YAMAHA XVS125 2001 Manual Online

8
SPECIFICATIONS
8-4
Battery
TypeGT6B-3
Voltage, capacity12 V, 6 Ah
Headlight typeHalogen bulb
Bulb voltage, wattage ´quantity
Headlight12 V, 60/55 W ´1
Tail/brake light12 V, 5/21 W ´1
Front flasher light12 V, 21 W ´2
Rear flasher light12 V, 21 W ´2
Auxiliary light12 V, 4 W ´1
Meter lighting12 V, 1.7 W ´1
Neutral indicator light12 V, 1.7 W ´1
High beam indicator light12 V, 1.7 W ´1
Turn indicator light12 V, 1.7 W ´1
Engine indicator light12 V, 1.7 W ´1
Fuses
Main fuse30 A
Headlight fuse15 A
Signaling system fuse10 A
Ignition fuse10 A
Carburetor heater fuse10 A
5JX-9-E1 9/27/00 10:45 AM Page 80

8
SPECIFICATIONS
8-5
EAU01064
Conversion tableAll specification data in this manual are listed in SI and
METRIC UNITS.
Use this table to convert METRIC unit data to
IMPERIAL unit data.
Ex.
METRICMULTIPLIERIMPERIAL
** mm´0.03937=** in
2 mm´0.03937=0.08 in
METRIC TO IMPERIAL
Metric unitMultiplierImperial unit
m¥kg7.233ft¥lb
Torquem¥kg86.794in¥lb
cm¥kg0.0723ft¥lb
cm¥kg0.8679in¥lb
Weightkg2.205lbg0.03527oz
Speedkm/hr0.6214mph
km0.6214mi
m3.281ft
Distancem1.094yd
cm0.3937in
mm0.03937in
cc (cm3)0.03527oz (IMP liq.)
Volume/cc (cm3)0.06102cu¥in
CapacityL (liter)0.8799qt (IMP liq.)L (liter)0.2199gal (IMP liq.)
kg/mm55.997lb/in
Misc.kg/cm214.2234psi (lb/in2)Centigrade (¡C)
9/5 + 32
Fahrenheit (¡F)
CONVERSION TABLE
5JX-9-E1 9/27/00 10:45 AM Page 81

9
EAU01039
CONSUMER INFORMATION
9-1
EAU02944
Identification numbersRecord the key identification number,
vehicle identification number and
model label information in the spaces
provided below for assistance when
ordering spare parts from a Yamaha
dealer or for reference in case the
vehicle is stolen.
1.KEY IDENTIFICATION
NUMBER:
2.VEHICLE IDENTIFICATION
NUMBER:
3.MODEL LABEL INFORMATION:
EAU01041
Key identification numberThe key identification number is
stamped into the key tag.
Record this number in the space pro-
vided and use it for reference when
ordering a new key.1.Key identification number
EAU01043
Vehicle identification numberThe vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.NOTE:
The vehicle identification number is
used to identify your motorcycle and
may be used to register your motor-
cycle with the licensing authority in
your area.1.Vehicle identification number
1
1
1
6
5JX-9-E1 9/27/00 10:45 AM Page 82

CONSUMER INFORMATION
9-2
89
EAU01049
Model labelThe model label is affixed to the loca-
tion shown in the figure. Record the
information on this label in the space
provided. This information will be
needed when ordering spare parts
from a Yamaha dealer.1.Model label
1
5JX-9-E1 9/27/00 10:45 AM Page 83

5JX-9-E1 9/27/00 10:45 AM Page 84

PRINTED ON RECYCLED PAPERPRINTED IN JAPAN
2000·9–0.2´1(E)
!
OWNER’S MANUAL
5JX-28199-E1
XVS125
YAMAHA MOTOR CO., LTD.
