Lubricating the drive chain ................ 8-83
Cable inspection and lubrication ....... 8-87
Brake and shift pedal/brake and
clutch lever lubrication ..................... 8-87
Front upper and lower arm pivot
lubrication ......................................... 8-89
Rear arm pivot lubrication .................. 8-91
Wheel removal .................................. 8-95
Wheel installation .............................. 8-97
Battery ............................................... 8-99
Battery maintenance ....................... 8-103
Fuse replacement ............................ 8-105
Replacing a headlight bulb ............... 8-107
Tail/brake light bulb replacement ..... 8-117
Troubleshooting ............................... 8-119
Troubleshooting chart ...................... 8-121
CLEANING AND STORAGE .................. 9-1
A. CLEANING ...................................... 9-1
B. STORAGE ...................................... 9-7
9
SPECIFICATIONS ................................ 10-1
CONVERSION TABLE .......................... 11-1
1011
U5LP61.book Page 3 Monday, August 27, 2001 3:49 PM

8-107 1. Headlight assembly 2. Bolt (× 2)
1. Bloc de phare 2. Boulon (× 2)
1. Conjunto faro 2. Perno (× 2)
1. Headlight coupler
1. Coupleur de phare
1. Acoplador
EBU01025
Replacing a headlight bulb
1. Remove the headlight assembly by removing
the bolts.
2. Disconnect the headlight coupler.
U5LP61.book Page 107 Monday, August 27, 2001 3:49 PM

8-111 1. Headlight unit 2. Headlight case
1. Optique de phare 2. Support du phare
1. Unidad del faro 2. Caja del faro
1. Headlight bulb holder cover
1. Cache de la fixation d’ampoule de phare
1. Cubierta del portabombillas del faro
6. Remove the headlight bulb holder cover.
U5LP61.book Page 111 Monday, August 27, 2001 3:49 PM

8-113 1. Headlight bulb holder
1. Fixation d’ampoule de phare
1. Portabombillas del faro
1. Headlight bulb 2. Headlight bulb holder
1. Ampoule de phare 2. Fixation d’ampoule
1. Bonbilla del faro 2. Portabombillas del faro
7. Push the headlight bulb holder inward, turn it
counterclockwise and remove the defective
bulb.
WARNING
_ A headlight bulb is hot when it is on and imme-
diately after it is turned off. Wait for the bulb to
cool down before touching or removing it. You
can be burned, or a fire could start if the bulb
touches something flammable. _8. Put a new headlight bulb into position and se-
cure it in place with the bulb holder.
9. Install the headlight bulb holder cover.CAUTION:_ Make sure the headlight bulb holder cover is
securely fitted over the bulb holder and seated
against the reflector. _10. Align the projections with the holders, install
the headlight unit into the case, and install the
screw.
11. Install the headlight cover in the original posi-
tion, and then install the screw.
U5LP61.book Page 113 Monday, August 27, 2001 3:49 PM

10-5
Wheel travel:
Front
Rear230 mm
220 mm
Electrical:
Ignition system
Generator system
Battery type/voltage capacityDC-C.D.I.
A.C. Magneto
YTX14-BS/12 V, 12 Ah
Headlight type Krypton bulb
Bulb voltage, wattage
× quantity:
Headlight
Tail/brake light
Indicator/warning lights:
Neutral
Reverse
Coolant temperature12 V, 30 W/30 W
× 2
12 V, 5 W/21 W
× 1
12 V, 1.7 W
× 1
12 V, 1.7 W
× 1
12 V, 1.7 W
× 1
Fuse 20 AMODEL YFM660R
