6-6
6
Always place a portable fuel container on the
ground before filling it. Before removing the
container cap, touch the container with the
fuel dispenser nozzle. Keep fuel dispenser
nozzle in contact with container inlet when fill-
ing. WARNING! Never refill a fuel container
in the bed of any vehicle. Fire may result
from a build-up of static electricity. The
discharge of this build-up while refueling
can cause a spark and ignite the gasoline.[EWB03270]
EBU35680Engine oilMake sure the engine oil is at the specified
level. Add oil as necessary. (See page 9-16.)NOTICEECB03020 Do not use oils with a diesel specifica-
tion of “CD” or oils of a higher quality
than specified. In addition, do not use
oils labeled “ENE RGY CONSERVING II”
or higher. 
Make sure that no foreign material en-
ters the oil tank.
EBU35322TransmissionMake sure there is no oil leaking from the
transmission case.EBU31761CoolantCheck the coolant level in the reservoir and
replenish if necessary. (See page 9-34.)EBU36020Final gearMake sure there is no oil leaking from the final
gear case.EBU36030Differential gearMake sure there is no oil leaking from the dif-
ferential gear case.Recommended engine oil type and quantity: See page 11-1.
UB5J7CE0.book Page 6 Thursday, November 26, 2020 1:37 PM

6-7
6
EBU31791Accelerator pedalBefore starting the engine, confirm that the
accelerator pedal operates correctly. It
should depress smoothly and spring back to
the idle position when released. Also check
the accelerator pedal for excessive free play.
If the accelerator pedal is not in correct work-
ing order, have the vehicle inspected before
starting off.EBU31800Seat beltsMake sure that the seat belts are not frayed,
torn, stretched, or damaged. The seat belts
must move smoothly when pulled out and re-
tract on its own when released. The seat belts
must also lock up when quickly pulled out.
The latch plate should click securely into the
buckle and release when the release button is
pushed firmly. Wash off any dirt or mud that
could affect operation. Have a Yamaha dealer
repair as necessary for proper operation. A crash can damage the restraint systems in
your vehicle. A damaged restraint system
may not properly protect the person using it,
resulting in serious injury or death in a crash.
To help make sure your restraint systems are
working properly after a crash, have them in-
spected and any necessary replacements
made as soon as possible.
EBU31810Passenger handholdCheck that the handhold bar and its supports
are in good condition. Confirm that the lock-
ing pins are securely fastened, and then push
and pull on the handhold to make sure that it
is not loose.EBU31820SteeringPark on level ground. Turn the steering wheel
right and left. Check for excessive free play,
abnormal noises, or a rough feeling. Have a
Yamaha dealer repair as necessary for proper operation.
UB5J7CE0.book Page 7 Thursday, November 26, 2020 1:37 PM

6-8
6
EBU35690Shift leverThe shift lever should move smoothly both
forward and backwards and return to its orig-
inal position after a gear change is made.
Check the shift lever and transmission for
roughness before starting off.TIPThe engine may need to be started for the
transmission to engage gears. EBU31832Fittings and fastenersAlways check the tightness of chassis fittings
and fasteners before starting off. Take the ve-
hicle to a Yamaha dealer or refer to the Servi-
ce Manual for correct tightening torque.EBU31840Instruments, lights and switchesCheck that all instruments, lights and switch-
es are working properly. Correct if necessary.
EBU31851Control cablesWhen driving in cold weather, always make
sure all control cables work smoothly before
starting off. WARNING! Control cables can
freeze in cold weather and you could be
unable to control the vehicle.
[EWB03280]
EBU37895
TiresCheck and adjust the tire pressure before
each ride. Check tires for wear and damage.
Tire pressure1. Tire pressure gauge
1
UB5J7CE0.book Page 8 Thursday, November 26, 2020 1:37 PM

