YAMAHA YFZ50 2017 Owners Manual

9-1
9
EBU25861
CLEANING AND STORAGE
EBU25903CleaningFrequent, thorough cleaning of your ATV will not
only enhance its appearance but will improve its
general performance and extend the useful life of
many components.1. Before cleaning the ATV: a. Block off the end of the exhaust pipe toprevent water entry. A plastic bag and
strong rubber band may be used.
b. Make sure the spark plug and all filler caps are properly installed.
2. If the engine case is excessively greasy, apply degreaser with a paint brush. Do not apply
degreaser to the chain, sprockets or wheel
axles.
3. Rinse the dirt and degreaser off with a garden hose. Use only enough pressure to do the
job. WARNING! Wet brakes may have re-
duced stopping ability, increasing the
chance of an accident. Test the brakes af-
ter washing. Apply the brakes several
times at slow speeds to let friction dry out
the linings.
[EWB02312]
NOTICE: Excessive wa- ter pressure may cause water seepage
and deterioration of wheel bearings,
brakes, transmission seals and electrical
devices. Many expensive repair bills have
resulted from improper high-pressure de-
tergent applications such as those avail-
able in coin-operated car washers.
[ECB00712]
4. Once most of the dirt has been hosed off,
wash all surfaces with warm water and mild,
detergent-type soap. An old toothbrush or
bottle brush is handy for hard-to-reach pla-
ces.
5. Rinse the ATV off immediately with clean wa- ter and dry all surfaces with a chamois, clean
towel or soft absorbing cloth.
6. Dry the chain and lubricate it to prevent it from rusting.
7. Clean the seat with a vinyl upholstery cleaner to keep the cover pliable and glossy.
8. Automotive type wax may be applied to all painted and chrome plated surfaces. Avoid
combination cleaner-waxes. Many contain
UBW460E0.book Page 1 Monday, May 23, 2016 11:12 AM

9-2
9abrasives which may mar the paint or protec-
tive finish. When finished cleaning, start the
engine and let it idle for several minutes.
EBU30361StorageShort-term
Always store your ATV in a cool, dry place and, if
necessary, protect it against dust with a porous
cover.
NOTICE: Storing the ATV in a poorly ven-
tilated room or covering it with a tarp while it is
still wet, will allow water and humidity to seep
in and cause rust. To prevent corrosion, avoid
damp cellars, stables (because of the presence
of ammonia) and areas where strong chemi-
cals are stored.
[ECB00722]
Long-term
Before storing your ATV for several months: 1. Follow all the instructions in the “Cleaning” section of this chapter.
2. Turn the fuel cock lever to “OFF”.
3. Drain the carburetor float chamber by loosen- ing the drain bolt; this will prevent fuel depos-
its from building up. Pour the drained fuel into
the fuel tank. 4. Fill up the fuel tank and add fuel stabilizer (if
available) to prevent the fuel from deteriorat-
ing.
5. Perform the following steps to protect the cyl- inder, piston rings, etc. from corrosion.a. Remove the spark plug cap and spark plug.
b. Pour a teaspoonful of engine oil into the spark plug bore.
c. Install the spark plug cap onto the spark plug, and then place the spark plug on the
cylinder head so that the electrodes are
grounded. (This will limit sparking during
the next step.)
d. Turn the engine over several times with the starter. (This will coat the cylinder wall
with oil.)
e. Remove the spark plug cap from the spark plug, and then install the spark plug and
the spark plug cap.
6. Lubricate all control cables and the pivoting points of all levers.
Specified amount:
7.5 ml of stabilizer to each liter of fuel (or 1
oz of stabilizer to each gallon of fuel)UBW460E0.book Page 2 Monday, May 23, 2016 11:12 AM

9-3
9
7. Check and, if necessary, correct the tire air
pressure, and then block up the ATV so that
all of its wheels are off the ground. Alterna-
tively, turn the wheels a little every month in
order to prevent the tires from becoming de-
graded in one spot.
8. Cover the muffler outlet with a plastic bag to prevent moisture from entering it.
9. Remove the battery and fully charge it. Store it in a cool, dry place and charge it once a
month. Do not store the battery in an exces-
sively cold or warm place [less than 0 °C (30
°F) or more than 30 °C (90 °F)]. For more infor-
mation on storing the battery, see page 8-32.
TIPMake any necessary repairs before storing the
ATV. UBW460E0.book Page 3 Monday, May 23, 2016 11:12 AM

