3-1
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-3.frame
EL
EBU00032
DESCRIPTION AND MACHINE
IDENTIFICATION
1. Rear spring preload
adjusting ring
2. Storage box and tool kit
3. Spark plug
4. Rear brake fluid
reservoir
5. Radiator cap
6. Front spring preload
adjusting ring
7. V-belt case
8. Rear brake pedal
9. Front spring preload
adjusting ring
10. Fuel cock
11. Air filter case
12. Fuses13. V-belt cooling duct
check hose
14. Coolant reservoir
15. Oil filter cartridge
16. Engine oil dipstick
17. Rear brake lever
18. Left handlebar switches
19. Starter (choke)
20. Horn switch
21. Drive select lever
22. Speedometer
23. Main switch
24. Fuel tank cap
25. Auxiliary DC jack
26. Right handlebar switch
27. Throttle lever
28. Front brake lever
NOTE:

The machine you have purchased may differ
slightly from those shown in the figures of this
manual.

8-117
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-8.frame
EL
EBU00745
Fuse replacement
1. The fuse cases are under the seat.
2. If a fuse is blown, turn off the main switch
and the switch of the circuit in question.
Then, install a new fuse of the specified
amperage. Turn on the main switch. If the
fuse immediately blows again, consult a
Yamaha dealer.
Specified fuses:
Main fuse: 30 A
Headlight fuse: 15 A
Ignition fuse: 10 A
Auxiliary DC jack fuse: 10 A
Four-wheel-drive fuse: 3 A
Signal fuse (horn): 10 A
1. Main fuse 2. Spare fuse
1. Fusible principal 2. Fusible de rechange
1. Fusible principal 2. Fusible de repuesto1. Fuse box
1. Boîte à fusibles
1. Caja de fusibles
