YAMAHA XJR 1300 2002 Owner's Manual

INSTRUMENT AND CONTROL FUNCTIONS
3-6
3
The clutch lever is equipped with a
clutch lever position adjusting dial. To
adjust the distance between the clutch
lever and the handlebar grip, turn the
adjusting dial while holding the lever
pushed away from the handlebar grip.
Make sure that the appropriate setting
on the adjusting dial is aligned with the
arrow mark on the clutch lever.
The clutch lever is equipped with a
clutch switch, which is part of the ignition
circuit cut-off system. (See page 3-17
for an explanation of the ignition circuit
cut-off system.)
EAU00157
Shift pedal The shift pedal is located on the left
side of the engine and is used in com-
bination with the clutch lever when
shifting the gears of the 5-speed con-
stant-mesh transmission equipped on
this motorcycle.
1. Clutch lever position adjusting dial
2. Arrow mark
1. Shift pedal
E_5ea.book Page 6 Tuesday, October 2, 2001 3:54 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-7
3
EAU00161
Brake lever The brake lever is located at the right
handlebar grip. To apply the front
brake, pull the lever toward the handle-
bar grip.The brake lever is equipped with a po-
sition adjusting dial. To adjust the dis-
tance between the brake lever and the
handlebar grip, turn the adjusting dial
while holding the lever pushed away
from the handlebar grip. Make sure that
the appropriate setting on the adjusting
dial is aligned with the arrow mark on
the brake lever.
EAU00162
Brake pedal The brake pedal is on the right side of
the motorcycle. To apply the rear
brake, press down on the brake pedal.
1. Brake lever
1. Arrow mark
2. Brake lever position adjusting dial
1. Brake pedal
E_5ea.book Page 7 Tuesday, October 2, 2001 3:54 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-8
3
EAU02935
Fuel tank cap To open the fuel tank cap
Open the fuel tank cap lock cover, in-
sert the key into the lock, and then turn
it 1/4 turn clockwise. The lock will be re-
leased and the fuel tank cap can be
opened.
To close the fuel tank cap
1. Push the fuel tank cap into posi-
tion with the key inserted in the
lock. 2. Turn the key counterclockwise to
the original position, remove it,
and then close the lock cover.
NOTE:_ The fuel tank cap cannot be closed un-
less the key is in the lock. In addition,
the key cannot be removed if the cap is
not properly closed and locked. _
EWA00025
WARNING
_ Make sure that the fuel tank cap is
properly closed before riding. _
1. Fuel tank cap lock cover
2. Unlock.
E_5ea.book Page 8 Tuesday, October 2, 2001 3:54 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-9
3
EAU03753
Fuel Make sure that there is sufficient fuel in
the tank. Fill the fuel tank to the bottom
of the filler tube as shown.
EW000130
WARNING
_

Do not overfill the fuel tank, oth-
erwise it may overflow when the
fuel warms up and expands.


Avoid spilling fuel on the hot
engine.
_
EAU00185
CAUTION:_ Immediately wipe off spilled fuel
with a clean, dry, soft cloth, since
fuel may deteriorate painted surfac-
es or plastic parts. _
EAU04284
ECA00104
CAUTION:_ Use only unleaded gasoline. The
use of leaded gasoline will cause se-
vere damage to internal engine
parts, such as the valves and piston
rings, as well as to the exhaust sys-
tem. _
Your Yamaha engine has been de-
signed to use regular unleaded gaso-
line with a research octane number of
91 or higher. If knocking (or pinging)
occurs, use a gasoline of a different
brand or premium unleaded fuel. Use
of unleaded fuel will extend spark plug
life and reduce maintenance costs.
1. Fuel tank filler tube
2. Fuel level
Recommended fuel:
REGULAR UNLEADED
GASOLINE ONLY
Fuel tank capacity:
Total amount:
21 L
Reserve amount:
4.5 L
E_5ea.book Page 9 Tuesday, October 2, 2001 3:54 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-10
3
EAU02955
Fuel tank breather hose Before operating the motorcycle:

Check the fuel tank breather hose
connection.


Check the fuel tank breather hose
for cracks or damage, and replace
it if damaged.