10-1
10
EBU25962
SPECIFICATIONS
Dimensions:Overall length:1250 mm (49.2 in)
Overall width: 820 mm (32.3 in)
Overall height:
770 mm (30.3 in)
Seat height: 585 mm (23.0 in)
Wheelbase: 830 mm (32.7 in)
Ground clearance:
88 mm (3.5 in)
Minimum turning radius: 2300 mm (91 in)Weight:Curb weight:
100.0 kg (220 lb)Noise and vibration level:Noise level (77/311/EEC):74.0 dB(A) (EUR, FRA, GBR)
Uncertainty of measurement:
2.0 dB(A) (EUR, FRA, GBR)
Vibration on seat (EN1032, ISO5008): Will not exceed 0.5 m/s² (EUR, FRA, GBR)
Uncertainty of measurement: 0.1 m/s² (EUR, FRA, GBR) Vibration on handle (EN1032, ISO5008):
4.7 m/s² (EUR, FRA, GBR)
Uncertainty of measurement: 0.4 m/s² (EUR, FRA, GBR)
Engine:Engine type:
Air cooled 4-stroke, SOHC
Cylinder arrangement: Single cylinder
Displacement: 49 cm³
Bore × stroke:
39.0 × 41.4 mm (1.54 × 1.63 in)
Compression ratio: 8.5 : 1
Starting system: Electric starter and kickstarter
Lubrication system:
Wet sumpEngine oil:Recommended brand:YAMALUBE
UBW460E0.book Page 1 Monday, May 23, 2016 11:12 AM

10-2
10
Type:SAE 5W-30, 10W-30, 10W-40, 15W-40, 20W-40 or 20W-
50
Recommended engine oil grade: API service SG type or higher, JASO standard MA
Engine oil quantity: Periodic oil change:0.90 L (0.95 US qt, 0.79 Imp.qt)Transmission oil:Type:
SAE 80W-90
Quantity: 0.35 L (0.37 US qt, 0.31 Imp.qt)Air filter:Air filter element:
Wet element
Fuel:Recommended fuel:Regular unleaded gasoline only
Fuel tank capacity:
5.6 L (1.48 US gal, 1.23 Imp.gal)
Fuel reserve amount: 0.7 L (0.18 US gal, 0.15 Imp.gal)Carburetor:Type × quantity:
VM12Spark plug (s):Manufacturer/model: NGK/CR6HSA
Spark plug gap:
0.6–0.7 mm (0.024–0.028 in)Clutch:Clutch type:Dry, centrifugal automaticTransmission:Secondary reduction system:Chain drive
Secondary reduction ratio: 38/13 (2.920)
Transmission type:
V-belt automatic
Operation: Centrifugal automatic typeChassis:Frame type:
Steel tube frame
0 10 30 50 70 90 110 130 ˚F
–20 –10 0 10 20 30 40 50 ˚CSAE 5W-30
SAE 10W-30
SAE 10W-40
SAE 15W-40
SAE 20W-40SAE 20W-50
UBW460E0.book Page 2 Monday, May 23, 2016 11:12 AM

10-3
10
Caster angle:1.10 °
Trail: 10.4 mm (0.41 in)Front tire:Type:Tubeless
Size: AT16 x 6.5-7
Manufacturer/model:
DURO/DI2040Rear tire:Type:Tubeless
Size:
AT16 x 7-7
Manufacturer/model: DURO/DI2041Loading:Maximum loading limit:
41.0 kg (90 lb)
(Total weight of rider, cargo, accessories, and tongue)Tire air pressure (measured on cold tires):Recommended:Front:
13.8 kPa (0.14 kgf/cm², 2.0 psi)
Rear: 13.8 kPa (0.14 kgf/cm², 2.0 psi)
Minimum: Front: 12.4 kPa (0.124 kgf/cm², 1.8 psi) Rear:
12.4 kPa (0.124 kgf/cm², 1.8 psi)
Front wheel:Wheel type:
Panel wheel
Rim size: 7 x 5.2ATRear wheel:Wheel type:
Panel wheel
Rim size: 7 x 5.2ATFront brake:Type:
Mechanical leading, trailing drum brake
Operation: Right hand operationRear brake:Type:
Mechanical leading, trailing drum brake
Operation: Left hand operationFront suspension:Type:
Swing axle
Spring/shock absorber type: Coil spring/oil damper
Wheel travel: 60 mm (2.4 in)
UBW460E0.book Page 3 Monday, May 23, 2016 11:12 AM

