uuIndicator, Coming On/Blinking uIf the Low Tire Pressure/TPMS Indicator Comes On or Blinks
Handling the Unexpected
If the Low Tire Pressure/TPMS Indicator Comes On or
Blinks
■Reasons for the indicator to come on or blink
A tire pressure is significantly low.
If there is a problem with the TPMS, the indicator blinks for about one
minute, and then stays on.
If the compact spare tire
* is installed, the indicator will either come on or
it will first blink for abou t one minute, then stay on.
■What to do when the indicator comes on
Drive carefully and avoid abrupt cornering and hard braking.
Stop your vehicle in a safe place. Ch eck the tire pressure and adjust the
pressure to the specified level. The sp ecified tire pressure is on a label on
the driver side doorjamb.
If the compact spare tire
* causes the indicator to come on, change the
tire to a full-size tire.
■What to do when the indicator blinks
Have the tire inspected by a dealer as soon as possible. If the compact
spare tire
* causes the indicator to first b link, and then stay on, change
the tire to a full-size tire. The indi cator goes off after driving for a few
miles (kilometers).
1 If the Low Tire Pressure/TPMS Indicator Comes On or Blinks
NOTICE
Driving on an extremely unde rinflated tire can cause
it to overheat. An overheated tire can fail. Always
inflate your tires to the prescribed level.
TPMS with Tire Fill Assist provides visual and audible
assistance during tire pre ssure adjustment. With the
power mode in ON, while y ou adjust tire pressure up
or down, the system alerts you as follows:
Below recommended pressure: The beeper
sounds and exterior lights flash once every five
seconds.
At recommended pressure: The beeper sounds
and exterior lights flash ra pidly for three seconds with
five seconds intervals.
Above recommended pressure: The beeper
sounds and lights flash tw ice every two seconds.
* Not available on all models
22 ACURA RDX-31TJB6300.book 672 ページ ２０２１年８月２日 月曜日 午前１１時０分
Page 689 of 709
687
uuSpecifications u
Information
■
Brake Fluid
■ Automatic Tran smission Fluid
*1: 2WD models
*2: AWD models
■
Rear Differential Fluid*
■Transfer Assembly Fluid*
SpecifiedAcura Heavy Duty Brake Fluid DOT 3
SpecifiedAcura ATF-type 2.0
Capacity Change 4.5 US qt (4.3 L)*1
5.1 US qt (4.8 L)*2
SpecifiedAcura DPSF-II
Capacity Change 1.76 US qt (1.67 L)
SpecifiedAcura HGO-1
Capacity Change 0.61 US qt (0.58 L)
■ Engine Oil
■ Engine Coolant
Recommended·Acura Genuine Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil
Capacity Change 4.6 US qt (4.4 L)
Change
including
filter
5.0 US qt (4.8 L)
SpecifiedAcura Long Life Antifreeze/Coolant Type 2
Ratio 50/50 with distilled water
Capacity1.43 US gal (5.40 L)
(change including the remaining 0.23 US gal
(0.86 L) in the reserve tank)
■ Tire
*1: Models with 19 inch wheel
*2: Models with 20 inch wheel
RegularSize235/55R19 101H*1
255/45R20 101V*2
Pressure
psi (kPa [kgf/cm2])33 (230 [2.3])*1
36 (250 [2.5])*2
Compact
Spare*
Size T155/90D17 101M
Pressure
psi (kPa [kgf/cm
2]) 60 (420 [4.2])
Wheel SizeRegular19 x 8J*1
20 x 8J*2
Compact Spare*17 x 4T
* Not available on all models
22 ACURA RDX-31TJB6300.book 687 ページ ２０２１年８月２日 月曜日 午前１１時０分
Page 701 of 709
699
Index
Sequential Shift Mode............................. 457
Shifting ................................................... 451
Average Fuel Economy ............................ 141
AWD ......................................................... 474
B
Battery ...................................................... 621
Charging System Indicator ................ 87, 668
If the Battery Is Dead............................... 663
Maintenance (Checking the Battery) ....... 621
Belts (Seat) .................................................. 37
Beverage Holders ..................................... 235
Blind Spot Information System ............... 479
Bluetooth ® Audio ..................................... 316
Bluetooth ® HandsFreeLink ®................... 389
Booster Seats (For Children) ...................... 76
Brake System ............................................ 545
Anti-lock Brake System (ABS) .................. 552
Automatic Brake Hold ............................. 550
Brake Assist System................................. 553
Fluid ....................................................... 601
Foot Brake .............................................. 549
Indicator ............................... 81, 82, 83, 669
Indicator (Red) ........................................ 671
Parking Brake.......................................... 545
Brightness Control (Instrument Panel) ... 208
Built-in Key ............................................... 157
Bulb Replacement .................................... 603
Fog Lights ............................................... 603 Front Turn Signal,
Parking/Daytime
Running and Front Side Marker Lights ... 603
Headlights ............................................... 603
High-Mount Brake Light .......................... 606
Puddle Lights ........................................... 606
Rear License Plate Light ........................... 606
Rear Turn Signal Light Bulbs .................... 604
Side Turn Signal/Em ergency Indicator
Lights .................................................... 603
Taillights, Brake and Rear Side Marker
Lights .................................................... 605
Taillights/Brake and Back-Up Lights .......... 606
