4-1
EAU01114
PRE-OPERATION CHECKS
1
2
34
5
6
7
8
9Owners are personally responsible for their vehicleÕs condition. Your motorcycleÕs vital functions can start to deteriorate
quickly and unexpectedly, even if it remains unused (for instance, if it is exposed to the elements). Any damage, fluid
leak or loss of tire pressure could have serious consequences. Therefore, it is very important that, in addition to a thor-
ough visual inspection, you check the following points before each ride.
EAU00340
PRE-OPERATION CHECK LIST
ITEMCHECKSPAGE
Front brake9Check operation, free play, fluid level and vehicle for fluid leakage.
9Fill with DOT 4 (or DOT 3) brake fluid if necessary.
Rear brake9Check operation, free play, fluid level and vehicle for fluid leakage.3-5, 6-18 ~ 6-22
9Fill with DOT 4 brake fluid if necessary.
Clutch9Check operation, condition and free play.
3-4, 6-18
9Adjust if necessary.
Throttle grip and housing9Check for smooth operation.
6-24
9Lubricate.
Engine oil9Check oil level.
6-10 ~ 6-12
9Fill with oil if necessary.
Drive chain9Check chain slack and condition.
6-22 ~ 6-24
9Adjust if necessary.
Wheels and tires9Check tire pressure, wear, damage and spoke tightness.
6-15 ~ 6-17
9Tighten spokes if necessary.
Control and meter cable9Check for smooth operation.
6-24
9Lubricate if necessary.
Brake and shift pedal shafts9Check for smooth operation.
6-25
9Lubricate if necessary.
Brake and clutch lever pivots9Check for smooth operation.
6-25
9Lubricate if necessary.
4PT-9-E6 (ENG) 1~5 12/27/00 1:28 PM Page 28

PERIODIC MAINTENANCE AND MINOR REPAIR
Tool kit ...................................................................6-1
Periodic maintenance and lubrication chart ...........6-3
Cowling and panel removal and installation...........6-6
Cowling A ...............................................................6-7
Panel A, B ..............................................................6-7
Spark plug ..............................................................6-8
Engine oil .............................................................6-10
Air filter .................................................................6-12
Carburetor adjustment .........................................6-13
Idle speed adjustment ..........................................6-14
Throttle cable free play adjustment ......................6-14
Valve clearance adjustment .................................6-15
Tires .....................................................................6-15
Wheels .................................................................6-17
Clutch lever free play adjustment.........................6-18
Front brake lever free play adjustment ................6-18
Rear brake pedal height adjustment ....................6-19
Brake light switch adjustment ..............................6-20
Checking the front and rear brake pads...............6-20
Inspecting the brake fluid level.............................6-21
Brake fluid replacement .......................................6-22
Drive chain slack check .......................................6-22
Drive chain slack adjustment ...............................6-23Drive chain lubrication............................................6-23
Cable inspection and lubrication ............................6-24
Throttle cable and grip lubrication ..........................6-24
Brake and shift pedal lubrication ............................6-25
Brake and clutch lever lubrication ..........................6-25
Sidestand lubrication..............................................6-25
Rear suspension lubrication...................................6-26
Front fork inspection ..............................................6-26
Steering inspection ................................................6-27
Wheel bearings ......................................................6-27
Battery....................................................................6-28
Fuse replacement ..................................................6-29
Headlight bulb replacement ...................................6-29
Turn signal light bulb replacement .........................6-31
Taillight bulb replacement ......................................6-32
Supporting the motorcycle .....................................6-32
Front wheel removal ..............................................6-33
Front wheel installation ..........................................6-34
Rear wheel removal ...............................................6-35
Rear wheel installation ...........................................6-36
Troubleshooting .....................................................6-36
Troubleshooting chart ............................................6-37
6
4PT-9-E6 (ENG) 6 12/27/00 1:29 PM Page 1

6-4
PERIODIC MAINTENANCE AND MINOR REPAIR
6
9
*Wheels¥Check runout, spoke tightness and for damage.
¥Tighten spokes if necessary.ÖÖÖÖ
10*Tires¥Check tread depth and for damage.
¥Replace if necessary.
¥Check air pressure.
¥Correct if necessary.ÖÖÖÖ
11*Wheel bearings¥Check bearing for looseness or damage.ÖÖÖÖ
12*Swingarm¥Check operation and for excessive play.ÖÖÖÖ
13Drive chain¥Check chain slack.
¥Make sure that the rear wheel is properly aligned.
¥Clean and lubricate.Every 500 km and after washing
the motorcycle or riding in the rain.
14*Steering bearings¥Check bearing play and steering for roughness.ÖÖÖÖÖ
¥Lubricate with lithium-soap-based grease.Every 20,000 km
15*Chassis fasteners¥Make sure that all nuts, bolts and screws are properly tightened.ÖÖÖÖÖ
16Sidestand¥Check operation.
¥Lubricate.ÖÖÖÖÖ
17*Sidestand switch¥Check operation.ÖÖÖÖÖÖ
18*Front fork¥Check operation and for oil leakage.ÖÖÖÖ
19*Shock absorber
assembly¥Check operation and shock absorber for oil leakage.ÖÖÖÖ NO.ITEMCHECK OR MAINTENANCE JOBODOMETER READING (´ 1,000 km)
ANNUAL
CHECK
110203040
4PT-9-E6 (ENG) 6 12/27/00 1:29 PM Page 5

