YAMAHA VX CRUISER HO 2021 Manual de utilização (in Portuguese)

–6–
Exercise 1: Controls
Objective:
This exercise trains you to locate and operate the watercraft’s controls without looking or
hesitating. You must master this skill so you can scan constantly for people, objects, and
other watercraft as you maneuver, rather than taking away concentration to find a control.
Skills:
Knowing where every control is and how to use it without having to stop and think about
it.
Directions:
Drill 1: Identifying the components and controls
Read your Owner’s/Operator’s Manual to identify the watercraft’s main components and
controls. Do not just assume you know how a control works, read the instructions to be sure!
Drill 2: Pre-operation checks
Practice performing the pre-operation checks listed in your Owner’s/Operator’s Manual.
You learned where everything is in Drill 1. Now make sure everything is working proper ly. Pay particular attention to the steering
controls and the throttle lever.
Drill 3: Operating positions
With the watercraft on land and the engine off, board and become familiar with the cor-
rect operating positions described in your Owner’s/Operator’s Manual. Then, with your
eyes facing straight ahead, locate each control and verify that you know how to use it.
Continue this drill until you feel comfortable with the controls.
F4S-70-forPrint.book Page 6 Friday, September 25, 2020 4:34 PM

–7–
Exercise 2: Starting and stopping engine
Objective:
This exercise teaches you about how the engine starts and stops and how the watercraft
behaves after starting and while idling.
Skills:
Identifying and performing engine starting and stopping controls and procedures.
Directions:
Launch the watercraft and practice this exercise while standing next to it in water free
from weeds or debris and at least 60 cm (2 ft) deep from the bottom of the watercraft. Never operate in water that is less than 60 cm (2 ft) deep, otherwise pebbles or sand
could be sucked into the jet intake, causing impeller damage or engine overheating.
F4S-70-forPrint.book Page 7 Friday, September 25, 2020 4:34 PM

–8–
Exercise 2: Starting and stopping engine
Drill 1: Starting the engine
1. Check that the unlock mode indicator “1” is displayed on the multifunction informationcenter to confirm that the unlock mode of the Yamaha Security System is selected.
(See the “Yamaha Security System” section in the owner’s/operator’s manual for more
information.)
2. Attach the engine shut-off cord “3” to your wrist. Insert the clip “1”, under the engine shut-off switch “2”. Make sure to keep the engine shut-off cord free from the handle-
bars so the engine stops if the operator falls off. The clip may not pull free if the cord is
wrapped around the handlebars.
3. Push the engine start/stop switch “1” (red button). (Do not squeeze either the throttle lever or RiDE lever. Otherwise, the engine will not
start.)
4. Release the start switch as soon as the engine starts to run.
1
12
3
1
F4S-70-forPrint.book Page 8 Friday, September 25, 2020 4:34 PM

–9–
Exercise 2: Starting and stopping engine
Drill 2: Stopping the engine
1. Release the throttle lever and let the engine slow to idle.
2. Push the engine start/stop switch “1” (red button). The ignition circuit opens and stopsthe engine immediately.
3. Practice pulling the engine shut-off cord to remove the clip from the engine shut-off
switch.
Tips:
1. Attach the engine shut-off cord to your left wrist before starting the engine. To prevent accidental starting, always remove the clip from the engine shut-off switch when the
engine is not running.
2. Do not operate the start switch for more th an 5 seconds at a time. Never push the start
switch while the engine is running.
3. If the engine does not start in 5 seconds, release the start switch and try again after 15 seconds. Continuous cranking for more than 5 seconds will discharge the battery
and the engine will not start.
4. When the engine starts, thrust from the jet unit will move the watercraft. Squeezing the throttle lever produces more thrust. Apply only enough throttle to keep the engine run-
ning.
1
F4S-70-forPrint.book Page 9 Friday, September 25, 2020 4:34 PM

–10–
Exercise 3: Boarding and balancing
Objective:
This exercise trains you to board the watercraft in deep water after falling off, and to upright
a capsized watercraft. Repeat these exercises until you can perform them without difficulty.
Skills:
Boarding in deep water and balancing at a standstill.
Directions:
Practice this exercise near shore before going out into open water.
The heavier the weight of an operator, the more difficult it will be to balance the water-
craft. These exercises should be done without starting the engine.
Attach the engine shut-off cord to your wrist and keep the watercraft afloat in water that
is at least chest deep.
Drill 1: Boarding the watercraft
1. Swim to the rear of the watercraft, lower the reboarding step with one hand and hold it in place.
2. Put one foot on the step, and then grasp the reboarding grip with your other hand.
F4S-70-forPrint.book Page 10 Friday, September 25, 2020 4:34 PM