10-4
10
Rear suspension:Type:Swingarm
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel: 51 mm (2.0 in)Electrical system:Ignition system:
CDI
Charging system: AC magnetoBattery:Model:
GTX5L-BS
Voltage, capacity: 12 V, 4.0 AhFuse:Fuse:
7.5 AEBU30402For Europe only
The figures quoted are emission levels and are not
necessarily safe working levels. Whilst there is a
correlation between the emission and exposure
levels, this cannot be used reliably to determine
whether or not further precautions are required.
Factors that influence the actual level of exposure of work-force include the characteristics of the
work room, the other sources of noise, etc. i.e. the
number of machines and other adjacent process-
es, and the length of time for which an operator is
exposed to the noise. Also the permissible expo-
sure level can vary from country. This information,
however, will enable the user of the machine to
make a better evaluation of the hazard and risk.UBW460E0.book Page 4 Monday, May 23, 2016 11:12 AM

11-1
11
EBU26001
CONSUMER INFORMATION
EBU28202Identification numbersRecord the vehicle identification number and
model label information in the spaces provided
below for assistance when ordering spare parts
from a Yamaha dealer or for reference in case the
ATV is stolen.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:EBU26031Vehicle identification number
The vehicle identification number is stamped into
the frame.
TIPThe vehicle identification number is used to iden-
tify your ATV. EBU26051Model label
The model label is affixed at the location in the il-
lustration. Record the information on this label in
the space provided. This information will be need-
ed when ordering spare parts from a Yamaha
dealer.1. Vehicle identification number
1
UBW460E0.book Page 1 Monday, May 23, 2016 11:12 AM

11-2
11
1. Model label
1
UBW460E0.book Page 2 Monday, May 23, 2016 11:12 AM

12-1
12
INDEX
AAccessories and loading ................................................ 6-5
Air filter element, cleaning ............................................ 8-16BBattery .......................................................................... 8-32
Brake lever free play, adjusting the front ..................... 8-23
Brake lever free play (rear), adjusting ........................... 8-25
Brake lever, front ............................................................ 4-5
Brake lever, rear ............................................................. 4-6
Brake levers, checking and lubricating ........................ 8-29
Brakes .......................................................................... 8-22
Brakes, front and rear .................................................... 5-3CCables, checking and lubricating ................................. 8-29
Carburetor, adjusting ...................................................8-20
Chassis fasteners ........................................................... 5-6
Cleaning ......................................................................... 9-1DDrive chain ..................................................................... 5-3
Drive chain, cleaning and lubricating ........................... 8-28
Drive chain slack .......................................................... 8-26EEngine break-in .............................................................. 6-3
Engine, cold start ........................................................... 6-1
Engine idling speed ...................................................... 8-20
Engine oil .............................................................. 5-3, 8-11
Engine, starting a warm ................................................. 6-3
Engine stop switch ......................................................... 4-1
Engine stop switch with lanyard .................................... 4-2
FFront and rear brake shoes, checking ......................... 8-22
Front arm pivots, lubricating ........................................ 8-30
Front knuckle pivots, lubricating .................................. 8-31
Fuel ........................................................................ 4-8, 5-3
Fuel cock ...................................................................... 4-10
Fuel tank cap ................................................................. 4-8
Fuse, replacing ............................................................. 8-35HHandlebar switches ....................................................... 4-1IIdentification numbers ................................................. 11-1
Instruments and switches .............................................. 5-6KKickstarter ...................................................................... 4-7LLabel locations ............................................................... 1-1MMain switch .................................................................... 4-1
Maintenance and lubrication chart ................................ 8-5
Maintenance chart, emission control system ................ 8-3
Model label .................................................................. 11-1OOwner’s manual and tool kit .......................................... 8-2PPanel, removing and installing ....................................... 8-9
Parking ........................................................................... 6-3
Parking brake ................................................................. 4-6
Parking on a slope ......................................................... 6-4
UBW460E0.book Page 1 Monday, May 23, 2016 11:12 AM
