TPMS Acura RDX 2013 User Guide

307
uuChecking and Maintaining Tires uTire and Wheel Replacement
Maintenance
Tire and Wheel ReplacementReplace your tires with radials of the same size, load range, speed rating, and
maximum cold tire pressure rating (as shown on the tire’s sidewall). Using tires of \
a
different size or construction can cause the ABS, VSA ® (vehicle stability assist), hill
start assist, and the AWD (All-Wheel Drive) with intelligent control system
* to work
incorrectly.
It is best to replace all four tires at the same time. If that isn’t possible, replace the
front or rear tires in pairs.
If you replace a wheel, only use TPMS specified wheels approved for your vehicle.
Make sure that the wheel’s specifications match those of the original wheels.
1 Tire and Wheel Replacement
3
WARNING
Installing improper tires on your vehicle can
affect handling and stability. This can cause
a crash in which you can be seriously hurt or
killed.
Always use the size and type of tires
recommended in this owner’s manual.
* Not available on all models

317
Handling the Unexpected
This chapter explains how to handle unexpected troubles.
Tools
Types of Tools .................................. 318
If a Tire Goes Flat Changing a Flat Tire ......................... 319
Engine Does Not Start Checking the Engine ........................ 325
If the Keyless Access Remote Battery is Weak ............................................. 326
Emergency Engine Stop ................... 327
Jump Starting .................................... 328
Shift Lever Does Not Move .............. 330Overheating
How to Handle Overheating............. 331
Indicator, Coming On/Blinking
If the Low Oil Pressure Indicator Comes On ............................................. 333If the Charging System Indicator Comes
On ................................................. 333
If the Malfunction Indicator Lamp Comes On or Blinks ................................... 334If the Brake System Indicator (Red) Comes On .................................................... 335If the EPS System Indicator Comes On...... 335
If the Low Tire Pressure/TPMS Indicator
Comes On or Blinks ....................... 336
Fuses Fuse Locations ................................. 337
Inspecting and Changing Fuses ........ 339
Emergency Towing ........................... 340When You Cannot Open the Tailgate
..... 341

uuIf a Tire Goes Flat uChanging a Flat Tire
324Handling the Unexpected
1. Store the jack in its holder. Turn the jack’s
end bracket to lock it in place.
2. Remove the center cap.
3. Place the flat tire face up in the spare tire
well.
4. Remove the spacer cone from the wing bolt
for the spare tire, and insert the wing bolt
for the normal tire back on the bolt. Secure
the flat tire with the wing bolt.
5. Securely store the wheel nut wrench and
jack handle bar back in the cargo area.
If you replace a flat tire with the spare tire, the low tire pressure/TPMS indicator
comes on while you are driving. After driving for a few miles (kilometers), the
indicator will start blinking for a short time and then stay on. CHECK TPMS
SYSTEM appears on the multi-information display, but this is normal.
If you replace the tire with a specified regular tire, the warning message on the
multi-information display and the low tire pressure/TPMS indicator will go off after
a few miles (kilometers).
■
Storing the Flat Tire
1 Storing the Flat Tire
3
WARNING
Loose items can fly around the interior in a
crash and can seriously injure the
occupants.
Store the wheel, jack, and tools securely
before driving.
Spacer
ConeWing
Bolt
For compact spare tire For normal tire
■
TPMS and the Spare Tire
1
TPMS and the Spare Tire
The system cannot monitor the pressure of the spare
tire. Manually check the spare tire pressure to be sure
that it is correct.
Use TPMS specific wheels. Each is equipped with a
tire pressure sensor mounted inside the tire behind
the valve stem.

336
uuIndicator, Coming On/Blinking uIf the Low Tire Pressure/TPMS Indicator Comes On or Blinks
Handling the Unexpected
If the Low Tire Pressure/TPMS Indicator Comes On or Blinks
■
Reasons for the indicator to come on or blink
A tire pressure is significantly low. If there is a problem with the TPMS or
the compact spare tire is installed, the indicator blinks for about one
minute, and then stays on.
■
What to do when the indicator comes on
Stop your vehicle in a safe place. Check the tire pressure and adjust the
pressure to the specified level. The specified tire pressure is on a label on
the driver side doorjamb.
■
What to do when the indicator blinks
Have the tire inspected by a dealer as soon as possible. If the compact
spare tire has triggered the indicator to blink, change the tire to a full-
size tire. The indicator goes off after a while.
1 If the Low Tire Pressure/TPMS Indicator Comes On or Blinks
NOTICEDriving on an extremely underinflated tire can cause
it to overheat. An overheated tire can fail. Always
inflate your tires to the prescribed level.

