light YAMAHA WARRIOR 350 2001 Notices Demploi (in French)

Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350TOC-E.frame
EL
EBU00015
CONTENTS
LOCATION OF THE WARNING AND
SPECIFICATION LABELS ....................... 1-1
SAFETY INFORMATION ........................ 2-1
DESCRIPTION AND MACHINE
IDENTIFICATION .................................... 3-1
Identification number records........... 3-3
Key identification number ................. 3-5
Vehicle identification number ........... 3-5
Model label ......................................... 3-7
CONTROL FUNCTIONS ......................... 4-1
Main switch ........................................ 4-1
Indicator lights.................................... 4-3
Handlebar switches............................ 4-5
Throttle lever ...................................... 4-9
Speed limiter .................................... 4-11
Clutch lever ....................................... 4-13
Front brake lever .............................. 4-13
Rear brake pedal .............................. 4-15
Parking brake .................................... 4-17
Shift pedal......................................... 4-21Drive select lever...............................4-21
Fuel tank cap .....................................4-23
Fuel cock ............................................4-23
Starter (choke) ...................................4-25
Seat ....................................................4-27
Front shock absorber adjustment....4-29
Rear shock absorber adjustment .....4-31
PRE-OPERATION CHECKS .....................5-1
Front and rear brakes .........................5-5
Fuel.......................................................5-9
Engine oil ...........................................5-13
Chain ..................................................5-15
Throttle lever .....................................5-17
Fittings and Fasteners ......................5-17
Lights .................................................5-17
Switches ............................................5-17
Battery................................................5-19
Tires ...................................................5-19
How to measure tire pressure .........5-23
Tire wear limit ...................................5-25
1234
5

Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350TOC-E.frame
EL
Drive chain cleaning and
lubrication....................................... 8-61
Cable inspection and lubrication .... 8-63
Brake and shift pedal/brake and
clutch lever lubrication .................. 8-63
Upper and lower arm pivot
lubrication....................................... 8-65
Rear arm pivot lubrication............... 8-67
Wheel removal ................................. 8-69
Wheel installation ............................ 8-71
Battery ............................................... 8-73
Replenishing the battery fluid ......... 8-77
Fuse replacement ............................. 8-81
Replacing the headlight bulb .......... 8-83
Headlight beam adjustment ............ 8-89
Troubleshooting ............................... 8-91
Troubleshooting chart ..................... 8-93
CLEANING AND STORAGE................... 9-1
A. Cleaning ......................................... 9-1
B. Storage ........................................... 9-7SPECIFICATIONS ..................................10-1
HOW TO USE THE CONVERSION
TABLE ....................................................11-1
9
1011

2-17
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-2.frame
EL
WARNING

l
Always turn off the engine when refuel-
ing.
l
Do not refuel right after the engine has
been running and is still very hot.
l
Do not spill gasoline on the engine or ex-
haust pipe/muffler when refueling. Never
refuel while smoking, or while in the vi-
cinity of sparks, open flames, or other
sources of ignition such as the pilot lights
of water heaters and clothes dryers. Gas-
oline can catch fire and you could be
burned.
l
When transporting the machine in anoth-
er vehicle, be sure it is kept upright and
that the fuel cock is in the “OFF” position.
Otherwise, fuel may leak out of the carbu-
retor or fuel tank.
l
Gasoline is poisonous. If you should swal-
low some gasoline or inhale a lot of gaso-
line vapor, or get some gasoline in your
eyes, see your doctor immediately. If gas-
oline spills on your skin, wash with soap
and water. If gasoline spills on your cloth-
ing, change your clothes.

3-1
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-3.frame
EL
EBU00032
DESCRIPTION AND MACHINE
IDENTIFICATION
1. Seat
2. Drive select lever
3. Fuel tank cap
4. Main switch
5. Brake pedal
6. Headlight
7. Front wheel
8. Fuel cock9. Rear wheel
10. Shift pedal
11. Starter (choke)
12. Clutch lever
13. Parking brake
14. Front brake lever
15. Throttle lever
16. Handlebar switch
NOTE:

The machine you have purchased may differ
slightly from those shown in the figures of this
manual.

4-1
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-4.frame
EL
EBU00040
CONTROL FUNCTIONS
EBU00041
Main switch
Functions of the respective switch positions
are as follows:
ON:
Engine can be started only at this position and
the headlight and taillight come on when the
light switch is on.
OFF:
All electrical circuits are switched off. The key
can be removed in this position.

