Periodic maintenance and adjustment6-26
1
2
3
4
567
8
9
10
11
12
EAU45512
Checking the steeringWorn or loose steering bearings may
cause danger. Therefore, the operation
of the steering must be checked as fol-
lows at the intervals specified in the pe-
riodic maintenance and lubrication
chart. 1. Place the vehicle on the center- stand. WARNING! To avoid inju-
ry, securely support the vehicle
so there is no danger of it falling
over.
[EWA10752]
2. Hold the lower ends of the front fork legs and try to move them for-
ward and backward. If any free
play can be felt, have a Yamaha
dealer check or repair the steering.
EAU23292
Checking the w heel bearingsThe front and rear wheel bearings must
be checked at the intervals specified in
the periodic maintenance and lubrica-
tion chart. If there is play in the wheel
hub or if the wheel does not turn
smoothly, have a Yamaha dealer check
the wheel bearings.
EAUT3762
BatteryThis model is equipped with a VRLA
(Valve Regulated Lead Acid) battery.
There is no need to check the electro-
lyte or to add distilled water. However,
the battery lead connections need to be
checked and, if necessary, tightened.
WARNING
EWA10761

Electrolyte is poisonous and
dangerous since it contains sul-
furic acid, which causes severe
burns. Avoid any contact with
skin, eyes or clothing and al-
ways shield your eyes when
working near batteries. In case
of contact, administer the fol-
lowing FIRST AID.
EXTERNAL: Flush with plenty
of water.
INTERNAL: Drink large quan- tities of water or milk and im-
mediately call a physician.
EYES: Flush with water for 15
minutes and seek prompt
medical attention.

Batteries produce explosive hy-
drogen gas. Therefore, keep
U52SE1E0 26 ページ ２０１５年９月１６日　水曜日　午後５時２７分

Periodic maintenance and adjustment
6-27
1
2
3
4
56
7
8
9
10
11
12 sparks, flames, cigarettes, etc.,
away from the battery and pro-
vide sufficient ventilation when
charging it in an enclosed
space.

KEEP THIS AND ALL BATTER-
IES OUT OF THE REACH OFCHILDREN.
NOTICE
ECA10621
Never attempt to remove the battery
cell seals, as this would permanent-ly damage the battery.
The battery is located behind panel A.
Remove the panel to access the bat-
tery. (See page 6-8.)
To charge the battery
Have a Yamaha dealer charge the bat-
tery as soon as possi
ble if it seems to
have discharged. Keep in mind that the
battery tends to discharge more quickly
if the vehicle is equipped with optional
electrical accessories.
NOTICE
ECA16522
To charge a VRLA (Valve Regulated
Lead Acid) battery, a special (con-
stant-voltage) battery charger is re-
quired. Using a conventional batterycharger will damage the battery.
To store the battery 1. If the vehicle will not be used for more than one month, remove the
battery, fully charge it, and then
place it in a cool, dry place.
NOTICE: When removing the
battery, be sure the key is
turned to “OFF”, then discon-
nect the negative lead before
disconnecting the positive
lead.
[ECA16303]
2. If the battery will be stored for morethan two months, check it at least once a month and fully charge it if
necessary.
3. Fully charge the battery before in- stalling it. NOTICE: When install-
ing the battery, be sure the key
is turned to “OFF”, then con-
nect the positive lead before
connecting the negative
lead.
[ECA16841]
4. After installing the battery, make sure that the battery leads are
properly connected to the battery
terminals.
5. Turn the key from “ON” to “OFF” three times in three-second inter-
vals to initialize the idle speed con-
trol system.NOTICE
ECA16531
Always keep the battery charged.
Storing a discharged battery cancause permanent battery damage.
1. Battery
1
U52SE1E0 27 ページ ２０１５年９月１６日　水曜日　午後５時２７分

Periodic maintenance and adjustment6-28
1
2
3
4
567
8
9
10
11
12
EAUT3752
Replacing the fusesThe fuse box is located beside the bat-
tery compartment under panel A. (See
page 6-8.)
If a fuse is blown, replace it as follows. 1. Turn the key to “OFF” and turn off the electrical circuit in question.
2. Remove the blown fuse, and then install a new fuse of the specified
amperage. WARNING! Do not
use a fuse of a higher amperage
rating than recommended to
avoid causing extensive dam-
age to the electrical system and
possibly a fire.
[EWA15132]
TIPAfter removing and installing the main
fuse, be sure to turn the main switch
from “ON” to “OFF” three times in
three-second intervals to initialize theidle speed control system.
3. Turn the key to “ON” and turn on the electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows again, have a Yamaha dealer
check the electrical system.
EAUT3661
Replacing the headlight bulbThis model is equipped with a halogen
bulb headlight. If a headlight bulb burns
out, replace it as follows.NOTICE
ECA10651
Take care not to damage the follow-
ing parts:
Headlight bulb
Do not touch the glass part of
the headlight bulb to keep it free
from oil, otherwise the transpar-
ency of the glass, the luminosity
of the bulb, and the bulb life will
be adversely affected. Thor-
oughly clean off any dirt and fin-
gerprints on the headlight bulb
using a cloth moistened with al-
cohol or thinner.