338
uuFuses uFuse Locations
Handling the Unexpected
Located under the dashboard.
Fuse locations are shown on the label on
the side panel.
Locate the fuse in question by the fuse
number and label number.■
Circuit protected and fuse rating
■
Interior Fuse BoxFuse Label
Fuse Box
Circuit Protected
Amps
1
−
−
2
ACG
15 A
3
SRS
10 A
4
Fuel Pump
15 A
5
Meter
7.5 A
6
Option
7.5 A
7
VB SOL
10 A
8
Front Right Side
Door Lock Motor (Unlock)
15 A
9
Rear Left Side
Door Lock Motor (Unlock)
15 A
10 Power Lumbar 7.5 A
11
Moonroof
20 A
12 Accessory Power Socket
(Center Console) 15 A
13
Washer Main
15 A
14 Seat Heaters 15 A
15
Driver’s Door Lock Motor (Unlock)
10 A
16 − −
17
−
−
18 − −
19
ACC
7.5 A
20 ACC Key Lock 7.5 A
21
Daytime Running Lights
7.5 A
22 A/C 7.5 A
23
Rear Wiper
10 A
24 ABS/VSA 7.5 A
25
−
−
26 Audio Amp 20 A
27
Accessory Power Socket (Front)
15 A
28 − −
29
ODS
7.5 A
30 Driver’s Door Lock Motor
(Lock) 10 A
Circuit Protected
Amps
31
Smart
10 A
32 Front Right Side
Door Lock Motor (Lock) 15 A
33
Rear Left Side
Door Lock Motor (Lock)
15 A
34 Small Lights 7.5 A
35
Illumination
7.5 A
36 Rear Wiper Main 10 A
37
−
−
38 Left Headlight High Beam 10 A
39
Right Headlight High Beam
10 A
40 TPMS 7.5 A
41
Door Lock
20 A
42 Driver’s Power Window 20 A
43
Rear Right Side Power Window
20 A
44 Front Right Side Power
Window 20 A
45
Rear Left Side Power
Window
20 A
46 Wiper 30 A
Circuit Protected
Amps

347Information
Devices that Emit Radio WavesThe following products and systems on your vehicle emit radio waves when in operation.Each of the above complies with the appropriate requirements or the required
standards of FCC (Federal Communications Commission) and Industry Canada
Standard, described below:As required by the FCC:
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.This device complies with Industry Canada Standard RSS-Gen/210/310. Operation is
subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.Audio SystemBluetooth ® AudioBluetooth ® HandsFreeLink ®HomeLink® Universal TransceiverImmobilizer SystemRemote TransmitterKeyless Access SystemTire Pressure Monitoring System (TPMS)

358Index
Gear Shift Lever PositionsAutomatic Transmission ........................... 244
Glass (care) ................................................ 316
Glove Box .................................................. 145HHalogen Bulbs ................................... 287, 289
Handling the Unexpected ........................ 317
HandsFreeLink ® (HFL) ............................... 196
Automatic Import of Cellular Phonebook and Call History ............................................ 212
Automatic Transferring ............................ 210
Caller’s ID Information ............................. 210
HFL Buttons ............................................. 196
HFL Menus .............................................. 198
HFL Status Display.................................... 197
Making a Call .......................................... 215
Options During a Call .............................. 219
Phone Setup ............................................ 203
Receiving a Call ....................................... 218
Speed Dial ............................................... 213
Text Message................................... 208, 220
To Clear the System ................................. 211
To Create a Security PIN........................... 209
Hazard Warning Button ............................... 2
Head Restraints ......................................... 138
Headlights ................................................. 122
Aiming .................................................... 287
Automatic Operation ............................... 123
Dimming ......................................... 122, 125 Operating................................................ 122
Heaters (Seat) ........................................... 151
HFL (HandsFreeLink ®)............................... 196
High Beam Indicator .................................. 74
Hill Start Assist System ............................. 241
HomeLink ® Universal Transceiver ............ 194
IIdentification Numbers ............................ 346
Engine and Transmission ......................... 346
Vehicle Identification .............. ................. 346
Illumination Control ................................. 128
Knob ....................................................... 128
Immobilizer System .................................. 113
Indicator.................................................... 75
Indicators .................................................... 68
ABS (Anti-lock Brake System)..................... 71
AWD System ............................................. 72
Brake System............................................. 68
Charging System ............................... 69, 333
CRUISE CONTROL ............................. 76, 249
CRUISE MAIN .................................... 76, 248
Door Open .......................................... 28, 73
EPS (Electric Power Steering) System .. 74, 335
Fog Light ................................................... 75
High Beam ................................................ 74
Immobilizer System ................................... 75
Lights On .................................................. 75
Low Fuel ................................................... 71
Low Oil Pressure ................................ 69, 333 Low Tire Pressure/TPMS ............................ 74
Maintenance Minder............................... 271
Malfunction Indicator Lamp .............. 69, 334
Parking Brake and Brake System ....... 68, 335
Seat Belt Reminder.............................. 30, 71
Security System Alarm............................... 76
Shift Lever Position.................................... 70
Side Airbag Off ................................... 50, 75
Supplemental Restraint System ........... 48, 72
System Message ....................................... 76
Transmission ............................................. 70
Turn Signal ............................................... 74
VSA
® (Vehicle Stability Assist)
System ............................................ 73, 251
VSA ® OFF.......................................... 73, 252
Information .............................................. 343
Instrument Panel ........................................ 67
Brightness Control .................................. 128
Interior Lights ........................................... 143
Interior Rearview Mirror ......................... 133
iPod ®......................................................... 174
JJack (Wheel Nut Wrench) ........................ 322
Jump Starting ........................................... 328

