clutch type:
Wet, centrifugal automaticTransmission:Secondary reduction system:Shaft drive
0 10 30 50 70 90 110 130 F
–20 –10 0 10 20 30 40 50 CSAE 5W-30
SAE 10W-30
SAE 10W-40
SAE 15W-40
SAE 20W-40SAE 20W-50
UB857AE0.book Page 2 Monday, August 24, 2015 8:59 AM

10-3
10
Secondary reduction ratio:41/21 × 17/12 × 33/9 (10.142)
Transmission type: V-belt automatic
Operation:
Right hand operation
Reverse gear: 23/14 × 28/23 (2.000)
Low range: 31/16 (1.938)
High range:
30/21 (1.429)Chassis:Frame type:Steel tube frame
Caster angle:
3.70 °
Trail: 19.0 mm (0.75 in)Front tire:Type:
Tubeless
Size: 25 x 8-12NHS
Manufacturer/model: MAXXIS/MU09Rear tire:Type:Tubeless
Size: 25 x 10-12NHS Manufacturer/model:
MAXXIS/MU10
Loading:Maximum loading limit:
594.0 kg (1309 lb)
(Total weight of operator, passengers, cargo, accessories,
and tongue)Tire air pressure (measured on cold tires):Recommended:
Vehicle load:0 - maximum
Front:
145.0 kPa (1.450 kgf/cm², 21.0 psi)
Rear: 165.0 kPa (1.650 kgf/cm², 24.0 psi)
Minimum: Vehicle load:0 - maximum
Front: 140.0 kPa (1.400 kgf/cm², 20.3 psi)
Rear:
160.0 kPa (1.600 kgf/cm², 23.2 psi)Front wheel:Wheel type:Panel wheel
Rim size:
12 x 6.0ATRear wheel:Wheel type:Panel wheel
UB857AE0.book Page 3 Monday, August 24, 2015 8:59 AM

10-4
10
Rim size:12 x 7.5ATFront brake:Type:
Disc brake
Operation: Unified brake
Specified brake fluid: DOT 4Rear brake:Type:Disc brake
Operation: Unified brake
Specified brake fluid:
DOT 4Front suspension:Type:Double wishbone
Spring/shock absorber type:
Coil spring/gas-oil damper
Wheel travel: 205 mm (8.1 in)Rear suspension:Type:
Double wishbone
Spring/shock absorber type: Coil spring/gas-oil damper
Wheel travel: 205 mm (8.1 in)
Electrical system:Ignition system:TCI
Charging system:
AC magnetoBattery:Model:U1-H11L
Voltage, capacity:
12 V, 28.0 AhHeadlight:Bulb type:Halogen bulbBulb voltage, wattage × quantity:Headlight:
12 V, 35.0/35.0 W × 2
Tail/brake light: 12 V, 5.0/21.0 W × 2
Neutral indicator light:
LED
Reverse indicator light: LED
Coolant temperature warning light: LED
Engine trouble warning light:
LED
Parking brake indicator light: LED
On-Command four-wheel-drive/differential gear lock
indicator: LCD
UB857AE0.book Page 4 Monday, August 24, 2015 8:59 AM

10-5
10
High-range indicator light:LED
Low-range indicator light: LED
Differential gear lock indicator light:
LED
EPS warning light: LED
Helmet/Seat belt indicator light: 14 V, 0.85 W × 2Fuses:Main fuse:
40.0 A
Fuel injection system fuse: 10.0 A
EPS fuse:
40.0 A
Headlight fuse: 15.0 A
Signaling system fuse: 10.0 A
Ignition fuse:
10.0 A
Auxiliary DC jack fuse: 10.0 A
Backup fuse: 10.0 A
Four-wheel-drive motor fuse:
10.0 A
Radiator fan motor fuse: 25.0 A
EBU33220For Europe only
The figures quoted are emission levels and
are not necessarily safe working levels. Whilst
there is a correlation between the emission
and exposure levels, this cannot be used reli-
ably to determine whether or not further pre-
cautions are required. Factors that influence
the actual level of exposure of work-force in-
clude the characteristics of the work room,
the other sources of noise, etc. i.e. the num-
ber of machines and other adjacent process-
es, and the length of time for which an
operator is exposed to the noise. Also the
permissible exposure level can vary from
country. This information, however, will en-
able the user of the machine to make a better
evaluation of the hazard and risk.
UB857AE0.book Page 5 Monday, August 24, 2015 8:59 AM

