5 - 62
CHASREAR SHOCK ABSORBER
EC5852B0
Rear shock absorber
1. Install:
lDust seal 1
lO-ring 2
lCollar 3
NOTE:
lApply the molybdenum disulfide grease on
the bearings.
lApply the lithium soap base grease on the
dust seals, O-rings and collars.
2. Install:
lRear shock absorber
3. Install:
lBolt (rear shock absorber-frame) 1
lNut (rear shock absorber-frame) 2
NOTE:
Apply the molybdenum disulfide grease on the
bolt.
4. Install:
lPlain washer 1
lBolt (rear shock absorber-relay arm) 2
NOTE:
lApply the molybdenum disulfide grease on
the bolt.
lInsert the bolt from right side.
New
T R..56 Nm (5.6 m · kg, 40 ft · lb)
T R..53 Nm (5.3 m · kg, 38 ft · lb)
5. Install:
lRear frame 1
lBolt (rear frame) 2
lBolt (reservoir tank) 3
T R..26 Nm (2.6 m · kg, 19 ft · lb)
T R..10 Nm (1.0 m · kg, 7.2 ft · lb)
6. Tighten:
lScrew (air cleaner joint) 1
