service interval Acura MDX 2009 Owner's Manual

Important Maintenance
Precautions
If you have the required service done
but do not reset the display, or reset
the display without doing the service,
the system will not show the proper
maintenance intervals. This can lead
to serious mechanical problems
because you will no longer have an
accurate record of when
maintenance is needed.Your authorized dealer knows your
vehicle best and can provide
competent, efficient service.
However, service at a dealer is not
mandatory to keep your warranties in
effect. Maintenance may be done by
any qualified service facility or
person who is skilled in this type of
automotive service. Keep all receipts
as proof of completion, and have the
person who does the work fill out
your Maintenance Journal or
Canadian Maintenance Log. Check
your warranty booklet for more
information.We recommend using Acura parts
and fluids whenever you have
maintenance done. These are
manufactured to the same high-
quality standards as the original
components, so you can be confident
of their performance and durability.Maintenance Minder38808/06/06 16:58:07 09 ACURA MDX MMC North America Owner's M 50 31STX620 enu
2009 MDX

U.S. Vehicles:
Maintenance, replacement, or
repair of emissions control
devices and systems may be done
by any automotive repair
establishment or individual using
parts that are‘‘certified’’to EPA
standards.
According to state and federal
regulations, failure to perform
maintenance on the items marked
with ＃will not void your emissions
warranties. However, Acura
recommends that all maintenance
services be performed in accordance
with the intervals indicated by the
multi-information display. Owner's Maintenance Checks
You should check the following
items at the specified intervals. If you
are unsure of how to perform any
check, turn to the appropriate page
listed.
●Engine oil level
－Check every
time you fill the fuel tank. See page
326.●Engine coolant level －Check the
radiator reserve tank every time
you fill the fuel tank. See page326.●Automatic transmission －Check
the fluid level monthly. See page
399.●Brakes －Check the fluid level
monthly. See page401.●Tires －Check the tire pressure
monthly. Examine the tread for
wear and foreign objects. See page
416.
●Lights －Check the operation of
the headlights, parking lights,
taillights, high-mount brake light,
and license plate lights monthly.
See page403.
Maintenance Minder
389
Maint enance
08/06/06 16:58:07 09 ACURA MDX MMC North America Owner's M 50 31STX620 enu
2009 MDX

Synthetic Oil
You may use a synthetic motor oil if
it meets the same requirements
given for a conventional motor oil: it
displays the API Certification Seal
and it is the proper weight. You must
follow the oil and filter change
intervals shown on the multi-
information display.
Engine Oil Additives
Your vehicle does not require any oil
additives. Additives may adversely
affect the engine or transmission
performance and durability.Changing the Engine Oil and
Filter
Always change the oil and filter
according to the maintenance
messages shown on the multi-
information display. The oil and filter
collect contaminants that can
damage your engine if they are not
removed regularly.
Changing the oil and filter requires
special tools and access from
underneath the vehicle. The vehicle
should be raised on a service station-
type hydraulic lift for this service.
Unless you have the knowledge and
proper equipment, you should have
this maintenance done by a skilled
mechanic.
1. Run the engine until it reaches
normal operating temperature,
then shut it off.
2. Open the hood, and remove theengine oil fill cap. Remove the oil
drain bolt and washer from the
bottom of the engine. Drain the oil
into an appropriate container.
WASHER DRAIN BOLT
Adding Engine Oil, Changing the Engine Oil and Filter39408/06/06 16:58:07 09 ACURA MDX MMC North America Owner's M 50 31STX620 enu
2009 MDX

Door Locks
..............................
11
Head Restraints
........................
14
Seat Belts
.................... ..........
8,15
Seats & Seat-Backs
..............
12, 13
Safety Labels, Location of
.............
59
Safety Messages
...........................
iii
Satellite Radio, XM
®............
185, 210
Seat Belts
.................................
8, 15
Additional Information
.............
20
Advice for Pregnant Women
....
18
Automatic Seat Belt Tensioners
.............. .............
22
Cleaning
...................... ............
409
Lap/Shoulder Belt
..............
15, 21
Maintenance
............................
23
Reminder Indicator and Beeper
.............................
20, 64
System Components
................
20
Use During Pregnancy
.............
18
Wearing a Lap/Shoulder Belt
.......................... .............
21
Seats
..........................................
140
Adjusting the Second Seat
.......
144
Folding the Second Seat
..........
144
Folding the Third Seat
............
145
Head Restraints
.......................
141 Heaters
...................................
148
Position Memory
....................
157
Third Row Access
...................
145
Seats, Adjusting the
...................
140
Security System
.........................
269
Sensors Driver's Seat Position Sensor
..................................
29
Front Passenger's Weight Sensors
............ ....................
29
Impact Sensors
...................
24, 25
Sequential SportShift Mode
........
343
Serial Number
............................
450
Service Intervals
.........................
383
Service Manual (U.S. only)
........
469
Service Station Procedures
........
323
SH-AWD
®
Indicator
...................................
69
Shifting the Automatic Transmission
..........................
341
Shift Lever Position
Indicators
...............................
341
Shift Lock Release
......................
346
Side Airbags
.................................
30
How the Side Airbag Off Indicator Works
...................
33 How Your Side Airbags
Work
....................................
30
Off Indicator
.............................
33
Side Curtain Airbags
....................
32
How Your Side Curtain Airbags Work
....................................
32
Side Marker Lights, Bulb Replacement in
.......................
404
Signaling Turns
........ ....................
67
Snow Tires
.................................
419
Sound System
.....................
180, 200
Spare Tire
................ ..................
424
Inflating
...........................
415, 424
Specifications
..........................
453
Spark Plugs
................................
453
Specifications
.............................
452
Speed Control
............................
270
Speed Limiter
.............................
346
Speedometer
................................
72
CONTINUED
Index
IX
INDEX
