If your vehicle is af f ected by a recall
or other important saf ety
inf ormation, a letter will be mailed to
you about the issue and how to f ix it.
If you don’t get your vehicle f ixed,
you will also receive a reminder
message through AcuraLink. You
can then use the message options to
call your dealer f or an appointment
or to f ind the nearest dealer.
You can then use the message
options to call your dealer f or an
appointment or to f ind the nearest
dealer.
These messages provide detailed
inf ormation about the service
needed f or your vehicle. When a
maintenance message appears on
the multi-information display, a list of
needed maintenance items is
provided through in an AcuraLink
message. These messages tell you
the exact maintenance needed,
helping you to avoid unnecessary
maintenance costs. Recall/Campaigns
Maintenance Minder
AcuraLink
Features
223
——
y

y
(%yy

Depending on the severity of the
problem, the message will let you
know if you should see your dealer
immediately or if you can wait until a
later date.
Wh
en an instrument panel indicator
comes on or a message is displayed
on the multi-information display
(MID), AcuraLink can provide
info rmation about the cause of the
indicator or message and the
recommended action to address it.
This helps you handle the problem
as it occu rs, preventing or limiting
costly repairs.
When an instrument panel indicator
comes on or a message is displayed
on the MID, AcuraLink immediately
notifies you with the message, ‘‘An
indicator is on. AcuraLink can help
you decide what to do.’’ If you do not
want the information right away,
select the Check Later option. If you
want the information now, select the
Check Now option. (If the navigation
screen is not active, you must select
OK from the navigation disclaimer
screen bef ore you can check the inf ormation.)
For more inf ormation on the
instrument panel indicators, see page .
The AcuraLink system cannot
determinesomemechanical
problems (such as squeaks or
rattles) that are not triggered by the
diagnostic indicator monitors.
57
Diagnostic Inf o
AcuraLink
224
——
y


y
(%yy

Compass operation can be affected
by driving near power lines or
stations, across bridges, through
tunnels, over railroad crossings, past
large vehicles, or driving near large
objects that can cause a magnetic
disturbance. It can also be affected
by accessories such as antennas and
roof racks that are mounted by
magnets.
In most areas, there is a variation
between magnetic north and true
north. Zone selection is required so
the compass can compensate for this
varia tion. To check and select the
zone, do this:
Press and hold the and
buttons simultaneously until
the temperature display changes
(about 5 seconds). Verif y the zone f or your area on
the map on page .
Press the button to cycle the
count down, or the button to
cycle the count up. Once the
correct zone is displayed, continue
to step 4.
Press the OFF button to save the
zone selection.
To exit the zone setting mode,
either press the button and
button simultaneously f or
about 5 seconds, or press any
climate control button on either
side of the display other than the or button.
1. 2.
3.
4.
5.
230
On models without navigation system
Compass Operation
Compass Zone Selection
Compass
228
——
y

y
(%yy

µµµµ µµ
If
you see ‘‘ ’’ in the compass
display, the compass is self-
calibrating. The compass may need
to be manually calibrated after
exposure to a strong magnetic field.
If the compass seems to be
continuously showing the wrong
direction and is not self-calibrating,
do the following.
Do this procedure in an open
area, away from buildings, power
lines, and other vehicles.
Press and hold the and
buttons simultaneously until
the temperature display changes
(about 5 seconds).
Verify that the zone setting is
correct by f inding your area on the
map on page . Press the button to cycle the
count down, or the button to
count up. Once the correct zone is
displayed, continue to step 4.
Press the OFF button to save the
zone selection.
Press the OFF button again to
begin calibrating the compass.
The heading should now show
‘‘ ’’.Drive the vehicle slowly in two
complete circles.
When the display goes f rom
‘‘ ’’ to an actual heading, the
unit is calibrated and the display
returns to normal.
1.
2. 3.
4.
5.6.
7.
230
CONT INUED
Compass
Compass Calibration
Features
229
NOTE:
——
y

y
(%yy

On vehicles with navigation systemSince the rearview camera display
area is limited, you should always
back up slowly and caref ully, and
look behind you f or obstacles.
Whenever you shif t to reverse (R)
with the ignition switch in the ON
(II) position, the rear view is shown
on the navigation system screen.
For the best picture, always keep the
rearview camera clean, and do not
cover the camera lens. To avoid
scratching the lens when you clean it,
use a moist, sof t cloth.
Rearview Camera and Monitor
Features
231
——
y

