YAMAHA YZ450F 2016  Owners Manual FUEL INJECTION SYSTEM
8-19
Fault code 16
SymptomThrottle position sensor: stuck throttle position sensor is de-
tected.
Fail-safe systemAble to start engine
Able to drive vehicle
Diagnostic code No.01

Page 312 of 362

YAMAHA YZ450F 2016  Owners Manual FUEL INJECTION SYSTEM
8-20
TIP
Make sure that the machine is completely cold before checking the coolant temperature sensor.
Fault code 21
Symptom Coolant temperature sensor: open or short circuit det

Page 313 of 362

YAMAHA YZ450F 2016  Owners Manual FUEL INJECTION SYSTEM
8-21
TIP
Make sure that the machine is completely cold before checking the intake air temperature sensor. 6 Faulty ECU Replace the ECU.
Fault code 22
Symptom Intake air temperatu

Page 314 of 362

YAMAHA YZ450F 2016  Owners Manual FUEL INJECTION SYSTEM
8-22
5 Defective intake air tempera-
ture sensor.Execute the diagnostic mode.
(Code No. 05)
When the machine is cold,
displayed temperature is
close to the ambient temper-
atu

Page 315 of 362

YAMAHA YZ450F 2016  Owners Manual FUEL INJECTION SYSTEM
8-23
Fault code 33
SymptomIgnition coil: open or short circuit detected in the primary lead
of the ignition coil.
Fail-safe systemUnable to start engine
Unable to drive vehicle

Page 316 of 362

YAMAHA YZ450F 2016  Owners Manual FUEL INJECTION SYSTEM
8-24
TIP
Disconnect the fuel pump coupler when this diagnostic tool is used. 6 Faulty  ECU Execute the diagnostic mode.
(Code No. 30)
No spark  Replace the
ECU.
Fault code 3

Page 317 of 362

YAMAHA YZ450F 2016  Owners Manual FUEL INJECTION SYSTEM
8-25
4 Connection of sub wire har-
ness coupler.
Check the locking condition
of the coupler.
Disconnect the coupler, and
check the pins (for bent or
broken terminals and locki

Page 318 of 362

YAMAHA YZ450F 2016  Owners Manual FUEL INJECTION SYSTEM
8-26
Fault code 44
SymptomEEPROM fault code No.: an error is detected while reading or
writing on EEPROM.
Fail-safe systemAble/Unable to start engine
Able/Unable to drive vehicl

Page 319 of 362

YAMAHA YZ450F 2016  Owners Manual FUEL INJECTION SYSTEM
8-27
Fault code 46
SymptomVehicle system power supply: normal voltage is not supplied
to the ECU.
Fail-safe systemAble/Unable to start engine
Able/Unable to drive vehicle
Diagno

Page 320 of 362

YAMAHA YZ450F 2016  Owners Manual FUEL INJECTION SYSTEM
8-28
Fault code 50
Symptom ECU: faulty ECU memory
Fail-safe systemUnable to start engine
Unable to drive vehicle
Diagnostic code No.—
Diagnostic tool display—
Procedure—
Or
