L
6-27
PERIODIC MAINTENANCE AND MINOR REPAIR
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9149_XV535-E6/English/E-6.frame
1. Main fuse
2. Headlight fuse
3. Signaling system fuse
4. Ignition fuse
5. Spare fuse (´ 2)
EAU00818
Fuse replacement
The fuse box is located under the rider
seat. If any fuse is blown, turn off the
main switch and the switch of the circuit
in question. Install a new fuse of the
specified amperage. Turn on the
switches and check if the electrical de-
vice operates. If the fuse immediately
blows again, consult a Yamaha dealer.
EC000103
CAUTION:
Do not use fuses of higher amper-
age rating than those recommend-
ed. Substitution of a fuse of
improper rating can cause extensive
electrical system damage and pos-
sibly a fire.
Specified fuses:
Main fuse: 30 A
Headlight fuse: 15 A
Signaling system fuse: 15 A
Ignition fuse: 15 A
1. Screw (´ 2)
EAU01524
Headlight bulb replacement
This motorcycle is equipped with a
quartz bulb headlight.
If the headlight bulb burns out, replace
the bulb as follows:
1. Remove the headlight unit screws.