Bulb Specifications ................................... 686
C
CAMERA Button....................................... 567
Carbon Monoxide Gas ................................ 77
Carrying Cargo .................................. 431, 433
Certification Label .................................... 688
Changing Bulbs ......................................... 603
Charging System Indicator ................. 87, 668
Child Safety ................................................. 64
Childproof Door Locks ............................. 171
Child Seat .................................................... 64
Booster Seats ............................................. 76
Child Seat for Infants ................................. 66
Child Seat for Small Children ..................... 67
Installing a Child Seat with a Lap/Shoulder Seat Belt .................................................. 71
Larger Children .......................................... 75 Rear-facing Child Seat ............................... 66
Selecting a Child Seat ................................ 68
Childproof Door Locks ............................. 171
Cleaning the Exterior ............................... 629
Cleaning the Interior ................................ 627
Client Service Information ....................... 697
Climate Control System ............................ 247
Changing the Mode ................................ 247
Defrosting the Windshield and Windows ............................................... 249
Dust and Pollen Filter............................... 626
Rear Temperature Control Dial ................ 251
Recirculation/Fresh Air Mode ................... 247
Sensors ................................................... 252
Synchronized Mode................................. 250
Using Automatic Climate Control ............ 247
Clock .......................................................... 154
CMBSTM (Collision Mitigation Braking
SystemTM) ................................................. 486
Coat Hook ................................................. 237
Collision Mitigation Braking System
TM
(CMBSTM) ................................................. 486
Compact Spare Tire .......................... 637, 687
Console Compartment ............................. 234
Controls ..................................................... 153
Coolant (Engine) ...................................... 598
Adding to the Radiator ............................ 599
Adding to the Reserve Tank..................... 598
Overheating ............................................ 665
Creeping (Automatic Transmission) ........ 450
Cross Traffic Monitor ............................... 560
22 ACURA RDX-31TJB6300.book 699 ページ ２０２１年８月２日 月曜日 午前１１時０分
Page 702 of 709
700
Index
Cup Holders............................................... 235
Customized Features ................................ 359
D
Daytime Running Lights ........................... 200
Dead Battery ............................................. 663
Defaulting All the Settings ...................... 385
Defrosting the Windshield and Windows .................................................. 249
Devices that Emit Radio Waves ................ 689
Dimming Headlights ............................................... 197
Rearview Mirror ....................................... 213
Dipstick (Engine Oil) ................................. 594
Directional Signals (Turn Signal) .............. 196
Door Mirrors ............................................. 214
Doors ......................................................... 156
Auto Door Locking .................................. 172
Auto Door Unlocking ............................... 172
Keys ........................................................ 156
Locking/Unlocking the Doors from the Inside ..................................................... 169
Locking/Unlocking the Doors from the
Outside .................................................. 160
Lockout Prevention System ...................... 167
DOT Tire Quality Grading ........................ 615
Driving ....................................................... 429
Automatic Transmission ........................... 450
Braking .................................................... 545
Off-Highway Driving Guidelines ............... 441 Shifting Gear ........................................... 451
Starting the Engine.................................. 443
Driving Position Memory System ............ 210
Dust and Pollen Filter ............................... 626
Dynamic Mode Switch ............................. 460
E
Electric Parking Brake
Switch ..................................................... 545
Electric Power Steering (EPS) System Indicator............................................ 95, 670
Electronic Stability Control (ESC) ............. 471
Emergency ................................................ 681
Emissions Testing (Readiness Codes) ....... 691
Engine ....................................................... 688
Coolant ................................................... 598
If the Battery Is Dead ............................... 663
Oil ........................................................... 593
Remote Engine Start................................ 445
Starting ................................................... 443
Engine Compartment Cover .................... 592
