CODE Acura MDX 2011 Owner's Guide

5. Look for a burned wire inside thefuse. If it is burned out, replace it
with one of the spare fuses of the
same rating or lower. If you cannot drive the vehicle
without fixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
from one of the other circuits. Make
sure you can do without that circuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown fuse with a
spare fuse that has a lower rating, it
might blow out again. This does not
indicate that anything is wrong.
Replace the fuse with one of the
correct rating as soon as you can.
Replacing a fuse with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement fuse with the proper rating
for the circuit, install one with a lower
rating.
6. If the replacement fuse of the same
rating blows in a short time, there
is probably a serious electrical
problem with your vehicle. Leave
the blown fuse in that circuit, and
have your vehicle checked by a
qualified technician.
If the radio fuse is removed, the
audio system will disable itself. The
next time you turn on the radio you
will see ‘‘ENTER CODE ’’in the
frequency display. Use the preset
buttons to enter the digit code (see
page 305).
BLOWN
Fuses56210/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

Your vehicle has several identifying
numbers located in various places.
The vehicle identification number
(VIN) is the 17-digit number your
dealer uses to register your vehicle
for warranty purposes. It is also
necessary for licensing and insuring
your vehicle. The easiest place to
find the VIN is on a plate fastened to
the top of the dashboard. You can
see it by looking through the
windshield on the driver's side. It is
also on the certification label
attached to the driver's doorjamb,
and is stamped on the engine
compartment bulkhead. The VIN is
also provided in bar code on the
certification label.
VEHICLE IDENTIFICATION NUMBERCERTIFICATION LABEL
Identification Numbers57010/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

The tires that came on your vehicle
have a number of markings. Those
you should be aware of are described
below.
Tire SizeWhenever tires are replaced, they
should be replaced with tires of the
same size. Following is an example
of tire size with an explanation of
what each component means.P255/55R18 104H
P －Vehicle type (P indicates
passenger vehicle).
255 －Tire width in millimeters.
55 －Aspect ratio (the tire's
section height as a
percentage of its width).
R －Tire construction code (R
indicates radial).
18 －Rim diameter in inches. 104
－Load index (a numerical code
associated with the
maximum load the tire can
carry).
H －Speed symbol (an
alphabetical code indicating
the maximum speed rating).
Tire Identification Number (TIN)The tire identification number (TIN)
is a group of numbers and letters that
look like the following example. TIN
is located on the sidewall of the tire.
DOT B97R FW6X 2202
DOT －This indicates that the tire
meets all requirements of
the U.S. Department of
Transportation.
B97R －Manufacturer's
identification mark.
TIRE LABELING EXAMPLE
(1) Tire Size
(2) Tire Identification Number (TIN)
(3) Maximum Tire Pressure
(4) Maximum Tire Load (4)
(3) (2)(1)
(1)Tire Labeling57610/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

FW6X－Tire type code. Glossary of Tire Terminology
Cold Tire Pressure
－The tire air
pressure when the vehicle has been
parked for at least three hours or
driven less than 1 mile (1.6 km).
Load Rating －Means the maximum
load that a tire is rated to carry for a
given inflation pressure.
Maximum Inflation Pressure －The
maximum tire air pressure that the
tire can hold.
Maximum Load Rating －Means the
load rating for a tire at the maximum
permissible inflation pressure for that
tire.
Recommended Inflation Pressure －
The cold tire inflation pressure
recommended by the manufacturer.
Treadwear Indicators (TWI) －
Means the projections within the
principal grooves designed to give a
visual indication of the degrees of
wear of the tread.2202 －
Year
Week
Date of manufacture.
Tire Labeling
577
Technical Information
10/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

Testing of Readiness Codes
If you take your vehicle for an
emissions test shortly after the
battery has been disconnected or
gone dead, it may not pass the test.
This is because of certain‘‘readiness
codes ’’that must be set in the on-
board diagnostics for the emissions
systems. These codes are erased
when the battery is disconnected,
and set again only after several days
of driving under a variety of
conditions. If the testing facility determines that
the readiness codes are not set, you
will be requested to return at a later
date to complete the test. If you must
get the vehicle retested within the
next two or three days, you can
condition the vehicle for retesting by
doing the following.
1. Make sure the gas tank is nearly,
but not completely, full (around
3/4).
2. Make sure the vehicle has been parked with the engine off for 6
hours or more.
3. Make sure the ambient temperature is between 40° and
95°F (4° and 35°C). 4. Without touching the accelerator
pedal, start the engine, and let it
idle for 20 seconds.
5. Keep the vehicle in Park. Increase the engine speed to 2,000 rpm, and
hold it there until the temperature
gauge rises to at least 1/4 of the
scale (about 3 minutes).
6. Without touching the accelerator pedal, let the engine idle for 20
seconds.
CONTINUED
Emissions Testing
583
Technical Information
10/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

7. Select a nearby lightly traveledmajor highway where you can
maintain a speed of 50 to 60 mph
(80 to 97 km/h) for at least 20
minutes. Drive on the highway in
D. Do not use the cruise control.
When traffic allows, drive for 90
seconds without moving the
accelerator pedal. (Vehicle speed
may vary slightly; this is okay.) If
you cannot do this for a continuous
90 seconds because of traffic
conditions, drive for at least 30
seconds, then repeat it two more
times (for a total of 90 seconds). 8. Then drive in city/suburban traffic
for at least 10 minutes. When
traffic conditions allow, let the
vehicle coast for several seconds
without using the accelerator pedal
or the brake pedal. 9. Make sure the vehicle has been
parked with the engine off for 30
minutes.
If the testing facility determines the
readiness codes are still not set, see
your dealer.Emissions Testing58410/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

