Acura MDX 2012 Owner's Manual

2. Remove the towing hook and
wheel nut wrench located behind
the cargo area cover on the
driver's side.
3. Screw the towing hook into the
hole, and tighten it with the wheel
nut wrench.
To avoid damage to your vehicle, use
the towing hook for straight, flat
ground towing only. Do not tow at an
angle. The tow hook should not be used
to tow the vehicle onto a flat bed. Do
not use it as a tie down.
TOWING HOOK and
WHEEL NUT WRENCH
WHEEL NUT WRENCH
TOWING HOOK
Front
If Your Vehicle Gets Stuck574

The diagrams in this section give you
the dimensions and capacities of
your vehicle and the locations of the
identification numbers. It also
includes information you should
know about your vehicle's tires and
emissions control systems.Identification Numbers
...............
576
Specifications
..............................
578
DOT Tire Quality Grading (U.S.
Vehicles)
.................................
581
Tire Labeling
..............................
583
Tire Pressure Monitoring System
(TPMS)－Required Federal
Explanation
.........................
585
Emissions Controls
.....................
587
Three Way Catalytic
Converter
................................
589
Emissions Testing
.......................
590
Technical Information
575
Technical Information

Your vehicle has several identifying
numbers located in various places.
The vehicle identification number
(VIN) is the 17-digit number your
dealer uses to register your vehicle
for warranty purposes. It is also
necessary for licensing and insuring
your vehicle. The easiest place to
find the VIN is on a plate fastened to
the top of the dashboard. You can
see it by looking through the
windshield on the driver's side. It is
also on the certification label
attached to the driver's doorjamb,
and is stamped on the engine
compartment bulkhead. The VIN is
also provided in bar code on the
certification label.
VEHICLE IDENTIFICATION NUMBER
CERTIFICATION LABEL
Identification Numbers576

The engine number is stamped into
the engine block. It is on the front.
The transmission number is on a
label on top of the transmission.
ENGINE NUMBER
AUTOMATIC TRANSMISSION NUMBER
Identification Numbers
577
Technical Information

Dimensions
Length 191.6 in (4,867 mm)
Width 78.5 in (1,994 mm)
Height 68.2 in (1,733 mm)
Wheelbase 108.3 in (2,750 mm)
Track Front 67.7 in (1,720 mm)
Rear 67.5 in (1,715 mm)
Weights
Gross vehicle weight rating See the tire information label
attached to the driver's doorjamb.
Gross combined weight
ᤳ1
rating (GCWR)10,053 lbs (4,560 kg)
ᤳ1: The GCWR must be reduced 2 percent for every 1,000 feet (305
meters) of elevation.
Air Conditioning
Refrigerant type HFC-134a (R-134a)
Charge quantity 21.2－22.9 oz (600－650 g)
Lubricant type ND-OIL 8
Seating Capacities
Total 7
Front 2
Second 3
Third 2Capacities
Fuel tank Approx.
21.00 US gal (79.5 L)
Engine
coolantChange
ᤳ1
1.93 US gal (7.3 L)
Total 2.43 US gal (9.2 L)
Engine oil Change
ᤳ2
4.5 US qt (4.3 L)
Including
filter
Without
filter4.2 US qt (4.0 L)
Total 5.3 US qt (5.0 L)
Automatic
transmission
fluidChange 3.3 US qt (3.1 L)
Total 8.5 US qt (8.0 L)
Rear
differential
fluidChange 2.6 US qt (2.5 L)
Total 3.0 US qt (2.8 L)
Transfer
assembly
fluidChange 0.4 US qt (0.4 L)
Total 0.4 US qt (0.4 L)
Windshield
washer
reservoirU.S. vehicles 4.2 US qt (4.0 L)
Canadian
vehicles6.1 US qt (5.8 L)
ᤳ1: Including the coolant in the reserve tank and that remaining in the
engine
Reserve tank capacity:
0.18 US gal (0.7 L)
ᤳ2: Excluding the oil remaining in the engine
Specifications578

Lights
Headlights High 60 W (HB3)
Low
ᤳ1
35 W (D2S)
Daytime running lights 60 W (HB3)
Front side marker lights 3 CP
Front turn signal lights 21 W (Amber)
Parking lights 3 CP
Stop/Tail lights LED
ᤳ2
Side turn signal lights LED
ᤳ2
Fog lights 55 W (H11)
Rear turn signal lights 21 W
Rear side marker lights 3 CP
Backup lights 18 W
High-mount brake light LED
ᤳ2
License plate lights 3 CP
Tailgate lights 5 W
Vanity mirror lights 2 W
Door lights 3.4 W
Glove box light 1.4 W
Foot light 3.4 W
ᤳ1: The low beam headlights are high voltage discharged type.
Replacement of a low beam headlight bulb should be performed by
your dealer.
ᤳ2: Replacement of a light bulb should be done by your dealer.Battery
Capacity 12 V－65AH/5 HR
12 V－76AH/20 HR
Fuses
Interior See page 571 or the fuse label attached
to the inside of the fuse box lid.
Rear See page 570 or the fuse label attached
to the inside of the fuse box lid.
Under-hood See page 569 and 570 or the fuse box
cover.
Engine
Type Water-cooled, 4-stroke SOHC VTEC V6
gasoline engine
Bore x Stroke 3.54 x 3.78 in (90.0 x 96.0 mm)
Displacement 223.5 cu-in (3,664 cm
3)
Compression ratio 11.2 : 1
Spark plugs DENSO:
NGK:SXU22HCR11S
ILZKR7B11S
Alignment
Toe-in Front 0.00 in (0.0 mm)
Rear 0.08 in (2.0 mm)
Camber Front－0°30’
Rear－0°30’
Caster Front 4 ° 12’
Specifications
579
Technical Information

