navigation system ACURA CSX 2006 Service Repair Manual

´´
´µ
Î
Î Î

´
Black Raster
Touch Panel Check 1Touch Panel Calibration
23-303
Black RasterReturn
Return
Return
SetX:0 Y:0
X:227 Y:111
X:479 Y:2331
2
3 4
5
Please press the center of’’ ’’button.
This diagnostic screen checks for pixels that may be
stuck on. The entire display must be black. If pixels are
stuck on, replace the navigation unit.
The panel touch sensing system consists of a touch
sensitive resistive membrane covering the display.
Contrary to other systems using infrared beams, the
screen has to be physically touched to make it work.
The display has the capability of 479 touch locations
(left to right), and 233 touch locations (top to bottom).
The upper left hand corner is position (0, 0) and the
lower right hand corner is (479, 233) as displayed.
Touching anywhere on the screen displays the
coordinate of the location, and a icon appears where
you touched the screen. If any area of the screen either
doesn’t respond, or responds at some other location
when touched, then replace the navigation unit.
NOTE: Unlike earlier screens that used infrared sensors,
direct sunlight does not affect this test. The display screen uses a touch sensitive membrane.
This means that every location of the entire surface of
the display is touch sensitive. This diagnostic allows
alignment of these touch locations with the location of
the buttons images on the screen.
Normally this should n
ever need adjustment, and is
used only to adjust the touch locations for parallax (the
touch locations appear different when viewed at an
angle). However, if an adjustment is necessary, follow
this procedure:
 The screen consists of the button icons. Touch the center of the five buttons on order 1 5.
 To store any change you make, touch the Set button.
 Use the Return key to exit the diagnostic.
(cont’d)
08/08/21 14:16:40 61SNR030_230_0306
ProCarManuals.com
DYNOMITE -2009-

Î

Î

Î
Î

Color Pattern
White Raster
Monitor Adjustment Touch Panel Check 2
23-304Navigation System
System Diagnostic Mode (cont’d)
Color Pattern
Return
Monitor Adjuntment
White RasterReturn
Return Tuning
Default
(0,0)
Default (0,0)
Setting
H-POS Return
The chart below shows the colors being used for the
map and menu screens. This is for factory use only. To
check the color signal use the RGB Color diagnostic
found under the Monitor Check.
This diagnostic screen checks for pixels that may be
dead (off). The entire display must be white. If there are
dead pixels, replace the navigation unit.
This allows you to center the navigation display. Use
the joystick to move the picture up/down or left/right. It
is unlikely that you will ever need to adjust the monitor
position. The Default button resets the display position
to factory specifications. The factory default is 0, 0 The
H-POS button is for factory use only.
If you touch the any icons on the screen, the icon
changes the color while pressing the icon. If any icons
of the screen doesn’t respond, replace the navigation
unit.
08/08/21 14:16:40 61SNR030_230_0307
ProCarManuals.com
DYNOMITE -2009-

Î
Î

GPS ECU Info.
23-306 Navigation System
System Diagnostic Mode (cont’d)
Return
Information
D-RAMCheckMem Clear
(2007.08.31 15:31:28)
Antenna OK
OK
GPS
ECU Info.Return
Receiver in Navi ECU
V-RAM OK
DVD Lid Close
Program Flash
1.64.00
Program on DVD 1.64.0000
DVD Version 4.62
Serial No. xxxxxxxxxx
Model SNRX D-RAM OK
If GPS indicates NG (ANT), then check the entire GPS
antenna wire from the navigation unit to the GPS
antenna. If the wire is crushed or damaged, try a
known-good antenna. If the diagnostic reads OK,
replace the original GPS antenna. If the diagnostic still
reads NG (ANT), replace the navigation unit.
Select information to see the GPS satellite details.
This screen looks for problems in the navigation unit.
When you initiate this diagnosis, the navigation unit
may freeze or delay up to a minute while the diagnosis
runs.
NOTE: Do not try to end this diagnostic by pressing OK
or Mem clear before it finishes, otherwise the system
may reboot.
 If V-RAM or D-RAM is NG, replace the navigation unit.
 DVD lid displays the state of DVD Lid of navigation unit.
 Program Flash: Displays the version of the navi software in memory.
 Program on DVD: If displayed, this value represents the version of the navigation software on the navi
DVD.
 DVD version represents the database version on the DVD. You can find this information in either the Setup
Screen Version, or in the Diagnostic Screen Version.
 Serial No. should be the same as the serial number found on the underside of the navigation unit. You
need this number to obtain the security code from the
Interactive Network (iN) system.
 The Mem Clr is for factory use and should not be used unless instructed by the factory.
Selecting this will clear the customer’s settings,
personal information, GPS orbital data, and anything
else stored in memory.
08/08/21 14:16:41 61SNR030_230_0309
ProCarManuals.com
DYNOMITE -2009-