BrakesAnti-lock Brakes (ABS)
...........
455
Break-in, New Linings
.............
418
Bulb Replacement
...................
525
Fluid
.......................................
519
Parking
...................................
163
System Design
........................
455
System Indicator
...............
67, 558
Wear Indicators
.......................
455
Braking System
..........................
454
Break-in, New Vehicle
................
418
Brightness Control,
Instruments
............................
132
Bulb Replacement Back-up Lights
................
525, 526
Brake Lights
...........................
525
Front Parking Lights
...............
523
Front Side Marker Lights
........
523
Headlights
..............................
521
Rear Bulbs
..............................
525
Rear License Plate Lights
........
527
Specifications
..........................
573
Taillights
.................................
525
Turn Signal Lights
..........
523, 525
Bulbs, Halogen
..........................
521 C
Capacities Chart
.........................
572
Carbon Monoxide Hazard
............
60
Cargo
.........................................
428
Cargo Hooks
..............................
432
Cargo, How to Carry
..................
428
Carrying Cargo
..........................
428
CAUTION, Explanation of
............
iii
CD Care
.....................................
244
CD Error Messages
...................
243
CD Player
..................................
232
Certification Label
......................
570
Chains, Tires
..............................
540
Changing a Flat Tire
..................
545
Changing Oil How to
....................................
512
When to
..................................
501
Charging System Indicator
...........................
67, 556
Checklist, Before Driving
...........
435
Childproof Door Locks
...............
140
Child Safety
..................................
39
Booster Seats
...........................
57
Child Seats
....................
44, 45, 47 Important Safety Reminders
.....
43
Infants
......................................
44
Larger Children
.......................
56
LATCH
.....................................
49
Risks with Airbags
...................
40
Small Children
.........................
45
Tethers
....................................
53
Warning Labels
........................
41
Where Should a Child Sit?
........
40
Child Seats
.............................
39, 47
LATCH Anchorage Points
........
49
Tether Anchorage Points
.........
53
Cleaning the Seat Belts
..............
528
Client Service Information
..........
586
Climate Control System
.............
180
Clock
..........................................
306
Code, Audio System
...................
305
CO in the Exhaust
................
60, 580
Cold Weather, Starting in
...........
436
Collision Mitigation Braking System ™(CMBS ™)
...............
457
Compact Spare Tire
....................
544
Compass Operation
....................
338
Console Compartment
...............
173
Consumer Information
...............
586
Controls, Instruments and
............
63
IndexII10/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

P
Panel Brightness Control
...........
132
Park Gear Position
.....................
438
Parking
......................................
448
Parking Brake
............................
163
Parking Brake and Brake System Indicator
...........................
67, 558
Parking Lights
...........................
127
Parking Over Things that Burn
................................
448, 582
Passenger Airbag Off Indicator
....
36
PGM-FI System
..........................
581
Playing a Disc
............................
232
Playing an iPod
®.........................
275
Playing a USB Flash Memory Device
....................................
284
Playing Disc
...............................
200
Playing Hard Disc Drive (HDD) Audio (Models with navigationsystem)
...............................
247
Playing the AM/FM Radio
...............................
191, 210
Playing the XM
®Radio
........
195, 223
Pollen Filter
...............................
528 Power Seat Adjustments
............
148
Power Socket Locations
.............
175
Power Steering Fluid
.................
520
Power Windows
.........................
158
Pregnancy, Using Seat Belts
........
19
Preparing to Drive
......................
435
Proper Seat Belt Usage
................
16
Protecting Adults and Teens
........
12
Additional Safety Precautions
...
20
Advice for Pregnant Women
....
19
Protecting Children
......................
39
General Guidelines
..................
39
Protecting Infants
.....................
44
Protecting Larger Children
......
56
Protecting Small Children
........
45
Using Child Seats with Tethers
.................................
53
Using LATCH
..........................
49
R
Radiator Overheating
.................
554
Radio/CD Sound System
...........
190
Radio/Disc Sound System
............................
191, 210 Radio Theft Protection
...............
305
Readiness Codes
........................
583
Rear A/C Unit
............................
185
Rear Audio Control Panel
...........
312
Rear Entertainment System
.......
307
Rear Lights, Bulb Replacement
...........................
525
Rearview Mirror
.........................
163
Rearview Mirror with Rearview Camera Display
......................
414
Rear Window Defogger
..............
131
Rear Window Wiper and
Washer
...................................
126
Recalling a Memorized Driving Position
..................................
147
Reclining the Seat Backs
............
148
Reclining the Second Seats
........
152
Refueling
....................................
419
Reminder Indicators
.....................
66
Remote Audio Controls
..............
302
Remote Control (RES)
...............
331
Remote Transmitter
...................
144
Replacement Information Dust and Pollen Filter
.............
528
Engine Oil and Filter
...............
512
Fuses
......................................
559
IndexVIII10/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu
