INSTRUMENT AND CONTROL FUNCTIONS
3-21
3
EAU49416
Traction control system The traction control system helps main-
tain traction when accelerating on slip-
pery surfaces, such as unpaved or wet
roads. If sensors detect that the rear
wheel is starting to slip (uncontrolled
spinning), the traction control system
assists by regulating engine power as
needed until traction is restored. The
traction control system indicator/warn-
ing light flashes to let the rider know
that traction control has engaged.TIPThe rider may also notice slight chang-
es in engine and exhaust sounds when
the traction control system is engaged.
WARNING
EWA15431
The traction control system is not a
substitute for riding appropriately
for the conditions. Traction control
cannot prevent loss of traction due
to excessive speed when entering
turns, when accelerating hard at a
sharp lean angle, or while braking,
and cannot prevent front wheel slip-
ping. As with any motorcycle, ap-proach surfaces that may be
slippery with caution and avoid es-
pecially slippery surfaces.
There are three traction control system
modes:

“
TCS ” mode “1 ”: Default mode


“TCS ” mode “2 ”: Sporty mode
This mode decreases traction con-
trol system assist, allowing the
rear wheel to spin more freely than
“ TCS ” mode “1 ”.


“TCS ” mode “Off ”: The traction
control system is turned off. The
system may also be automatically
disabled in some riding conditions
(see “Resetting ” on page 3-22).
When the key is turned to “ON ”, the
traction control system is enabled and
“ TCS ” “ 1 ” displays in the multi-function
meter.
The traction control system mode can
be changed only when the key is in the
“ ON ” position and the vehicle is not
moving.
TIPUse “TCS ” mode “ Off” to help free the
rear wheel if the motorcycle gets stuck
in mud, sand, or other soft surfaces.NOTICE
ECA16800
Use only the specified tires. (See
page 6-18.) Using different sized
tires will prevent the traction control
system from controlling tire rotation
accurately.Setting the traction control system
WARNING
EWA15440
Be sure to stop the vehicle before
making any setting changes to the
traction control system. Changing
settings while riding can distract the
operator and increase the risk of an
accident.Push the traction control system switch
on the multi-function meter for less than
one second to change between “TCS ”
modes “1 ” and “ 2”. Push the switch for
at least two seconds to select “TCS ”
mode “Off ” and turn the traction control
U23PE1E0.book Page 21 Tuesday, August 10, 2010 8:39 AM

OPERATION AND IMPORTANT RIDING POINTS
5-1
5
EAU15951
Read the Owner’s Manual carefully to
become familiar with all controls. If
there is a control or function you do not
understand, ask your Yamaha dealer.
WARNING
EWA10271
Failure to familiarize yourself with
the controls can lead to loss of con-
trol, which could cause an accident
or injury.
EAU48710
TIPThis model is equipped with:

a lean angle sensor to stop the en-
gine in case of a turnover. In this
case, the multi-function display in-
dicates error code 30, but this is
not a malfunction. Turn the key to
“ OFF ” and then to “ ON” to clear the
error code. Failing to do so will pre-
vent the engine from starting even
though the engine will crank when
pushing the start switch.


an engine auto-stop system. The
engine stops automatically if left
idling for 20 minutes. If the engine
stops, simply push the start switch
to restart the engine.
EAU49541
Starting the engine In order for the ignition circuit cut-off
system to enable starting, one of the
following conditions must be met:

The transmission is in the neutral
position.


The transmission is in gear with
the clutch lever pulled and the
sidestand up.
See page 3-32 for more informa-
tion.
1. Turn the key to “ ON” and make
sure that the engine stop switch is
set to “”.
The following warning lights and
indicator lights should come on for
a few seconds, then go off.

Oil level warning light


Engine trouble warning light


Coolant temperature warning
light


ABS warning light


Traction control system indi-
cator/warning light


Immobilizer system indicator
light
