snow chains Acura RL 2000 3.5 Owner's Manual

Maintenanc
e

This section explains why it is important to keep your car well
maintained and to follow basic
maintenance safety precautions.
This section also includes Maintenance Schedules for normal
driving and severe driving conditions,
a Maintenance Record, and instruc-
tions for simple maintenance tasks
you may want to take care of
yourself.
If you have the skills and tools to per-
form more complex maintenance tasks on your Acura, you may want
to purchase the Service Manual. See
page 315 for information on how to obtain a copy, or see your Acura

dealer.
Maintenance Safety....................... 202
Important Safety Precautions.. 203
Maintenance Schedule.................. 204
Required Maintenance Record.... 211
Owner Maintenance Checks........ 213
Fluid Locations............................... 214

Engine Oil....................................... 215 Adding Oil................................... 215
Recommended Oil..................... 215
Synthetic Oil............................... 216

Additives..................................... 216 Changing the Oil and Filter...... 217
Cooling System.............................. 219 Adding Engine Coolant............. 219Replacing Engine Coolant........ 221
Windshield Washers..................... 225
Automatic Transmission Fluid..... 226

Differential Oil............................... 227
Brake Fluid..................................... 227
Brake System............................. 228
Power Steering............................... 228
Hood Latch..................................... 229
Air Cleaner Element...................... 229 Spark Plugs..................................... 231 Replacement............................... 231
Specifications............................. 234 Battery............................................ 234
Wiper Blades.................................. 237
Air Conditioning System............... 239
Air Conditioning Filter.................. 240
Drive Belts...................................... 240
Timing Belt..................................... 241 Tires................................................ 241 Inflation....................................... 241
Inspection................................... 243
Maintenance............................... 244
Tire Rotation.............................. 244
Replacing Tires and Wheels.... 245
Wheels and Tires....................... 246
Winter Driving........................... 246
Snow Tires.............................. 247
Tire Chains............................. 247
Lights.............................................. 248 Replacing Bulbs......................... 250
Storing Your Car............................ 259

Maintenance

Tire
s

The ABS and VSA system work by comparing the speed of the wheels.
When replacing tires, use the same size originally supplied with the car.
Tire size and construction can affect wheel speed and may cause the system to work inconsistently.
If you ever need to replace a wheel,
make sure you use an identical style
aluminum alloy wheel that originally
came on your Acura. Replacement
wheels are available at your Acura
dealer.
Wheel
s an d Tire s
Wheels:16x 7 J J

Tires:

P215/60R1694 V
See page 301 for information about
DOT Tire Quality Grading.
Winte
r Drivin g

Tires that are marked "M
+ S" or
"All Season
" on the sidewall have an
all-weather tread design. They should be suitable for most winter
driving conditions. Tires without
these markings are designed for optimum traction in dry conditions.
They may not provide adequate performance in winter driving.For the best performance in snowy
or icy conditions, you should installsnow tires or tire chains. They may
be required by local laws under certain conditions.

Maintenanc e

Tire
s

Snow Tires
If you mount snow tires on your
Acura, make sure they are radial tires of the same size and load rangeas the original tires. Mount snow
tires on all four wheels to balance
your car's handling in all weather conditions. Keep in mind the traction
provided by snow tires on dry roads
may not be as high as your car's original equipment tires. You should
drive cautiously even when the roads
are clear. Check with the tire dealer
for maximum speed recommen-
dations.
Tire Chains
Because your Acura has limited tire
clearance, mount only SAE Class "S"
cable-type traction devices on the
front tires. Use traction devices only when required by driving conditionsor local laws. Make sure they are the
correct size for your tires.
Metal link-type "chains" should not
be used. No matter how tight they seem to be installed, they can come
into contact with the body and
suspension, causing serious damage. When installing cables, follow the
manufacturer's instructions and
mount them as tightly as you can.
Drive slowly with them installed. If
you hear them coming in contact with the body or chassis, stop andinvestigate. Make sure the cables are
installed tightly, and that they are
not contacting the brake lines or
suspension.

