YAMAHA XVS125 2002 User Guide
Manufacturer: YAMAHA, Model Year: 2002, Model line: XVS125, Model: YAMAHA XVS125 2002Pages: 86, PDF Size: 1.63 MB
Page 11 of 86

2-3
DESCRIPTION
2
1. Clutch lever (page 3-5, 6-19)
2. Left handlebar switches (page 3-3)
3. Speedometer unit (page 3-2)
4. Right handlebar switches (page 3-4)5. Brake lever (page 3-5, 6-20)
6. Throttle grip (page 6-15, 6-28)
7. Fuel tank cap (page 3-6)
8. Starter (choke) lever (page 3-9)
123
45
6 7
8
Controls and instruments
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 10
Page 12 of 86

3-1
EAU00027
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU00029
Main switch/steering lock
Main switch/steering lock
The main switch/steering lock con-
trols the ignition and lighting systems,
and is used to lock the steering. The
various positions are described
below.
EAU00036
ON
All electrical systems are supplied
with power, and the engine can be
started. The key cannot be removed.
EAU00038
OFF
All electrical systems are off. The key
can be removed.
EAU00040
LOCK
The steering is locked, and all electri-
cal systems are off. The key can be
removed.
To lock the steering1. Turn the handlebars all the way
to the left.
2. Push the key in from the “OFF”
position, and then turn it to
“LOCK” while still pushing it.
3. Remove the key.
To unlock the steeringPush the key in, and then turn it to
“OFF” while still pushing it.
EW000016
wNever turn the key to “OFF” or
“LOCK” while the motorcycle is
moving, otherwise the electrical
systems will be switched off,
which may result in loss of control
or an accident. Make sure that the
motorcycle is stopped before turn-
ing the key to “OFF” or “LOCK”.
EAU01590
.
.
(Parking)
The steering is locked, and the tail-
light and auxiliary light are on, but all
other electrical systems are off. The
key can be removed.
The steering must be locked before
the key can be turned to "
.
".
ECA00043
cCDo not use the parking position for
an extended length of time, other-
wise the battery may discharge.
OFFON
LOCKPPUSH
IGNITION
ON
OFF
LOCK
(Parking)
.
ab
a. Push.
b. Turn.
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 11
Page 13 of 86

3-2
EAU03034
Indicator and warning lights
Indicator lights
EAU00063
High beam indicator light “&”
High beam indicator light
This indicator light comes on when
the high beam of the headlight is
switched on.
EAU00057
Turn signal indicator light “5”
Turn signal indicator light
This indicator light flashes when the
turn signal switch is pushed to the left
or right.
EAU00061
Neutral indicator light “N”
Neutral indicator light
This indicator light comes on when
the transmission is in the neutral
position.
EAU04243
Engine trouble warning light “”
Engine trouble warning light
This warning light comes on or flash-
es when an electrical circuit monitor-
ing the engine is defective. When this
occurs, have a Yamaha dealer check
the self-diagnosis system.NOTE:
This warning light comes on for a few
seconds when the key is turned to
“ON”, but this does not indicate a
malfunction.
EAU01087
Speedometer unit The speedometer unit is equipped
with a speedometer, an odometer
and a tripmeter. The speedometer
shows riding speed. The odometer
shows the total distance traveled.
The tripmeter shows the distance
traveled since it was last set to zero
with the reset knob. The tripmeter
can be used to estimate the distance
that can be traveled with a full tank of
fuel. This information will enable you
to plan future fuel stops.
INSTRUMENT AND CONTROL FUNCTIONS
3
2040
600
km/h80
100
120140160
12 34
2040600
km/h80
100
120140160
1
23
4
1. High beam indicator light “&”
2. Turn signal indicator light “5”
3. Neutral indicator light “N”
4. Engine trouble warning light “”
1. Speedometer
2. Odometer
3. Tripmeter
4. Reset knob
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 12
Page 14 of 86

