phone Acura ILX 2013 Navigation Manual

196
XX
Troubleshooting
XGuidance, Routing
Troubleshooting
Guidance, Routing
Problem
Solution
The navigation system does not route me the same
way I would go or the same way as other mapping
systems.
The navigation system attempts to generate the optimal route. You can change the
route preferences used when calculating a route. 2Changing the Route Preference
P. 88
The street I’m on is not shown on the map screen.
The mapping database is constantly undergoing revision. You can access the most
recent information on the internet. 2Map Coverage
P. 211
The vehicle position icon is not following the road and
the “GPS icon” text in the upper left hand corner of
the screen is white or missing.
• Check that the GPS antenna (located in the dashboard) is not blocked. For best
reception, remove items from the dashboard, such as radar detectors, cell phones,
or loose articles.
• Metallic tinting or other aftermarket devices can interfere with the GPS reception.
Please consult a dealer. 2GPS System
P. 208
The blue highlighted route and voice guidance
stopped or turned into a blue/pink dashed line before I
got to my destination.
Your route has entered an unverified area. 2Unverified Area Routing
P. 50
How do I stop the map from rotating as I drive along?
Press the ENTER button to display the Map Menu. Select Map Information > North-
up, or say d “Display north-up” to change the map orientation.
Sometimes, I cannot select between the North-up and
Heading-up map orientations.
The Heading-up map orientation can only be shown in the lower scales (80 m - 1.6 km
scales). 2Map Scale and Functions
P. 108
The “time to destination” display sometimes increases
even though I am getting closer to my destination.
If your speed reduces due to slower traffic, the navigation system updates the “time to
destination” based on your actual road speed to give you a better estimate of arrival
time.
The vehicle position icon on the map “lags” a short
distance behind, especially when I arrive at an
intersection.
This is normal. The navigation system is unaware of the width of intersections. Large
differences in vehicle position can indicate a temporary loss of the GPS signal. 2GPS System
P. 208

208Reference Information
System LimitationsGPS SystemThe signals received from the GPS satellites
are extremely weak (less than a millionth
of the strength of a local FM station) and
require an unobstructed view of the sky.
The GPS antenna is located in the
dashboard. The signal reception can easily
be interrupted or interfered with by the
following:
•Metallic window tint on the front or side
windows
•Cell phones, PDAs, or other electronic
devices docked in a cradle or lying loose
on the dashboard
•Remote starters or “hidden” vehicle
tracking systems mounted near the
navigation unit
•Audio electronic devices mounted near
the navigation unit
•Trees, tall buildings, highway
overpasses, tunnels, or overhead
electrical power wires
The GPS is operated by the U.S.
Department of Defense. For security
reasons, there are certain inaccuracies built
into the GPS for which the navigation
system must constantly compensate. This can cause occasional positioning errors of
up to several hundred feet.
Address CalculationThe destination icon shows only the
approximate location of a destination
address. This occurs if the number of
possible addresses is different from the
number of actual addresses on a block. For
example, the address 1425 on a 1400
block with 100 possible addresses
(because it is followed by the 1500 block)
will be shown a quarter of the way down
the block by the system. If there are only
25 actual addresses on the block, the
actual location of address 1425 would be
at the end of the block.
DatabaseThe digitised map database reflects
conditions as they existed at various points
in time before production. Accordingly,
your database may contain inaccurate or
incomplete data or information due to the
passage of time, road construction,
changing conditions, or other causes.
For example, some places/landmarks may
be missing when you search the database
because the name was misspelled, the
place was improperly categorised, or a
place/landmark is not yet in the database.
This is also true for police stations,
hospitals, and other public institutions. Do
not rely on the navigation system if you
need law enforcement or hospital services.
Always check with local information
sources.

