PERIODIC MAINTENANCE AND MINOR REPAIR
6-32
6
EAU01297
Troubleshooting chart
EW000125
WARNING
@ Keep away open flames and do not smoke while checking or working on the fuel system.@
Check the fuel level in
the fuel tank.1. Fuel
There is enough fuel.
There is no fuel.
Check the compression.
Supply fuel.
The engine does not start.
Check the compression.
Operate the electric starter.2. Compression
There is compression.
There is no compression.
Check the ignition.
Have a Yamaha dealer
check the vehicle.
Remove the spark plugs
and check the electrodes.3. Ignition
Wipe off with a dry cloth and correct the
spark plug gaps, or replace the spark plugs.
Have a Yamaha dealer check the vehicle.
The engine does not start.
Have a Yamaha dealer
check the vehicle.
The engine does not start.
Check the battery.
Operate the electric starter.4. Battery
The engine turns over
quickly.
The engine turns over
slowly.
The battery is good.Check the battery lead connections,
and charge the battery if necessary.
DryWet
Open the throttle halfway and operate
the electric starter.
E_5KS.book Page 32 Monday, August 21, 2000 10:48 AM

MOTORCYCLE CARE AND STORAGE
7-5
7c. Install the spark plug caps onto the
spark plugs, and then place the
spark plugs on the cylinder head
so that the electrodes are ground-
ed. (This will limit sparking during
the next step.)
d. Turn the engine over several times
with the starter. (This will coat the
cylinder walls with oil.)
e. Remove the spark plug caps from
the spark plugs, and then install
the spark plugs and the spark plug
caps.
EWA00003
WARNING
@ To prevent damage or injury from
sparking, make sure to ground the
spark plug electrodes while turning
the engine over. @6. Lubricate all control cables and
the pivoting points of all levers and
pedals as well as of the sidestand/
centerstand.7. Check and, if necessary, correct
the tire air pressure, and then lift
the motorcycle so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
8. Cover the muffler outlets with plas-
tic bags to prevent moisture from
entering them.
9. Remove the battery and fully
charge it. Store it in a cool, dry
place and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place (less
than 0 °C or more than 30 °C). For
more information on storing the
battery, see page 6-27.
NOTE:@ Make any necessary repairs before
storing the motorcycle. @
E_5KS.book Page 5 Monday, August 21, 2000 10:48 AM

10-INDEXAAir filter element, cleaning ...................... 6-11
Anti-theft alarm (optional) .........................3-4BBattery ................................................... 6-26
Brake and clutch levers, checking
and lubricating ..................................... 6-23
Brake and shift pedals, checking
and lubricating ..................................... 6-23
Brake fluid, changing ............................. 6-22
Brake fluid level, checking...................... 6-21
Brake lever...............................................3-6
Brake lever free play, adjusting .............. 6-17
Brake light switch, adjusting ................... 6-19
Brake pads, checking............................. 6-20
Brake pedal..............................................3-7
Brake pedal position, adjusting .............. 6-19CCables, checking and lubricating............ 6-22
Carburetors, adjusting............................ 6-12
Care.........................................................7-1
Clutch lever ..............................................3-5
Clutch lever free play, adjusting ............. 6-17
Controls and instruments
(XVS1100/XVS1100A)...........................2-5
Conversion table ......................................8-6EEngine break-in........................................5-5
Engine oil and oil filter element.................6-7
Engine, starting a warm ...........................5-3
FFinal gear oil ............................................ 6-9
Front fork, checking ............................... 6-24
Fuel ......................................................... 3-8
Fuel cock ................................................. 3-9
Fuel consumption, tips for reducing ......... 5-4
Fuel tank cap ........................................... 3-8
Fuses, replacing .................................... 6-27HHandlebar switches ................................. 3-4
Dimmer switch ................................... 3-4
Engine stop switch ............................. 3-5
Horn switch ........................................ 3-4
Light switch ........................................ 3-5
Pass switch ........................................ 3-4
Start switch ........................................ 3-5
Turn signal switch .............................. 3-4
Headlight bulb, replacing ....................... 6-29
Helmet holder ........................................ 3-13IIdentification numbers ............................. 9-1
Idling speed, adjusting ........................... 6-12
Ignition circuit cut-off system.................. 3-19
Indicator lights ......................................... 3-2
Engine trouble warning light ............... 3-3
High beam indicator light .................... 3-3
Neutral indicator light.......................... 3-2
Oil level warning light ......................... 3-2
Turn signal indicator light ................... 3-2KKey identification number ........................ 9-1
LLeft view (XVS1100) ................................2-1
Left view (XVS1100A) ..............................2-3
Luggage strap holders ...........................3-18MMain switch/steering lock .........................3-1
Model label ..............................................9-2PPanel, removing and installing..................6-5
Parking.....................................................5-5
Periodic maintenance and
lubrication chart .....................................6-2
Pre-operation check list ............................4-1RRight view (XVS1100) ..............................2-2
Right view (XVS1100A)............................2-4SSeats (XVS1100) ...................................3-11
Passenger seat.................................3-11
Rider seat .........................................3-11
Seats (XVS1100A) .................................3-12
Passenger seat.................................3-12
Rider seat .........................................3-13
Shifting .....................................................5-3
Shift pedal (XVS1100)..............................3-6
Shift pedal (XVS1100A) ...........................3-6
Shift points (for Switzerland only) .............5-4
Shock absorber assembly, adjusting ......3-15
Sidestand ...............................................3-18
Sidestand, checking and lubricating .......6-24
Spark plugs, checking ..............................6-6
E_5KS.book Page 1 Monday, August 21, 2000 10:48 AM

INDEX
Specifications .......................................... 8-1
Speedometer unit .................................... 3-3
Starter (choke) lever .............................. 3-10
Starting a cold engine .............................. 5-1
Steering, checking ................................. 6-25
Storage.................................................... 7-4
Storage compartment ............................ 3-14TThrottle cable free play, adjusting .......... 6-13
Throttle grip and cable, checking
and lubricating ..................................... 6-22
Tires ...................................................... 6-13
Tool kit..................................................... 6-1
Troubleshooting..................................... 6-31
Troubleshooting chart ............................ 6-32
Turn signal or tail/brake light bulb,
replacing ............................................. 6-30VValve clearance, adjusting ..................... 6-13
Vehicle identification number ................... 9-1WWheel bearings, checking...................... 6-25
Wheels .................................................. 6-16
