Acura ILX Hybrid 2013 Owners Manual

uuGauges and Multi-Information DisplayuMulti-Information Display
90Instrument Panel
Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).■Adjusting the outside temperature display
Adjust the temperature reading up to ±5°F or ±3°C if the temperature reading
seems incorrect.
The fuel economy indicator changes its size while driving. The indicator shrinks with
aggressive acceleration and deceleration, and grows back bigger again as fuel
economy gets better, and the halo appears around it when driving in the most fuel
efficient style.
Keep the indicator size as big as possible.■Outside Temperature■Fuel Economy Indicator
1Outside Temperature
The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).
It may take several minutes for the display to be
updated after the temperature reading has stabilized.
Use the multi-information display's customized
features to correct the temperature.
2Customized Features P. 95
Sphere Size:
Fuel Economy:
Acceleration/
Deceleration:Maximum
BestMiddle Minimum
Moderate AggressiveBetter
Slow
Worse

Continued
91
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
Shows the average fuel economy for the last
three driving cycles (1-3), and the current
driving cycle (0) in mpg or l/100 km.
Each time you set the power mode to ON, the
display is updated, and the oldest record is
deleted.
Shows the estimated average fuel economy of each trip meter in mpg (U.S.) or l/100
km (Canada). The display is updated at set intervals. When a trip meter is reset, the
average fuel economy is also reset.
Shows the instant fuel economy as a bar graph in mpg or l/100 km.
Shows the estimated distance you can travel on the remaining fuel. This distance is
estimated from the fuel economy of your trips in the past.
Shows the time elapsed since the last time Trip A or Trip B was reset.
■Average Fuel Economy RecordsLatest Average Fuel Economy
Past Average Fuel Economy
■Average Fuel Economy■Instant Fuel Economy■Range■Elapsed Time
1Average Fuel Economy
You can change the way the average fuel economy is
reset.
2Customized Features P. 95

92
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
Shows the average speed in mph or km/h since the last time Trip A or Trip B was
reset.■Average Speed

Continued
93
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
Displays engine and IMA motor power flow – whether the system is assisting the
engine or charging the battery.■IMA Battery Charge Level Indicator/Power Flow Monitor
1IMA Battery Charge Level Indicator/Power Flow Monitor
The IMA battery charge level may decrease rapidly
under the following conditions:•When the 12 volt battery has been replaced.•When the IMA battery has been disconnected.•When the IMA battery control system corrects its
reading.
The charge level reading will be corrected
automatically while driving.
If the IMA battery is too hot or too cold, the battery
stops outputting power for protection when it gets
too hot or cold. This disables the hybrid system assist
and Auto Idle Stop, even though the battery is well-
charged.
It takes a short time to normalize the IMA battery’s
output power depending on the weather.
Engine Operation Icon
IMA Battery Icon
Shows Charge Level
Power is supplied by
only the IMA motor. Power is supplied by the
engine and the IMA motor is
assisting the engine.
The IMA motor is
charging the IMA
battery.Power is only supplied
by the engine.Power is only supplied
by the engine and the
IMA motor is charging
the IMA battery. Power Flow
Operating
Not operating

94
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
Shows the remaining oil life and Maintenance Minder
TM.
2Maintenance Minder
TM P. 263
■Engine Oil Life

Continued
95
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
Use the multi-information display to customize certain features.■How to customize
Press the button to select CUSTOMIZE SETTINGS while the power mode
is in ON.■Customized Features
1Customized Features
To customize other features, press the
button.
2List of customizable options P. 97
When you customize settings:
Shift to
(P
Multi-Information
Display:
Goes to customize
settings.
SEL/RESET Button:
Enters the selected item Button:
Changes the customize
menus and items