210Reference Information
Client AssistanceResolving ProblemsIf you run into a specific issue that you
cannot resolve, consult the following help
resources:
•For navigation system issues: 2Troubleshooting
P. 194
There are also FAQs available online at
www.acuranavi.ca.
•For questions regarding Bluetooth®
HandsFreeLink®:
2Bluetooth® HandsFreeLink®
P. 162
•For reporting issues with the database
or places/landmarks:
2Reporting Errors
P. 210
•Call Acura Client Relations.
2Acura Client Relations Contact
Information
P. 210
Reporting ErrorsYou can help to improve database
accuracy by reporting any errors you
encounter.
•Report errors in highways and main
“verified” roads shown in black on the
map at http://mapreporter.navteq.com/
dur-web-external/.
•Please do not report errors in purple
“unverified” roads. Maps for these
areas are provided for reference only. 2Unverified Area Routing
P. 50
•Please do not report errors in places/
landmarks, such as changes in business
names. Information about points of
interest are constantly being updated.
An updated database is available for
purchase, usually in the fall of each year.
2Obtaining a Navigation Update Data P. 211
•For vehicle position icon errors, screen
error messages, or other GPS-related
errors: 2Troubleshooting
P. 194
2System Limitations
P. 208
Acura Client Relations Contact InformationAcura Navi
Acura Client Relations
Honda Canada Inc.
Telephone: (888) 9-ACURA-9
8:00 am to 7:30 pm Monday to Friday
(Eastern time)
180 Honda Boulevard Markham, ON
L6C 0H9
E-Mail: [email protected] a DealerIf you have a question that you cannot
resolve using the available help resources,
you can consult a dealer. Please identify
the specific issue (e.g., error occurs when
you enter a specific address, when driving
on a certain road, or just when it’s cold) so
that the service technician can refer the
issue to the factory so that a solution can
be found. Be patient, the service technician
may be unfamiliar with your specific issue.

217
Voice Commands
Voice Commands.................................. 218
Global Commands ............................... 218
Navigation Commands ......................... 218
Climate Control Commands ................. 220
Audio Commands ................................ 221
Cellular Phone Commands ................... 224
Main Setup Screen Commands ............ 224
On-Screen Commands ......................... 225
Spelling Assistance ............................... 225

218Voice Commands
Voice CommandsGlobal CommandsThe system accepts these commands on
any screen.
Help (displays commands for current
screen)
Display map (equivalent to MAP)
Display destination (equivalent to DEST/
ROUTE)
Display information (equivalent to INFO)
Display audio (equivalent to AUDIO)
Display phone (equivalent to PHONE)
Back (returns to previous screen)
Cancel (equivalent to CANCEL)
What is today’s date?
What time is it?
Navigation CommandsThe system accepts these commands on a
map/guidance screen.
Display destination (if en route, displays
the Route screen)
Display navigation (if en route, displays
the Route screen)
Display map
Display map guide (when en route,
shows the next guidance point)
Display information (or Information)
Display audio
Display phone
Cancel
Backward (or Back)
What time is it?
What is today’s date?
Help (reads list of General and Map
Display Commands)■General Commands
Display current location (shows current
latitude, longitude, and elevation)
Display/Hide (specify icon type):
ATM
gas station
restaurant
ZAGAT restaurant
post office
grocery store
lodging (hotel, motel)
parking garage
parking lot
school
hospital
highway exit information
Go home 1
Go home 2■Map Display Commands

223
XX
Voice Commands
XAudio Commands
Voice Commands
iPod play
iPod play track # (#: 1-30)
iPod skip forward
iPod skip back
iPod track shuffle*
iPod album shuffle*
iPod track repeat*
iPod normal play (cancels repeat or
shuffle play mode, resumes normal
play mode)
* These commands toggle the function
on and off, so the command may not
match your intended action.■iPod® Commands
Bluetooth audio play
Bluetooth audio skip forward
Bluetooth audio skip back
Bluetooth audio pause
Bluetooth audio resume
Bluetooth audio group up
Bluetooth audio group down
NOTE:
Bluetooth® Audio commands may not
work on some phones or Bluetooth®
audio devices.
AUX play (or Auxiliary play)■Bluetooth® Audio Commands■AUX Commands
iPod search (activates Song By Voice™)
HDD search (activates Song By Voice™)
List album (specify album)
List artist (specify artist)
List composer (specify composer)
List genre (specify genre)
List playlist (specify playlist)
Play album (specify album)
Play artist (specify artist)
Play composer (specify composer)
Play genre (specify genre)
Play playlist (specify playlist)
Play song (specify song)
What/Who am I listening to?
Who is this?
What’s playing?
Who’s playing?
What album is this?
NOTE:
Song By Voice™ commands are available
for tracks stored on the HDD or iPod®.■Song By Voice™ Commands

