Page 71 of 609

70
uuChild Safety uSafety of Larger Children
Safe Driving
Safety of Larger Children
The following pages give instructions on how to check proper seat belt fit, what kind
of booster seat to use if one is needed, and important precautions for a child who
must sit in front.
When a child is too big for a child seat, secure the child in a rear seat using the lap/
shoulder seat belt. Have the child sit upright and all the way back, then answer the
following questions.
■Checklist
• Do the child’s knees bend comfortably over
the edge of the seat?
• Does the shoulder belt cross between the
child’s neck and arm?
• Is the lap part of the seat belt as low as
possible, touching the child’s thighs?
• Will the child be able to stay seated like this
for the whole trip?
If you answer yes to all thes e questions, the child is read y to wear the lap/shoulder
seat belt correctly. If you answer no to any question, the child needs to ride on a
booster seat until the seat belt fits properly without a booster seat.
■Protecting Larger Children
■Checking Seat Belt Fit
1 Safety of Larger Children
3WARNING
Allowing a child age 12 or under to sit in
front can result in injury or death if the
passenger’s front airbag inflates.
If a larger child must ri de in front, move the
vehicle seat as far to the rear as possible,
have the child sit up properly and wear the
seat belt properly, using a booster seat if
needed.
20 ACURA RLX HYBRID-31TY36601.book 70 ページ 2019年7月23日 火曜日 午後6時25分
Page 72 of 609

71
uuChild Safety uSafety of Larger Children
Safe DrivingIf a lap/shoulder seat belt cannot be used
properly, position the child in a booster seat in
the rear seat. For the child’s safety, check that
the child meets the booster seat
manufacturer’s recommendations.
Your vehicle has a rear seat where children can be properly restrained. If you ever
have to carry a group of children, and a child must ride in front:
• Make sure you read and fully understand the instructions and safety information
in this manual.
• Move the front passenger seat as far back as possible.
• Have the child sit upright and well back in the seat.
• Check that the seat belt is properly positi oned so that the child is secure in the
seat.
■Monitoring child passengers
We strongly recommend that you keep an ey e on child passengers. Even older, more
mature children sometimes need to be remi nded to fasten their seat belts and sit up
properly.
■Booster Seats1 Booster Seats
When installing a booster seat , make sure to read the
instructions that came with it, and install the seat
accordingly.
There are high- and low-type booster seats. Choose a
booster seat that allows the child to wear the seat
belt correctly.
Some U.S. states, and Canadian provinces and
territories require children to use a booster seat until
they reach a given age or we ight (e.g. six years or 60
lbs). Be sure to check current laws in the state or
province, or territory where you intend to drive.
■Protecting Larger Children-Final Checks
20 ACURA RLX HYBRID-31TY36601.book 71 ページ 2019年7月23日 火曜日 午後6時25分
Page 73 of 609

72
Safe Driving
Exhaust Gas Hazard
Carbon Monoxide Gas
The engine exhaust from this vehicle contains carbon monoxide, a colorless,
odorless, and highly toxic gas. As long as you properly maintain your vehicle, carbon
monoxide gas will not get into the interior.
■Have the exhaust system inspected for leaks whenever
• The exhaust system is m aking an unusual noise.
• The exhaust system may have been damaged.
• The vehicle is raised for an oil change.
When you operate a vehicle with the trunk open, airflow can pull exhaust gas into
the interior and create a hazardous condition. If you must drive with the trunk open,
open all the windows and set the climate control system as shown below.
1. Select the fresh air mode.
2. Select the mode.
3. Set the fan speed to high.
4. Set the temperature control to a comfortable setting.
Adjust the climate control system in the same manner if you sit in your parked
vehicle with the engine running.
1 Carbon Monoxide Gas
An enclosed area such as a garage can quickly fill up
with carbon monoxide gas.
Do not turn the power system on with the garage
door closed. Even when th e garage door is open,
drive out of the garage i mmediately after turning the
power system on.
3WARNING
Carbon monoxide gas is toxic.
Breathing it can cause unconsciousness and
even kill you.
Avoid any enclosed areas or activities that
expose you to carbon monoxide.
20 ACURA RLX HYBRID-31TY36601.book 72 ページ 2019年7月23日 火曜日 午後6時25分
Page 74 of 609

73
Safe Driving
Safety Labels
Label Locations
These labels are in the locations shown. They warn you of potential hazards that can cause serious injury or death. Read these labels
carefully.
If a label comes off or becomes hard to read (except for the U. S. dashboard label which may be removed by the owner), contact a dealer
for a replacement.
Radiator Cap Dashboard
Sun Visors
U.S. models Canadian models
U.S. models only Radiator Cap
High Voltage System Components
U.S. models Canadian models
20 ACURA RLX HYBRID-31TY36601.book 73 ページ 2019年7月23日 火曜日 午後6時25分
Page 75 of 609

