torque YAMAHA YXZ1000R 2017 Owners Manual

4-36
4
YXZ10YEXH
YXZ10YESH3. Tighten the locknut to the specified
torque. NOTICE: Always tighten the
locknut against the adjusting nut, and
then tighten it to the specified torque.
[ECB00082]
Crossover setting (YXZ10YESH)
The crossover setting adjusts the timing when
the shock absorber transitions from the soft
spring to the hard spring.TIP It is recommended to adjust the crossover
setting a similar distance whenever the
spring preload is adjusted.
 The crossover setting is measured from the
bottom of the spring preload adjusting ring
to the bottom of the crossover adjusting
ring.
1. Distance A
1. Distance A
11
Tightening torque:
Locknut:41 N·m (4.1 kgf·m, 30 lb·ft)
UB577AE0.book Page 36 Wednesday, June 8, 2016 9:35 AM

4-38
4
3. Tighten the locknut to the specifiedtorque. NOTICE: Always tighten the
locknut against the adjusting nut, and
then tighten it to the specified torque.
[ECB00082]
1. Distance B
2. Crossover locknut
3. Crossover adjusting nutCrossover setting: Minimum (soft):Distance A = 47.6 mm (1.88 in)
Standard (recommended): Distance A = 60.3 mm (2.38 in)
Maximum (hard): Distance A = 73.0 mm (2.88 in)
2
3
1(b)
(a)
Tightening torque:
Locknut:41 N·m (4.1 kgf·m, 30 lb·ft)1. Special tool
2. Torque wrench
3. Crossover locknut
21
3
90
UB577AE0.book Page 38 Wednesday, June 8, 2016 9:35 AM

4-47
4
3. Tighten the locknut to the specifiedtorque. NOTICE: Always tighten the
locknut against the adjusting nut, and
then tighten it to the specified torque.
[ECB00082]
Crossover setting (YXZ10YESH)
The crossover setting adjusts the timing when
the shock absorber transitions from the soft
spring to the hard spring.TIP It is recommended to adjust the crossover
setting a similar distance whenever the
spring preload is adjusted.
 The crossover setting is measured from the
bottom of the spring preload adjusting ring
to the bottom of the crossover adjusting
ring.
1. Loosen the crossover locknut as shown.
Tightening torque:
Locknut:41 N·m (4.1 kgf·m, 30 lb·ft)
1. Distance B
2. Crossover locknut
3. Crossover adjusting nut
2
3
1
UB577AE0.book Page 47 Wednesday, June 8, 2016 9:35 AM

4-49
4
3. Tighten the locknut to the specifiedtorque. NOTICE: Always tighten the
locknut against the adjusting nut, and
then tighten it to the specified torque.
[ECB00082]
Rebound damping force (YXZ10YEXH)
Turn the rebound damping force adjusting
screw in direction (a) to increase the rebound
damping force and thereby harden the damp-
ing, and in direction (b) to decrease the re-
bound damping force and thereby soften the
damping.
Tightening torque: Locknut:41 N·m (4.1 kgf·m, 30 lb·ft)1. Special tool
2. Torque wrench
3. Crossover locknut
21
3
90
1. Rebound damping force adjusting screw
1(a)
(b)
UB577AE0.book Page 49 Wednesday, June 8, 2016 9:35 AM

5-8
5
EBU36672YCC-S clutchCheck the YCC-S clutch fluid level and cor-
rect if necessary. (See page 8-45.)
Check the operation of the drive select lever
and shift paddles at the start of each drive.TIPIf the YCC-S clutch fluid level was low, be
sure to check the clutch system for leak-
age.
 If any leakage is found, or if shifting is not
smooth, have a Yamaha dealer service the
vehicle. EBU35700Fittings and fastenersAlways check the tightness of chassis and
wheel fittings and fasteners before starting
off. Take the vehicle to a Yamaha dealer or re-
fer to the Service Manual for correct tighten-
ing torque.
EBU31840Instruments, lights and switchesCheck that all instrument s, lights and switch-
es are working properly. Correct if necessary.EBU31851Control cablesWhen driving in cold weather, always make
sure all control cables work smoothly before
starting off. WARNING! Control cables can
freeze in cold weather and you could be
unable to control the vehicle.
[EWB03280]
EBU35331
TiresCheck tire pressure regularly to make sure it
is at the recommended specifications. Also
check for wear and damage.
Tire pressure
Use the tire pressure gauge to check and ad-
just tire pressures when the tires are cold. Tire
pressures must be equal on both sides.
WARNING! Operation of this vehicle with improper tire pressure may cause severe
UB577AE0.book Page 8 Wednesday, June 8, 2016 9:35 AM