y
(%yy

Help assure your vehicle’s f uture
reliability and perf ormance by paying
extra attention to how you drive
during the f irst 600 miles (1,000 km).
During this period:
You should also f ollow these
recommendations with an
overhauled or exchanged engine, or
when the brakes are replaced.Do not change the oil until the
multi-inf ormation display indicates
it is needed. Avoidhardbrakingforthefirst
200 miles (300 km). Avoid full-throttle starts and rapid
acceleration.
Your vehicle is designed to operate
on premium unleaded gasoline with a
pump octane of 91 or higher. If this
octane grade is unavailable, regular
unleaded gasoline with a pump
octane of 87 or higher may be used
temporarily. The use of regular
unleaded gasoline can cause metallic
knocking noises in the engine and
will result in decreased engine
perf ormance. The long-term use of
regular-grade gasoline can lead to
engine damage.
Your vehicle is designed to operate
on premium unleaded gasoline with a
pump octane number of 91 or higher.
Useof aloweroctanegasolinecan
cause occasional metallic knocking
noises in the engine and will result in
decreased engine perf ormance. Use
of a gasoline with a pump octane
number less than 87 can lead to engine damage.
We recommend quality gasolines
containing detergent additives that
help prevent f uel system and engine
deposits.
In addition, in order to maintain good
perf ormance, f uel economy, and
emissions control, we strongly
recommend, in areas where it is
available, the use of gasoline that
does NOT contain manganese-based
f uel additives such as MMT.
Use of gasoline with these additives
may adversely af f ect perf ormance,
and cause the malfunction indicator
lamp on your instrument panel to
come on. If this happens, contact
your dealer f or service.Type S
All models except Type S
Break-in Period Fuel Recommendation
Break-in Period, Fuel Recommendation
234
——
y

y
(%yy

Your vehicle’s on board diagnostic
system will detect a loose or missing
fuel fill cap as an evaporative system
leak. The first time a leak is detected
a ‘‘TIGHTEN FUEL CAP’’ message
appears on the multi-info rmation
display. Turn the engine off, and
confirm the fuel fill cap is installed. If
it is, loosen it, then retighten it until
it clicks at least once. The message
should go off after several days of
normal driving once you tighten or replace
the fuel fill cap. To scroll to
another message, press the INFO
button. The ‘‘TIGHTEN FUEL CAP’’
message will appear each time you
restart the engine until the system
turns the message off.
even
though the tank is not full, there may
be a problem with your vehicl e’s fuel
vapor recovery system. The system
helps keep fuel vapor from going
into the atmosphere. Try filling at
another pump. If this does not fix the
problem, consult your dealer.
Screw the fuel fill cap back on
until it clicks at least once. If you
do not properly tighten the cap,
you will see a ‘‘TIGHTEN FUEL
CAP’’ message on the multi-
inf ormation display, and the
malf unction indicator lamp may
also come on (see page ).
Push the f uel f ill door closed until
it latches.
5.
6.
68
If the f uel nozzle keeps clicking of fTighten Fuel Cap Message
Service Station Procedure
236
——
y

y
(%y
y

Try to maintain a constant speed.
Everytimeyouslowdownand
speed up, your vehic le uses extra
fuel. Use cruise control when
appropriate.
Combine several short trips into
one.
The air conditioning puts an extra
load on the engine which makes it
usemorefuel.Usethefresh-air
ventilation when possible.
Always
maintain your vehicle
according to the maintenance
messages given by the multi-
information display. See
on page
.
an underinflated tire
causes more ‘‘rolling resistance,’’
which uses more fuel.
The build-up of snow or mud on
your vehicl e’s underside adds
weight and rolling resistance.
Frequent cleaning helps your fuel
mileage and reduces the chance of
corrosion.
Drive moderately. Rapid
acceleration, abrupt cornering,
and hard braking use more fuel.
Always drive in the highest gear
possible.
Refer
to
on page for information
about checking other items on your
vehicle. Look at the coolant level in the
radiator reserve tank. Make sure it is
between the MAX and MIN lines. If
it is below the MIN line, see
on page f or
inf ormation on adding the proper
coolant. 277
286
277
For example,
Improving Fuel Economy Owner’s
Maintenance Checks
Engine Coolant Check
Owner’s Maintenance
Checks A dding
Engine Coolant
Service Station Procedures, Fuel Economy
Bef ore Driving
239
RESERVE TANK
MINMAX
——
y
y
(%yy

Youshoulddothefollowingchecks
and adjustments every day before
you drive your vehicle.
Make sure all windows, mirrors,
and outside lights are clean and
unobstructed. Remove frost, snow,
or ice.
Check that the hood and trunk are
fully closed.
Visually check the tires. If a tire
looks low, use a g auge to check its
pressure. Check the seat adjustment (see
page ).
Check the adjustment of the
inside and outside mirrors (see
page ).
Check the steering wheel
adjustment (see page ).
Make sure the doors are securely
closed and locked.
Fasten your seat be
lt. Check that
your passengers have fastened
their seat belts (see page ).
Check that any items you may be
carrying are stored properly or
fastened down securely. When you start the engine, check
the gauges and indicato
rs in the
instrument panel, and the
messages on the multi-inform ation
display (see pages , and
).
3. 2.
1.
4. 5.
6.
7.
8.
9. 10.
103
107 91
14 57 65
68
Preparing to Drive
246
——
y
y
(%y
y

If there is a problem with the
starting system, you will see a
‘‘CHECK STARTING SYSTEM’’
message on the multi-inf ormation
display when the ignition switch is
turned to the ON (II) position. You
will also see this message when the
auto control mode of the starting
system has a problem.If this message is on, the ignition
switchhastobeheldintheSTART
(III) position manually until the
engine starts. The ignition switch
canbeheldinthatpositionupto15
seconds.
Even though you may be able to
start the engine manually without
the auto control mode of the starting
system, have your vehicle inspected
by a dealer.
Check Starting System Message
Starting the Engine (Models with Automatic Transmission)
Driving
249
——
y


y
(%yy