6-15
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
* Load is the total weight of cargo, rider, passenger
and accessories.Maximum load*176 kg (XT500E)
180 kg (XT600E)
Cold tire pressure:FrontRear
150 kPa150 kPa
Up to 90 kg(1.5 kg/cm
2, (1.5 kg/cm
2,
1.5 bar)1.5 bar)
90 kg load ~150 kPa225 kPa
Maximum load*(1.5 kg/cm
2, (2.25 kg/cm
2,
1.5 bar) 2.25 bar)
125 kPa125 kPa
Off-road riding(1.25 kg/cm
2, (1.25 kg/cm
2,
1.25 bar) 1.25 bar)
150 kPa150 kPa
High speed riding(1.5 kg/cm
2, (1.5 kg/cm
2,
1.5 bar) 1.5 bar)
EAU00652
TiresTo ensure maximum performance,
long service and safe operation, note
the following:
Tire air pressure
Always check and adjust the tire
pressure before operating the motor-
cycle.
EW000082
wTire inflation pressure should be
checked and adjusted when the
temperature of the tire equals the
ambient air temperature. Tire infla-
tion pressure must be adjusted
according to total weight of cargo,
rider, passenger, and accessories
(fairing, saddlebags, etc. if
approved for this model), and vehi-
cle speed.
EAU00637
Valve clearance adjustmentThe correct valve clearance changes
with use, resulting in improper fuel/air
supply or engine noise. To prevent
this, the valve clearance must be
adjusted regularly. This adjustment
however, should be left to a profes-
sional Yamaha service technician.
4PT-9-E6 (ENG) 6 12/27/00 1:29 PM Page 16

6-16
EW000083
wProper loading of your motorcycle
is important for several character-
istics of your motorcycle, such as
handling, braking, performance
and safety. Do not carry loosely
packed items that can shift.
Securely pack your heaviest items
close to the center of the motorcy-
cle, and distribute the weight even-
ly from side to side. Properly
adjust the suspension for your
load, and check the condition and
pressure of your tires. NEVER
OVERLOAD YOUR MOTORCYCLE.
Make sure the total weight of the
cargo, rider, passenger, and
accessories (fairing, saddlebags,
etc. if approved for this model)
does not exceed the maximum
load of the motorcycle. Operation
of an overloaded motorcycle could
cause tire damage, an accident, or
even injury.
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
1
2
Tire inspection
Always check the tires before operat-
ing the motorcycle. If center tread
depth reaches the limit as shown, if
the tire has a nail or glass fragments
in it, or if the side wall is cracked,
contact a Yamaha dealer immediate-
ly and have the tire replaced.1.Tread depth
2.Side wall
EW000078
wAfter extensive tests, the tires
mentioned below have been
approved by Yamaha Motor Co.,
Ltd. for this model. No guarantee
for handling characteristics can be
given if tire combinations other
than what is approved are used on
this motorcycle. The front and rear
tires should be of the same manu-
facture and design.ManufacturerSizeTypeBRIDGESTONE90/90-21 54STW47
DUNLOP90/90-21 54STRAIL MAX LFRONTManufacturerSizeTypeBRIDGESTONE120/90-17 64STW48
DUNLOP120/90-17 64STRAIL MAXREAR
Minimum tire tread
depth 0.8 mm
(front and rear)
4PT-9-E6 (ENG) 6 12/27/00 1:29 PM Page 17

