YAMAHA XMAX 125 2013 Owners Manual

SPECIFICATIONS
8-3
8
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
95.0 mm (3.74 in)Electrical system:Ignition system:
TCI
Charging system:
AC magnetoBattery:Model:
GTX9-BS
Voltage, capacity:
12 V, 8.0 AhHeadlight:Bulb type:
Halogen bulbBulb voltage, wattage × quantity:Low beam headlight:
12 V, 55.0 W × 1
High beam headlight:
12 V, 55.0 W × 1
Tail/brake light:
12 V, 5.0 W/21.0 W × 2
Front turn signal light:
12 V, 10.0 W × 2
Rear turn signal light:
12 V, 10.0 W × 2
Auxiliary light:
12 V, 5.0 W × 2
License plate light:
12 V, 5.0 W × 1
Meter lighting:
12 V, 2.0 W × 3High beam indicator light:
12 V, 1.4 W × 1
Turn signal indicator light:
12 V, 1.4 W × 2
Engine trouble warning light:
12 V, 1.4 W x 1
ABS warning light:
YP125RA 12 V, 1.4 W × 1
Immobilizer system indicator light:
LED
Fuses:Main fuse:
30.0 A
Headlight fuse:
15.0 A
Signaling system fuse:
10.0 A
Ignition fuse:
10.0 A
Radiator fan fuse:
7.5 A
Hazard fuse:
10.0 A
ECU fuse:
5.0 A
ABS control unit fuse:
YP125RA 5.0 A
ABS motor fuse:
YP125RA 30.0 A
Backup fuse:
5.0 A
U2ABE2E0.book Page 3 Thursday, August 30, 2012 2:36 PM

CONSUMER INFORMATION
9-1
9
EAU48612
Identification numbers Record the vehicle identification num-
ber and model label information in the
spaces provided below for assistance
when ordering spare parts from a
Yamaha dealer or for reference in case
the vehicle is stolen.
VEHICLE IDENTIFICATION
NUMBER:
MODEL LABEL INFORMATION:
EAU26410
Vehicle identification number
The vehicle identification number is
stamped into the frame.TIPThe vehicle identification number is
used to identify your vehicle and may
be used to register it with the licensing
authority in your area.
EAU26460
Model label
The model label is affixed to the loca-
tion shown. Record the information on
this label in the space provided. This in-
formation will be needed when ordering
spare parts from a Yamaha dealer.
1. Vehicle identification number
1
1. Model label
U2ABE2E0.book Page 1 Thursday, August 30, 2012 2:36 PM

INDEX
AABS (for ABS models) .......................... 3-13
ABS warning light (for ABS models) ....... 3-4
Acceleration and deceleration ................ 5-3
Air filter and V-belt case air filter
elements ............................................. 6-16
Anti-theft alarm (optional) ..................... 3-11
Auxiliary DC jack .................................. 3-23
Auxiliary light bulb, replacing ................ 6-33BBattery .................................................. 6-27
Brake fluid, changing ............................ 6-24
Brake fluid level, checking .................... 6-22
Brake lever, front .................................. 3-12
Brake lever, rear ................................... 3-13
Brake levers, lubricating ....................... 6-25
Braking ................................................... 5-3CCables, checking and lubricating .......... 6-24
Care ........................................................ 7-1
Catalytic converters .............................. 3-16
Centerstand and sidestand,
checking and lubricating ..................... 6-25
Coolant ................................................. 6-14
Cowling and panel,
removing and installing......................... 6-8DDimmer switch ...................................... 3-12EEngine break-in ...................................... 5-4
Engine oil .............................................. 6-10
Engine trouble warning light ................... 3-4FFinal transmission oil ............................ 6-13Front and rear brake lever free play,
checking .............................................. 6-21
Front and rear brake pads, checking .... 6-21
Front fork, checking...............................6-26
Fuel ....................................................... 3-15
Fuel consumption, tips for reducing ........ 5-4
Fuel tank cap......................................... 3-14
Fuses, replacing .................................... 6-29
HHandlebar switches ............................... 3-11
Hazard switch........................................ 3-12
Headlight bulb, replacing....................... 6-30
High beam indicator light......................... 3-4
Horn switch ........................................... 3-12IIdentification numbers ............................. 9-1
Ignition circuit cut-off system ................. 3-21
Immobilizer system .................................3-1
Immobilizer system indicator light ........... 3-5
Indicator lights and warning lights ........... 3-4LLicense plate light .................................6-33MMain switch/steering lock ........................ 3-2
Maintenance and lubrication, periodic..... 6-4
Maintenance, emission control system ... 6-3
Matte color, caution .................................7-1
Model label .............................................. 9-1
Multi-function display...............................3-6PParking ....................................................5-5
Part locations .......................................... 2-1
Pass switch ........................................... 3-12
SSafe-riding points .................................... 1-5
Safety information ................................... 1-1
Seat ...................................................... 3-17
Securing bracket ................................... 3-17
Shock absorber assemblies,
adjusting ............................................. 3-20
Sidestand .............................................. 3-21
Spark plug, checking .............................. 6-9
Specifications.......................................... 8-1
Speedometer .......................................... 3-5
Starting off .............................................. 5-2
Starting the engine.................................. 5-1
Start switch ........................................... 3-12
Steering, checking ................................ 6-27
Storage ................................................... 7-3
Storage compartments ......................... 3-18TTachometer............................................. 3-6
Tail/brake light bulb or
rear turn signal light bulb, replacing.... 6-31
Throttle grip and cable,
checking and lubricating ..................... 6-24
Throttle grip free play, adjusting ........... 6-17
Tires ...................................................... 6-18
Tool kit .................................................... 6-2
Travel trunk ........................................... 3-19
Troubleshooting .................................... 6-33
Troubleshooting charts ......................... 6-35
Turn signal indicator lights ...................... 3-4
Turn signal light bulb (front),
replacing ............................................. 6-31
Turn signal switch ................................. 3-12
U2ABE2E0.book Page 1 Thursday, August 30, 2012 2:36 PM

INDEXVValve clearance .................................... 6-18
Vehicle identification number .................. 9-1WWheel bearings, checking ..................... 6-27
Wheels .................................................. 6-20
U2ABE2E0.book Page 2 Thursday, August 30, 2012 2:36 PM

U2ABE2E0.book Page 3 Thursday, August 30, 2012 2:36 PM

PRINTED IN FRANCE
2012.09 (E)
DIC183
MBK IndustrieZ.I. de Rouvroy 02100 Saint Quentin
