If the AFS indicator comes on and
starts blinking while driving, pull to
the side of the road when it is saf e,
andturnoff theengine.If theAFS
indicator keeps blinking, or starts
blinking again while driving af ter
turning the ignition switch to the ON
(II) position, the AFS is not working
properly (see page ). Have the
AFS inspected by your dealer.
When the AFS indicator comes on,
you will also see a ‘‘CHECK
ADAPTIVE FRONT LIGHTING
SYSTEM’’ message on the multi-
inf ormation display (see page ).
Without AFS, your vehicle still has
normal lighting ability to continue
driving.
The adaptive f ront lighting system
(AFS) helps to improve visibility
during nighttime driving. The AFS
controls the aiming direction and
lighting distribution of the low
beams according to the amount of
turn applied to the steering wheel
during cornering or turning. Press
the AFS OFF switch to turn the AFS
on and off when the ignition switch
is in the ON (II) position and the
headlights are turned on.
69
78
If equippedAFS Indicator
A daptive Front L ighting System (A FS)
144
2009 RL

´
µ´ µ
Push the button between the center
vents to turn on the hazard warning
lights (f our-way f lashers). This
causes all f our outside turn signals
and both indicators in the instrument
panel to f lash. Use the hazard
warning lights if you need to park in
a dangerous area near heavy traffic,
or if your vehicle is disabled. Adjust the brightness of the
instrument panel by pressing the
or button. Press the button to
increase the brightness and the
button to decrease it. The brightness
can be set differently for when the
headlights are on, and when they are
off.
The level of brightness is shown on
the multi-information display while
you adjust it. It goes out 5 seconds
af ter you f inish adjusting.
Instrument Panel Brightness
Hazard Warning Button
Hazard Warning Button, Instrument Panel Brightness
146
ADJUSTMENT BUTTON
CANADA
U.S.
2009 RL

µ
µ
µ µ
The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), and START (III). Use this position
only to start the engine. The switch
returns to the ON (II) position when
you let go of the ignition switch.
To use the built-in key, you have to
remove the cover (see page ). This is the normal
ignition switch position when driving.
Several of the indicators on the
instrument panel come on as a test
when you turn the ignition switch
f rom the ACCESSORY (I) to the ON
(II) position.
If the f ront wheels are turned, the
anti-thef t lock may make it dif f icult
to turn the ignition switch. Firmly
turn the steering wheel to the left or
right as you turn the ignition switch.
You can insert or
remove the built-in key only in this
position. To turn the ignition switch
to the LOCK (0) position, the shift
lever must be in Park, and you must
push the knob or built-in key in slightly.
TheshiftlevermustbeinPark
bef ore you turn the ignition switch
knob to the LOCK (0) position or
remove the built-in key from the
ignition switch.
You can
operate the audio system and the
accessory power sockets in this
position.
When you turn the ignition switch to
the ACCESSORY (I) position, an
‘‘ACCESSORY (I) POSITION’’
message is shown on the multi-
inf ormation display. If you open the driver’s door and
leave the key in the ignition switch,
you will hear a reminder beeper, and
a message appears on the multi-
inf ormation display according to the
ignition switch position. When the
ignition switch is in the ACC (I)
position, a ‘‘RETURN IGNITION
SWITCH TO LOCK (0) POSITION’’
message is shown on the multi-
inf ormation display. When the
ignition switch is in the LOCK (0)
position, a ‘‘REMOVE KEY’’
message is shown on the multi-
inf ormation display.
180 ST A RT (III)
ON (II)
LOCK (0) A CCESSORY (I)
Ignition Switch
152
IGNITION SWITCH
COVER BUILT-IN KEY
2009 RL

When you push the ignition switch,
theremoteandthevehiclerecognize
each other. Af ter the recognition,
the remote indicator f lashes, and a
beeper sounds once. Af ter the beep,
turn the ignition switch.
When the remote is out of the
operating range, the ignition switch
is locked.
If the ignition switch cannot be
turned f rom the LOCK (0) position
to the ACCESSORY (I) position afterthe beep, the steering wheel is
locked. To unlock the steering wheel,
turn it right and lef t while turning
the ignition switch at the same time.
If theremoteandthevehicledonot
recognize each other, turn the
ignition switch to the LOCK (0)
position, remove the ignition switch
cover, insert the built-in key, and
turn the switch (see pages and
). Before leaving the vehicle, make
sure the ignition switch is in the
LOCK (0) position.
You will also see a ‘‘RETURN
IGNITION SWITCH TO LOCK (0)
POSITION’’ message on the multi-
inf ormation display.
To turn the ignition switch to the
LOCK (0) position, put the
transmission in Park, press the
switch in, and turn it to the LOCK
(0) position. When the transmission
is not in Park, you cannot turn the
ignition switch to the LOCK (0)
position.
If you open the driver’s door with the
ignition switch in the ACCESSORY
(I) position, a beeper will sound.
152
177
Ignition Switch
K eyless A ccess System
176
2009 RL