Make sure that the end of the fuel
tank breather hose is not blocked,
and clean it if necessary.
EAU00207
Fuel cock The fuel cock supplies fuel from the
tank to the carburetors while also filter-
ing it.
The fuel cock lever positions are ex-
plained as follows and shown in the il-
lustrations.
ON
With the fuel cock lever in this position,
fuel flows to the carburetors when the
engine is running. Turn the fuel cock le-
ver to this position when starting the
engine and riding.RES
This indicates reserve. With the fuel
cock lever in this position, the fuel re-
serve is made available. Quickly turn
the fuel cock lever to this position if you
run out of fuel while riding, otherwise
the engine may stall and will have to be
primed (see “PRI”). After turning the
fuel cock lever to “RES”, refuel as soon
as possible and be sure to turn the fuel
cock lever back to “ON”!
1. Fuel tank breather hose
2. Original position (white mark)
1. Arrow mark positioned over “ON”ON: Normal position
1. Arrow mark positioned over “RES”RES: Reserve position
E_5ea.book Page 10 Tuesday, October 2, 2001 3:54 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-11
3
PRI
This indicates prime. With the fuel cock
lever in this position, the engine can be
“primed”. Turn the fuel cock lever to
this position when the engine has been
allowed to run out of fuel. This sends
fuel directly to the carburetors, which
will make starting easier. After the en-
gine has started, be sure to turn the le-
ver to “ON” (or “RES” if you have not
refueled yet).
EAU03839
Starter (choke) lever “” Starting a cold engine requires a richer
air-fuel mixture, which is supplied by
the starter (choke).
Move the lever in direction
a to turn on
the starter (choke).
Move the lever in direction
b to turn off
the starter (choke).
EAU04406
Seat To remove the seat
1. Insert the key into the seat lock,
and then turn it as shown.
2. Pull the seat off.
1. Arrow mark positioned over “PRI”PRI: Priming position
1. Starter (choke) lever “”
1. Unlock.
E_5ea.book Page 11 Tuesday, October 2, 2001 3:54 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-12
3
To install the seat
1. Insert the projection on the front of
the seat into the seat holder as
shown.
2. Push the rear of the seat down to
lock it in place.
3. Remove the key.
NOTE:_ Make sure that the seat is properly se-
cured before riding. _
EAU04291
Helmet holder To open the helmet holder, insert the
key into the seat lock, and then turn the
key as shown.
To lock the helmet holder, turn the key
to the original position, and then re-
move it.
EW000030
WARNING
_ Never ride with a helmet attached to
the helmet holder, since the helmet
may hit objects, causing loss of
control and possibly an accident. _
1. Projection
2. Seat holder
1. Unlock.
E_5ea.book Page 12 Tuesday, October 2, 2001 3:54 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-13
3
EAU04292
Storage compartment This storage compartment is designed
to hold an optional genuine Yamaha
U-LOCK. (Other locks may not fit.)
When placing a U-LOCK in the stor-
age compartment, securely fasten it
with the straps. When the U-LOCK is
not in the storage compartment, be
sure to secure the straps to prevent
losing them.When storing the owner’s manual or
other documents in the storage com-
partment, be sure to wrap them in a
plastic bag so that they will not get
wet. When washing the motorcycle,
be careful not to let any water enter
the storage compartment.
EAU00285
Adjusting the front fork This front fork is equipped with spring
preload adjusting bolts.
EW000035
WARNING
_ Always adjust both fork legs equal-
ly, otherwise poor handling and loss
of stability may result. _
1. U-LOCK bar
2. Strap (× 2)
3. Lock of the U-LOCKE_5ea.book Page 13 Tuesday, October 2, 2001 3:54 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-14
3
Adjust the spring preload as follows.
To increase the spring preload and
thereby harden the suspension, turn
the adjusting bolt on each fork leg in di-
rection
a. To decrease the spring pre-
load and thereby soften the
suspension, turn the adjusting bolt on
each fork leg in direction
b.
NOTE:_ Align the appropriate groove on the ad-
justing mechanism with the top of the
front fork cap bolt. _CI-10E
1. Spring preload adjusting bolt
1. Current setting
2. Front fork cap bolt
Setting
Minimum (soft) 7
Standard 5
Maximum (hard) 1
E_5ea.book Page 14 Tuesday, October 2, 2001 3:54 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-15
3
EAU04407
Adjusting the shock absorber
assemblies Each shock absorber assembly is
equipped with a spring preload adjust-
ing ring.
EC000015
CAUTION:_ Never attempt to turn an adjusting
mechanism beyond the maximum
or minimum settings. _
EW000040
WARNING
_ Always adjust both shock absorber
assemblies equally, otherwise poor
handling and loss of stability may
result. _
Adjust the spring preload as follows,
using the special wrenches included
along with the owner’s tool kit.
To increase the spring preload and
thereby harden the suspension, hold
the upper ring in place while turning the
lower ring (adjusting ring) on each
shock absorber assembly as shown in
illustration
+.To decrease the spring preload and
thereby soften the suspension, hold the
upper ring in place while turning the
lower ring (adjusting ring) on each
shock absorber assembly as shown in
illustration
,.1. Upper ring
2. Lower ring (spring preload adjusting ring)
1. Upper ring
2. Lower ring (spring preload adjusting ring)