Engine Coolant ......................................... 598
Adding to the Radiator ............................ 599
Adding to the Reserve Tank..................... 598
Overheating ............................................ 665
Temperature Gauge ................................ 136
Engine Oil ................................................. 593
Adding .................................................... 595
Checking................................................. 594
Displaying Oil Life .................................... 584 Engine Oil Pressure Low Warning ............ 667
Recommended Engine Oil ....................... 593
ENGINE START/STOP Button .................... 193
EPS (Electric Power Steering) System ...... 670
Exhaust Gas Hazard (Carbon Monoxide) .. 77
Exterior Care (Cleaning) .......................... 629
Exterior Mirrors ........................................ 214F
Features.................................................... 253
Filters Dust and Pollen....................................... 626
Oil .......................................................... 596
Flat Tire ............................................. 637, 645
Floor Mats ................................................ 628
Fluids Automatic Transmission .......................... 600
Brake ...................................................... 601
Engine Coolant ....................................... 598
Windshield Washer ................................. 602
FM/AM Radio ........................................... 293
Fog Lights Indicator ................................................... 98
Folding Down the Rear Seats .................. 222
Foot Brake ................................................ 549
Front Airbags (SRS) .................................... 49
Front Seats ................................................ 216
Adjusting ................................................ 216
Front Sensor Camera ............................... 541
22 ACURA RDX-31TJB6300.book 700 ページ ２０２１年８月２日 月曜日 午前１１時０分
Page 704 of 709
702
Index
Indicators..................................................... 80
Adaptive Cruise Control (ACC) with Low
Speed Follow (Amber) ............................ 102
Adaptive Cruise Control (ACC) with Low Speed Follow (White/Green) ... 102, 503
Anti-lock Brake System (ABS) ..................... 94
Auto High-Beam ........................................ 98
Auto Idle Stop (Green) ............................... 90
Auto Idle Stop OFF..................................... 90
Auto Idle Stop Suspend ................. 90, 91, 92
Auto Idle Stop System (Amber) .................. 90
Automatic Brake Hold........................ 85, 550
Automatic Brake Hold System ............ 85, 550
Charging System ............................... 87, 668
Cruise Mode (White/Green) ..................... 101
Electric Power Steering (EPS) System .. 95, 670
Engine Oil Pressure Low Warning............. 667
Fog Light ................................................... 98
Gear Position ............................................. 87
High Beam................................................. 98
Immobilizer System .................................... 99
Lane Keeping Assist System (LKAS) (Amber) ................................................. 102
Lane Keeping Assist System (LKAS) (White/Green) ........................................ 102
Lights On ................................................... 98
Low Fuel (Amber) ...................................... 94
Low Tire Pressure/TPMS ..................... 97, 672
M (sequential mode ) Indicator/Gear
Selection Indicator ................................... 87
Maintenance Minder ............................... 101 Malfunction Indicator Lamp............... 86, 668
Parking Brake a
nd Brake System
(Amber) ........................................... 83, 671
Parking Brake and Brake System (Red)...................... 81, 82, 669, 671
Safety Support (Amber) ........... 103, 104, 105
Safety Support (Green/Gray) .................... 106
Seat Belt Reminder .............................. 39, 93
Security System Alarm ............................... 99
Super Handling-All Wheel Drive
TM
(SH-AWD ®) ............................................ 101
Supplemental Restraint System ............ 60, 95
System Message ...................................... 100
Transmission System.......................... 88, 673
Turn Signal and Hazard Warning ............... 98
Vehicle Stability Assist
TM (VSA ®) OFF .......... 96
Vehicle Stability AssistTM (VSA ®)
System ............................................ 96, 471
VSA ® OFF ................................................ 472
Information .............................................. 685
Instant Fuel Economy ............................... 141
Instrument Panel ........................................ 79
Brightness Control................................... 208
Interior Lights ........................................... 230
Interior Rearview Mirror .......................... 213
iPad ........................................................... 337
iPhone ....................................................... 337
iPod ................................................... 310, 337
J
Jack (Wheel Nut Wrench) ........................ 641
Jump Starting ........................................... 663
K
Key Number Tag ...................................... 158