Headlight lens
Do not affix any type of tinted
film or stickers to the headlight
lens.
Do not use a headlight bulb of awattage higher than specified.
1. Remove cowling A together with the headlight unit. (See page 6-8.)
1. Fuse box
1
Specified fuses:Main fuse:20.0 A
Ignition fuse:
7.5 A
Signaling system fuse: 15.0 A
Headlight fuse: 15.0 A
Backup fuse:
7.5 A
U52SE1E0 28 ページ ２０１５年９月１６日　水曜日　午後５時２７分

Periodic maintenance and adjustment
6-29
1
2
3
4
56
7
8
9
10
11
12 2. Remove the bulb cover, and then
disconnect the headlight coupler.
3. Unhook the headlight bulb holder, and then remove the burnt-out
bulb. 4. Place a new headlight bulb into po-
sition, and then secure it with the
bulb holder.
5. Connect the coupler, and then in- stall the headlight bulb cover.
6. Install the cowling together with the headlight unit.
7. Have a Yamaha dealer adjust the headlight beam if necessary.
EAUT3641
Replacing an auxiliary light
bulbIf an auxiliary light bulb burns out, re-
place it as follows.1. Remove cowling A. (See page 6-8.)
2. Remove the socket (together with the bulb) by turning it counter-
clockwise.
3. Remove the burnt out bulb by pull- ing it out.
1. Headlight bulb cover
1. Headlight coupler
2. Headlight bulb holder
3. Headlight bulb
1
1
2
3
1. Auxiliary light bulb socket
1
U52SE1E0 29 ページ ２０１５年９月１６日　水曜日　午後５時２７分

Periodic maintenance and adjustment6-30
1
2
3
4
567
8
9
10
11
12
4. Insert a new bulb into the socket.
5. Install the socket (together with the
bulb) by turning it clockwise.
6. Install the cowling.
EAU24182
Tail/brake lightThis model is equipped with an
LED-type tail/brake light.
If the tail/brake light does not come on,
have a Yamaha dealer check it.
EAUT3652
Replacing a front turn signal
light bulbIf a front turn signal light burns out, re-
place it as follows. 1. Remove cowling A. (See page 6-8.)
2. Remove the socket (together with the bulb) by turning it counter-
clockwise.
3. Remove the burnt out bulb by pushing it in and turning it counter-
clockwise.
1. Auxiliary light bulb
1
1. Turn signal light bulb socket
1
U52SE1E0 30 ページ ２０１５年９月１６日　水曜日　午後５時２７分

Periodic maintenance and adjustment
6-31
1
2
3
4
56
7
8
9
10
11
12 4. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
NOTICE
ECAU0081
If a turn signal light bulb of different
wattage than recommended is used,
the turn signal light flashing may beaffected.
5. Install the socket (together with the bulb) by turning it clockwise.
6. Install the cowling.
EAUT3671
Replacing a rear turn signal
light bulb1. Remove the turn signal lens by re- moving the screw.
2. Remove the burnt-out bulb by pushing it in and turning it counter-
clockwise.
3. Insert a new bulb into the socket, push it in, and then turn it clock-
wise until it stops.NOTICE
ECAU0081
If a turn signal light bulb of different
wattage than recommended is used,
the turn signal light flashing may beaffected. 4. Install the lens by installing the
screw. NOTICE: Do not over-
tighten the screw, otherwise the
lens may break.
[ECA11192]
1. Turn signal light bulb
1
1. Turn signal light bulb
1
U52SE1E0 31 ページ ２０１５年９月１６日　水曜日　午後５時２７分

Periodic maintenance and adjustment6-32
1
2
3
4
567
8
9
10
11
12
EAU24331
License plate lightIf the license plate light does not come
on, have a Yamaha dealer check the
electrical circuit or replace the bulb.
EAU25882
TroubleshootingAlthough Yamaha scooters receive a
thorough inspection before shipment
from the factory, trouble may occur dur-
ing operation. Any problem in the fuel,
compression, or ignition systems, for
example, can cause poor starting and
loss of power.
The following troubleshooting charts
represent quick and easy procedures
for checking these vital systems your-
self. However, should your scooter re-
quire any repair, take it to a Yamaha
dealer, whose skilled technicians have
the necessary tools, experience, and
know-how to service the scooter prop-
erly.
Use only genuine Yamaha replace-
ment parts. Imitation parts may look like
Yamaha parts, but they are often inferi-
or, have a shorter service life and can
lead to expensive repair bills.
WARNING
EWA15142
When checking the fuel system, do
not smoke, and make sure there are
no open flames or sparks in the ar-
ea, including pilot lights from water heaters or furnaces. Gasoline or
gasoline vapors can ignite or ex-
plode, causing severe injury or
property damage.
U52SE1E0 32 ページ ２０１５年９月１６日　水曜日　午後５時２７分

