sensor ACURA CSX 2006 Service Repair Manual

Climate Control UnitDTC Description DTC typePage
HandsFreeLink Control Unit DTC Description DTC typePage
Immobilizer-Keyless Control Unit DTC Description DTC typePage
22-79
B1200 Communication bus line error (BUS-OFF) Loss of
communication (see page 22-107)
B1202 Climate control unit internal error ( EEPROM error)Internal error (see page 21-28)
B1205 Climate control unit lost communication with the gauge control module (VSP/NE message) Loss of
communication(see page 21-28)
B1206 Climate control unit lost communication with the gauge control module (ECT message) Loss of
communication(see page 21-28)
B1207 Climate control unit lost communication with the gauge control module (ILLUMI message) Loss of
communication(see page 21-28)
B1220 Recirculation control motor circuit short Signal error (see page 21-29)
B1225 In-car temperature sensor circuit open Signal error (see page 21-31)
B1226 In-car temperature sensor circuit short Signal error (see page 21-32)
B1227 Outside air temperature sensor circuit open Signal error (see page 21-33)
B1228 Outside air temperature sensor circuit short Signal error (see page 21-34)
B1229 Sunlight sensor circuit open Signal error (see page 21-35)
B1230 Sunlight sensor circuit short Signal error (see page 21-36)
B1231 Evaporator temperature sensor circuit open Signal error (see page 21-37)
B1232 Evaporator temperature sensor circuit short Signal error (see page 21-39)
B1233 Air mix control motor circuit open Signal error (see page 21-40)
B1234 Air mix control motor circuit short Signal error (see page 21-41)
B1235 Air mix control motor stuck Signal error (see page 21-42)
B1239 Mode control motor circuit open or short Signal error (see page 21-44)
B1240 Mode control motor, linkage, door malfunctionSignal error (see page 21-46)
B1241 Blower motor circuit malfunction Signal error (see page 21-47)
B2983 Recirculation control motor, linkage, door malfunctionSignal error (see page 21-51)
B2986 Recirculation control motor circuit open Signal error (see page 21-52)
B1750 Communication bus line error (BUS-OFF) Loss of
communication (see page 22-107)
B1775 Microphone input/output short to power/open Signal error (see page 23-376)
B1776 Microphone input/output short to ground/open Signal error (see page 23-377)
B1779 HFL switch (HFL talk/HFL back buttons) circuit open/short Signal error (see page 23-379)
B1780 HFL switch (HFL talk/HFL back buttons) circuit short Signal error (see page 23-381)
B1792 HandsFreeLink control unit internal error Internal error (see page 23-382)
B1900 Communication bus line error (BUS-OFF) Loss of
communication (see page 22-108)
B1905 Immobilizer-keyless control unit lost communication with the MICU (DRLOCKSW message) Loss of
communication(see page 22-317)
B1906 Immobilizer-keyless control unit lost communication with the gauge control module (A/T message) Loss of
communication(see page 22-318)
B1925 Ignition key switch signal error Signal error (see page 22-319)
08/08/21 14:24:08 61SNR030_220_0081
ProCarManuals.com
DYNOMITE -2009-

Î
(#')

µµ
µ
Body Controller Area Network (B-CAN) and Fast Controller Area Network (F-CAN)
22-80 Multiplex Integrated Control System
System Description
GAUGE CONTROL MODULE (TACH)
CAN H CAN L
MICU
ECM/PCM
(F-CAN)
(B-CAN)UNDER-DASH FUSE/RELAY BOX
DATA LINK CONNECTOR
SRS UNIT
ABS MODULATOR-CONTROL UNIT*1
VSA MODULATOR-CONTROL UNIT*2
YAW RATE-LATERAL
ACCELERATION SENSOR*2
EPS CONTROL UNIT
TPMS CONTROL UNIT*3






 F-CAN
TRANSCEIVER
B-CAN
TRANSCEIVER
IMMOBILIZER-
KEYLESS CONTROL
UNITCLIMATE
CONTROL
UNIT
HANDSFREELINK
CONTROL UNIT*4
*1: ’06 07 Touring and Premium models
*2: ’07 TYPE S and ’08 09 models
*3: ’08 09 models
*4: ’09 model with navigation system
The body controller area network (B-CAN) and the fast controller area network (F-CAN) share information between
multiple electronic control units (ECUs). B-CAN communication moves at a slower speed (33.33 kbps) for convenience
related items and for other functions. F-CAN information moves at a faster speed (500 kbps) for ‘‘real time’’ functions
such as fuel and emissions data. To allow both systems to share information, the gauge control module translates
information from B-CAN to F-CAN and from F-CAN to B-CAN.
 The single wire method is used between the units not requiring the communication to move at a fast speed.
 Using a single wire method reduces the number of the wires used on the body controller area network.
08/08/21 14:24:08 61SNR030_220_0082
ProCarManuals.com
DYNOMITE -2009-