Keyless Access System .............................. 160
Keyless Lockout Prevention ..................... 167
Keys ........................................................... 156
Lockout Prevention ................................. 167
Number Tag............................................ 158
Rear Door Won’t Open ........................... 171
Remote Transmitter ................................ 165
Two-way Keyless Remote ........................ 168
Types and Functions................................ 156
Kickdown (Automatic Transmission) ...... 450
Knee Airbags .............................................. 54
L
Lane Keeping Assist System (LKAS) ........ 522
LATCH (Child Seats) ............................. 69, 73
Legal Information .................................... 351
License Information ................................. 354
Lights ................................................ 197, 603
Automatic............................................... 198
Bulb Replacement ................................... 603
Daytime Running Lights .......................... 200
Fog Lights ............................................... 200
High Beam Indicator ................................. 98
22 ACURA RDX-31TJB6300.book 702 ページ ２０２１年８月２日 月曜日 午前１１時０分
Page 705 of 709
703
Index
Interior.................................................... 230
Light Switches......................................... 197
Lights On Indicator.................................... 98
Turn Signals and Hazard Warning ........... 196
Load Limits ............................................... 433
Locking/Unlocking ................................... 156
Auto Door Locking/Unlocking ................. 172
Childproof Door Locks ............................ 171
From Inside ............................................. 169
From Outside .......................................... 160
Keys........................................................ 156
Using a Key............................................. 166
Lockout Prevention System ..................... 167
Low Battery Charge ................................. 668
Low Fuel Indicator ..................................... 94
Low Speed Braking Control .................... 497
Lower Anchors ..................................... 69, 73
Luggage (Maximum Load Limit) ............. 433
Lumbar Support ....................................... 216
M
Maintenance.................................... 142, 579
Battery .................................................... 621
Brake Fluid .............................................. 601
Cleaning ................................................. 627
Climate Control System .......................... 625
Coolant .................................................. 598
Maintenance Minder
TM............................ 583
Oil .......................................................... 594
Precautions ............................................. 580 Radiator .................................................. 599
Remote Transmitter ......................... 623, 624
Replacing Light Bulbs ............................... 603
Safety ...................................................... 581
Service Items ........................................... 587
Tires ........................................................ 612
Transmission Fluid ................................... 600
Under the Hood ...................................... 590
Malfunction Indicator Lamp .............. 86, 668
Map Lights ................................................ 231
Maximum Load Limit ............................... 433
Meters, Gauges ......................................... 136
Mirrors ....................................................... 213
Adjusting ................................................. 213
Door ........................................................ 214
Exterior .................................................... 214
Interior Rearview ..................................... 213
Modifications (and Accessories) .............. 633
MP3 ........................................................... 313
MP3/WMA/AAC ........................................ 313
Multi-Information Display ....................... 137
Switching the Display .............................. 139
Warning and Information Messages ........ 107
Multi-View Rear Camera .......................... 564
N
Navigation................................................ 141
Numbers (Identification) .......................... 688
O
Odometer................................................. 137
Off-Highway Driving Guidelines ............. 441
Oil (Engine) ............................................... 593
Adding .................................................... 595
Checking................................................. 594
Displaying Oil Life .................................... 584
Engine Oil Pressure Low Warning ............ 667
Recommended Engine Oil ............... 593, 687
Viscosity .......................................... 593, 687
Open Source Licenses ............................... 353
Opening/Closing Hood....................................................... 591
Panoramic Roof ....................................... 189
Power Windows ...................................... 186
Tailgate ................................................... 173
Outside Temperature Display .................. 137
Overheating .............................................. 665