´µ ´µ
Î
Î Î
Î
Î
´
µ
´
µ
´µ
Hard Key
Yaw Sensor DVD
Aircon
HFL
23-308Navigation System
System Diagnostic Mode (cont’d)
Hard KeyReturn
Return
ZOOM OUT ZOOM IN
CANCEL SET UP MAP
MENU INFO
MODE CH
CH
VOL
VOL
FF
REW
RPT RDM
SEEK UP SCAN
AUDIO
CD/AUX
AM/FMSKIP
SKIP
SEEK DOWN Keep Pushing to Return.
Yaw Sensor
Zero Point Output OK OK
Output Value x.xxxV
Current Offset x.xxxV
Temperature in ECU xx°C
Return
Return
ReturnDVD
Error Detail -
Version 20050404
Maker ID 0x01
Navi Platform 0x01
Connection OK Aircon
HFL
Connection OK
This diagnostic screen checks the status of each of the
hard buttons surrounding the navigation display. When
you press each hard button, the corresponding item on
the screen should flash blue. Touch the return key, or
press and hold the joystick to exit.
NOTE: It is normal for the VOL ( , ) CH ( , ) and
MODEbuttontobeinactive.
This screen gives a quick test of the yaw sensor
functionality based on the two voltages Sensor and
Offset. For more information see the Yaw Rate
Diagnostic. This diagnostic tests the navigation DVD reader.
This diagnostic tests the climate bus connection (AC-SI
and AC-SO) between the navigation unit and climate
control unit. Make sure the engine is running for this
test.
 This checks the 4 wire communication bus between the HFL and the navigation.
 When connection is shown with NG, check the connection between the navigation unit and the
HandsFreeLink control unit.
08/08/21 14:16:42 61SNR030_230_0311
ProCarManuals.com
DYNOMITE -2009-

ÎÎ
Î


Save Users Memory
23-310Navigation System
System Diagnostic Mode (cont’d)
Return
EXPORT
IMPORT
Save Users Memory
Return
Yes No
Return
Yes NoSave Users Memory Export User Data
Save Users Memory Import User Data
When replacing the navigation unit, this function allows
the dealer to transfer the client’s personal data to the
new navigation unit. The transferred information
includes their Setup settings, and personal addresses.
The dealer inserts a PC card to the navigation unit, and
then selects the Save Users Memory function. The two
functions in this diagnostic screen are EXPORT and
IMPORT. EXPORT saves the client’s data to the PC card,
andIMPORTmovesthePCcardfilestothenew
navigation unit.
Before starting this function, see the PC Card FAQs for
information regarding PC cards, and how to use this
function. 1. Select EXPORT button to move the client’s data
from the original navigation unit to the PC card.
Select YES on the Export User Data Confirmation
screen. The process takes only a couple of seconds.
The system stores two files on the card.
NOTE: If the EXPORT button is grayed out, check
the PC card’s edge connector, and the pins inside
the navigation unit (with a flashlight) for damage.
2. After installing the client’s original DVD in the new navigation unit, allow the system to boot up. Insert
the PC card in the new navigation unit and enter the
Save Users Memory in the navigation system
diagnostic mode.
3. Select IMPORT button to move the two files stored by the Export process from the PC card to the new
navigation unit. Select YES on the Import User Data
Confirmation screen. When the transfer is finished
(a few seconds) the system automatically reboots.
After the system reboots, remove the PC card from
the PC slot.
NOTE: If the IMPORT button is grayed out, check if
the Model and the Program Flash shown on the
Version screen are the same.
08/08/21 14:16:43 61SNR030_230_0313
ProCarManuals.com
DYNOMITE -2009-