Î
Self-diagnostic Function
22-83
GAUGE CONTROL MODULE
CAN H CAN L B-CAN
B-CAN (33.33 kbps)
F-CAN (500 kbps)
SRS UNIT MICU
ECM/PCM
ABS MODULATOR-
CONTROL UNIT* IMMOBILIZER-
KEYLESS
CONTROL UNIT
K-LINE
DATA LINK
CONNECTOR HDS CLIMATE CONTROL
UNIT
TMPS CONTROL
UNIT* EPS CONTROL
UNIT
NAVIGATION
UNIT
VSA MODULATOR-
CONTROL UNIT*
HANDSFREELINK
CONTROL UNIT*
AUDIO UNIT
YAWRATE-LATERAL
ACCELERATION
SENSOR*
*1: ’06-08 Touring and Premium models
*2: ’07 TYPES and ’08-09 models
*3: ’08-09 models
*4: ’09 model with navigation system
1
3 2
4
2
By connecting the HDS to the data link connector (DLC), the HDS can retrieve the diagnostic results from the MICU via
a diagnostic line called K-LINE. The K-LINE is distinguished from the CAN line, and connected to the CAN related ECUs.
The MICU is a gateway between the HDS and B-CAN related ECUs, and sends B-CAN diagnostic results to the HDS.
When doing a function test with the HDS, the HDS sends an output signal through the K-LINE to the MICU. The MICU
either relays the request to another ECU, or commands the function its self.
(cont’d)
08/08/21 14:24:09 61SNR030_220_0085
ProCarManuals.com
DYNOMITE -2009-

Security Alarm System
Key-in Reminder
Key Interlock (A/T)
Answer Back Response Operation
Wiper/Washer
Collision Detection Signal (CDS)
InputOutput
Input Output
Input Output
Input Output
Input Output
Input Output
22-87
The MICU controls the lighting system and horn based upon B-CAN signals and input signals from the each switch.
MICU IG1 power supply Ignition key switch
Audio switch
Driver’s door switch
Front passenger’s door switch
Left rear door switch
Right rear door switch
Trunk lid latch switch
Driver’s door key cylinder switch (UNLOCK)
Driver’s door lock knob switch (UNLOCK)
Front passenger’s door lock knob switch (UNLOCK)
Left rear door lock knob switch (UNLOCK)
Right rear door lock knob switch (UNLOCK)
Hood switch Horn
Headlights
Parking lights
Side marker lights
License plate lights
Taillights
B-CAN Keyless LOCK signal Door lock signal
The MICU controls the door lock actuators based upon ignition key switch, the driver’s door switch, and driver’s door lock knob switch signals. MICU Ignition key switch Driver’s door switch
Driver’s door lock knob switch Door lock actuator (LOCK/UNLOCK)
Driver’s door lock actuator (UNLOCK)
The MICU controls the key interlock solenoid based upon IG1, transmission range switch, and park-pin switch signals. MICU Ignition switch ACC Transmission range switch (P position)
Park-pin switch Key interlock solenoid
The MICU controls the lighting system and horn based upon B-CAN signals. B-CAN Answer back signals (headlight low, horn, parking lights) Horn Headlights
Parking lights
Side marker lights
License plate lights
Taillights
The MICU controls the wiper motor and the washer motor based upon IG1 and wiper/washer switch signals. MICU IG1 power supply Wiperswitch(INTandLO)
Wiper switch (LO and HI)
Wiper switch (MIST)
Washer switch
Wiper intermittent speed Wiper motor
Washer motor
The MICU controls the door lock actuators based upon IG1 and B-CAN signals. MICU IG1 power supply Door lock (LOCK/UNLOCK)
B-CAN SRS signal (front, side and rear) Impact sensors
(cont’d)
08/08/21 14:24:09 61SNR030_220_0089
ProCarManuals.com
DYNOMITE -2009-

Î
µµ
µ
22-101







 124
19
1
RED
WHT CAN L
F-CAN TRANSCEIVER
CAN H
LT GRN
3
G504BLK
5
32
PNK
(B-CAN) (B-CAN) BRN/YELBRNLG
G101 BLK
7 2
IG1
YEL
VBU
B-CAN 1
4
PNK
16
BLK
G504 WHT
21
PNK GAUGE CONTROL MODULE (TACH)
BRN
WHT
17
18
MAIN CIRCUIT
B-CAN
TRANSCEIVER LCD DISPLAY
(DTC CODE DISPLAY)
IMMOBILIZER-KEYLESS
CONTROL UNIT
CLIMATE
CONTROL UNIT
No. 36 (10 A) FUSE
(UNDER-DASH
FUSE/RELAY BOX)
ABS MODULATOR-CONTROL UNIT*1
VSA MODURATOR-CONTROL UNIT*2
YAW RATE-LATERAL ACCELERATION
SENSOR*2
DATA LINK CONNECTOR
SRS UNIT
ECM/PCM
TPMS CONTROL UNIT*3
EPS CONTROL UNIT
WHT
: CAN line
No. 2 (15 A) FUSE
(UNDER-DASH
FUSE/RELAY BOX)
: Other communication line
*1: ’06 07 Touring and Premium models
*2: ’07 TYPE S and ’08 09 models
*3: ’08 09 models
*4: ’09 model with navigation system
*5: With navigation system
*6: Without navigation system
BLK*2
PNK
PNK
08/08/21 14:25:01 61SNR030_220_0103
ProCarManuals.com
DYNOMITE -2009-

