8-121
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-8.frame
EL
EBU00685
Replacing the headlight bulb
If the headlight bulb burns out, replace it as fol-
lows:
1. Remove the cover at the rear of the head-
light.
2. Remove the bulb holder cover.
1. Cover
1. Cache
1. Cubierta1. Bulb holder cover
1. Cache du support d’ampoule
1. Cubierta del portabombillas

8-123
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-8.frame
EL
3. Unhook the bulb holder spring and re-
move the defective bulb.
WARNING
The headlight bulb is hot when it is on and im-
mediately after it is turned off. Wait for the
bulb to cool down before touching or remov-
ing it. You can be burned, or a fire could start ifthe bulb touches something flammable.
4. Put a new bulb into position and secure it
in place with the bulb holder spring.
5. Install the bulb holder cover.
1. Bulb holder
1. Fixation d’ampoule
1. Portabombillas

Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600SPEC-
EL
10-5
Brake:
Front brake type Dual disc brake
operation Right hand operation
Rear brake type Single disk brake
operation Left hand and right foot operation
Suspension:
Front suspension Double wishbone
Rear suspension Swingarm (monocross)
Shock absorber:
Front shock absorber Coil spring / oil damper
Rear shock absorber Coil spring / oil damper
Wheel travel:
Front wheel travel 160 mm
Rear wheel travel 180 mm
Electrical:
Ignition system DC-C.D.I.
Generator system A.C. magneto
Battery type YTX20L-BS
Battery voltage, capacity 12 V, 18 AH
Headlight type: Krypton bulbModel YFM400FA / YFM400FWAN

Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600SPEC-
ER
10-6
Bulb voltage, wattage
´
quantity:
Headlight 12 V, 30 W / 30 W
´
2
Taillight 12 V, 7.5 W
´
1
Neutral indicator light 12 V, 1.7 W
´
1
Reverse indicator light 12 V, 1.7 W
´
1
Coolant oil temperature warning light 12 V, 1.7 W
´
1
Park indicator light 12 V, 1.7 W
´
1
Four wheel drive indicator light 12 V, 1.7 W
´
1 Model YFM400FA / YFM400FWAN
