YAMAHA XT1200Z 2010 Owners Manual

SPECIFICATIONS
8-3
8
Spring/shock absorber type:Coil spring/gas-oil damper
Wheel travel: 190.0 mm (7.48 in)Electrical system:Ignition system:TCI
Charging system: AC magnetoBattery:Model:YTZ12S
Voltage, capacity: 12 V, 11.0 AhHeadlight:Bulb type:Halogen bulbBulb voltage, wattage × quantity:Headlight:
12 V, 55 W × 2
Tail/brake light: LED
Front turn signal light: 12 V, 10.0 W × 2
Rear turn signal light:
12 V, 10.0 W × 2
Auxiliary light: 12 V, 5.0 W × 2
License plate light: 12 V, 5.0 W × 1
Meter lighting:
LED
Neutral indicator light: LED High beam indicator light:
LED
Oil level warning light: LED
Turn signal indicator light:
LED
Coolant temperature warning light: LED
Engine trouble warning light: LED
ABS warning light:
LED
Immobilizer system indicator light: LED
Traction control system indicator/warning
light: LED
Fuses:Main fuse:
50.0 A
Headlight fuse: 20.0 A
Taillight fuse: 7.5 A
Signaling system fuse:
10.0 A
Ignition fuse: 20.0 A
Radiator fan fuse: 20.0 A
Fuel injection system fuse:
10.0 A
ABS control unit fuse: 7.5 A ABS motor fuse:
30.0 A
ABS solenoid fuse: 20.0 A
Auxiliary DC jack fuse:
3.0 A
Backup fuse: 7.5 A
Electronic throttle valve fuse: 7.5 A
O/P (option) fuse:
20.0 A
U23PE0E0.book Page 3 Wednesday, March 3, 2010 2:29 PM

CONSUMER INFORMATION
9-1
9
EAU48610
Identification numbers Record the vehicle identification num-
ber and model label information in the
spaces provided below for assistance
when ordering spare parts from a
Yamaha dealer or for reference in case the vehicle is stolen.
VEHICLE IDENTIFICATION
NUMBER:
MODEL LABEL INFORMATION:
EAU26400
Vehicle identification number
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26470
Model label
The model label is affixed to the frame
under the rider seat. (See page 3-25.)
Record the information on this label in
the space provided. This information
will be needed when ordering spare
parts from a Yamaha dealer.
1. Vehicle identification number
1
1. Model label
1
U23PE0E0.book Page 1 Wednesday, March 3, 2010 2:29 PM

INDEX
AABS ...................................................... 3-20
ABS warning light ................................... 3-7
Air filter element.................................... 6-16
Anti-theft alarm (optional) ..................... 3-15
Auxiliary DC jack .................................. 3-35
Auxiliary light bulb, replacing ................ 6-34BBattery .................................................. 6-28
Brake and clutch fluids, changing ......... 6-23
Brake and clutch levers, checking and lubricating ........................................... 6-25
Brake and shift pedals, checking and lubricating ........................................... 6-24
Brake fluid level, checking .................... 6-22
Brake lever ........................................... 3-18
Brake lever free play, checking ............ 6-20
Brake light switches .............................. 6-21
Brake pedal .......................................... 3-19CCables, checking and lubricating .......... 6-23
Care ........................................................ 7-1
Carriers ................................................. 3-31
Catalytic converter ................................ 3-25
Centerstand and sidestand, checking and lubricating .................................... 6-25
Clutch lever.................................. 3-17, 6-20
Coolant ................................................. 6-15
Coolant temperature warning light.......... 3-5
Cowlings, removing and installing .......... 6-8DDimmer switch ...................................... 3-16
D-mode (drive mode).............................. 3-1
EEngine break-in .......................................5-3
Engine idling speed, checking............... 6-17
Engine oil and oil filter cartridge ............ 6-11
Engine stop switch ................................ 3-16
Engine trouble warning light .................... 3-7FFinal gear oil.......................................... 6-14
Front and rear brake pads, checking .... 6-21
Front fork, adjusting .............................. 3-28
Front fork, checking...............................6-26
Fuel ....................................................... 3-23
Fuel consumption, tips for reducing ........ 5-3
Fuel tank breather/overflow hose .......... 3-24
Fuel tank cap......................................... 3-22
Fuses, replacing .................................... 6-29HHandlebar switches ............................... 3-16
Hazard switch........................................ 3-17
Headlight bulb, replacing....................... 6-31
High beam indicator light......................... 3-5
Horn switch ........................................... 3-16IIdentification numbers ............................. 9-1
Ignition circuit cut-off system ................. 3-33
Immobilizer system .................................3-1
Immobilizer system indicator light ........... 3-8
Indicator lights and warning lights ........... 3-4LLicense plate light bulb, replacing ......... 6-33
Luggage strap holders .......................... 3-32MMain switch/steering lock ........................ 3-3
Maintenance and lubrication, periodic..... 6-4 Maintenance, emission control system ... 6-3
Matte color, caution ................................ 7-1
Model label ............................................. 9-1
Multi-function meter unit ......................... 3-8
NNeutral indicator light .............................. 3-5OOil level warning light .............................. 3-5PParking.................................................... 5-4
Part locations .......................................... 2-1
Pass switch ........................................... 3-16RRider seat ............................................. 3-25
Rider seat height, adjusting .................. 3-26SSafety information ................................... 1-1
Shifting .................................................... 5-2
Shift pedal ............................................. 3-18
Shock absorber assembly, adjusting .... 3-30
Sidestand .............................................. 3-32
Spark plugs, checking........................... 6-10
Specifications.......................................... 8-1
Starting the engine.................................. 5-1
Start switch ........................................... 3-16
Steering, checking ................................ 6-27
Storage ................................................... 7-3
Swingarm pivots, lubricating ................. 6-26TTail/brake light ...................................... 6-32
Throttle cable free play, checking ......... 6-17
Throttle grip and cable, checking and
lubricating ........................................... 6-24
Tires ...................................................... 6-18
U23PE0E0.book Page 1 Wednesday, March 3, 2010 2:29 PM

INDEXTool kit .................................................... 6-1
Traction control system ......................... 3-21
Traction control system indicator/warning light ......................................... 3-7
Troubleshooting .................................... 6-36
Troubleshooting charts ......................... 6-37
Turn signal indicator lights ...................... 3-5
Turn signal light bulb, replacing ............ 6-32
Turn signal switch ................................. 3-16VValve clearance .................................... 6-17
Vehicle identification number .................. 9-1WWheel bearings, checking ..................... 6-27
Wheels .................................................. 6-20
Windshield ............................................ 3-28
U23PE0E0.book Page 2 Wednesday, March 3, 2010 2:29 PM

U23PE0E0.book Page 3 Wednesday, March 3, 2010 2:29 PM

PRINTED ON RECYCLED PAPER
YAMAHA MOTOR CO., LTD.
PRINTED IN JAPAN2010.03-0.6×1 CR (E)
DIC183