4-3
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-4.frame
EL
1. Reverse indicator light “REVERSE”
2. Neutral indicator light “NEUTRAL”
1. Témoin de marche arrière “REVERSE”
2. Témoin de point mort “NEUTRAL”
1. Luz de control de marcha atrás “REVERSE”
2. Luz de control de punto muerto “NEUTRAL”
EBU00043
Indicator lights
EBU00044
Reverse indicator light “REVERSE”
This indicator light comes on when the trans-
mission is in reverse.
EBU00045
Neutral indicator light “NEUTRAL”
This indicator light comes on when the trans-
mission is in neutral.

4-5
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-4.frame
EL
1. Lights switch “LIGHTS”
2. Engine stop switch “ENG. STOP”
3. Start switch “START”
1. Contacteur d’éclairage “LIGHTS”
2. Coupe-circuit du moteur “ENG. STOP”
3. Contacteur du démarreur “START”
1. Interruptor de luces “LIGHTS”
2. Interruptor de paro del motor “ENG. STOP”
3. Interruptor de arranque “START”
EBU00053
Handlebar switches
EBU00054
Engine stop switch “ENG. STOP”
Make sure that the engine stop switch is in the
“RUN” position. The engine stop switch con-
trols ignition and can be used at all times to
stop the engine, especially in an emergency.
The engine will not start or run when the en-
gine stop switch is turned to “OFF”.
EBU00647
Start switch “START”
The starter motor cranks the engine when this
switch is pushed.
CAUTION:

See the starting instructions on page 6-3 prior
to starting the engine.

4-7
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-4.frame
EL
EBU00734
Light switch “LIGHTS”
Turn the switch to the “LO” position to switch
on the low beam and the taillight.
Turn the switch to the “HI” position to switch
on the high beam and the taillight.
Turn the switch to the “OFF” position to switch
off the headlight and the taillight.
CAUTION:

Do not use the headlight with the engine
turned off for more than thirty minutes. The
battery may discharge to the point that the
starter motor will not operate properly. If this
should happen, remove the battery and re-
charge it.

4-8
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-4.frame
ER
FBU00734
Contacteur d’éclairage “LIGHTS”
Tourner le contacteur à la position “LO” pour allumer le
feu de croisement et le feu arrière.
Tourner le contacteur à la position “HI” pour allumer le
feu de route et le feu arrière.
Placer le contacteur sur “OFF” pour éteindre le phare et
le feu arrière.
ATTENTION:ATTENTION:ATTENTION:ATTENTION:

Ne jamais laisser le phare allumé pendant plus d’une
demi-heure après avoir coupé le moteur. La batterie
risque de se décharger au point d’empêcher la mise
en marche du moteur. Si cela devait se produire, dé-
poser et recharger la batterie.
SBU00734
Interruptor de luces “LIGHTS”
Gire el interruptor a la posición “LO” para encen-
der la luz de cruce del faro y la luz trasera.
Gire el interruptor a la posición “HI” para encen-
der la luz de carretera del faro y la luz trasera.
Gire el interruptor a la posición “OFF” para apa-
gar el faro y la luz trasera.
ATENCION:

No mantenga el faro encendido durante más de
treinta minutos con el motor parado. La batería
podría descargarse hasta el extremo de que el
motor de arranque no funcione debidamente. Si
sucediese esto, desmonte la batería y recárgue-
la.

5-1
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-5.frame
EL
EBU00113
PRE-OPERATION CHECKS
Before using this machine, check the following points:
ITEM ROUTINE PAGE
Brake
• Check operation, free play, fluid level and fluid leakage.
• Fill with DOT 4 (or DOT 3) brake fluid if necessary.5-5 ~ 5-7,
8-39 ~ 8-49
Clutch
• Check operation, condition and lever free play. 8-55
Parking brake
• Check operation, condition and cable slack. 8-51 ~ 8-53
Fuel
• Check fuel level.
• Fill with fuel if necessary.5-9 ~ 5-11
Engine oil
• Check oil level.
• Fill with oil if necessary.5-13 ~ 5-15,
8-15 ~ 8-23
Drive chain
• Check chain slack and condition.
• Adjust if necessary.5-15, 8-57 ~ 8-61
Throttle
• Check for proper throttle cable operation. 5-17, 8-37
Wheels and tires
• Check tire pressure, wear and damage.5-19 ~ 5-25,
8-69 ~ 8-71
Fittings and Fasteners
• Check all fittings and fasteners. 5-17
Lights
• Check for proper operation. 5-17, 8-83 ~ 8-89
Battery
• Check fluid level.
• Fill with distilled water if necessary.5-19, 8-73 ~ 8-79