ÎÎ
Demo ModeMic Level
23-311
ReturnDemo Mode
OFF
Demo
Speed Rate 150 ms ON OFF
Mic LevelReturn
Mic Level
Steering Switch
This screen is for factory use only, and should always
be set to OFF. Occasionally the DEMO setting is turned
ON when vehicles are being used at Auto Shows or
similar events. Turning this feature on, allows the
navigation system to automatically follow a route to a
destination when the vehicle is stationary. The Speed
changes the speed of the demo mode. This diagnostic allows you to independently test the
microphone and the navigation TALK and BACK
buttons. They are used to activate the voice control
system. The microphone is located near the map light
in the roof console. It is directional, and works only with
the voice coming from the driver’s seat.
 Press the navigation TALK button on the steering wheel, wait unit you hear a beep, and in a normal
voice say ‘‘testing’’. The TALK indicator on the screen
should momentarily turn green, and the text Now
Recording... should appear in yellow. If the talk
indicator shown on the screen does not briefly turn
green, check the wiring from the steering wheel
navigation TALK button to the navigation unit. If there
is no Mic Level movement when you speak, then you
should check the wires running from the microphone
in the roof console to the HandsFreeLink control unit
and the navigation unit. If the wires are OK, the
microphone must be faulty; replace the microphone
located in roof console (see page 23-358).
 PressthenavigationBACKbuttononthesteering wheel. This should cause the Cancel indicator on the
screen to momentarily turn green. If it does not
briefly turn green, check the wiring from the steering
wheel navigation BACK button to the navigation unit.
(cont’d)
08/08/21 14:16:43 61SNR030_230_0314
ProCarManuals.com
DYNOMITE -2009-

Î
¡
¡
GPS Information
23-312 Navigation System
System Diagnostic Mode (cont’d)
ReturnGPS Information
Number of Satellites
Current Position Latitude
Elevation Longitude
xxxx.xx.xx xx:xx:xx N xx°xx’xx
Exxx°xx’xx
xx feet
In Use
Search
This screen shows the current status of GPS reception.
The circular diagram shows the current location of the
GPS satellites (yellow numbers) as they would appear
in the sky. The outer circle represents the horizon
(0 degrees elevation). The middle and inner circles
represents 30 and 60 degrees respectively. The very
center of the diagram (90 degrees elevation) is directly
overhead. Nearby obstructions, like tall buildings will
block satellites in that direction. That is why it is
necessary to be in an open area to effectively
troubleshoot GPS reception issues. The sate llite
numbers shown on the diagram correspond to the PRN
number in the GPS Details screen. There are always at
least 24 active GPS satellites in orbit. Because satellites
fail, and have to be removed from service, spares are
always parked in orbit, ready to be activated. This is
why the PRN (satellite ID number) can be greater than
24.
NOTE: When you use this screen for troubleshooting,
park the vehicle outside, away from buildings, tall trees,
and high-tension wires for at least 10 minutes with the
engine running.  The Number of Satellites box shows the number of
acquired satellites (maximum of 12). It should contain
three or more icons. If not troubleshoot for GPS icon
is white or not shown (see page 23-341).
 The Current Position shows latitude, longitude, and elevation (in feet). If there are less than four satellites,
the elevation can be grossly inaccurate.
 The Date/Time field shows the current date, and also a time that includes daylight savings and other
offsets entered by the customer in Setup screen 2
Adjust Time Zone/Clock.
NOTE: Pressing the map/guide button displays the
satellite number on each circle.
08/08/21 14:16:43 61SNR030_230_0315
ProCarManuals.com
DYNOMITE -2009-

´µµ Î
Yaw Rate
Example: Vehicle stopped
Normal Abnormal
Example: Vehicle turning
Normal Abnormal
23-314Navigation System
System Diagnostic Mode (cont’d)
ReturnYaw Rate
Sensor Offset
CCW Factor
CW Factor x.xxxV
x.xxxV
x.x%
x.x% Tuning
This diagnostic checks the yaw rate sensor in the
navigation unit. This device detects when the vehicle
turns, and repositions the vehicle position icon on the
map screen. For more detailed information, see the yaw
rate sensor theory of operation under System
Description (see page 23-283).
 Sensor indicates the voltage output from the yaw rate sensor. It should indicate about 2.500 V when the
vehicle is stopped.
 Offset is the reference voltage or standard within the yaw rate sensor. It also should indicate about 2.500 V
when the vehicle is stopped.
 A sensor output voltage LOWER than the Offset voltage indicates that the vehicle is turning to the
right.
A sensor output voltage HIGHER than the Offset
voltage indicates that the vehicle is turning to the left.
 The yaw rate offset, and sensor should both indicate about 2.500 V when the vehicle is stopped. If either
reads zero, or 5.000 V, replace the navigation unit.
 The yaw rate offset and sensor should be within / 0.01 V of each other when the vehicle is stopped.
The sensor value should change relative to the offset
as the vehicle turns while driving. If not, replace the
navigation unit.
Offset 2.526 V Offset 2.526 V
Sensor 2.516 2.536 V Sensor 2.623 V
Offset 2.526 V Offset 2.526 V
Sensor 2.678 V (left turn)
2.478 V
(right turn) Sensor 2.623 V
(no change on
turns)  Sensitivity study represents the status of the internal
tuning function. At initialization, this value starts at 6
and increases to 10 as the internal correction values
become more accurate.
 The settings CCW Cal Factor, CW Cal Factor, and Set are for factory use only. THIS SHOULD NEVER BE
ADJUSTED.
 For detailed analysis of the yaw rate select tuning.
08/08/21 14:16:44 61SNR030_230_0317
ProCarManuals.com
DYNOMITE -2009-