96
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
■Customization flow
Press the button to select CUSTOMIZE SETTINGS and press the SEL/
RESET button.CUSTOMIZE SETTINGS
LANGUAGE SELECTION
ADJUST OUTSIDE TEMP. DISPLAY
“TRIP B” RESET TIMING
KEYLESS START GUIDANCE SCREENS
KEYLESS ACCESS BEEP
INTERIOR LIGHT DIMMING TIMEHEADLIGHT AUTO OFF TIMER
AUTO DOOR LOCKAUTO DOOR UNLOCK
KEYLESS LOCK ACKNOWLEDGMENT
DOOR LOCK MODE
SECURITY RELOCK TIMER“TRIP A” RESET TIMINGDOOR UNLOCK MODE
KEYLESS ACCESS LIGHT FLASHAUTO LIGHT SENSITIVITY
RESET/CANCELCANCEL/SET
SEL/RESET
METER SETUPDOOR SETUPDEFAULT ALLLIGHTING SETUP
KEYLESS ACCESS SETUPMAINTENANCE INFO.
SEL/RESETSEL/RESETSEL/RESETSEL/RESETSEL/RESETSEL/RESET

97
uuGauges and Multi-Information DisplayuMulti-Information Display
Continued
Instrument Panel
■List of customizable options
*1: Default SettingSetup GroupCustomizable
FeaturesDescription Selectable settingsMETER
SETUP
LANGUAGE
SELECTION
Changes the displayed language.
ENGLISH
*1/FRENCH/
SPANISH
ADJUST OUTSIDE
TEMP. DISPLAY
Adjust the temperature reading by a few degrees.
-5°F ~ ±0°F
*1 ~ +5°F (U.S.)
-3°C ~ ±0°C
*1 ~ +3°C
(Canada)
“TRIP A” RESET
TIMING
Changes the setting of how to reset trip meter A, average
fuel economy A, average speed A, and elapsed time A.
WITH REFUEL/IGN OFF/
MANUALLY RESET
*1
“TRIP B” RESET
TIMING
Changes the setting of how to reset trip meter B, average
fuel economy B, average speed B, and elapsed time B.
WITH REFUEL/IGN OFF/
MANUALLY RESET
*1
KEYLESS START
GUIDANCE SCREENS
Changes the display of the keyless start guidance screens.
ON
*1 / OFF
KEYLESS
ACCESS
SETUPDOOR UNLOCK
MODEChanges which doors unlock when you grab the driver’s
door handle.DRIVER DOOR ONLY
*1 / ALL
DOORS
KEYLESS ACCESS
LIGHT FLASHCauses some exterior lights to blink when you unlock/lock
the doors.ON
*1 / OFF
KEYLESS ACCESS
BEEPCauses the beeper to sound when you unlock/lock the doors.ON*1 / OFF

98
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
*1:Default SettingSetup
GroupCustomizable Features Description Selectable settingsLIGHTING
SETUP
INTERIOR LIGHT
DIMMING TIME
Changes the length of time the interior lights stay
on after you close the doors.
60sec / 30sec
*1 / 15sec
HEADLIGHT AUTO OFF
TIMER
Changes the length of time the exterior lights stay
on after you close the driver’s door.
60sec / 30sec / 15sec
*1 / 0sec
AUTO LIGHT
SENSITIVITY
Changes the timing for the headlights to come on.
MAX / HIGH / MID
*1 / LOW / MIN
DOOR
SETUPAUTO DOOR LOCKChanges the setting for the automatic locking
feature.WITH VEH SPD
*1 / SHIFT FROM
(P
/OFF
AUTO DOOR UNLOCKChanges the setting for when the doors unlock
automatically.DRIVER DOOR with SHIFT to
(P*1
/ ALL DOORS with SHIFT to
(P /
DRIVER DOOR with IGN OFF / ALL
DOORS with IGN OFF / OFF
DOOR LOCK MODESets up either the driver’s door or all doors to unlock
on the first operation of the remote or Built-in key.DRIVER DOOR
*1 / ALL DOORS
KEYLESS LOCK
ACKNOWLEDGMENTLOCK/UNLOCK - The exterior lights flash
LOCK (2nd push) - The beeper soundsON
*1 / OFF
SECURITY RELOCK
TIMERChanges the time it takes for the doors to relock and
the security system to set after you unlock the
vehicle without opening any door.90sec / 60sec / 30sec
*1

99
uuGauges and Multi-Information DisplayuMulti-Information Display
Continued
Instrument Panel
Setup Group Customizable Features Description Selectable settings
MAINTENANCE INFO.
Reset the Maintenance Minder
TM.
RESET/CANCEL
DEFAULT ALLSets/Cancels all the customized settings as default.CANCEL/SET
