Acura MDX 2004 Owners Manual

The left and right halves can be
f olded up separately.To get into the third row seats, pull
uptheleveronthesideof the
passenger’s side second row seat-
back. The seat-back will tilt f orward,
and the seat will slide f orward.
After you return the seat-back to the
upright position, push the whole seat
backwards until it latches. Make
sure the seat is f ully latched bef ore
sitting in it.
To change the seat-back angle of the
seats in the second row, pull up on
thehandleontheoutsideof theseat-
back. If you are f olding the lef t half of
the seat, use the ignition key to
release the center seat belt from
the detachable anchor. Allow the
seat belt to retract into the roof.
Insert the latch plate into the roof
holder.
Lower the head restraint to its
lowest position.
Pull up the handle on the outside
of the seat-back.
Fold the seat-back forward.
Reverse this procedure to return the
seat to the upright position. Make
sure the seat is locked securely
bef ore driving. 2.
3. 1.
4. Folding the Second Seat
A djusting the Second Seat T hird Row A ccess
Seats
Inst rument s and Cont rols87
HANDLERELEASE LEVER

Store the head restraints in the
storage compartment. Make sure
the head restraints are f ace up
(storing them face down can
damage the compartment or the
headrests), then insert the shaf ts
into the holes in the sides of the
storage compartment.
Pull on the handle on the back of the
seat-back, move the seat-back to the
desired position, and release the
handle. Let the seat-back latch in the
new position.
Use the ignition key to release the
seat belt from the detachable
anchor.Unlock the seat-back by pulling
the handle. Push the seat-back
forward.
Make sure the outer shoulder belts
are positioned on each hook
whenever the third seat is f olded.
Remove the head restraints by
pushing the release buttons and
pulling the restraints out. To f old the third row seat,
the second row must be f olded down
or completely up right.
Reverse this procedure to return the
seat to the upright position. Make
sure the seat is locked securely
bef ore driving. Reinstall the head
restraints. Reconnect the seat belts
to the detachable anchors.
Make sure all items in the cargo area
are secured. Loose items can f ly
f orward and cause injury if you have
to brake hard. See
on page .
1. 2.
3.4.
165
Seats
Inst rument s and Cont rols
A djusting the T hird Row Seat
Folding the T hird Row Seat Carrying Cargo
88
NOTE:
HANDLE
THIRD
SEAT

Both f ront seats are equipped with
seat heaters. The ignition switch
must be in the ON (II) position to
usethem.Pushthefrontof the
switch, HI, to rapidly heat up the seat.
After the seat reaches a comfortable
temperature, select LO by pushing
the back of the switch. This will keep
the seat warm.In HI, the heater turns of f when the
seat gets warm, and turns back on
after the seat’s temperature drops.
In LO, the heater does not cycle with
temperature change.
Because of the sensors f or the side
airbag system, there is no heater in
the passenger’s seat-back.
Follow these precautions when using
the seat heaters:
Use the HI setting only to heat the
seats quickly, because it draws
large amounts of current f rom the
battery.
If the engine is lef t idling f or an
extended period, do not use the
seat heaters, even on the LO
setting. It can weaken the battery,
causing hard starting.
Seat Heaters
Inst rument s and Cont rols89
SEAT HEATERS

µ
µ
Turn the ignition switch to ON (II)
toraiseorloweranywindow.To
open the window, push the switch
downandholdit.Releasetheswitch
when you want the window to stop.
Pull back on the switch and hold it to
close the window. If the MAIN switch is OFF, the
passenger windows cannot be raised
or lowered. Keep the MAIN switch
off whenyouhavechildreninthe
vehicle so they do not injure
themselves by operating the
windows unintentionally. If the driver’s
window runs into any obstacle while
it is closing automatically, it will
reverse direction and then stop. To
close the window, remove the
obstacle, then use the window switch
again.
If your vehicle’s battery is
disconnected or goes dead, or the
driver’s window f use is removed, the
AUTO f unction will be disabled. The
power window system needs to be
reset af ter reconnecting the battery
or installing the f use.
Start the engine. Push down and
hold the driver’s window switch
until the window is f ully open.
Pull and hold the driver’s window
switch to close the window
completely, then hold the switch
f or a second or two more.
If the power windows do not operate
properly af ter resetting, have your
vehicle checked by an Acura dealer.
The windows will operate f or up to
10 minutes af ter you turn of f the
ignition switch. Opening either f ront
door cancels this f unction. To open/close the driver’s
window, push the window switch
f irmly down or up to the second
detent, and release it. The window
will automatically go up or down all
the way. To stop the window, pull/
push on the window switch brief ly. 1.
2.
Power Windows
Inst rument s and Cont rols
AUTO REVERSE
AUTO
90
DRIVER’S WINDOW
SWITCH MAIN SWITCH
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.

To open the moonroof , pull back the
moonroof switch f irmly.
To close the moonroof f ully, push
the switch forward.To tilt the moonroof up, press the
button in. To closed it, push the
button f orward. Make sure everyone’s
hands are away f rom the moonroof
bef ore opening or closing it.
You can still open and close the
moonroof f or up to 10 minutes af ter
you turn of f the ignition. Opening
either f ront door cancels this
f unction.
Moonroof
Inst rument s and Cont rols91
NOTICE:
MOONROOF SWITCHOpen
Close
Opening or closing the
moonroof on someone’s hands
or fingers can cause serious
injury.
Make sure all hands and fingers
are clear of the moonroof
before opening or closing it. If you try to open moonroof
in below-f reezing temperatures, or
when it is covered with snow or ice, you
can damage the moonroof panel or its
motor.