When you are pressing the ignition
switch, or when the ignition switch is
in the ON (II) position, the beeper
sounds if you take the remote out of
the vehicle and close the door.
To remove the ignition switch cover,
insert the built-in key (see page ),
then pull the cover out by pulling the
built-in key while pushing it.
Also, if you close the door when the
ignition switch is not in the LOCK
(0) position and the remote is not
inside the vehicle, the keyless access
alarm sounds outside the vehicle, a
message appears on the multi-
inf ormation display, and the beeper
sounds if the ignition switch is in the
ON (II) position.
When the beeper sounds af ter you
close the driver’s door outside the
vehicle, check the position of the
ignition switch and the location of
the remote.
If the engine is running and you
removetheremotefromthevehicle,
it will continue to run. But once
turned to the LOCK (0) position, the
engine will not restart until a remote
is brought back into the vehicle.
180
CONT INUED
Beeper and Message
Removing the Ignition Switch
Cover
K eyless Remot e Not Det ect ed
K eyless A ccess System
Inst rument s and Cont rols
177
BUILT-IN KEY
IGNITION SWITCH COVER
pushpull
2009 RL

Thebatteriesintheremotenormally
last about 2 years. To ensure
maximum battery lif e, do not store
the remote close to electrical devices
such as computers or TVs. When the
multi-inf ormation display shows
‘‘KEYLESS REMOTE LOW
BATTERY,’’ replace the batteries as
soon as possible (see page ).
The engine does not restart if you
turn the ignition switch to the LOCK
(0) position when the remote is
outside the vehicle. Check where the
remote is. Make sure that you carry
the remote or built-in key with you
when you operate the ignition switch.
When the ignition switch is in the
ON (II) position, the multi-
inf ormation display shows
‘‘KEYLESS REMOTE NOT
DETECTED,’’ and the inside and
outside beepers sound.
The multi-inf ormation display
message goes away when you
bring the remote back inside the
vehicle, and close the door or
apply the parking brake.
The outside beeper sounds when
the ignition switch is in the
ACCESSORY (I) or the ON (II)
position.
If the engine is running and you
removetheremotefromthe
vehicle, it will continue to run.
Once turned to the LOCK (0)
position, the engine will not restart
until a remote is brought back into
the vehicle. If you pass the remote through an
open window, the system does not
respond.Also,evenwhentheremote
is inside the vehicle, the beeper may
sound when the location of the
remote is not detected due to
surrounding conditions. It is not a
f ailure. Make sure that you carry the
remote with you.
174
K eyless Remot e L ow Bat t ery
K eyless A ccess System
178
2009 RL

The keyless access system
indicator comes on and stays on
while you are driving.
The indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. Have
your vehicle checked by your dealer
if : In this case, use the built-in key to
lock/unlock the doors and start the
engine.The multi-inf ormation display
shows ‘‘CHECK KEYLESS
ACCESS SYSTEM.’’
The indicator comes on with the
ignition switch in the ON (II)
position.Check K eyless A ccess Syst em
K eyless A ccess System
Inst rument s and Cont rols
179
KEYLESS ACCESS SYSTEM
INDICATOR
2009 RL

Climate Control System
204
RECIRCULATION
BUTTONREAR
WINDOW
DEFOGGER/
MIRROR
HEATER
BUTTON
U.S. models
(Technology package model is shown) INTERFACE DIAL
MODE
BUTTON
A/C
BUTTON
PASSENGERS’S SIDE
TEMPERATURE CONTROL BAR
DRIVER’S SIDE TEMPERATURE
CONTROL BAR
AUTO
BUTTONOFF
BUTTON WINDSHIELD
DEFROSTER
BUTTON
FAN CONTROL
BUTTONS
TEMPERATURE DISPLAY
2009 RL

Û
Ý To select the desired temperature,
push the temperature control bar up
or down.
Press the A/C button to view the
climate control display. Pushing
ENTER on the interf ace selector
turns the air conditioning on and of f .
You will see A/C ON or A/C OFF in
the display.
When you turn the A/C of f , the
system cannot regulate the inside
temperature if you set the
temperature control below the
outside temperature.
Press the button to increase
the fan speed and airflow. Press the button to decrease it. To set the driver’s and passenger’s
temperature separately, push the
temperature control bar up or down
on the driver’s or passenger’s side.
The driver and passenger can each
set the temperature to the desired
setting.
Press the A/C button to view the
climate control display, then turn the
interf ace knob to increase or
decrease the f an speed and airf low.
Using the Fan Control Buttons Using the Interf ace Dial
Fan Control T emperature Control Bars A ir Conditioning (A /C)
Climate Control System
206
2009 RL

When is selected, you can
increase or decrease the
temperature of airf low f rom the
dashboard vent f or the driver’s side
and the passenger’s side without
changing the temperature of airf low
f rom the f loor vent.
Push the interf ace selector right or
left,thenturntheinterfaceknobto
select the desired temperature.
Air flows from the center
and corner vents in the dashboard.
Airf low is divided between
the vents in the dashboard and the
f loor vents.
Air f lows f rom the f loor
vents.
Airf low is divided between
the floor vents and defroster vents at
the base of the windshield.
Use the mode control button to
select the vents the air flows from.
Some air will flow from the
dashboard vents in all modes.
Press the A/C button to view the
climate control display, then push
the interf ace selector down. Select
any of the modes by turning the
interf ace knob.
Using the Mode Control Button
Using the Interf ace Dial
Climate Control System
208
2009 RL