Remove them as soon as you begin driving on cleared roads.

Traction devices that are the wrong
size or improperly installed can damage your car's brake lines,
suspension, body, and wheels. Stop
driving if they are hitting any part of the car.
Maintenance

NOTIC
E

Compac
t Spar e Tir e

Your car has a compact spare tire that takes up less space. Use this spare tire as a temporary replace-
ment only. Get your regular tire
repaired or replaced and put back on
your car as soon as you can.
Check the inflation pressure of the
compact spare tire every time you
check the other tires. It should be
inflated to:6 0 ps i (42 0 kP a , 4. 2 kgf/cm 2)

Follow these precautions whenever
you are using the compact spare tire: Do not exceed 50 mph (80 km/h)
under any circumstances.
This tire gives a harsher ride and less traction on some road sur-
faces than the regular tire. Use
greater caution while driving on
this tire. Do not mount snow chains on the
compact spare.
The wheel of the compact spare
tire is designed especially to fit
your car. Do not use your spare
tire on another vehicle unless it is
the same make and model.
Turn off the VSA system (see page 190).Driving with the compact spare
tire may activate the VSA system.
The compact spare tire has a shorter
tread life than a regular tire. Replace
it when you can see the tread wear
indicator bars. The replacementshould be the same size and design
tire, mounted on the same wheel.
The compact spare tire is not designed to be mounted on a regular
wheel, and the compact wheel is not designed for mounting a regular tire.
Takin g Car e o f th e Unexpecte d INDICATO
R LOCATIO N MAR K
TREA D WEA R INDICATO R BA R

Inde
x

Steering Wheel
Adjustments................................. 71

Anti-theft Column Lock.............. 80
Position Memory....................... 100

Stereo Sound System.................... 134

Storing Your Car............................ 259
Sun Visor......................................... 113

Sunglasses Holder......................... 110

Supplemental Restraint
System............................. 9
,
43, 4
6

Service Precautions..................... 48

Servicing....................................... 48

SRS Indicator.......................... 45, 55

System Components.................... 43

Tensioners, Seat Belts................ 41
Synthetic Oil................................... 216
Tachometer...................................... 58
Taillights, Changing Bulbs in....... 254
Taking Care of the Unexpected .. 269
Tape Player ........................... 139, 154
Technical Descriptions
DOT Tire Quality Grading....... 301
Driving in Foreign Countries... 304 Emissions Control Systems...... 305
Oxygenated Fuels...................... 303
Three Way Catalytic Converter................................ 307
Vehicle Stability Assist (VSA) System..................................... 300
Temperature Gauge........................ 60
Tensioners, Seat Belts .................... 41
Tether Anchorage Points............... 39
Theft Deterrent System................ 163
Theft Protection............................. 162
Three Way Catalytic Converter... 307
Time, Setting the........................... 108
Timing Belt..................................... 241
Tire Chains..................................... 247
Tire, How to Change a Flat.......... 271
Tires................................................ 241 Air Pressure............................... 242Balancing.................................... 244
Checking Wear.......................... 243
Compact Spare........................... 270
DOT Tire Quality Grading....... 301
Inflation....................................... 241
Inspection................................... 243
Maintenance............................... 244
Replacing.................................... 245
Rotating....................................... 244

Snow............................................ 247

Specifications............................. 299

Tools, Tire Changing.................... 271

Torn Seat Belts................................ 42

Towing

A Trailer...................................... 194
By Emergency Wrecker........... 292

Transmission
Checkin g
Fluid Level,

Automatic............................... 226

Fluid Selection............................ 226

Identification Number............... 297

Shifting the Automatic.............. 180

Treadwear...................................... 301

Trip Meter........................................ 59

Trunk................................................. 86

Opening the.................................. 86

Open Monitor Light.................... 57

Turn Signals..................................... 66

CONTINUED