74
20 ACURA RLX HYBRID-31TY36601.book 74 ページ 2019年7月23日 火曜日 午後6時25分
Page 76 of 609

75
Instrument Panel
This chapter describes the buttons, indicators, and gauges that are used while driving.
Indicators............................................ 76
Multi-Information Display Warning and Information Messages ...................... 94
Gauges and Displays Gauges ............................................ 112
Multi-Information Display ................ 114
Head-Up Display .............................. 119
20 ACURA RLX HYBRID-31TY36601.book 75 ページ 2019年7月23日 火曜日 午後6時25分
Page 77 of 609

76
Instrument Panel
Indicators
IndicatorNameOn/BlinkingExplanationMessage
Brake System
Indicator (Red)
•Comes on for a few seconds when
you set the power mode to ON, then
goes off.
• Comes on when the brake fluid level
is low.
• Comes on if there is a problem with
the brake system.• Comes on while driving - Check the
brake fluid level.
2 What to do when the indicator comes
on while driving P. 568
•Comes on along with the brake system
indicator (amber) - Immediately stop in a
safe place. Contact a dealer for repair. The
brake pedal becomes harder to operate.
Depress the pedal further than you
normally do.
• Comes on along with the ABS indicator
- Have your vehicle checked by a dealer.
2 If the Brake System Indicator (Red)
Comes On P. 568
Low Oil Pressure
Indicator
•Comes on when you set the power
mode to ON, and goes off when the
power system starts.
• Comes on when the engine oil
pressure is low.•Comes on while driving - Immediately
stop in a safe place.
2 If the Low Oil Pressure Indicator
Comes On P. 567
U.S.
Canada
(Red)
20 ACURA RLX HYBRID-31TY36601.book 76 ページ 2019年7月23日 火曜日 午後6時25分
Page 78 of 609

77
uuIndicators u
Continued
Instrument Panel
IndicatorNameOn/BlinkingExplanationMessage
Electric Parking
Brake Indicator
•Comes on for a few seconds when
you set the power mode to ON, then
goes off if the parking brake has
been released.
• Comes on when the parking brake is
applied, and goes off when it is
released.
• Comes on for about 15 seconds then
goes off when you pull the electric
parking brake switch with the power
mode in OFF.
• Comes on for about 15 seconds then
goes off when you set the power
mode to OFF with the parking brake
applied.•Blinks and the electric parking brake
system indicator comes on at the same
time - There is a problem with the electric
parking brake system. The parking brake
may not be set.
•Comes on when you press the
electric parking brake switch without
depressing the brake pedal.•Depress the brake pedal to release the
parking brake.
2 Parking Brake P. 450
Electric Parking
Brake System
Indicator
•Comes on for a few seconds when
you set the power mode to ON, then
goes off.
• Comes on if there is a problem with
the electric parking brake system.•Comes on while driving - Avoid using the
parking brake and have your vehicle
checked by a dealer immediately.
2 If the Electric Parking Brake System
Indicator Comes On P. 569
U.S.
Canada
20 ACURA RLX HYBRID-31TY36601.book 77 ページ 2019年7月23日 火曜日 午後6時25分
Page 79 of 609

78
uuIndicators u
Instrument Panel
IndicatorNameOn/BlinkingExplanationMessage
Automatic Brake
Hold System
Indicator
•Comes on for a few seconds when
you set the power mode to ON, then
goes off.
• Comes on when the automatic
brake hold system is on.
2 Automatic Brake Hold P. 454
Automatic Brake
Hold Indicator
•Comes on for a few seconds when
you set the power mode to ON, then
goes off.
• Comes on when the automatic
brake hold is activated.
2 Automatic Brake Hold P. 454—
U.S.
Canada
20 ACURA RLX HYBRID-31TY36601.book 78 ページ 2019年7月23日 火曜日 午後6時25分
Page 80 of 609

79
uuIndicators u
Continued
Instrument Panel
IndicatorNameOn/BlinkingExplanationMessage
Brake System
Indicator (Amber)
•Comes on for a few seconds when
you set the power mode to ON, then
goes off.
• Comes on if there is a problem with
a system related to braking other
than the conventional brake system.
• Comes on if there is a problem with
the cooperative control with
regenerative braking, the electric
servo brake system, or the hill start
assist system.•Comes on while driving - Have your
vehicle checked by a dealer.
• Stays on constantly - Avoid high speeds
and sudden braking. Take the vehicle to a
dealer immediately.
• With this indicator on, your vehicle still has
normal braking ability.
•Comes on if there is a problem with
the automatic brake hold system.
2 Automatic Brake Hold P. 454
U.S.
Canada
(Amber)
U.S.
Canada
U.S.
Canada
20 ACURA RLX HYBRID-31TY36601.book 79 ページ 2019年7月23日 火曜日 午後6時25分