6-9
6
A tire pressure gauge is included as standard
equipment. Make two measurements of the
tire pressure and use the second reading.
Dust or dirt in the gauge could cause the first
reading to be incorrect.
Tire pressure must be checked and set when
the tires are cold. The tire pressure should be
the same on both sides, and must be adjust-
ed according to vehicle loading conditions.
Set the tire pressure as specified below.
WARNING! Operation of this vehicle with
improper tire pressure may cause severe
injury or death from loss of control or roll-
over. Tire pressure below the minimum
specified could also cause the tire to dis-
lodge from the rim under severe driving
conditions.
[EWB04120]
OPERATING TIRE PRESSURE (cold): VEHICLE LOAD of 0.0–195.0 kg (0–430 lb) FRONT: (Recommended)114.0 kPa (1.140 kgf/cm², 16.5 psi)
REAR: (Recommended) 128.0 kPa (1.280 kgf/cm², 18.5 psi)
Front: (Minimum) 110.0 kPa (1.100 kgf/cm², 16.0 psi)
Rear: (Minimum) 124.0 kPa (1.240 kgf/cm², 18.0 psi)
VEHICLE LOAD of 195.0–328.0 kg (430–
723 lb) FRONT: (Recommended)114.0 kPa (1.140 kgf/cm², 16.5 psi)
REAR: (Recommended) 169.0 kPa (1.690 kgf/cm², 24.5 psi)
Front: (Minimum) 110.0 kPa (1.100 kgf/cm², 16.0 psi)
Rear: (Minimum) 165.0 kPa (1.650 kgf/cm², 24.0 psi)
Vehicle load is total weight of operator, pas-
senger, accessories, and cargo. Do not ex-
ceed maximum vehicle load of 328.0 kg
(723 lb).
UB5J7CE0.book Page 9 Thursday, November 26, 2020 1:37 PM

6-10
6
Tire inspection
When the tire tread depth has worn to 3 mm
(0.12 in) replace the tire. If the tire has a nail or
glass fragments in it, or if the sidewall is
cracked, replace the tire.1. Tire tread depth
1
UB5J7CE0.book Page 10 Thursday, November 26, 2020 1:37 PM

7-1
7
EBU31872
OPERATION
EBU31880Read the Owner’s Manual carefully to be-
come familiar with all controls. If there is a
control or function you do not understand,
ask your Yamaha dealer.
WARNING
EWB03290Failure to familiarize yourself with the con-
trols can lead to loss of control, which
could cause an accident or injury. EBU35720Engine break-inThere is never a more important period in the
life of your vehicle than the period between 0
and 20 hours.
For this reason, we ask that you read the fol-
lowing material carefully. Because the engine
is brand new, you must not put an excessive
load on it for the first several hours of opera-
tion. During the first 20 hours, the variousparts in the engine wear and polish them-
selves to achieve the correct operating clear-
ances.
During this period, prolonged full-throttle op-
eration or any condition that might result in
excessive engine heating must be avoided.
However, momentary (2–3 seconds maxi-
mum) full-throttle operation under load does
not harm the engine.
Each full-throttle acceleration sequence
should be followed with a substantial rest pe-
riod for the engine, by cruising at lower r/min
so the engine can rid itself of the temporary
build-up of heat. If any abnormality is noticed
during this period, consult a Yamaha dealer.
0–10 hours:
Avoid prolonged operation above 5300 r/min.
Allow a cooling-off period of 5 to 10 minutes
after every hour of operation. Vary the speed
of the vehicle from time to time. Do not oper-
ate it at one set throttle position.UB5J7CE0.book Page 1 Thursday, November 26, 2020 1:37 PM

7-2
7
10–20 hours:
Avoid prolonged operation above 6300 r/min.
After break-in:
The vehicle may now be operated normally.EBU35342Starting the engine1. Turn the key to “ ” (on).NOTICEECB02291The coolant temperature warning light and
engine trouble warning light should come
on, then go off.
The EPS warning light should come on,
then go off when the engine is started.
To avoid possible damage, do not operate
the vehicle if a warning light does not work
as described above. 2. Press the brake pedal.
3. Shift the transmission into neutral.
When the transmission is in the neutral
position, the transmission gear display
shows “N” and the neutral indicator
light should come on.
 The engine can be started in any gear if
the clutch pedal is applied. However, it
is recommended to shift into neutral
before starting the engine.
4. With your foot off the accelerator pedal, start the engine by turning the key to “ ”
(start).
If the engine fails to start, release the key, and
then try starting it again. Wait a few seconds
before the next attempt. Each attempt should
be as short as possible, to preserve battery
energy. NOTICE: Do not crank the engine
more than 5 seconds on each attempt, or
starter damage could occur. Wait at least
5 seconds between each operation of the
electric starter to let it cool.
[ECB02140]
Do not turn the key to the “ ” (start) position
with the engine running; otherwise, damage
to the electric starter may result.
UB5J7CE0.book Page 2 Thursday, November 26, 2020 1:37 PM