–11–
Exercise 3: Boarding and balancing
3. Pull yourself up onto the boarding platform and grasp the handgrip, and then move tothe seat and sit astride.
4. With the engine shut-off cord attached to your wrist, install the clip to the engine shutoff switch.
5. Grip the handlebars firmly with both hands and place both feet in the footwell.
6. Practice boarding and balancing several times until you can maintain good balance of the watercraft during the entire process.
F4S-70-forPrint.book Page 11 Friday, September 25, 2020 4:34 PM

–12–
Exercise 3: Boarding and balancing
Drill 2: Uprighting a capsized watercraft
Do not leave the watercraft capsized longer than necessary to upright it again. More
water may enter the engine compartment the longer the watercraft is capsized.
1. To practice uprighting, first purposely capsize the watercraft.
2. Remove the clip from the engine shut-off switch.
3. Swim to the rear of the watercraft. Turn the watercraft over by pulling on the ride plate with one hand while pushing down on the gunwale with your other hand or your foot.
4. Start the engine and operate the watercraft above planing speed as straight as possible for at least 2 minutes to discharge any water remaining in the engine compartment.
(See the “Capsized watercraft” section in the owner’s/operator’s manual for more infor-
mation.)
F4S-70-forPrint.book Page 12 Friday, September 25, 2020 4:34 PM

–13–
Exercise 4: Trolling speed maneuvering
Objective:
This exercise familiarizes you with the watercraft’s handling characteristics at trolling
speed. It teaches techniques you will use when beaching, docking, or approaching
objects.
Skills:
Starting and turning at trolling speed.
Directions:
Drill 1: Moving straight and turning at trolling speed
1. Board the watercraft, and check for people, objects and other watercraft.
2. Start the engine and go straight ahead.
3. Begin to turn, making a large figure eight about 15–21 m (50–70 ft) long. Do not apply throttle.
Drill 2: Making full-lock turns at trolling speed
1. Turn the handlebars as far as possible in either direction. Allow the watercraft to turn360°.
2. Practice turning both clockwise and counterclockwise to get a feel for how the water- craft responds to handlebar movement.
F4S-70-forPrint.book Page 13 Friday, September 25, 2020 4:34 PM

–14–
Exercise 5: Sub-planing speed maneuvering
Objective:
This exercise shows you how to move ahead, turn in small circles, and combine the two
maneuvers to make a figure eight.
Skills:
Throttle control and slow to medium speed turning.
Directions:
Steering
Your watercraft is steered by a combination of applying throttle and turning the handle-
bars “1”. When the handlebars are turned, the angle of the jet thrust nozzle “2” at the stern
is changed, which changes the direction of the watercraft.
Since the strength of the jet thrust determines the speed and direction of a turn, the
throttle must always be open when attempting a turn, except at trolling speed.
1
2
F4S-70-forPrint.book Page 14 Friday, September 25, 2020 4:34 PM

–15–
Exercise 5: Sub-planing speed maneuvering
Stopping
The watercraft is not equipped with a separate braking system. The watercraft slows
down by water resistance or, when operating in reverse, by the water jet. The watercraft
slows down as soon as the throttle lever is released, but will coast for a distance before
fully stopping. If you are not sure you can stop in time before hitting an obstacle, apply
throttle and turn in another direction. From full speed, the watercraft comes to a complete stop due to water resistance in
approximately 95 m (310 ft) after the throttle lever is released or the engine is stopped,
although this distance will vary depending on many factors, including gross weight, water
surface conditions, and wind direction.
If the RiDE lever is squeezed to slow down, the stopping distance is approximately 30%
shorter than when the RiDE lever is not used. However, this distance will vary depending
on many factors, including gross weight, water surface conditions, and wind direction.
Drill 1: Moving forward and turning in large ovals
1. Gradually accelerate forward to sub-planing speed, and then make a gradual right turn while maintaining your speed.
2. Repeat the drill, making a gradual left turn.
3. Repeat the drill, traveling forward and turning to make a complete oval.
Stopping distance
F4S-70-forPrint.book Page 15 Friday, September 25, 2020 4:34 PM