6-17
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU00685
WheelsTo ensure maximum performance,
long service, and safe operation, note
the following:
8Always inspect the wheels
before a ride. Check for cracks,
bends or warpage of the wheel.
Be sure the spokes are tight and
undamaged. If any abnormal
condition exists in a wheel, con-
sult a Yamaha dealer. Do not
attempt even small repairs to the
wheel. If a wheel is deformed or
cracked, it must be replaced.
8Tires and wheels should be bal-
anced whenever either one is
changed or replaced. Failure to
have a wheel balanced can
result in poor performance,
adverse handling characteristics,
and shortened tire life.
8Ride at moderate speeds after
changing a tire since the tire sur-
face must first be broken in for it
to develop its optimal character-
istics.
EAU00681
w8 8
Operating the motorcycle with
excessively worn tires
decrease riding stability and
can lead to loss of control.
Have excessively worn tires
replaced by a Yamaha dealer
immediately. Brakes, tires, and
related wheel parts replace-
ment should be left to a
Yamaha Service Technician.
8 8
Patching a punctured tube is
not recommended. If it is
absolutely necessary to do so,
use great care and replace the
tube as soon as possible with
a good quality replacement.
NOTE:
These limits may be different by regu-
lation from country to country. If so,
conform to the limits specified by the
regulations of your own country.
4PT-9-E6 (ENG) 6 12/27/00 1:29 PM Page 18

7-3
EWA00001
wMake sure that there is no oil or
wax on the brakes and tires. If nec-
essary, clean the brake discs and
linings with a regular brake disc
cleaner or acetone, and wash the
tires with warm water and mild
soap. Then, carefully test the
motorcycle for its braking perfor-
mance and cornering behavior.
ECA00013
cC8
8
Apply spray oil and wax spar-
ingly and wipe off any excess.
8 8
Never apply oil or wax on rub-
ber and plastic parts, but treat
them with a suitable care prod-
uct.
8 8
Avoid using abrasive polish-
ing compounds as they wear
away the paint.
MOTORCYCLE CARE AND STORAGE
1
2
3
4
5
67
8
9
NOTE:
Consult a Yamaha dealer for advice
on what products to use.
After cleaning
1.Dry the motorcycle with a
chamois or an absorbing cloth.
2.Immediately dry the drive chain
and lubricate it to prevent it from
rusting.
3.Use a chrome polish to shine
chrome, aluminum and stainless-
steel parts, including the exhaust
system. (Even the thermally
induced discoloring of stainless-
steel exhaust systems can be
removed through polishing.)
4.To prevent corrosion, it is recom-
mended to apply a corrosion pro-
tection spray on all (even
chrome- and nickel-plated) metal
surfaces.
5.Use spray oil as a universal
cleaner to remove any remaining
dirt.
6.Touch up minor paint damage
caused by stones, etc.
7.Wax all painted surfaces.
8.Let the motorcycle dry complete-
ly before storing it or covering it.
4PT-9-E6 (ENG) 7~9 12/27/00 1:30 PM Page 4

7-5
MOTORCYCLE CARE AND STORAGE
1
2
3
4
5
67
8
9
6.Lubricate all control cables and
the pivoting points of all levers
and pedals as well as of the
sidestand/centerstand.
7.Check and, if necessary, correct
the tire air pressure, then raise
the motorcycle so that both of its
wheels are off the ground.
Alternatively, turn the wheels a
little every month in order to pre-
vent the tires from becoming
degraded in one spot.
8.Cover up the muffler outlet with a
plastic bag to prevent moisture
from entering.9.Remove the battery and fully
charge it. Store it in a cool, dry
place and recharge it once a
month. Do not store the battery
in an excessively cold or warm
place (less than 0¡C or more
than 30¡C). For more informa-
tion, see
ÒBattery storageÓ in the
chapter ÒPERIODIC MAINTE-
NANCE AND MINOR
REPAIRSÓ.
NOTE:
Make any necessary repairs before
storing the motorcycle.
4PT-9-E6 (ENG) 7~9 12/27/00 1:30 PM Page 6

INDEX
Sidestand/clutch switch operation
check..................................................3-12
Spark plug...............................................6-8
Specifications..........................................8-1
Speedometer...........................................3-2
Start switch..............................................3-4
Starter (choke).........................................3-8
Starting a warm engine...........................5-3
Starting the engine..................................5-1
Steering inspection................................6-27
Storage....................................................7-4
Supporting the motorcycle.....................6-32
T
Tachometer.............................................3-3
Taillight bulb replacement.....................6-32
Throttle cable and grip lubrication.........6-24
Throttle cable free play adjustment.......6-14
Tips for reducing fuel consumption.........5-5
Tires......................................................6-15
Tool kit.....................................................6-1
Troubleshooting.....................................6-36
Troubleshooting chart............................6-37
Turn indicator light...................................3-2
Turn signal light bulb replacement........6-31
Turn signal switch....................................3-3
V
Valve clearance adjustment..................6-15
Vehicle identification number..................9-1
W
Wheel bearings.....................................6-27
Wheels..................................................6-17
4PT-9-E6 (ENG) 7~9 12/27/00 1:30 PM Page 17