361
Index
Shifting (Transmission)............................ 244
Shoulder Anchor ........................................ 33
Side Airbags ............................................... 44
Cutoff System ........................................... 46
Off Indicator ............................................. 46
Side Curtain Airbags .................................. 47
SMS Text Message ............................ 208, 220
Snow Tires ................................................ 309
Spare Tire ......................................... 319, 345
Spark Plugs ............................................... 344
Specifications ........................................... 344
Specified Fuel ................................... 263, 344
Speedometer .............................................. 82
SRS Airbags (Airbags) ................................ 40
Starting the Engine .................................. 240
Does Not Start ........................................ 325
Jump Starting ......................................... 328
Steering Wheel ........................................ 132
Adjusting ................................................ 132
Stopping ................................................... 261
Summer Tires ............................................ 309
Sunglasses Holder .................................... 150
Supplemental Restraint System (SRS) ....... 40
Switches (Around the Steering Wheel) ........ 2, 3, 119
Synchronized Mode ................................. 154
System Message Indicator ......................... 76
TTachometer................................................. 82
Tailgate ..................................................... 107
Unable to Open ....................................... 341
Temperature Outside Temperature Display ..................... 85
Temperature Gauge ................................... 82
Temperature Sensor ........................... 85, 155
Text Message .................................... 208, 220
Time (Setting) ............................................. 96
Tire Pressure Monitoring System (TPMS) ..................................................... 253
Indicator ............................................ 74, 336
Tires ........................................................... 301
Air Pressure ..................................... 302, 345
Checking and Maintaining....................... 301
Inspection................................................ 301
Labeling .................................................. 302
Puncture (Flat Tire)................................... 319
Regulations ............................................. 304
Rotation .................................................. 308
Spare Tire ........................................ 319, 345
Summer .................................................. 309
Tire Chains .............................................. 309
Wear Indicators ....................................... 306
Winter ..................................................... 309
Tools .......................................................... 318
Towing a Trailer ....................................... 233
Equipment and Accessories ..................... 234
Load Limits .............................................. 233 Towing Your Vehicle
................................ 237
Emergency .............................................. 340
TPMS (Tire Pressure Monitoring System) ........ 253
Indicator............................................ 74, 336
Transmission ............................................. 244
Automatic ............................................... 244
Fluid ........................................................ 284
Number................................................... 346
Sequential Shift Mode ............................. 246
Shift Lever Position Indicator.............. 70, 245
Trip Meter ................................................... 85
Troubleshooting ....................................... 317
Blown Fuse...................................... 337, 338
Brake Pedal Vibrates .................................. 18
Buzzer Sounds When Opening Door.......... 19
Emergency Towing .................................. 340
Engine Won’t Start .................................. 325
Noise When Braking .................................. 20
Overheating ............................................ 331
Puncture/Flat Tire .................................... 319
Rear Door Won’t Open...................... 19, 105
Select Lever Won’t Move ......................... 330
Warning Indicators .................................... 68
Turn Signals .............................................. 122
Indicators (Instrument Panel) ..................... 74