224
XX
Voice Commands
XCellular Phone Commands
Voice Commands
Cellular Phone CommandsThe system accepts these commands only
on the Cellular Phone screen.
Redial
Call history
Phone book
Dial
Text message
More speed dial
Phone setup
These commands can be made from any
screen.
Dial/call by number
Dial/call by voice tagThe system accepts these commands on
the Inbox Message screen.
Reply
Call
Send
Full message
Next message
Previous message
Read*
Cancel*
* These commands are accepted when
a text message is received.
■Text Message Commands
Main Setup Screen CommandsThe system accepts these commands on
the Main Setup screen.
Brightness up
Brightness down
Brightness minimum/min.
Brightness maximum/max.
Contrast up
Contrast down
Contrast minimum/min.
Contrast maximum/max.
Black level up
Black level down
Black level minimum/min.
Black level maximum/max.
Volume up
Volume down
Volume minimum/min.
Volume maximum/max.
Volume off
Interface dial feedback off
Interface dial feedback auto
Interface dial feedback on

225
XX
Voice Commands
XOn-Screen Commands
Voice Commands
On-Screen CommandsThe system accepts these commands on
any screen. There are over 100 on-screen
commands. Say what is written on the
screen to activate that selection. For lists,
you can say the list item number to select
that item.
Next (or Down)
Previous (or Up)
Return
OK (excluding Startup Confirmation
screen)
DeleteSpelling AssistanceThe voice control system can also
recognize phonetic alphabet input for
numbers, letters, accented letters,
punctuation marks, and symbols.
NOTE:
When selecting letters using the voice
control system, a confirmation box may
pop up to confirm the entry.
■Numbers
Say … Say … or Number …
1
One
2Two
3
Three
4Four
5
Five
6Six
7
Seven
8 Eight
9
Nine
0 Zero
■Letters
Say … Or say…
A
Apple/Alpha
BBoy/Bravo
C
Charlie
D Dog/Delta
E
Edward/Echo
F Frank/Foxtrot
G
George/Golf
H Henry/Hotel
I
Igloo/India
J John/Juliet
K
King/Kilo
L Larry/Lima
M
Mary/Mike
Continued

229Index
IndexSymbolsK (Back) Button
.................................... 5
, 22
a (Display Mode) Button
...................... 29
j (Hang-Up) Button
................................ 177
h (Pick-Up) Button
.......................... 177
, 178
8 (Sound) Button
............................. 6
, 158
d (Talk) Button
...................................... 5
, 22
AA.SEL (Auto Select)
.................................... 127
Acura Client Relations
.............................. 210
Add to Address Book
.......................... 87
, 121
Add to Dest. List
..........87
, 115
, 119
, 120
, 121
Address
Editing Address Book
................................. 39
Editing Avoid Area
..................................... 53
Setting Destination
..................................... 66
Address Book
Editing Address Book
................................. 37
Setting Destination
..................................... 71
Address Book PIN
........................................ 42
Adjust Time
.................................................. 56
Advanced (Place Category)
........................ 76
Audio
........................................................... 123
Basic Operation
............................................ 6
Control Display
............................................. 7
Remote Control
........................................ 159
Sound Setup
............................................. 158
Voice Commands List
............................... 221
AUDIO Button
................................................ 7
Audio Menu
Bluetooth® Audio
....................................157
Disc
...........................................................134
FM/AM Radio
............................................127
HDD
..........................................................138
iPod®
........................................................149
USB Flash Drive
.........................................154
XM® Radio
...............................................131
Auto Answer
.............................................. 172
Auto Daylight
...............................................55
Auto Service (Place Category)
....................76
Auto Time Zone
...........................................55
Auto Transfer
.............................................172
AUX
Input Jack
..................................................124
Voice Commands List
...............................223
Avoid Streets
.............................................. 111
BBanking (Place Category)
...........................76
Basic Settings
................................................ 26
Black Level
....................................................24
Bluetooth® Audio
Playing
......................................................156
Voice Commands List
...............................223
Bluetooth® HandsFreeLink®
...................161
Editing User Name/PIN
..............................171
Making a Call
...........................................174
Pairing a Phone
.........................................164
Receiving a Call
.........................................177
Setting Speed Dials
...................................169
Brightness
...............................................24
, 29
CCalculator
................................................... 186
Calendar
..................................................... 184
Call
........................................................ 87
, 121
Making
..................................................... 174
Receiving
.................................................. 177
Call History
................................................. 176
Cancel Route
.............................................. 111
Category
Editing Address Book
................................. 39
Place Category List
................................... 228
Setting Destination
.................................... 76
CATEGORY Bar
.............................................. 6
Category Scan
............................................ 131
Cellular Phone
Voice Commands List
.............................. 224
CH (Channel) Button
................................ 160
Change Language
....................................... 20
Change Province
......................................... 67
Change Route Preference
.......................... 88
Channel List
............................................... 131
Channel Scan
............................................. 131
City
................................................................ 68
City Vicinity
.................................................. 77
Clear Cellular Phone Information
........... 173
Clear Personal Data
.................................... 61
Clock Adjustment
........................................ 55
Adjust Time
................................................ 56
Auto Daylight
............................................. 55
Auto Time Zone
......................................... 55
Resetting
.................................................... 56
Colour
........................................................... 27
Map Colour
................................................ 28
Menu Colour
.............................................. 28