7-3
7
TIPFor maximum engine life, never accelerate
hard when the engine is cold! EBU35413Shift lever operation and reverse driv-
ingThis vehicle has a 5-speed forward and 1-
speed reverse transmission. The transmis-
sion allows you to control the amount of pow-
er you have available at a given speed or for
starting, accelerating, climbing hills, etc.
To shift into neutral, release the accelerator
pedal, apply the clutch, and then repeatedly
move the shift lever forward until it stops.
When it stops, it will be in first gear. Move the
shift lever rearward slightly to reach the neu-
tral position, and then release the clutch.
NOTICEECB03040 Even with the transmission in the neutral
position, do not coast for long periods of
time with the engine off. The transmis-
sion is properly lubri cated only when the
engine is running. Inadequate lubrication
may damage the transmission.1. Shift lever
2. Neutral position
1
2
R 1
N 2
3
4
5
UB5J7CE0.book Page 3 Thursday, November 26, 2020 1:37 PM

7-4
7
Always use the clutch when changing
gears. The engine and drivetrain are not
designed to withstand the shock of
forced shifting and can be damaged by
shifting without using the clutch. To start out and accelerate
1. Take your foot off the accelerator pedal,
apply the brake, and then release the
parking brake if applied. NOTICE: Al-
ways take your foot off the accelerator
pedal before shifting gears, otherwise
damage to the engine and drivetrain
may result.
[ECB02930]
2. Press the clutch pedal to disengage the
clutch.
3. Shift into first gear by moving the shift le-
ver forward. (The transmission gear dis-
play will show “1” when the transmission
gears have properly engaged.)
4. Release the brake pedal. 5. Press the accelerator pedal gradually and
at the same time, release the clutch pedal
slowly.
6. Once the vehicle has attained adequate speed, release the accelerator pedal, and
at the same time, quickly press the clutch
pedal.
7. Shift the transmission into second gear.
(Make sure not to shift the transmission
into neutral.)
8. Press the accelerator pedal gradually and
release the clutch pedal slowly.
9. Follow the same procedure when shifting to the next higher gear.
To decelerate
When slowing down or stopping, release the
accelerator pedal and press the brake pedal
smoothly and evenly. As you slow down, shift
to a lower gear. Be sure that the engine has
sufficiently slowed before engaging a lower
gear. Improper use of the brake or shifting
UB5J7CE0.book Page 4 Thursday, November 26, 2020 1:37 PM

7-5
7
can cause the tires to lose traction, reducing
control and increasing the possibility of an ac-
cident.
WARNING
EWB00712Make sure the engine has sufficiently
slowed before shifting to a lower gear. En-
gaging a lower gear when the engine
speed is too high could make the wheels
stop rotating and lose traction. This could
cause loss of control, an accident and inju-
ry. It could also cause engine or drivetrain
damage. Recommended shift points
The recommended shift points during accel-
eration and deceleration are shown in the ta-
ble below.To drive in reverse
WARNING
EWB03300Before you shift into reverse, make sure
there are no obstacles or people behind
you. When it is safe to proceed, go slowly.
Hitting an obstacle or
person could result
in serious inju ry or death. 1. Stop the vehicle and continue to apply
the brake pedal.
2. Check behind you.
3. Press the clutch pedal, and pull the re- verse gear lock lever.
4. Shift the transmission into reverse.Shift up points: 1st → 2nd: 19 km/h (12 mi/h)
2nd → 3rd: 33 km/h (21 mi/h)
3rd → 4th: 44 km/h (27 mi/h)
4th → 5th: 53 km/h (33 mi/h)
Shift down points: 5th → 4th: 30 km/h (19 mi/h)
4th → 3rd: 17 km/h (11 mi/h)
UB5J7CE0.book Page 5 Thursday, November 26, 2020 1:37 PM
