3-1
EBU00032
DESCRIPTION AND MACHINE
IDENTIFICATION1. Seat
2. Drive select lever
3. Fuel tank cap
4. Main switch
5. Brake pedal
6. Headlights
7. Front wheel
8. Fuel cock9. Rear wheel
10. Shift pedal
11. Starter (choke)
12. Clutch lever
13. Parking brake
14. Brake lever
15. Throttle lever
16. Handlebar switchesNOTE:The machine you have purchased may differ
slightly from those shown in the figures of this
manual.
U5NF61.book Page 1 Wednesday, June 13, 2001 5:18 PM

4-13 1. Clutch lever
1. Levier d’embrayage
1. Palanca de embrague
1. Brake lever
1. Levier de frein
1. Palanca del freno
EBU00069
Clutch lever
The clutch lever is located on the left handlebar
and the ignition circuit cut-off system is incorporat-
ed in the clutch lever holder. Pull the clutch lever to
the handlebar to disengage the clutch, and release
the lever to engage the clutch. The lever should be
pulled rapidly and released slowly for smooth
clutch operation. (Refer to “Starting a cold engine”
for a description of the ignition circuit cut-off sys-
tem.)
EBU00070*
Brake lever
The front brake lever is located on the right handle-
bar. Pull it toward the handlebar to apply the front
brake.
U5NF61.book Page 13 Wednesday, June 13, 2001 5:18 PM

4-17 1. Button 2. Lock plate
1. Bouton 2. Verrou
1. Botón 2. Placa de bloqueo
1. Locked position
1. Position verrou bloqué
1. Posición bloqueada
EBU00081
Parking brake
Use the parking brake when you have to start the
engine or park the machine, especially on a slope.
Squeeze the clutch lever while pushing the button,
then push in the lock plate to apply the parking
brake. Squeeze the clutch lever to release the
parking brake.NOTE:When the parking brake is used, engine speed is
limited to 2,300 r/min. Be sure the parking brake is
released before moving the throttle lever. Other-
wise, the engine will misfire, preventing normal op-
eration.
U5NF61.book Page 17 Wednesday, June 13, 2001 5:18 PM

4-21 1. Shift pedal
1. Pédale de sélection
1. Pedal del cambio
1. Drive select lever
1. Levier de présélection
1. Palanca de selección de gama
EBU00082
Shift pedal
This machine is equipped with a constant-mesh 6-
speed transmission. The shift pedal is located on
the left side of the engine and is used in combina-
tion with the clutch when shifting.
EBU00085
Drive select lever
The drive select lever is used for driving the machine
either forward or in reverse. Refer to page 6-11 for
drive select lever operation.
U5NF61.book Page 21 Wednesday, June 13, 2001 5:18 PM

5-1
EBU00113
PRE-OPERATION CHECKS
Before using this machine, check the following points:
ITEM ROUTINE PAGE
BrakeCheck operation, fluid level and fluid leakage.
Fill with DOT 4 brake fluid if necessary.5-5 ~ 5-7,
8-39 ~ 8-49
ClutchCheck operation, condition and lever free play. 8-57
Parking brakeCheck operation, condition and cable free play. 8-51 ~ 8-53
FuelCheck fuel level.
Fill with fuel if necessary.5-9 ~ 5-11
Engine oilCheck oil level.
Fill with oil if necessary.5-13 ~ 5-15,
8-15 ~ 8-23
Drive chainCheck chain slack and condition.
Adjust if necessary.5-15, 8-59 ~ 8-63
ThrottleCheck for proper throttle cable operation and free play. 5-17, 8-37
Wheels and tiresCheck tire pressure, wear and damage.5-19 ~ 5-25,
8-71 ~ 8-73
Fittings and FastenersCheck all fittings and fasteners. 5-17
LightsCheck for proper operation. 5-17, 8-85 ~ 8-95
BatteryCheck fluid level.
Fill with distilled water if necessary.5-19, 8-75 ~ 8-81
U5NF61.book Page 1 Wednesday, June 13, 2001 5:18 PM

5-15
CAUTION:_ Be sure to use motor oils that do not contain
anti-friction modifiers. Passenger car motor
oils (often labeled “ENERGY CONSERVING II”)
contain anti-friction additives which will cause
clutch and/or starter clutch slippage, resulting
in reduced component life and poor engine
performance.
EBU00498
Chain
Check the general condition of the chain and check
the chain slack before every ride. Lubricate and ad-
just the chain as necessary. (See pages 8-59 ~ 8-63
for details.)Oil quantity:
Total amount:
3.2 L
Periodic oil change:
2.4 L
With oil filter replacement:
2.5 L
U5NF61.book Page 15 Wednesday, June 13, 2001 5:18 PM

6-5 a. Starter (choke) 1. Fully open
2. Half open 3. Closed
a. Starter (enrichisseur) 1. Complètement ouvert
2. Mi-ouvert 3. Fermé
a. Starter (choke) 1. Abre completamente
2. Semiabierto 3. Cerrado
NOTE:_ This model is equipped with an ignition circuit cut-
off system. The engine can be started under the
following conditions.

When the transmission is in neutral. At this
time the neutral indicator light should come on.
If the light does not come on, ask a Yamaha
dealer to inspect it.


When the clutch is disengaged with the trans-
mission and drive select lever in any position.
However, it is recommended to shift into neu-
tral before starting the engine.
_5. Use the starter (choke) in reference to the fig-
ure:
Position
1: Cold engine start-ambient tempera-
ture below 5°C.
Position
2: Cold engine start-ambient tempera-
ture at 0°C ~ 30°C and warming up
position.
Position
3: Cold engine start- ambient tempera-
ture above 25°C and warm engine
start position.
U5NF61.book Page 5 Wednesday, June 13, 2001 5:18 PM