230
XX
Index
Index
Community (Place Category)
.....................76
Continue Trip
.............................................121
Contrast
.........................................................24
Coordinate
....................................................83
Correct Vehicle Position
..............................59
Current Location
........................................106
Current Position
Editing Address Book
.................................39
Setting Destination
.....................................85
DDay Mode
Map Colour
................................................28
Menu Colour
..............................................28
Switching Display Mode
.............................29
Delete a Phone
...........................................167
Dest. Menu 1
................................................64
Dest. Menu 2
................................................64
DEST/ROUTE Button
Changing Route
.......................................110
Entering a Destination
................................64
Destination List
Adding Waypoint
.....................................112
Editing
.......................................................116
Destination Map
..........................................89
Detour
.........................................................111
Dial
...............................................................175
Dial Tones
...................................................177
Direct Dial
...................................................177
Directions
......................................................98
Disc
Playing
......................................................133
Voice Commands List
...............................222
DISC Button
............................................6
, 133
Display Voice Command Tips
.................... 26
EEdit Album
................................................. 143
Edit Avoid Area
........................................... 52
Edit Phone Name/PIN
............................... 171
Edit Speed Dial
.......................................... 169
Edit Track
................................................... 144
Edit Waypoint Search Area
........................ 54
Emergency (Place Category)
...................... 76
ENT Button
..................................................... 8
Error Messages
.......................................... 200
Disc Player
................................................ 201
iPod®
....................................................... 202
Navigation System
................................... 200
USB Flash Drive
........................................ 203
Exit Info
........................................................ 99
FFavorite Subcategory
.................................. 78
Find Nearest...
............................................ 117
FM/AM Button
....................................... 6
, 126
FM/AM Radio
Playing
...................................................... 126
Voice Commands List
.............................. 221
Folder List
Disc
........................................................... 135
USB Flash Drive
........................................ 155
GGet Album Info
.......................................... 145
Go Home 1
................................................... 12
Go Home 1 PIN
............................................ 42
Go Home 2
................................................... 12
Go Home 2 PIN
............................................ 42
Guidance Menu
........................................... 97
Directions
................................................... 98
Exit Info
...................................................... 99
Guidance Mode
........................................ 100
Guidance Mode
......................................... 100
HHDD
Playing
...................................................... 137
Voice Commands List
............................... 222
HDD Setup
Disc
........................................................... 134
HDD
.......................................................... 139
HDD/AUX Button
...........6
, 137
, 148
, 153
, 156
Heading-up
................................................ 105
Home Address 1
..................................... 12
, 41
Home Address 2
..................................... 12
, 41
IIcon Option
................................................ 104
Interface Dial
................................................. 8
Interface Dial Feedback
.............................. 25
Intersection
.................................................. 84
iPod®
Connecting, Disconnecting
.............. 147
, 152
Playing
...................................................... 147
Voice Commands List
............................... 223
