8-48
82. Connect the positive battery lead first, then
connect the negative battery lead by installing
their bolt. NOTICE: When installing the bat-
tery, the main switch must be off, and the
positive lead must be connected before
the negative lead.
[ECB01110]
3. Hook the battery holding plate onto the battery box. 4. Install the battery holding plate with the bat-
tery cover by installing the bolts and the quick
fastener screws.
5. Install the seat. (See page 4-12.)
EBU25327Replacing a fuse The main fuse and the fuse box are located under
the seat. (See page 4-12.)
1. Positive battery lead (red)
2. Negative battery lead (black)
2 1
1. Battery holding plate
2. Battery box
2
1