3-3
INSTRUMENT AND CONTROL FUNCTIONS
3
NOTE:
Only for the German model equipped
with a speed limiter:
The speed limiter prevents the motor-
cycle from exceeding a riding speed
of 80 km/h.
EAU00109
Anti-theft alarm (optional)
Anti-theft alarm (optional)
This motorcycle can be equipped
with an optional anti-theft alarm by a
Yamaha dealer. Contact a Yamaha
dealer for more information.
EAU00118
Handlebar switches
Handlebar switchesEAU00119
Pass switch “&”
Pass switch
Press this switch to flash the head-
light.
EAU03888
Dimmer switch “&/%”
Dimmer switch
Set this switch to “&” for the high
beam and to “%” for the low beam.
1
2
3
4
1. Pass switch“&”
2. Dimmer switch“&/%”
3. Turn signal switch“4/6”
4. Horn switch “*”
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 13
Page 15 of 86

3-4
EAU03889
Turn signal switch “4/6”
Turn signal switch
To signal a right-hand turn, push this
switch to “6”. To signal a left-hand
turn, push this switch to “4”. When
released, the switch returns to the
center position. To cancel the turn
signal lights, push the switch in after
it has returned to the center position.
EAU00129
Horn switch “*”
Horn switch
Press this switch to sound the horn.
EAU03890
Engine stop switch “#/$”
Engine stop switch
Set this switch to “#” before starting
the engine. Set this switch to “$” to
stop the engine in case of an emer-
gency, such as when the motorcycle
overturns or when the throttle cable is
stuck.
EAU03898
Light switch “9/
'
/:”
Light switch
Set this switch to “
'
” to turn on
the auxiliary light, meter lighting and
taillight. Set the switch to “:” to turn
on the headlight also. Set the switch
to “9” to turn off all the lights.
EAU00143
Start switch “,”
Start switch
Push this switch to crank the engine
with the starter.
EC000005
cCSee page 5-1 for starting instruc-
tions prior to starting the engine.
INSTRUMENT AND CONTROL FUNCTIONS
3
1
2
3
4
1
2
3
1. Pass switch“&”
2. Dimmer switch“&/%”
3. Turn signal switch“4/6”
4. Horn switch “*”1. Engine stop switch“#/$”
2. Light switch“9/
'
/:”
3. Start switch “,”
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 14
Page 16 of 86

3-5
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU00152
Clutch lever
Clutch lever
The clutch lever is located at the left
handlebar grip. To disengage the
clutch, pull the lever toward the han-
dlebar grip. To engage the clutch,
release the lever. The lever should
be pulled rapidly and released slowly
for smooth clutch operation.
The clutch lever is equipped with a
clutch switch, which is part of the igni-
tion circuit cut-off system. (See page
3-11 for an explanation of the ignition
circuit cut-off system.)
EAU00157
Shift pedal
Shift pedal
The shift pedal is located on the left
side of the engine and is used in
combination with the clutch lever
when shifting the gears of the
5-speed constant-mesh transmission
equipped on this motorcycle.
EAU00158
Brake lever
Brake lever
The brake lever is located at the right
handlebar grip. To apply the front
brake, pull the lever toward the han-
dlebar grip.
1
1
1
1. Clutch lever 1. Shift pedal 1. Brake lever
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 15
Page 17 of 86

3-6
EAU00162
Brake pedal
Brake pedal
The brake pedal is on the right side
of the motorcycle. To apply the rear
brake, press down on the brake
pedal.
EAU03756
Fuel tank cap
Fuel tank cap
To remove the fuel tank cap
Insert the key into the lock and turn it
1/4 turn clockwise. The lock will be
released and the fuel tank cap can be
removed.
To install the fuel tank cap
1. Push the fuel tank cap into posi-
tion with the key inserted in the
lock.
2. Turn the key counterclockwise to
the original position, and then
remove it.
NOTE:
The fuel tank cap cannot be installed
unless the key is in the lock. In addi-
tion, the key cannot be removed if the
cap is not properly installed and
locked.
EWA00032
wMake sure that the fuel tank cap is
properly installed before riding.
INSTRUMENT AND CONTROL FUNCTIONS
3
1
a
1. Brake pedal a. Unlock.
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 16
Page 18 of 86