Periodic maintenance and adjustment
6-33
1
2
3
4
56
7
8
9
10
11
12
EAU42706
Troubleshooting chartsStarting problems or poor engine performanceCheck the fuel level in
the fuel tank.1. Fuel
There is enough fuel.
There is no fuel.
Check the battery.
Supply fuel.
The engine does not start.
Check the battery.
Operate the electric starter.4. Compression
There is compression.
There is no compression.
The engine does not start.
Have a Yamaha dealer check the vehicle.Have a Yamaha dealer check the vehicle.
Remove the spark plug
and check the electrodes.3. Ignition
Wipe off with a dry cloth and correct the
spark plug gap, or replace the spark plug. Have a Yamaha dealer check the vehicle.
The engine does not start.
Check the compression.
Operate the electric starter.2. Battery
The engine turns over
quickly.
The engine turns over
slowly.
The battery is good.
DryWet
Operate the electric starter.
Check the battery lead connections,
and have a Yamaha dealer charge
the battery if necessary.
The engine does not start.
Check the ignition.
U52SE1E0 33 ページ ２０１５年９月１６日　水曜日　午後５時２７分

Periodic maintenance and adjustment6-34
1
2
3
4
567
8
9
10
11
12
Engine overheating
WARNING
EWAT1041

Do not remove the radiator cap when the engine and radiator are hot. Scalding hot fluid and steam may be
blown out under pressure, which could cause serious injury. Be sure to wait until the engine has cooled.

Place a thick rag, like a towel, over the radiator cap, and then slowly rotate the cap counterclockwise to the de-
tent to allow any residual pressure to escape. When the hissing sound has stopped, press down on the capwhile turning it counterclockwise, and then remove the cap.
TIPIf coolant is not available, tap water can be temporarily
used instead, provided that it is changed to the recommended coolantas soon as possible.Wait until the
engine has cooled.
Check the coolant level in the
reservoir and radiator.
The coolant level
is OK.The coolant level is low.
Check the cooling system
for leakage.
Have a Yamaha dealer checkand repair the cooling system.Add coolant. (See TIP.)
Start the engine. If the engine overheats again,
have a
Yamaha dealer check
and repair the cooling system.
There is
leakage.
There is
no leakage.
U52SE1E0 34 ページ ２０１５年９月１６日　水曜日　午後５時２７分

7-1
1
2
3
4
5
67
8
9
10
11
12
Scooter care and storage
EAU37834
Matte color cautionNOTICE
ECA15193
Some models are equipped with
matte colored finished parts. Be
sure to consult a Yamaha dealer for
advice on what products to use be-
fore cleaning the vehicle. Using a
brush, harsh chemical products or
cleaning compounds when cleaning
these parts will scratch or damage
their surface. Wax also should not
be applied to any matte colored fin-ished parts.
EAU26096
CareWhile the open design of a scooter re-
veals the attractiveness of the technol-
ogy, it also makes it more vulnerable.
Rust and corrosion can develop even if
high-quality components are used. A
rusty exhaust pipe may go unnoticed
on a car, however, it detracts from the
overall appearance of a scooter. Fre-
quent and proper care does not only
comply with the terms of the warranty,
but it will also keep your scooter looking
good, extend its life and optimize its
performance.
Before cleaning 1. Cover the muffler outlet with a plastic bag after the engine has
cooled down.
2. Make sure that all caps and covers as well as all electrical couplers
and connectors, including the
spark plug cap, are tightly in-
stalled.
3. Remove extremely stubborn dirt, like oil burnt onto the crankcase,
with a degreasing agent and a
brush, but never apply such prod- ucts onto seals, gaskets and wheel
axles. Always rinse the dirt and de-
greaser off with water.
Cleaning
NOTICE
ECA10784

Avoid using strong acidic wheel
cleaners, especially on spoked
wheels. If such products are
used on hard-to-remove dirt, do
not leave the cleaner on the af-
fected area any longer than in-
structed. Also, thoroughly rinse
the area off with water, immedi-
ately dry it, and then apply a cor-
rosion protection spray.

Improper cleaning can damage
plastic parts (such as cowlings,
panels, windshields, headlight
lenses, meter lenses, etc.) and
the mufflers. Use only a soft,
clean cloth or sponge with wa-
ter to clean plastic. However, if
the plastic parts cannot be thor-
oughly cleaned with water, di-
luted mild detergent with water
may be used. Be sure to rinse
off any detergent residue using
U52SE1E0 1 ページ ２０１５年９月１６日　水曜日　午後５時２７分