P
Paddle Shifters (Sequential Shift
Mode) ...................................................... 457
Panic Mode ............................................... 185
Panoramic Roof ........................................ 189
Parking ...................................................... 554
Parking Brake ........................................... 545
Parking Brake and Brake System Indicator .................................................. 669
Parking Brake and Brake System
Indicator (Amber) ..................................... 83
22 ACURA RDX-31TJB6300.book 703 ページ ２０２１年８月２日 月曜日 午前１１時０分
Page 707 of 709
705
Index
Snow Tires................................................ 620
Sonar Sensors ........................................... 544
Spare Tire ......................................... 637, 687
Spark Plugs ............................................... 686
Specifications ........................................... 686
Specified Fuel ................................... 574, 686
Speed Limit Information ......................... 138
Speed/Distance Units ............................... 142
Speedometer ............................................ 136
Sport Gauge Settings ............................... 143
SRS Airbags (Airbags) ................................ 49
Starting Assist Brake Function ................ 470
Starting the Engine .................................. 443
Does Not Start ........................................ 660
If the Battery Is Dead............................... 663
Remote Engine Start ............................... 445
Steering Wheel ........................................ 212
Adjusting ................................................ 212
Stopping ................................................... 554
Summer Tires ............................................ 620
Sunglasses Holder .................................... 238
Super Handling-All Wheel Drive
TM
(SH-AWD ®).............................................. 474
Supplemental Restraint System (SRS) ....... 49
Surround View Camera System ............... 566
Switches (Around the Steering Wheel) ............................................ 6, 7, 193
Synchronized Mode ................................. 250
System Message Indicator ....................... 100
System Updates ........................................ 281
T
Tachometer............................................... 142
Tailgate ..................................................... 173
Unable to Open ....................................... 683
Temperature
Gauge ..................................................... 136
Outside Temperature Display ................... 137
Temperature Sensor ......................... 137, 252
Temporary Tire Repair Kit ........................ 646
Tie-down Anchors .................................... 237
Time (Setting) ........................................... 154
Tire Fill Assist ............................................ 672
Tire Pressure Monito ring System (TPMS)
with Tire Fill Assist .................................. 475
Indicator ............................................ 97, 672
Tire Repair Kit ........................................... 645
Tires ........................................................... 612
Air Pressure ..................................... 613, 687
Checking and Maintaining ....................... 612
Inspection ................................................ 612
Labeling .................................................. 613
Puncture (Flat Tire) ........................... 637, 645
Regulations ............................................. 615
Rotation .................................................. 619
Spare Tire ........................................ 637, 687
Summer .................................................. 620
Temporary Tire Repair Kit ........................ 646
Tire Chains .............................................. 620
Tire Repair Kit .......................................... 645
Wear Indicators ....................................... 617
Winter ..................................................... 620 Tools
.......................................................... 636
Towing a Trailer ....................................... 435
Equipment and Accessories ..................... 437
Load Limits .............................................. 435
Towing Behind a Motorhome ................. 440
Emergency .............................................. 681
TPMS (Tire Pressure Monitoring System) with Tire Fill Assist .................................. 475
Indicator............................................ 97, 672
Traffic Sign Recognition System .............. 535
Transmission ....................................... 21, 451
Automatic ......................................... 21, 451
Fluid ........................................................ 600
Gear Position Indicator ...................... 87, 453
Indicator.................................................. 673
Number................................................... 688
Sequential Shift Mode ............................. 457
Transmission System Indicator.................................................... 88
Trip Computer .......................................... 140
Trip Meter ................................................. 140
22 ACURA RDX-31TJB6300.book 705 ページ ２０２１年８月２日 月曜日 午前１１時０分