Tires
Size Front/Rear 255/55R18 105H
ᤳ1
P255/50R19 103H
ᤳ2
Spare T165/80D17 104M
Pressure Front/Rear 32 psi (220 kPa, 2.2 kgf/cm
2)
Spare 60 psi (420 kPa, 4.2 kgf/cm2)
ᤳ1: MDX, Technology Package, and U.S. Technology Package with
Entertainment models
ᤳ2: U.S. Advance Package, Advance Package with Entertainment, and
Canadian Elite Package models
Specifications580

The tires on your vehicle meet all U.
S. Federal Safety Requirements. All
tires are also graded for treadwear,
traction, and temperature
performance according to
Department of Transportation (DOT)
standards. The following explains
these gradings.
Uniform Tire Quality Grading
Quality grades can be found where
applicable on the tire sidewall
between tread shoulder and
maximum section width. For
example:
Treadwear 200
Traction AA
Temperature A
All passenger car tires must conform
to Federal Safety Requirements in
addition to these grades.Treadwear
The treadwear grade is a
comparative rating based on the wear
rate of the tire when tested under
controlled conditions on a specified
government test course. For
example, a tire graded 150 would
wear one and one-half (1 1/2) times
as well on the government course as
a tire graded 100. The relative
performance of tires depends upon
the actual conditions of their use,
however, and may depart
significantly from the norm due to
variations in driving habits, service
practices and differences in road
characteristics and climate.Traction
The traction grades, from highest to
lowest, are AA, A, B, and C. Those
grades represent the tire's ability to
stop on wet pavement as measured
under controlled conditions on
specified government test surfaces of
asphalt and concrete. A tire marked
C may have poor traction
performance.
Warning: The traction grade
assigned to this tire is based on
straight-ahead braking traction tests,
and does not include acceleration,
cornering, hydroplaning, or peak
traction characteristics.
CONTINUED
DOT Tire Quality Grading (U.S. Vehicles)
581
Technical Information

Temperature
The temperature grades are A (the
highest), B, and C, representing the
tire's resistance to the generation of
heat and its ability to dissipate heat
when tested under controlled
conditions on a specified indoor
laboratory test wheel. Sustained high
temperature can cause the material
of the tire to degenerate and reduce
tire life, and excessive temperature
can lead to sudden tire failure. The
grade C corresponds to a level of
performance which all passenger car
tires must meet under the Federal
Motor Vehicle Safety Standard No.
109. Grades B and A represent
higher levels of performance on the
laboratory test wheel than the
minimum required by law.Warning: The temperature grade for
this tire is established for a tire that
is properly inflated and not
overloaded. Excessive speed,
underinflation, or excessive loading,
either separately or in combination,
can cause heat buildup and possible
tire failure.DOT Tire Quality Grading (U.S. Vehicles)582

The tires that came on your vehicle
have a number of markings. Those
you should be aware of are described
below.
Tire SizeWhenever tires are replaced, they
should be replaced with tires of the
same size. Following is an example
of tire size with an explanation of
what each component means.
P255/50R19 103H
P－Vehicle type (P indicates
passenger vehicle).
255－Tire width in millimeters.
50－Aspect ratio (the tire's
section height as a
percentage of its width).
R－Tire construction code (R
indicates radial).
19－Rim diameter in inches.103－Load index (a numerical code
associated with the
maximum load the tire can
carry).
H－Speed symbol (an
alphabetical code indicating
the maximum speed rating).
Tire Identification Number (TIN)The tire identification number (TIN)
is a group of numbers and letters that
look like the following example. TIN
is located on the sidewall of the tire.
DOT B97R FW6X 2202
DOT－This indicates that the tire
meets all requirements of
the U.S. Department of
Transportation.
B97R－Manufacturer's
identification mark.
TIRE LABELING EXAMPLE
(1) Tire Size
(2) Tire Identification Number (TIN)
(3) Maximum Tire Pressure
(4) Maximum Tire Load(4)
(3) (2)(1)
(1)
CONTINUED
Tire Labeling
583
Technical Information
