YAMAHA YZF-R1 2001 User Guide

DESCRIPTION
2
Left view ............................................................................................. 2-1
Right view ........................................................................................... 2-2
Controls and instruments ................................................................... 2-3
E_5jj.book Page 1 Friday, September 8, 2000 3:33 PM

2-1
2
2-DESCRIPTION
EAU00026
Left view1. Front fork compression damping force adjusting screw (page 3-17)
2. Front fork rebound damping force adjusting screw (page 3-17)
3. Front fork spring preload adjusting bolt (page 3-16)
4. Air filter element (page 6-15)
5. Shift pedal (page 3-10)
6. Shock absorber compression damping force adjusting screw (page 3-19)
7. Passenger seat lock (page 3-14)
8. Shock absorber rebound damping force adjusting screw (page 3-19)
9. Luggage strap holders (page 3-22)
10. Helmet holders (page 3-15)
E_5jj.book Page 1 Friday, September 8, 2000 3:33 PM

DESCRIPTION
2-2
2
Right view11. Owner’s tool kit (page 6-1)
12. Fuses (page 6-34)
13. Rear brake fluid reservoir (page 6-26)
14. Battery (page 6-33)
15. Shock absorber spring preload
adjusting ring (page 3-18)16. Radiator and coolant reservoir (page 6-12)
17. Front brake fluid reservoir (page 6-25)
18. Engine oil filter cartridge (page 6-9)
19. Engine oil level check window (page 6-9)
20. Brake pedal (page 3-11)
E_5jj.book Page 2 Friday, September 8, 2000 3:33 PM

DESCRIPTION
2-3
2
Controls and instruments1. Clutch lever (page 3-10)
2. Left handlebar switches (page 3-9)
3. Starter (choke) lever (page 3-13)
4. Speedometer unit (page 3-6)
5. Main switch/steering lock (page 3-1)6. Tachometer (page 3-7)
7. Right handlebar switches (page 3-9)
8. Throttle grip (page 6-18)
9. Brake lever (page 3-11)
E_5jj.book Page 3 Friday, September 8, 2000 3:33 PM

3
INSTRUMENT AND CONTROL FUNCTIONS
Main switch/steering lock ...................................... 3-1
Indicator and warning lights ................................ 3-2
Speedometer unit ................................................ 3-6
Tachometer ........................................................... 3-7
Self-diagnosis devices ......................................... 3-7
Anti-theft alarm (optional) ..................................... 3-8
Handlebar switches .............................................. 3-9
Clutch lever ......................................................... 3-10
Shift pedal ........................................................... 3-10
Brake lever .......................................................... 3-11
Brake pedal......................................................... 3-11
Fuel tank cap ..................................................... 3-11
Fuel..................................................................... 3-12Fuel tank breather hose ..................................... 3-13
Starter (choke) lever........................................... 3-13
Seats .................................................................. 3-14
Helmet holders .................................................. 3-15
Storage compartment ........................................ 3-16
Adjusting the front fork ...................................... 3-16
Adjusting the shock absorber assembly ............ 3-18
Matching the front and rear suspension
settings ............................................................ 3-21
Luggage strap holders ...................................... 3-22
EXUP system ..................................................... 3-22
Sidestand ........................................................... 3-23
Ignition circuit cut-off system.............................. 3-23
E_5jj.book Page 1 Friday, September 8, 2000 3:33 PM

3-1
3
EAU00027
3-INSTRUMENT AND CONTROL FUNCTIONS
EAU00029
Main switch/steering lockThe main switch/steering lock controls
the ignition and lighting systems, and is
used to lock the steering. The various
positions are described below.
EAU00036
ON
All electrical systems are supplied with
power, and the engine can be started.
The key cannot be removed.
EAU00038
OFF
All electrical systems are off. The key
can be removed.
EAU00040
LOCK
The steering is locked, and all electrical
systems are off. The key can be
removed.
To lock the steering1. Turn the handlebars all the way to
the left.
2. Push the key in from the “OFF” po-
sition, and then turn it to “LOCK”
while still pushing it.
3. Remove the key.
To unlock the steeringPush the key in, and then turn it to
“OFF” while still pushing it.
EW000016
WARNING
@ Never turn the key to “OFF” or
“LOCK” while the motorcycle is
moving, otherwise the electrical
systems will be switched off, which
may result in loss of control or an
accident. Make sure that the motor-
cycle is stopped before turning the
key to “OFF” or “LOCK”. @1. Push.
2. Turn.
E_5jj.book Page 1 Friday, September 8, 2000 3:33 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-2
3
EAU01574
(Parking)
The steering is locked, and the taillights
and auxiliary lights are on, but all other
electrical systems are off. The key can
be removed.
The steering must be locked before the
key can be turned to “ ”.
ECA00043
CAUTION:@ Do not use the parking position for
an extended length of time, other-
wise the battery may discharge. @
EAU03034
Indicator and warning lights
EAU00061
Neutral indicator light “ ”
This indicator light comes on when the
transmission is in the neutral position.
EAU00063
High beam indicator light “ ”
This indicator light comes on when the
high beam of the headlight is switched
on.
EAU00057
Turn signal indicator light “ ”
This indicator light flashes when the
turn signal switch is pushed to the left
or right.
EAU03284
Fuel level warning light “ ”
This warning light comes on when the
fuel level drops below approximately
3.8 L. When this occurs, refuel as soon
as possible.
The electrical circuit of the warning light
can be checked according to the fol-
lowing procedure.
1. Turn the key to “ON”.
2. If the warning light does not come
on, have a Yamaha dealer check
the electrical circuit.NOTE:@ This model is equipped with a self-di-
agnosis device for the fuel level warn-
ing light circuit. (See page 3-7 for an
explanation of the self-diagnosis
device.) @
1. Neutral indicator light “ ”
2. High beam indicator light “ ”
3. Turn signal indicator light “ ”
4. Fuel level warning light “ ”
5. Oil level warning light “ ”
E_5jj.book Page 2 Friday, September 8, 2000 3:33 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-3
3
EAU03285
Oil level warning light “ ”
This warning light comes on when the
engine oil level is low.
The electrical circuit of the warning light
can be checked according to the fol-
lowing procedure.
1. Turn the key to “ON”.
2. If the warning light does not come
on, have a Yamaha dealer check
the electrical circuit.
NOTE:@ Even if the oil level is sufficient, the warn-
ing light may flicker when riding on a
slope or during sudden acceleration or
deceleration, but this is not a malfunction. @
EAU03205
Coolant temperature warning light
“”
This warning light comes on when the
engine overheats. When this occurs,
stop the engine immediately and allow
the engine to cool.
The electrical circuit of the warning light
can be checked according to the fol-
lowing procedure.
1. Turn the key to “ON”.
2. If the warning light does not come
on, have a Yamaha dealer check
the electrical circuit.
1. Neutral indicator light “ ”
2. High beam indicator light “ ”
3. Turn signal indicator light “ ”
4. Fuel level warning light “ ”
5. Oil level warning light “ ”
1. Coolant temperature gauge
2. Coolant temperature warning light “ ”
E_5jj.book Page 3 Friday, September 8, 2000 3:33 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-4
3
EC000002
CAUTION:@ Do not operate the engine if it is
overheated. @
E_5jj.book Page 4 Friday, September 8, 2000 3:33 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-5
3
CB-25E
Coolant
temperatureDisplay Conditions What to do0–39°C Message “LO” is
displayed.OK. Go ahead with riding.
40–116°CTemperature is
displayed.OK. Go ahead with riding.
117–139°CTemperature flashes.
Warning light comes on.Stop the motorcycle and allow it to
idle until the coolant temperature
goes down.
If the temperature does not go
down, stop the engine. (See the
“Engine overheating” section on
page 6-44 for further instructions.)
Above 140°CMessage “HI” flashes.
Warning light comes on.Stop the engine and allow it to cool.
(See the “Engine overheating” sec-
tion on page 6-44 for further in-
structions.)
E_5jj.book Page 5 Friday, September 8, 2000 3:33 PM