Î
µ
µ
Version
23-316 Navigation System
System Diagnostic Mode (cont’d)
Return
DownLoad
Program Flash x.xx.xxKA
Program Disc IPL x.xxx.xxx
APL
DBOOT x.x.xxx
System uCom x.xxx
Model SNRX Version
 ILL-Illumination Indication
(Connector A (24P) terminal No. 13)
a) OFF (0) when parking lights, or headlights are off
b) ON (1) when parking lights, or headlights are on
The navigation uses the signal to determine whether to
put the navigation screen into the Day or Night
brightness mode. (Setup screen 1) ILLCANCEL a) OFF (0) when the dash lights brightness control
button is less than 90 % brightness with the
headlights turned on.
b) ON (1) when the dash lights brightness control
button is more than 90 % brightness with the
headlights turned on. This screen displays the current version information for
the navigation system software. In addition, this screen
allows the loading of updated software if requested by
the factory, or instructed by a Service Bulletin. Software
may be loaded from a CD or a PC card.
 Program Flash: Displays the version of the navigation software in memory.
 Program Disc: If displayed, this value represents the version of the navi software on the navi DVD.
NOTE: The last two letters of the Program Flash or
DVD fields indicate which DVD is installed in the unit.
 IPL, APL, DBOOT, and System uCom, are all for factory use.
 Model: For this model, the field should begin with SNR
 Download: Do not touch, unless instructed by the factory.
Check any official Acura service website for more
service information about navigation DVDs.
08/08/21 14:16:45 61SNR030_230_0319
ProCarManuals.com
DYNOMITE -2009-

PC Card FAQs
QuestionAnswer
23-317
Wheredowebuytheflashmemoryor
adaptors, and what do we ask for?You need a PCMCIA type II adaptor and a flash memory chip. You can
purchase them at a computer, or office supply store. The card is the
same size and shape as the PC card in the HDS. Adaptors that accept
multiple flash types are not recommended.
What memory flash chips will work
with what adaptors? The flash memory devices that have been tested include Compact Flash
(CF), and ATA style (like the card in the HDS). Other card types and flash
memory chips may work, but have not been tested.
What capacity card do I need for this
function? A memory chip with capacity of 64 MB to 2 GB will work. The two files
moved to the PC card during export are less than a Megabyte in size.
Should the dealer have a dedicated PC
card for the Export and Import
navigation function? Yes, treat the PC card as a dedicated special tool that you can use any
time you need to transfer the navigation personal files to a new
navigation unit or ’09 and later vehicles.
What device can I use to maintain the
PC card, and delete files? Any computer store sells USB style card readers that accept the PC card,
and allow you to do file maintenance on your PC card. Most laptops will
also accept the PC card.
Can we move the client’s data to
different models? No, the files are model specific and will only load into a navigation unit
with the same part number.
Can we move the client’s data to the
same vehicle with a different software
version (like moving from version 4.41
to version 4.51)? The client’s files can only be transferred to a new navigation unit, if the
Model and the Program Flash shown on the Version screen are the same.
Files cannot be transferred to the different model and different versions.
Will other files on the PC card like
images or music files prevent the
Export/Import function from working? No, the system simply adds two small files that are recognized by the
new navigation unit when performing the import function. However, it
the PC card is full, the Export function won’t work correctly.
Do I have to delete the files on the PC
card after each transfer of the
personal data? After the transfer of personal data to the new navigation unit, the files
remain on the PC card. Since this is confidential information, Acura
recommends deleting these files after the transfer use. Please note that
each time you export navigation files of the same model and version, the
files are overwritten. Over time the PC card accumulates two files for
each version of the 8 or so Acura navigation models.
It the memory card needs formatting,
what format should I use? It is unlikely that the PC card will ever need formatting, however, if it
does, use the FAT (file allocation table) file system.
I can’t enter the navigation diagnostic
mode to do the Export/Import function.
How can I transfer the personal data? Some internal navigation unit ECU failures may make it impossible to
use the Export/Import function.
(cont’d)
08/08/21 14:16:45 61SNR030_230_0320
ProCarManuals.com
DYNOMITE -2009-