(#') (#'

)µ
µ
µ
µ
Doors automatically relock 30, 60, or 90
seconds after being unlocked with the
transmitter even though a door has been
opened
YES
NO
YES
NO
22-13022-130 Keyless/Power Door Locks/Security System
Symptom Troubleshooting (cont’d) Tripped Sensor History
1. Turn the ceiling light switch in DOOR position.
2. Turn the ignition switch to ON (II).
3. Close all doors.
4. Watch the ceiling light and the
door indicator on
the gauge control module.
Go to step 5.
Repair a short to ground in the wire between
the MICU and door switch.
5. Open and close each door one at a time.
6. Watch the ceiling light and the door indicator on
the gauge control module.
Substitute a known-good MICU and recheck.
If the symptom goes away, replace the original
MICU (see page 22-66).
Repair an open in the wire between the MICU
and the door switch. If the wire is OK, faulty the
door switch, replace the door lock actuator
assembly. The security system stores information on the last
tripped sensor if the security system has been violated.
The information can be retrieved using the HDS.
To retrieve the last tripped sensor data:
1. Select HISTORY DATA from the security system test mode menu.
2. Select CURRENT DATA.
3. Confirm that the VIN matches the Vehicle then press the enter button.
4. Scroll through the data list.  Sensors that were violated will indicate DETECT.
 Sensors that were not violated will indicateNONE.
5. Inspect the DETECT circuit for:  Misadjusted or damaged switch.
 Loose or corroded connections.
 Intermittent short to ground.
Do the ceiling light and door indicator go of f ?
Do the ceiling light and door indicator come onw hen t he d oor i s open, and go of f w hen t he d oor i sclosed?
08/08/21 14:26:04 61SNR030_220_0132
ProCarManuals.com
DYNOMITE -2009-

(#') (#'

)µ
µ
µ
µ
Doors automatically relock 30, 60, or 90
seconds after being unlocked with the
transmitter even though a door has been
opened
YES
NO
YES
NO
22-13022-130 Keyless/Power Door Locks/Security System
Symptom Troubleshooting (cont’d) Tripped Sensor History
1. Turn the ceiling light switch in DOOR position.
2. Turn the ignition switch to ON (II).
3. Close all doors.
4. Watch the ceiling light and the
door indicator on
the gauge control module.
Go to step 5.
Repair a short to ground in the wire between
the MICU and door switch.
5. Open and close each door one at a time.
6. Watch the ceiling light and the door indicator on
the gauge control module.
Substitute a known-good MICU and recheck.
If the symptom goes away, replace the original
MICU (see page 22-66).
Repair an open in the wire between the MICU
and the door switch. If the wire is OK, faulty the
door switch, replace the door lock actuator
assembly. The security system stores information on the last
tripped sensor if the security system has been violated.
The information can be retrieved using the HDS.
To retrieve the last tripped sensor data:
1. Select HISTORY DATA from the security system test mode menu.
2. Select CURRENT DATA.
3. Confirm that the VIN matches the Vehicle then press the enter button.
4. Scroll through the data list.  Sensors that were violated will indicate DETECT.
 Sensors that were not violated will indicateNONE.
5. Inspect the DETECT circuit for:  Misadjusted or damaged switch.
 Loose or corroded connections.
 Intermittent short to ground.
Do the ceiling light and door indicator go of f ?
Do the ceiling light and door indicator come onw hen t he d oor i s open, and go of f w hen t he d oor i sclosed?
08/08/21 14:26:04 61SNR030_220_0132
ProCarManuals.com
DYNOMITE -2009-


