2 - 3
SPEC

GENERAL SPECIFICATIONS
Tire:
Type With tube
Size (front) 80/100-21 51M (USA, CDN, ZA)
90/90-21 54R (EUROPE, AUS, NZ)
Size (rear) 110/100-18 64M (USA, CDN, ZA)
120/90-18 65R (EUROPE, AUS, NZ)
Tire pressure (front and rear) 100 kPa (1.0 kg/cm
2

, 15 psi)
Brake:
Front brake type Single disc brake
Operation Right hand operation
Rear brake type Single disc brake
Operation Right foot operation
Suspension:
Front suspension Telescopic fork
Rear suspension Swingarm (link type monocross suspension)
Shock absorber:
Front shock absorber Coil spring/oil damper
Rear shock absorber Coil spring/gas, oil damper
Wheel travel:
Front wheel travel 300 mm (11.8 in)
Rear wheel travel 315 mm (12.4 in)
Electrical:
Ignition system CDI magneto

7 - 11
TUN
EC72N000
Drive and driven sprockets setting parts
Part name Size Part number
Drive sprocket 1
(STD) 14T 9383E-14215
Driven sprocket 2
(STD)48T
50T
52T5GS-25448-50
5GS-25450-50
5GS-25452-50
EC721002
Tire pressure
Tire pressure should be adjust to suit the road
surface condition of the circuit.
lUnder a rainy, muddy, sandy, or slippery
condition, the tire pressure should be lower
for a larger area of contact with the road sur-
face.
lUnder a stony or hard road condition, the tire
pressure should be higher to prevent a flat
tire.
Standard tire pressure:
100 kPa (1.0 kg/cm2, 15 psi)
Extent of adjustment:
60 ~ 80 kPa
(0.6 ~ 0.8 kg/cm
2, 9.0 ~ 12 psi)
Extent of adjustment:
100 ~ 120 kPa
(1.0 ~ 1.2 kg/cm
2, 15 ~ 18 psi)
SETTING