Theinsidemirrorcanautomatically
darken to reduce glare. To turn on
this feature, press the button on the
bottom of the mirror. The AUTO
indicator comes on as a reminder.
When it is on, the mirror darkens
when it senses the headlights of a
vehicle behind you, then returns to
normal visibility when the lights are
gone. Press the button again to turn
of f this sensing.
To apply the parking brake, push the
pedal down with your f oot. To
release it, push on the pedal again.
The parking brake indicator on the
instrument panel should go out when
the parking brake is fully released
with the engine running (see page ). Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.
59
Inst rument s and Cont rols
Parking Brake
Mirrors
Parking Brake, Mirrors
92
NOTICE:
PARKING BRAKE PEDAL
AUTO SWITCH
SENSOR
INDICATOR
Driving the vehicle with the
parking brake applied can damage the
rear brakes and axles. A beeper will sound if the vehicle is put into gear
with the parking brake on.

Turn the ignition switch to ON (II).
Move the selector switch to L
(driver’s side) or R (passenger’s
side).
Push the appropriate edge of the
adjustment switch to move the
mirrorright,left,up,ordown.When you f inish, move the
selector switch to the center (off)
position. This turns of f the
adjustment switch to keep your
settings.
The outside mirrors are heated to
remove fog and frost. With the
ignition switch in the ON (II)
position, turn on the heaters by
pressing the button. The indicator in
the button comes on as a reminder.
Press the button again to turn the
heaters of f .
Turn this f eature of f by leaving the
selector switch in the Lef t or Right
position. With the selector switch in the
center (of f ) position, the passenger’s
side mirror will pivot downward
slightly when you shif t the
transmission into Reverse. This
gives you a better view of the side of
the vehicle while parallel parking.
The mirror returns to its original
position when you take the
transmission out of reverse.
1.
2.
3. 4.
Touring model only
Adjusting the Power Mirrors
Mirrors
Inst rument s and Cont rols93
HEATED MIRROR BUTTON
SELECTOR SWITCH
ADJUSTMENT SWITCH

Touring Model
Seat and outside mirror positions,
canbestoredinseparatememories.
Youselectamemorizedpositionby
pushing the appropriate button or
using the appopriate remote
transmitter (Memory 1 or Memory2).Store a driving position only when
the vehicle is parked.
Turn the ignition switch to ON (II).
You cannot add a new driving
position in the memory unless the
ignition switch is the ON (II)
position. You can recall a
memorized position with the
ignition switch in any position.
Adjust the seat to a comfortable
position (see page ).
Adjust the outside mirrors f or best
visibility (see page ). Press and release the MEMO
buttononthecontrolpanel.You
will hear a beep. Immediately
press and hold one of the memory
buttons (1 or 2) until you hear two
beeps. The indicator in the
memory button will come on. The
current positions of the driver’s
seat and outside mirrors are now
stored.
Your Acura has a memory f eature
f or the driver’s seat and outside
mirror positions.
3.
1.
2.
84
93
St oring a Driving Posit ion in Memory
Inst rument s and Cont rols
Driving Posit ion Memory Syst em
94
MEMO BUTTON
MEMORY BUTTONS

Doing any of the f ollowing af ter
pressing the MEMO button will
cancel the storing procedure.Not pressing a memory button
within 5 seconds.
Readjusting the seat position.
Readjusting the outside mirror
position.
Each memory button stores only one
driving position. Storing a new
position erases the previous setting
stored in that button’s memory. If
you want to add a new position while
retaining the current one, use the
other memory button. To select a memorized position, do
this:
Make sure the parking brake is set
and the shif t lever is in Park.
Press the desired memory button
(1 or 2) until you hear a beep, then
release the button.
The system will move the seat and
outside mirrors to the memorized
positions. The indicator in the
selected memory button will f lash
during movement. When the
adjustments are complete, you will
hear two beeps, and the indicator will
remain on. To stop the system’s automatic
adjustment, do any of these actions:
Press any button on the control
panel: MEMO, 1, or 2.
Push any of the adjustment
switches f or the seat.
Shif t out of Park.
Adjust the outside mirrors.
If desired, you can use the
adjustment switches to change the
positions of the seat or outside
mirrors af ter they are in their
memorized position. If you change
the memorized position, the
indicator in the memory button will
go out. To keep this driving position
f or later use, you must store it in the
driving position memory.
1.
2.Select ing a Memorized Posit ion
Inst rument s and Cont rols
Driving Posit ion Memory Syst em
95

When this switch is in the position:When the switch is in the
position:
When the light control switch is in theposition:OFF
None of the lights come on when a
door or the tailgate is opened. Door
Activated Withanydoororthetailgateleft
open, the lights stay on about 3
minutes, then go out.
ON
All the individual map lights come
onandstayonaslongasthe
switch remains in the ON position.
The lights go out about six seconds
after all the doors and the tailgate
are closed. The individual map lights come on
whenanydoororthetailgateis
opened, or when the remote
transmitter is used to unlock the
doors. When the doors and the
tailgate are closed, each light can
be turned on and of f by pushing
the lens.
The cargo area (3rd row) light
comes on when any door or the
tailgate is opened if the switch in
the light is in the door activated
position. When the doors and the
tailgate are closed, the cargo area
lightcanbeturnedonwiththe
switch in the light.
The cargo (3rd row) area light
comes on if the switch is in the
door activated position.
The individual map lights in the
f ront can be turned on and of f by
pushing each lens.
L ight Control Switch
Interior Lights
Inst rument s and Cont rols96
DOOR ACTIVATED POSITION
ON
OFF