(#')
Auto Reverse Operation
22-209
System Description
HALL IC UNITMAGNET
POWERWINDOWMASTERSWITCH
(Power window control unit)
Sensor MAGNET IC
IC
N
S
Period of
pulses
Period of
pulses Position when obstacle
is pinched
Threshold value for
judgment of obstacle
Period of
pulses
POWER WINDOW MOTOR Power Window Motor
OBSTACLE
The system is composed of the power window master switch and the driver’s power window motor.
The driver’s power window motor incorporates a Hall IC unit (pulser) which generates pulses during the motor’s
operation and sends the pulses to the driver’s power window control unit. As soon as the power window control unit
detects a change in the pulse frequency from the Hall IC unit, the power window control unit makes the driver’s power
window motor stop and r
everse. If the window is more than halfway closed, it will r everse to half open position. If the
window is less than halfway closed, it will stop and r everse about 50 mm (2 in.). This prevents pinching your hand or
fingers during auto-up operation. The auto reverse operation is not active when the switch is held in the up position.
08/08/21 14:28:38 61SNR030_220_0211
ProCarManuals.com
DYNOMITE -2009-

Î(#'
)
Except TYPE S model
22-244Gauges
Circuit Diagram - Gauge Control Module (Tach)
UART
WHT
IG1 HOT in ON (II) and START (III)
UNDER-HOOD FUSE/RELAY BOX
5V



MAIN CIRCUIT
MAIN CIRCUIT
MICU
  LT GRN
20
21
PNK
124
CAN L
CAN H

 CHIME
BRN
WHT BRN
RED 19
1
WHT No. 2 (IG) (50 A)
GAUGE CONTROL MODULE (TACH) 18 17 TACHOMETER ORN
IG1
BAT
BLU
WHT
No. 23 (10 A)
BATTERY
IGNITION SWITCH
No. 1 (BAT) (100 A)
(7.5 A) No. 10UNDER-DASH
FUSE/RELAY
BOX
GAUGE CONTROL
MODULE (SPEEDO)
DRIVE
CIRCUIT DIMMING
CIRCUIT
PARKING
BRAKE
REMINDER
SEAT
BELT
REMINDER
KEY-IN
REMINDER
F-CAN
TRANSCEIVER B-CAN
TRANSCEIVER
IMMOBILIZER-
KEYLESS
CONTROL UNIT GAUGE
CONTROL
MODULE
(SPEEDO) 10 V
STABILIZING
CIRCUIT
HIGH BEAM
INDICATOR
(LED)
LIGHTS-ON
REMINDER
CLIMATE CONTROL
UNIT
HANDSFREELINK
CONTROL UNIT*3 IMMOBILIZER
INDICATOR
(LED)
ON/OFF
5V
5V
CONTROL
CIRCUIT
H1
D4 G2D2
Q1 P5 P10 Q9
A
ECM/PCM
ABS MODULATOR-
CONTROL UNIT*1
VSA MODULATOR-
CONTROL UNIT*2
YAW RATE-LATERAL
ACCELERATION SENSOR*2
EPS CONTROL UNIT
TPMS CONTROL UNIT*2
DATA LINK CONNECTOR
SRS UNIT







 MICU
08/08/21 14:35:12 61SNR030_220_0246
ProCarManuals.com
DYNOMITE -2009-

Î(#'
)
TYPE S model
22-250Gauges
Circuit Diagram - Gauge Control Module (Tach) (cont’d)
UART
WHT
IG1 HOT in ON (II) and START (III)
UNDER-HOOD FUSE/RELAY BOX









 ECM
VSA MODULATOR-
CONTROL UNIT
YAW RATE-LATERAL
ACCELERATION SENSOR
EPS CONTROL UNIT
TPMS CONTROL UNIT*1
DATA LINK CONNECTOR
SRS UNIT MAIN CIRCUIT
MAIN CIRCUIT
MICU
  GRY
2
21
PNK
124
CAN L
CAN H

 CHIME
BRN
WHT BRN
RED 19
1
WHT No. 2 (IG) (50 A)
GAUGE CONTROL MODULE (TACH) 18 17 TACHOMETER ORN
IG1
BAT
BLU
WHT
No. 23 (10 A)
BATTERY
IGNITION SWITCH
No. 1 (BAT) (100 A)
(7.5 A) No. 10UNDER-DASH
FUSE/RELAY
BOX
GAUGE CONTROL
MODULE (SPEEDO)
DRIVE
CIRCUIT DIMMING
CIRCUIT
PARKING
BRAKE
REMINDER
SEAT
BELT
REMINDER
KEY-IN
REMINDER
F-CAN
TRANSCEIVER B-CAN
TRANSCEIVER
IMMOBILIZER-
KEYLESS
CONTROL UNIT GAUGE
CONTROL
MODULE
(SPEEDO) 10 V
STABILIZING
CIRCUIT
HIGH BEAM
INDICATOR
(LED)
LIGHTS-ON
REMINDER
CLIMATE CONTROL
UNIT
HANDSFREELINK
CONTROL UNIT*2 IMMOBILIZER
INDICATOR
(LED)
H1
D4 G2D2
Q1 P5 P10 Q9
A DRIVER DRIVERMAIN CIRCUIT
MICU
08/08/21 14:35:15 61SNR030_220_0252
ProCarManuals.com
DYNOMITE -2009-
