This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it.This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise to
about the middle of the gauge. In
severe driving conditions, the pointer
mayrisetotheupperwhitemark.If
it reaches the red (Hot) mark, pull
safely to the side of the road. Turn to
page f or instructions and
precautions on checking the engine’s
cooling system.
To reset a trip meter, display it, and
then press and hold the Reset button
until the number resets to ‘‘0.0’’.
Both trip meters will reset if the
vehicle’s battery goes dead or is
disconnected. There are two trip meters: Trip A
and Trip B. Switch between these
displays by pressing the Select
button repeatedly. Each trip meter
works independently, so you can
keep track of two dif f erent distances.
When you turn the ignition switch
ON (II), what you last selected is
displayed.
240
Gauges
Inst rument s and Cont rols
Trip Meter Temperature Gauge
67
SELECT BUTTON
RESET BUTTON

Î
Î
To use the horn, press the pad around the ‘‘A’’ logo.
Inst rument s and Cont rols
Controls Near the Steering Wheel
68
REAR WINDOW
DEFOGGER
VTM-4 LOCK
INSTRUMENT PANEL
BRIGHTNESS
FOG LIGHTS HEADLIGHTS/TURN SIGNALS
REMOTE AUDIO
CONTROLS HORN
CRUISE CONTROL
VEHICLE STABILITY
ASSIST SYSTEM OFF
SWITCH
STEERING WHEEL ADJUSTMENT WINDSHIELD WIPERS/WASHERS
(P.72)
(P.75)
CRUISE CONTROL
(P.144)
(P.184)
(P.128)
(P.76) (P.74)
(P.176)
(P.75)
(P.74)
(P.69) (P.30)
(P.144) PASSENGER AIRBAG OFF INDICATORHAZARD WARNING
BUTTON

OFF
INT : Intermittent: Low speed
: High speed
MIST
Windshield Washers Turntherotaryswitchattheendof
the lever or push down or pull the
lever to select a position.
The wipers are not activated.
The length of the wiper interval is varied
automatically according to the
vehicle’s speed.
Vary the delay by turning the
INT TIME ring. If you turn it
to the shortest delay, the
wipers will change to low
speed operation when the
vehicle speed exceeds 12 mph
(20 km/h).
: The wipers run at low speed.
: The wipers run at high speed. The wipers run at high speed
until you release the lever.
:Pullthewiper
control lever toward you and
hold it. The washers spray
until you release the lever.
The wipers run at low speed,
then complete one more
sweep after you release the
lever.
1.
2.
3.
4.
5.
6.
Windshield Wipers and Washers
Inst rument s and Cont rols
OFF:
INT : MIST :
Windshield Washer
69

Touring Model
The automatic wiper system senses
rainf all and automatically turns on
the windshield wipers. To enable
sensing, turn the rotary switch at the
end of the wiper lever to AUTO.When the system senses rainf all, it
turns on the windshield wipers and
varies their speed (intermittent, low
speed, or high speed) depending on
how hard it is raining.
Whentherotaryswitchisinthe
(low speed) or (high speed)
position, the windshield wipers run
at that speed. Automatic sensing is
disabled.
You can adjust the sensitivity of the
system by turning the AUTO SENS
ring next to the rotary switch.
Inst rument s and Cont rols
Windshield Wipers and Washers
Automatic Wipers
70

The rainfall sensor is located in the
windshield near the rearview mirror.
If the sensor is covered with mud, oil,
dust, etc., the wipers may not
operate properly or may operate
unexpectedly.The rear window wiper switch is
located next to the windshield wiper
switch.
Do not put the wiper switch in
AUTO when driving through a car
wash. OFF
ON
Turnandholdtousethewiper
and washer.
1.
2.
3.
Windshield Wipers and Washers
Inst rument s and Cont rols
Rear Window Wiper and Washer
71
RAINFALL SENSOR