11-1
11
EBU32770
CONSUMER INFORMATION
EBU33320Identification number recordsRecord the vehicle identification number and
model label information in the spaces provid-
ed for assistance when ordering spare parts
from a Yamaha dealer or for reference, in
case the vehicle is stolen.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:EBU32800Vehicle identification number
The vehicle identification number is stamped
into the frame.The vehicle identification number is used to
identify your vehicle.
EBU32810Model label
The model label is affixed to the frame under
the rear left passenger seat. Record the infor-
mation on this label in the space provided.
This information will be needed to order spare
parts from your Yamaha dealer.1. Vehicle identification number
1
UB857AE0.book Page 1 Monday, August 24, 2015 8:59 AM

11-2
11
1. Model label
1
UB857AE0.book Page 2 Monday, August 24, 2015 8:59 AM

12-1
12
INDEX
AAccelerator pedal ......................................................... 4-12
Accelerator pedal, Pre-operation check ........................ 5-7
Air filter case/duct check hose, cleaning ..................... 8-33
Air filter element, cleaning ............................................ 8-28
Auxiliary DC jacks ........................................................ 4-25
Axle boots .................................................................... 8-25BBasic guide for safe use ................................................. 7-1
Battery, Periodic maintenance ..................................... 8-45
Brake fluid level, checking ........................................... 8-37
Brake fluid, replacing ...................................................8-39
Brake light switch, adjusting ........................................ 8-41
Brake pedal .................................................................. 4-12
Brake pedal and accelerator pedal, lubrication ........... 8-41
Brake pedal, checking ................................................. 8-39
Brakes, Periodic maintenance ..................................... 8-36
Brakes, Pre-operation check ......................................... 5-3CCable, inspecting and lubrication ................................ 8-41
Cargo bed .................................................................... 4-22
Cleaning ......................................................................... 9-1
Control cables, Pre-operation check ............................. 5-8
Coolant, Periodic maintenance .................................... 8-20
Coolant, Pre-operation check ........................................ 5-6
Coolant temperature warning light ................................. 4-4
Cup holders .................................................................. 4-21DDifferential gear oil, Periodic maintenance .................. 8-18Differential gear oil, Pre-operation check ...................... 5-6
Doors ........................................................................... 4-15
Driver seat position ...................................................... 4-16
Drive select lever .......................................................... 4-14
Drive select lever operation and reverse driving ............ 6-3
EEngine break-in .............................................................. 6-1
Engine oil and oil filter cartridge, Periodic
maintenance .............................................................. 8-12
Engine oil, Pre-operation check ..................................... 5-5
Engine trouble warning light .......................................... 4-4
EPS warning light ........................................................... 4-5FFinal gear oil, Periodic maintenance ............................ 8-16
Final gear oil, Pre-operation check ................................ 5-6
Fittings and fasteners, Pre-operation check .................. 5-8
Front and rear brake pads, checking ........................... 8-36
Front and rear shock absorber assemblies ................. 4-24
Fuel, Pre-operation check .............................................. 5-3
Fuel tank cap ............................................................... 4-14
Fuse, replacing ............................................................. 8-50GGlove compartment ..................................................... 4-18HHeadlight beam, adjusting ........................................... 8-55
Headlight bulb, replacing ............................................. 8-53
Helmet indicator light ..................................................... 4-5
High-range indicator light .............................................. 4-2
Hood ............................................................................ 8-10
Horn switch .................................................................. 4-12
UB857AE0.book Page 1 Monday, August 24, 2015 8:59 AM