3-7
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU03753
Fuel
Fuel
Make sure that there is sufficient fuel
in the tank. Fill the fuel tank to the
bottom of the filler tube as shown.
EW000130
w8Do not overfill the fuel tank,
otherwise it may overflow
when the fuel warms up and
expands.
8Avoid spilling fuel on the hot
engine.
EAU00185
cCImmediately wipe off spilled fuel
with a clean, dry, soft cloth, since
fuel may deteriorate painted sur-
faces or plastic parts.
EAU04284
ECA00104
cCUse only unleaded gasoline. The
use of leaded gasoline will cause
severe damage to internal engine
parts, such as the valves and pis-
ton rings, as well as to the exhaust
system.
Your Yamaha engine has been
designed to use regular unleaded
gasoline with a research octane num-
ber of 91 or higher. If knocking (or
pinging) occurs, use a gasoline of a
different brand or premium unleaded
fuel. Use of unleaded fuel will extend
spark plug life and reduce mainte-
nance costs.
1
2
1. Filler tube
2. Fuel level
Recommended fuel:
REGULAR UNLEADED
GASOLINE ONLY
Fuel tank capacity:
Total amount:
11 L
Reserve amount:
3.4 L
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 17
Page 19 of 86

3-8
EAU03236
Fuel cock
Fuel cock
This motorcycle is equipped with a
negative pressure fuel cock. The fuel
cock supplies fuel from the tank to
the carburetors while also filtering it.
The fuel cock lever positions are
explained as follows and shown in
the illustrations.
ON
With the fuel cock lever in this posi-
tion, fuel flows to the carburetor when
the engine is running. Turn the fuel
cock lever to this position when start-
ing the engine and riding.RES
This indicates reserve. With the fuel
cock lever in this position, the fuel
reserve is made available. Quickly
turn the fuel cock lever to this posi-
tion if you run out of fuel while riding,
otherwise the engine may stall and
will have to be primed (see “PRI”).
After turning the fuel cock lever to
“RES”, refuel as soon as possible
and be sure to turn the fuel cock
lever back to “ON”!PRI
This indicates prime. With the fuel
cock lever in this position, the engine
can be “primed”. Turn the fuel cock
lever to this position when the engine
has been allowed to run out of fuel.
This sends fuel directly to the carbu-
retor, which will make starting easier.
After the engine has started, be sure
to turn the lever to “ON” (or “RES” if
you have not refueled yet).INSTRUMENT AND CONTROL FUNCTIONS
3
1
1
1. Arrow mark positioned over “RES”1. Arrow mark positioned over “PRI”
1
1. Arrow mark positioned over “ON”ON: normal
position
RES: reserve position
PRI: priming position
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 18
Page 20 of 86

3-9
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU03839
Starter (choke) lever “1”
Starter (choke) lever
Starting a cold engine requires a rich-
er air-fuel mixture, which is supplied
by the starter (choke).
Move the lever in direction ato turn
on the starter (choke).
Move the lever in direction bto turn
off the starter (choke).
EAU00260
Helmet holder
Helmet holder
To open the helmet holder, insert the
key into the lock, and then turn the
key as shown.
To lock the helmet holder, place it in
the original position, and then remove
the key.
EW000030
wNever ride with a helmet attached
to the helmet holder, since the hel-
met may hit objects, causing loss
of control and possibly an acci-
dent.
EAU00300
Adjusting the shock
absorber assemblies
Shock absorber assemblies, adjusting
Each shock absorber assembly is
equipped with a spring preload
adjusting ring.
EC000015
cCNever attempt to turn an adjusting
mechanism beyond the maximum
or minimum settings.
1
a
b
1
a
1
2
3
4
5
b
a
2
1
1. Starter (choke) lever “1”1. Helmet holder
a Open.1. Shock absorber spring preload
adjusting ring
2. Position indicator
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 19