8-2
8
EBU33560Owner’s manual and tool kitYou are recommended to put this owner’s
manual in the vinyl bag and always carry it in
the glove compartment as shown. Put the
owner’s tool kit and tire pressure gauge under
the passenger seat.The service information included in this man-
ual is intended to provide you, the owner, with
the necessary information for completing
your own preventive maintenance and minor
repairs.
The tools provided in the owner’s tool kit are
sufficient for this purpose, except that a
torque wrench is also necessary to properly
tighten nuts and bolts.1. Owner’s manual
1
1. Owner’s tool kit
2. Tire pressure gauge
1
2
UB577AE0.book Page 2 Wednesday, June 8, 2016 9:35 AM

8-3
8
If you do not have a torque wrench available
during a service operation requiring one, take
your vehicle to a Yamaha dealer to check the
torque settings and adjust them as neces-
sary.UB577AE0.book Page 3 Wednesday, June 8, 2016 9:35 AM

8-14
8
2. Install the passenger seat by installing thebolts, and then tighten them to the spec-
ified torque.TIPMake sure that the seat frame is properly
secured. 
Place the passenger seat belt in the original
position.
3. Install the passenger seat cushion.
4. Install the top cover by installing the bolts
and quick fastener screw.
5. Install panel A and the hood.
Panel C
To remove the panelRemove the quick fastener screws, and then
pull the panel off as shown.
1. Panel BTightening torque: Passenger seat bolt:32 N·m (3.2 kgf·m, 23 lb·ft)
1
1. Panel C
2. Quick fastener screw
1
2
2
2
UB577AE0.book Page 14 Wednesday, June 8, 2016 9:35 AM

8-18
8
9. Place an oil pan under the engine to col-lect the used engine oil.
10. Remove the engine oil drain bolt and its gasket to drain the oil from the engine.
TIPA “ ” mark is stamped on the crankcase
near the engine oil drain bolt for easy identifi-
cation. 11. Install the engine oil drain bolt, engine oil
tank drain bolt and their new gaskets,
and then tighten the bolts to the specified
torques.
1. Engine oil tank drain bolt
2. Gasket
2
1
1. Engine oil drain bolt
2. Gasket
3. “ ” mark
1 2
3
UB577AE0.book Page 18 Wednesday, June 8, 2016 9:35 AM

8-19
8
12. Add 2.00 L (2.11 US qt, 1.76 Imp.qt) ofthe recommended engine oil to the oil
tank, and then install and tighten the en-
gine oil tank filler cap and the cylinder
head cap.
13. Start the engine, warm it up for several minutes, and then turn it off.
14. Remove the engine oil tank filler cap, and then add sufficient oil of the recommend-
ed type to raise it to the maximum level
mark on the dipstick.
TIPBe sure to wipe off spilled oil on any parts af-
ter the engine and exhaust system have
cooled down. NOTICEECB03020Do not use oils with a diesel specifica-
tion of “CD” or oils of a higher quality
than specified. In addition, do not use
oils labeled “ENERGY CONSERVING II”
or higher.
 Make sure that no foreign material en-
ters the oil tank.
Tightening torques:
Engine oil drain bolt:10 N·m (1.0 kgf·m, 7.2 lb·ft)
Engine oil tank drain bolt: 16 N·m (1.6 kgf·m, 12 lb·ft)
Recommended engine oil: See page 10-1.
Oil quantity: Oil change only:2.50 L (2.64 US qt, 2.20 Imp.qt)
Oil change and filter replacement: 2.70 L (2.85 US qt, 2.38 Imp.qt)
UB577AE0.book Page 19 Wednesday, June 8, 2016 9:35 AM