µµ
µ Push down on the
lef t lever to signal a lef t turn and up
to signal a right turn. To signal a lane
change, push lightly on the lever and
hold it. The lever will return to
center when you release it or
complete a turn. When the light switch is in either of
these positions, the Lights On
indicator comes on as a reminder.
This light remains on if you leave the
light switch on and turn the ignition
switch to ACCESSORY (I) or LOCK
(0).
To turn on, pull the
lever back until you hear a click. The
blue high beam indicator will come
on (see page ). Pull it back again
to return to low beams.
To f lash the high beams, pull the
lever back lightly, then release it.
The high beams will stay on as long
as you hold the lever back.
Rotating the switch
on the lef t lever to the ‘‘ ’’
position turns on the parking lights,
taillights, instrument panel lights,
side-marker lights, and rear license
plate lights.
Turning the switch to the ‘‘ ’’
position turns on the headlights. If
you leave the lights on with the key
removed f rom the ignition switch,
you will hear a reminder chime when
you open the driver’s door.
Turn signal
Of f
Parking and indicator lights
AUTO
Headlights on
High beams
Flashhighbeams
1.
2.
3.
4.
5.
6.
7. 61
Inst rument s and Cont rols
Turn Signal and Headlights Turn Signal
High Beams
Headlights
Turn Signal, Headlights
72

µThe Automatic Lighting
f eature turns on the headlights, all
other exterior lights, and the
instrument panel lights when it
senses low ambient light.
To turn on automatic lighting, turn
the light switch to AUTO at any time.
The lights will come on automatically
when the outside light level becomes
low (at dusk, f or example). The
Lights On indicator comes on as a
reminder. The lights and indicator
will turn of f automatically when the
system senses high ambient light. The lights will remain on when you
turn of f the ignition switch. They will
turn of f automatically when you open
the driver’s door. To turn them on
again, either turn the ignition switch
to ON (II) or turn the light switch to
.
Even with the automatic lighting
f eature turned on, we recommend
thatyouturnonthelightsmanually
when driving at night or in a dense
f og, or when you enter dark areas,
such as long tunnels or parking
structures.
Do not leave the light switch in
AUTO if you will not be driving the
vehicle f or an extended period (a
weekormore).Youshouldalsoturn
of f the lights if you plan to leave the
engine idling or the engine of f f or a
long time. The automatic lighting f eature is
controlledbyasensorlocatedontop
of the dashboard. Do not cover this
sensor or spill liquids on it.
Headlights
Inst rument s and Cont rols
AUTO
73
LIGHT SENSOR

With the headlight switch off, the
high beam headlights come on with
reduced brightness when you turn
the ignition switch to ON (II) and
release the parking brake. They
remain on until you turn the ignition
of f , even if you set the parking brake.
The headlights revert to normal
operation when you turn them on
with the switch.The dial on the instrument panel
controls the brightness of the
instrument panel lights. Turn the dial
to adjust the brightness.Push the red button to the right of
the display to turn on the hazard
warning lights (f our-way f lashers).
This causes all f our outside turn
signals and both indicators in the
instrument panel to f lash. Use the
hazard warning lights if you need to
park in a dangerous area near heavy
traf f ic, or if your vehicle is disabled.
Canadian Models
Daytime Running L ights
Instrument Panel Brightness Hazard Warning Button
Inst rument s and Cont rols
Headlights, Instrument Panel Brightness, Hazard Warning Button
74
INSTRUMENT PANEL BRIGHTNESS
CONTROL DIAL

Make sure the rear window is clear
and you have good visibility bef ore
starting to drive.Turn the f og lights on and of f by
pressing the button. The indicator in
the button lights to show the f og
lights are on.
You can use the f og lights only when
the headlights are on low beam.
They will go of f when you turn the
headlights of f or onto high beam.
The rear window def ogger will clear
fog,frost,andthinicefromthe
window. Push the def ogger button to
turn it on and off. The indicator in
the button lights to show the
def ogger is on. If you do not turn it
of f , the def ogger will shut itself of f
af ter about 15 minutes. It also shuts
of f when you turn of f the ignition.
You have to turn it on again when
you restart the vehicle. Thedefoggerwiresontheinsideof
the rear window can be accidentally
damaged. When cleaning the glass,
always wipe side to side.
Rear Window Def ogger
Fog Lights
Rear Window Def ogger, Fog Lights
Inst rument s and Cont rols75

See page f or important saf etyinf ormation about how to properlyposition the steering wheel. 16
Make any steering wheel adjustment
bef ore you start driving.
Push the lever under the steering
column all the way down.
Move the steering wheel so it
points toward your chest, not
toward your f ace. Make sure you
can see the instrument panel
gauges and indicators.Push the lever up to lock the
steering wheel in position.
Make sure you have securely
locked the steering wheel in place
by trying to move it up and down.
3.
4.
1.
2.
Steering Wheel A djustment
Inst rument s and Cont rols76
Adjusting the steering wheel
position while driving may
cause you to lose control of the
vehicle and be seriously injured
inacrash.
Adjust the steering wheel only
when the vehicle is stopped.
